S7AIW01ZIGBEE SERIAL MODULE

1 ProBee-ZE20S Series User Guide Rev.0.1 ZigBee OEM Module ProBee-ZE20S Series User Guide Sena Technologies, Inc. Rev 0.1 2 ProBee-ZE20S Series User Guide Rev.0.1 ProBee-ZE20S Series User Guide Firmware version PTv1.X Copyright Copyright 2010 Sena Technologies, Inc. All rights reserved. Sena Technologies reserves the right to make changes and improvements to its product without providing notice. Trademark ProBee™ is a trademark of Sena Technologies, Inc. Windows® is a registered trademark of Microsoft Corporation. Ethernet® is a registered trademark of XEROX Corporation. Notice to Users When a system failure may cause serious consequences, protecting life and property against such consequences with a backup system or safety device is essential. The user agrees that protection against consequences resulting from system failure is the user's responsibility. This device is not approved for life-support or medical systems. Changes or modifications to this device not explicitly approved by Sena Technologies will void the user's authority to operate this device. Technical Support Email: [email protected] Website: http://www.sena.com 3 ProBee-ZE20S Series User Guide Rev.0.1 Contents 1 INTRODUCTION ....................................................................................................... 9 1.1 About This Document ..................................................................................................................... 9 1.2 Overview ......................................................................................................................................... 9 2 GETTING STARTED ............................................................................................... 11 2.1 Hardware Installation .................................................................................................................... 11 2.1.1 Development Board Layout ................................................................................................... 11 2.1.2 Antenna Installation ............................................................................................................... 12 2.1.3 Module Installation on the Development Board .................................................................... 12 2.1.4 Serial/USB Cable Installation ................................................................................................ 13 2.1.5 Powering Development Board ............................................................................................... 14 2.1.6 USB Driver Installation .......................................................................................................... 14 2.2 Using Terminal Software for AT Commands ................................................................................. 15 2.3 Using ProBee Manager for Configuration .................................................................................... 17 3 ZIGBEE NETWORK CONFIGURATION ................................................................. 18 3.1 Setting up ZE20S as a Coordinator .............................................................................................. 18 3.1.1 Node Type Selection for Coordinator .................................................................................... 19 3.1.2 Channel Mask Configuration for Coordinator ........................................................................ 19 3.1.3 PAN ID Configuration for Coordinator ................................................................................... 20 3.1.4 Permit Joining ........................................................................................................................ 20 3.2 Setting up ZE20S as a Router ...................................................................................................... 21 3.2.1 Node Type Selection for Router ............................................................................................ 21 3.2.2 Channel Mask Configuration for Router ................................................................................ 22 3.2.3 PAN ID Configuration for Router ........................................................................................... 22 3.2.4 Permit Joining ........................................................................................................................ 22 3.3 Setting up ZE20S as an End Device ............................................................................................ 23 3.4 Setting up ZE20S as a Sleepy End Device .................................................................................. 23 3.5 ZigBee Security ............................................................................................................................ 25 3.5.1 Security Level ........................................................................................................................ 26 3.5.2 Link Key ................................................................................................................................. 26 3.5.3 Network Key .......................................................................................................................... 26 3.5.4 Update Key ............................................................................................................................ 26 4 DATA TRANSMISSION........................................................................................... 27 4.1 Command Mode ........................................................................................................................... 27 4.1.1 Unicast ................................................................................................................................... 27 4 ProBee-ZE20S Series User Guide Rev.0.1 4.1.2 Multicast ................................................................................................................................ 27 4.1.3 Broadcast ........…

Text truncated - open the document above for the full version.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 May 13, 2011 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 In re : Sena Technologies, Inc. FCC Application for FCC ID: S7AIW01 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 May 13, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7AIW01. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Sena Technologies, Inc. LTA Co.,LTD. (Contact Person) Contact name: LEE, Kyung-Taek Position: Manager Phone:(82)31-323-6008 E-mail: [email protected] YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 May 13, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Sena Technologies, Inc. FCC ID : S7AIW01 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Sena Technologies, Inc.. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Sena Technologies, Inc.. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX S7AIW01 SCH DIA.pdf Parts list CONF APPENDIX S7AIW01 PL.pdf Block diagram CONF APPENDIX S7AIW01 BLK DIA.pdf Operational description CONF APPENDIX S7AIW01 OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF S7AIW01 EXT Photo.pdf Internal Photos SHORT-TERM CONF S7AIW01 INT Photo.pdf Test-Setup Photos SHORT-TERM CONF S7AIW01 Test Photo.pdf User’s Manual SHORT-TERM CONF S7AIW01 Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 FCCID: S7AIW01 Request for transmitter Modular approval Transmitter Module Characteristics No Requirements EUT 1 Have its own RF shielding Device is equipped with metal shielding to cover RF section. Refer to external photos. 2 Have buffered modulation/data inputs (if such inputs are provi ded) All inputs to the modules are buffered thought logic or mi croprocessor inputs. 3 Have it own power supply regulation Internal 1.8V powe r regulation. Refer to Module Block diagram and schematic. 4 Meet the antenna requirements of Section 15.203 Device is equipped with unique antenna connector (U.FL, RPSMA), and chip antenna. Refer to external photos. 5 Be tested in a stand-alone configuration, i.e., the antenna, AC or DC power and data input/output lines must be connected to the module but, the module must not be inside another case during testing Device was tested on a supplied development platform for limited modular approval. Refer to setup photos. 6 Be labeled with its own FCC ID number, and if t he FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label re ferring to the enclosed module Label is to be placed in front of the EUT(ProBee -ZE20SDU), and other label is to be placed in the User’s Guide. Refer to FCC ID label format. 7 The modular transmitter is manufactured so that the user cannot influence the operation of the transmitter that will operate outside of the scope of the regulations. Refer to “User’s Guide” 8 Address compliance with the Commission’s RF exposure limits in Sections 1.1310 and 2.1091. In addition, spread spectrum transmitters operatin g under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4). This device is categorically excluded from routine environmental because it operate at Very low power level.

FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 1 of 14 Basic model (DIP Type & U.FL Type) Upper Lower FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 2 of 14 Front Rear FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 3 of 14 DIP Type & RP-SMA Type Upper Lower FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 4 of 14 Front Rear FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 5 of 14 DIP Type & Chip Type Upper Lower FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 6 of 14 Front Rear FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 7 of 14 SMD Type & U.FL Type Upper Lower FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 8 of 14 Front Rear FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 9 of 14 SMD Type & Chip Type Upper Lower FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 10 of 14 Front Rear FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 11 of 14 ANTENNA- M/N: R-AN2400-1901RS FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 12 of 14 ANTENNA- M/N: R-AN2400-5801RS FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 13 of 14 ANTENNA- M/N: AN2400-3306RS FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 14 of 14 ANTENNA- M/N: SENA_009

FCC ID: S7AIW01 Copyright Ⓒ 2011, LTA Co., Ltd. SAMPLE LABEL & LOCATION M/N Interface Type ANT Connector TypeType Description ZE20SDU DIP Type U.FL D DIP(Interface) ZE20SDC DIP Type CHIP S SMD(Interface) ZE20SDS DIP Type RPSMA U U.FL Connector ANT ZE20SSC SMD Type CHIP CCHIP ANT ZE20SSU SMD Type U.FL S RPSMA Connector ANT

FCC ID: S7AIW01 Copyright ○ c 2011, LTA Co., Ltd. Page 1 of 1 MainBoard - Front MainBoard - Rear

FCC ID: S7AIW01 ATTACHMENT ** MPE Calculations ** The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 8.26dBm + 5.37dBi EIRP = 13.63 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 π) Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) S = (6.70 * 3.44) / (4 * 20 2 * π) S = 0.0046 mW/cm 2 The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density does not exceed the 1 mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. Estimated safe separation: R = √(PG / 4π) Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) R = √(6.70* 3.44 / 4π) R = 1.83Cm The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (5.37 / 10) G = 3.44
