M10 Manual (SP78) Charging Charging Fully charged Power On/Off Power On : Press and Hold the Phone Button and Jog Dial for 1 sec Power Off : Tap the Phone Button and Jog Dial for 1 sec Volume Adjustment Up the Jog Dial : Increase the volume Down the Jog Dial : Decrease the volume Phone, Music Pairing 1. Press and Hold the Phone Button for 5 seconds. 2. Search for Bluetooth devices on your mobile phone. Select the M10 in the list of the devices detected on the mobile phone. 3. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN. Music Operation Play or pause music:Press and Hold the Jog Dial for 1 second. Track back: Press and Down the Jog Dial. Track forward: Press and Up the Jog Dial. Mobile Phone Call Making and Answering Answering/Ending a call: Tap the Phone Button Rejecting a call: Press and Hold the Jog Dial for 2 seconds. Intercom Pairing(LED/LCD Type) 1. Press and hold the Jog Dial of two headsets for 5 seconds. 2. Simply tap the Jog Dial of any one of the two headsets. Intercom Start/End 1st Friend: Tap the Phone Button once. 2nd Friend: Tap the Phone Button twice. 3rd Friend: Tap the Phone Button triple times Radio On/Off Turn on/Turn off the FM radio: Press and Hold the Phone Button for 1 second. Radio Seek Stations Seek up stations: Press and Up the Jog Dial. Seek down stations: Press and Down the Jog Dial. Troubleshooting Factory Reset If you want to restore the M10 to factory default settings, use the Factory Reset. Press and Hold the Phone Button for 12 seconds, and tap the Jog Dial. Certification and Safety Approvals FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antennae -Increase the separation between the equipment and the receiver -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. The antenna used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. When equipped, the distance between antenna and oneâs head surface is 38mm. FCC Caution Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void userâs authority to operate the equipment. Certification et homologation de sĂ©curitĂ© DĂ©claration de conformitĂ© FCC Cet appareil est en conformitĂ© avec la partie 15 des rĂšgles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes : (1) Cet appareil ne doit pas crĂ©er dâinterfĂ©rences prĂ©judiciables et (2) Cet appareil doit accepter toutes les interfĂ©rences reçues, y compris celles qui pourraient entraver son bon fonctionnement. Cet Ă©quipement a Ă©tĂ© testĂ© et jugĂ© conforme aux limites pour un appareil numĂ©rique de classe B, conformĂ©ment Ă la partie 15 des rĂšgles de la FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interfĂ©rences nuisibles dans une installation rĂ©sidentielle. Cet Ă©quipement gĂ©nĂšre et utilise de lâĂ©nergie radio frĂ©quence et, sâil nâest pas installĂ© et utilisĂ© conformĂ©ment. aux instructions, il peut occasionner des interfĂ©rences nuisibles au niveau des communications radios. Cependant, il nâexiste aucune garantie que ces interfĂ©rences ne se produiront pas dans une installation particuliĂšre. Si cet Ă©quipement gĂ©nĂšre des interfĂ©rences nuisibles Ă la rĂ©ception de la radio ou de la tĂ©lĂ©vision (ce quâil est possible de dĂ©terminer en mettant lâĂ©quipement hors tension, puis sous tension), lâutilisateur est invitĂ© Ă suivre une ou plusieurs des mesures suivantes pour corriger le problĂšme des interfĂ©rences en prenant lâune des mesures suivantes : -Modifier lâemplacement ou lâorientation de lâantenne de rĂ©ception. -Ă loigner lâappareil du rĂ©cepteur. -Brancher lâappareil sur une prise situĂ©e sur un circuit diffĂ©rent de celui du rĂ©cepteur. -Consulter le revendeur ou un technicien expĂ©rimentĂ© pour obtenir de lâaide. Ă noncĂ© FCC sur lâexposition aux radiations RF Cet Ă©quipement est conforme aux rĂ©glementations FCC dâexposition aux radiations dĂ©finies pour un environnement non contrĂŽlĂ©. Les utilisateurs doivent respecter les instructions dâexploitation spĂ©cifiques pour rĂ©pondre aux exigences de conformitĂ© sur lâexposition aux RF. Lâantenne utilisĂ©e pour cet appareil ne doit pas fonctionner en mĂȘme temps quâune autre antenne ou Ă©metteur, sauf sâil y a conformitĂ© avec les procĂ©dures FCC des produits multi-Ă©metteurs. Cet appareil est conforme Ă l'exigence d'exposition aux RF. Lorsque Ă©quipĂ©, la distance entre lâantenne et la surface de la tĂȘte est de 38mm. LâEST Ă©tant commercialisĂ© sans casque, il doit donc rester Ă une distance de 30mm de la surface de la tĂȘte.âŠ
Text truncated - open the document above for the full version.
SENA TECHNOLOGIES.Inc 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Mar 24 th , 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370a Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Kenneth Kim of NCT Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7A-SP78 / IC : 8154A-SP78 including signing of all documents relating to these matters. Any and all acts carried out by Kenneth Kim of NCT Co.,Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SENA TECHNOLOGIES.Inc âI, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).â Sincerely, Seunghyun KIM / Research Engineer
SENA TECHNOLOGIES.Inc Mar 24 th , 2020 Applicant: SENA TECHNOLOGIES.Inc FCC ID: S7A-SP78 / IC: 8154A-SP78 To. Whom it may concern: So, We, SENA TECHNOLOGIES.Inc. confirm that when equipped, the distance between antenna and oneâs head surface is 38mm. EUT is marketed without helmet, so when the EUT is mounted with helmet, it has to be to maintain a distance of 38mm from oneâs head surface. Seunghyun Kim, Research Engineer
SENA TECHNOLOGIES.Inc 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: S7A-SP78 Pursuant to Sections 0.457 and 0.459 of the Commissionâs Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Part List [SP78] BLK [SP78] SCH [SP78] OpDes [SP78] Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photos Internal Photos Test Setup Photos Manual [SP78] EXT Photo [SP78] INT Photo [SP78] Test Setup Photo [SP78] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Seunghyun KIM / Research Engineer
SENA_SP78_Label & Location
Internal Antenna
Model Name : FCC ID : (mm)(dBm)(dB)(dBm)(mW) 240217.2717.7759.843.00PASS 244117.0017.5056.233.00PASS 248017.1117.6157.683.00PASS 24028.138.637.293.00PASS 24418.148.647.313.00PASS 24808.208.707.413.00PASS 24028.138.637.293.00PASS 24418.168.667.353.00PASS 24808.258.757.503.00PASS S7A-SP78Separation distance : 38.0 mm Standalone SAR test exclusion considerations Step 1) SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance †50 mm = Used [(max.power of channel, including tune-up torelance, mW)/(min. test separation distance, mm)] * [âf(GHz)] SP78Device Category : Portable device SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance †50 mm LimitResult GFSK 38.00± 0.50 2.4406 2.3121 2.3902 Modulation Frequency (MHz) Min. Test separation distance Measured Maximum Average power Tune-up tolerance Max. Power with tune-up tolerance Ï/4DQPSK 38.00± 0.50 0.2975 0.3006 0.3072 8DPSK 38.00± 0.50 0.2975 0.3020 0.3108
Certificate of Test NTP-015-F06(Rev.03) NCT.CO., LTD. NCT Co., Ltd. 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea (Tel: +82-31-323-6070 / Fax: +82-31-323-6071) Report No.: NW2003-F006 Page (1) / (53) 1. Client â Name : SENA TECHNOLOGIES.Inc â Address : 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea â Date of Receipt : 2020-03-16 2. Use of Report : FCC & IC Approval 3. Test Sample â Description / Model Name : M10 / SP78 â FCC ID : S7A-SP78 / IC ID : 8154A-SP78 4. Date of Test : 2020-03-16 ~ 2020-03-23 5. Test method used : FCC Part 15 Subpart C 15.247 RSS-247 Issue 2(2017-02), RSS-GEN Issue 5(2018-04) 6. Testing Environment : â Temperature: (25 ï± 5) °C, Humidity: Less than 75 % R.H. * Unless specified otherwise in the individual methods, the tests were conducted on ambient conditions. 7. Test Results : Refer to the test results The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This Test Report cannot be reproduced, except in full This test report is prepared according to the requirements of ISO / IEC 17025. Affirmation Tested by Jong-Myoung, Shin (signature) Technical Manager Kyung-Taek, Lee (signature) March 24, 2020 NCT CO., LTD. (seal) Test Repot No.: NW2003-F006 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 2 of 53 Table of contents 1. General Information -------------------------------------------------------------------------------- 2. Informationâs about Test Item ------------------------------------------------------------------- 3. Test Report -------------------------------------------------------------------------------------------- 3.1 Test Summary ------------------------------------------------------------------------------------- 3.2 Test Report Version ----------------------------------------------------------------------------- 3.3 Transmitter Requirements 3.3.1 Antenna Requirement --------------------------------------------------------------------- 3.3.2 20 ă Bandwidth & Occupied Bandwidth (99%) ----------------------------------- 3.3.3 Number of Hopping Frequencies ------------------------------------------------------- 3.3.4 Time of Occupancy (Dwell Time) ------------------------------------------------------- 3.3.5 Carrier Frequencies Separation -------------------------------------------------------- 3.3.6 Peak Output Power ------------------------------------------------------------------------ 3.3.7 TX Radiated Spurious Emission and Conducted Spurious Emission --------- 3.3.8 Conducted Emission ----------------------------------------------------------------------- APPENDIX APPENDIX I TEST SETUP ---------------------------------------------------------------------- APPENDIX II TEST EQUIPMENT USED FOR TESTS ---------------------------------- 3 3 5 5 6 7 8 15 18 20 24 31 47 50 52 Test Repot No.: NW2003-F006 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 3 of 53 1. General Informationâs 1.1 Test Performed Laboratory : NCT Co., Ltd. Address : 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea Telephone : +82-31-323-6070 Facsimile : +82-31-323-6071 FCC Designation No. : KR0166 FCC Registration No. : 409631 IC Site Registration No. : 25897 2. Informationâs about Test Item 2.1 Applicant Information Company name : SENA TECHNOLOGIES.Inc Address : 19, Heolleung-ro 569-gil, Gangnam-gu, Seoul, Korea Telephone / Facsimile : +82-2-571-8283 / +82-2-573-7710 2.2 Equipment Under Test (EUT) description Test item particulars : M10 Model and/or type reference : SP78 Additional model name : - Serial number : Identification Antenna type and gain : PCB Pattern Antenna with Max gain : -1.79 ăi Date (s) of performance of tests: : 2020-03-16 ~ 2020-03-23 Date of receipt of test item : 2020-03-16 EUT condition : Pre-production, not damaged Number of channel : 79 EUT Power Source : DC 3.7 V Type of Modulation : Basic Mode(GFSK), EDR Mode(Pi/4 DQPSK, 8DPSK) Firăœare version : 1.0 Hardware version : 1.0 Test software name(version) : CSR BlueSuite_BlueTest3(2.6.2) Test Repot No.: NW2003-F006 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 4 of 53 2.3 Tested Frequency Test Mode Test frequency (ă) Low frequency Middle frequency High frequency GFSK 2 402 2 442 2 480 Pi/4 DQPSK 2 402 2 442 2 480 8DPSK 2 402 2 442 2 480 2.4 Worst-Case BDR GFSK(DH5) EDR 8DPSK(3-DH5) Note: The power measurement has been conducted to determine the worst-case mode from all possible combinations between available modulations, data rates. Test Repot No.: NW2003-F006 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 5 of 53 3. Test Report 3.1 Test Summary Applied FCC Rule IC Rule Test Items Test Condition Result 15.203 - Antenna Requirement Conducted C 15.247(a) - 20 ă Bandwidth C - RSS GEN (6.7) Occupied Bandwidth (99%) C 15.247(a) RSS-247 (5.1) Number of Hopping Frequencies C 15.247(a) RSS-247 (5.1) Time of Occupancy (Dwell Time) C 15.247(a) RSS-247 (5.1) Carrier Frequencies Separation C 15.247(b) RSS-247 (5.4) Peak Output Power C 15.247(d) RSS-247 (5.5) Conducted Spurious Emission C 15.247(d) 15.205 & 15.209 RSS-247 (5.5) RSS-GEN (8.9 & 8.10) Radiated Spurious Emission Radiated C 15.207 RSS-GEN (8.8) Conducted Emissions AC Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C63.10:2013. Compliance was determined by specification limits of the applicable standard according to customer requirements. Test Repot No.: NW2003-F006 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6âŠ
Text truncated - open the document above for the full version.
Below 30 MHz Below 1 GHz Above 1 GHz Conducted Emission
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 56.00 mW |
Wireless Communication Systems
Equipment Class
NII - Unlicensed National Information Infrastructure TXWireless Communication Systems
Equipment Class
DTS - Digital Transmission SystemWireless Communication Systems
Equipment Class
DTS - Digital Transmission SystemWireless Communication Systems
Equipment Class
DTS - Digital Transmission SystemWireless Communication Systems
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
