S7APARANISD1000ABLUETOOTH SERIAL ADAPTER

Parani-SD1000 User Guide Version 2.0.1 2010-02-04 2 User Guide for the Parani-SD1000 Version 2.0.1 Firmware version 2.0.X Printed in Korea Copyright Copyright 2010, Sena Technologies, Inc. All rights reserved. Sena Technologies reserves the right to make changes and improvements to its product without providing notice. Trademark Parani™ is a trademark of Sena Technologies, Inc. Windows® is a registered trademark of Microsoft Corporation. Ethernet® is a registered trademark of XEROX Corporation. Notice to Users When a system failure may cause serious consequences, protecting life and property against such consequences with a backup system or safety device is essential. The user agrees that protection against consequences resulting from system failure is the user's responsibility. This device is not approved for life-support or medical systems. Changes or modifications to this device not explicitly approved by Sena Technologies will void the user's authority to operate this device. Precautions and Safety Electricity Use only the supplied AC adapter. Use of unauthorized power adapter is not recommended. Electrical shock may result. Do not kink or crease the power cable or place heavy objects on the power cable. Fire can result from damaged power cables. Do not handle power plug and adapter with wet hands. Electrical shock may result. Immediately power off the product and unplug the AC adapter if smoke or odors emit from the product and adapter. Fire can result from improper use. Immediately power off the product and unplug the AC adapter if water or other liquids are present. Fire can result from improper use. Product Parani-SD meets the RS-232 standards. Do not wire with non-standard products. Damage to your products may result from improper use. Do not drop or subject the device to impact. Damage to your products may result from improper use. Keep away from harsh environments including humid, dusty, and smoky areas. Damage to your products may result from improper use. Do not use excessive force on the buttons or attempt to disassemble the device. Damage to your products may result from improper use. Do not place heavy objects on the product. Damage to your products may result from improper use. 3 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is con- nected. • Consult the dealer or an experienced radio/TV technician for help. Caution Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Technical Support Sena Technologies, Inc. 210 Yangjae-dong, Seocho-gu Seoul 137-130, Korea Tel: (+82-2) 573-5422 Fax: (+82-2) 573-7710 E-Mail: [email protected] Website: http://www.sena.com 4 Revision History Revision Date Name Description V1.0.0 2008-09-25 Cp Moon Initial Writing V1.0.1 2008-10-24 Marc Woo 2 nd Revision V1.0.2 2009-01-21 WJ Kim 3 rd Revision V1.0.3 2009-03-24 Cp Moon Update pairing button Modify S-Register 12 V1.0.4 2009-06-01 WJ Kim Modify package Info. Update attaching battery pack info. V2.0.0 2009-11-19 Yh Moon Multiple connection mode V2.0.1 2010-02-04 HR Zo Add a CE regulation in Approval Information 5 Contents 1. Introduction 8 1.1. Overview .................................................................................................................................... 8 1.2. Package Check List.................................................................................................................... 8 1.2.1. Single Unit Package......................................................................................................... 8 1.2.2. Bulk-Pack Package .......................................................................................................... 8 1.3. Product Specification.................................................................................................................. 9 2. Getting Started 11 2.1. Panel Layout ............................................................................................................................ 11 2.2. Connecting the Hardware ........................................................................................................ 11 2.2.1. Connecting Power to Parani-SD1000 ............................................................................ 11 2.2.2. Connecting Device to Parani-SD1000 .......…

Text truncated - open the document above for the full version.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 October 7, 2010 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 In re : Sena Technologies, Inc. FCC Application for FCC ID: S7APARANISD1000A To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 October 7, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7APARANISD1000A. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Sena Technologies, Inc. LTA Co.,LTD. (Contact Person) Contact name: LEE, Kyung-Taek Position: Manager Phone:(82)31-323-6008 E-mail: [email protected] YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 October 7, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Sena Technologies, Inc. FCC ID : S7APARANISD1000A Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Sena Technologies, Inc.. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Sena Technologies, Inc.. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name Schematics CONF APPENDIX S7APARANISD1000A SCH DIA.pdf Parts list CONF APPENDIX S7APARANISD1000A PL.pdf Block diagram CONF APPENDIX S7APARANISD1000A BLK DIA.pdf CONFIDENTIAL Operational description CONF APPENDIX S7APARANISD1000A OpDes.pdf External Photos SHORT-TERM CONF S7APARANISD1000A EXT Photo.pdf Internal Photos SHORT-TERM CONF S7APARANISD1000A INT Photo.pdf Test-Setup Photos SHORT-TERM CONF S7APARANISD1000A Test Photo.pdf SHORT-TERM CONFIDENTIAL User’s Manual SHORT-TERM CONF S7APARANISD1000A Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 ATTESTATION STATEMENT In re : Sena Technologies, Inc. FCC ID: S7APARANISD1000A Date : October 7, 2010 15.247(a)(1) The hopping sequence must be pseudorandom all Channels are used equally on average the receiver input bandwidth is approximately equal to the transmit ba ndwidth the receiver hops in sequence with the transmitted signal 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) The system does not coordinate its channel selection/hopping sequence with oth er frequency hopping systems for the express purpose of avoiding the simultane ous occupancy of individual hopping frequencies by multiple transmitters. Regards, YoungSam, KIM / Vice President Sena Technologies, Inc.

FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 8 Upper Lower FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 8 Front Rear FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 8 Left Right FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 8 ANTENNA- M/N: HIF-2400 FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 5 of 8 ANTENNA- M/N: R-AN2400-1901RS FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 6 of 8 ANTENNA- M/N: R-AN2400-5801RS FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 7 of 8 ANTENNA- M/N: AN2400-3306RS FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 8 of 8

FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright Ⓒ 2010, LTA Co., Ltd. SAMPLE LABEL & LOCATION

FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 2 Internal photo Module FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 2 MainBoard - Front MainBoard - Rear

FCC ID: S7APARANISD1000A ATTACHMENT ** MPE Calculations ** The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 14.84dBm + 8.92dBi EIRP = 23.76 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 π) S = (30.48 * 7.80) / (4 * 20 2 * π) S = 0.0473 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density does not exceed the 1 mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. Estimated safe separation: R = √(PG / 4π) R = √(30.48 * 7.80/ 4π) R = 4.35Cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (8.92 / 10) G = 7.80

Ref. No.: LR500191010D Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 43 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: Oct 01~08, 2010 Test Report S/N: LR500191010D Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. IC APPLICANT Equipment Class : Part 15 Spread Spectrum Transmitter (DSS) Manufacturing Description : Bluetooth Serial Adapter Manufacturer : Sena Technologies, Inc. Model name : Parani-SD1000 Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 RSS-210 and ISSUE No.: 7 Date: 2007 Frequency Range : 2402 ~ 2480MHz RF power : 14.84 dBm - Conducted Data of issue : October 8, 2010 This test report is issued under the authority of: The test was supervised by: Kyung-Taek LEE, Technical Manager Hyun-Chae You, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 S7APARANISD1000A 8154A-SD1000A Sena Technologies, Inc. Ref. No.: LR500191010D Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 43 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 TTANSMITTER OUTPUT POWER ---------------------------------------------------------- 3.2.6 BAND – EDGE & SPURIOUS ----------------------------------------------------------------- 3.2.7 FIELD STRENGTH OF HARMONICS -Transmitter ---------------------------------------- 3.2.8 FIELD STRENGTH OF HARMONICS -Receiver ------------------------------------------ 3.2.9 AC CONDUCTED EMISSIONS --------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 8 10 17 22 26 32 36 39 42 Ref. No.: LR500191010D Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 43 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2011-09-30 ECT accredited Lab. RRL KOREA KR0049 2011-06-20 EMC accredited Lab. FCC U.S.A 610755 2011-04-22 FCC filing VCCI JAPAN R2133, C2307 2011-06-21 VCCI registration IC CANADA IC5799 2012-05-14 IC filing Ref. No.: LR500191010D Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 43 2. Information’s about test item 2-1 Applicant & Manufacturer Company name : Sena Technologies, Inc. Address : 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel / Fax : +82-2-571-8283/ +82-2-573-7710 2-2 Equipment Under Test (EUT) Trade name : Bluetooth Serial Adapter FCC ID : S7APARANISD1000A Model name : Parani-SD1000A Serial number : Identical prototype Date of receipt : October 1, 2010 EUT condition : Pre-production, not damaged Patch Antenna (M/N: HIF-2400) Max Gain 8.92 dBi Dipole Antenna (M/N: R-AN2400-1901RS) Max Gain 5.37 dBi Dipole Antenna (M/N: R-AN2400-5801RS) Max Gain 3.27 dBi Antenna type : Dipole Antenna (M/N: AN2400-3306RS) Max Gain 1.40 dBi Frequency Range : 2402 ~ 2480MHz RF output power : Maximum 14.84 dBm Number of channels : 79 Channel spacing : 1MHz Channel Access Protocol : Frequency Hopping Spread Spectrum (FHSS) Type of Modulation : Basic Mode(GFSK), EDR Mode(Pi/4 DQPSK, 8DPSK) Power Source for adapter : DC 9.0V 0.66A(M/N : 3A-061WP12) Power Source for battery : DC 3.7V 2-3 Tested frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC HP Compaq dx7400 dx7400 microtower CNG8330J9R HP MONITOR HPL1710 CNC816QHF2 HP KEYBOARD SK-8115 68A-04Q6 DELL MOUSE MO56UOA F0J00NOL DELL PRINTER STYLUS C65 N/A EPSON Ref. No.: LR500191010D Copyright ○ c 2010, LTA Co., Ltd. Page 5 of 43 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) Carrier Frequency Separation > 25 kHz C 15.247(a) Number of Hopping Frequencies > 15 hops C 15.247(a) 20 dB Bandwidth 99% Bandwidth > 1.5 MHz C 15.247 Dwell Time < 0.4 seconds C 15.247(b) Transmitter Output Power < 250 mWatt C 15.247(d) Conducted Spurious emission > 20 dBc C 15.247(d) Band Edge > 20 dBc Conducted C 15.249 / 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) C 15.109 Field Strength - Radiated C 15.207 /15.107 AC Conducted Emissions EN 55022 Line Conducted C 15.203 Antenna requirement - - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 RSS-210 and ISSUE No.: …

Text truncated - open the document above for the full version.

FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 2 Radiated Emission FCC ID: S7APARANISD1000A IC : 8154A-SD1000A Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 2 Conducted Emission
