S7APARANISD1000UBLUETOOTH USB-SERIAL ADAPTER

Parani-SD1000U User Guide Version 1.0.0 2010-10-22 00019500 User Guide for the Parani-SD1000U Version 1.0.0 Firmware version 1.0.X Printed in Korea Copyright Copyright 2010, Sena Technologies, Inc. All rights reserved. Sena Technologies reserves the right to make changes and improvements to its product without providing notice. Trademark Parani™ is a trademark of Sena Technologies, Inc. Windows® is a registered trademark of Microsoft Corporation. Ethernet® is a registered trademark of XEROX Corporation. Notice to Users When a system failure may cause serious consequences, protecting life and property against such consequences with a backup system or safety device is essential. The user agrees that protection against consequences resulting from system failure is the user's responsibility. This device is not approved for life-support or medical systems. Changes or modifications to this device not explicitly approved by Sena Technologies will void the user's authority to operate this device. Precautions and Safety Product Parani-SD meets the USB standards. Do not wire with non-standard products. Damage to your products may result from improper use. Do not drop or subject the device to impact. Damage to your products may result from improper use. Keep away from harsh environments including humid, dusty, and smoky areas. Damage to your products may result from improper use. Do not use excessive force on the buttons or attempt to disassemble the device. Damage to your products may result from improper use. Do not place heavy objects on the product. Damage to your products may result from improper use. 02 TA FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is con- nected. • Consult the dealer or an experienced radio/TV technician for help. Caution Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device has been designed to operate with the antennas listed below, and having a maximum gain of 8.92dB. Antennas not included in this list or having a gain greater than 8.92 dB are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. Antenna list : Antenna type Model name Max gain(dBi) Patch Antenna HIF-2400 Max Gain 8.92 dBi Dipole Antenna R-AN2400-1901RS Max Gain 5.37 dBi Dipole Antenna R-AN2400-5801RS Max Gain 3.27 dBi Dipole Antenna AN2400-3306RS Max Gain 1.40 dBi To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for successful communication. Technical Support Sena Technologies, Inc. 210 Yangjae-dong, Seocho-gu Seoul 137-130, Korea Tel: (+82-2) 573-5422 Fax: (+82-2) 573-7710 E-Mail: [email protected] Website: http://www.sena.com 02 TA Revision History Revision Date Name Description V1.0.0 2010-10-22 JH Park Initial Writing 02 TA Contents 1. Introduction 8 1.1. Overview .................................................................................................................................... 8 1.2. Product Specification.................................................................................................................. 9 2. Getting Started 10 USB Driver Installation .................................................................................................................. 10 2.1.................................................................................................................................................... 10 2.2. Operation Modes...................................................................................................................... 11 2.3. LED Indicators.......................................................................................................................... 11 2.4. Serial Ports ............................................................................................................................... 12 2.5. Data Bit..................................................................................................................................... 12 2.6. Hardware Flow Control ............................................................................................................ 12 2.7. Reset to Factory Defaults.......................…

Text truncated - open the document above for the full version.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 October 28, 2010 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 In re : Sena Technologies, Inc. FCC Application for FCC ID: S7APARANISD1000U To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 ATTESTATION STATEMENT In re : Sena Technologies, Inc. FCC ID: S7APARANISD1000U Date : October 28, 2010 15.247(a)(1) The hopping sequence must be pseudorandom all Channels are used equally on average the receiver input bandwidth is approximately equal to the transmit ba ndwidth the receiver hops in sequence with the transmitted signal 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) The system does not coordinate its channel selection/hopping sequence with oth er frequency hopping systems for the express purpose of avoiding the simultane ous occupancy of individual hopping frequencies by multiple transmitters. Regards, YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 October 28, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: S7APARANISD1000U. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Sena Technologies, Inc. LTA Co.,LTD. (Contact Person) Contact name: LEE, Kyung-Taek Position: Manager Phone:(82)31-323-6008 E-mail: [email protected] YoungSam, KIM / Vice President Sena Technologies, Inc.

Sena Technologies, Inc. 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel. +82-2-571-8283 Fax +82-2-573-7710 October 28, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Sena Technologies, Inc. FCC ID : S7APARANISD1000U Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Sena Technologies, Inc.. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Sena Technologies, Inc.. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name Schematics CONF APPENDIX S7APARANISD1000U SCH DIA.pdf Parts list CONF APPENDIX S7APARANISD1000U PL.pdf Block diagram CONF APPENDIX S7APARANISD1000U BLK DIA.pdf CONFIDENTIAL Operational description CONF APPENDIX S7APARANISD1000U OpDes.pdf External Photos SHORT-TERM CONF S7APARANISD1000U EXT Photo.pdf Internal Photos SHORT-TERM CONF S7APARANISD1000U INT Photo.pdf Test-Setup Photos SHORT-TERM CONF S7APARANISD1000U Test Photo.pdf SHORT-TERM CONFIDENTIAL User’s Manual SHORT-TERM CONF S7APARANISD1000U Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. YoungSam, KIM / Vice President Sena Technologies, Inc.

FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 7 Upper Lower FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 7 Front Rear FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 7 Left Right FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 7 ANTENNA- M/N: HIF-2400 FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 5 of 7 ANTENNA- M/N: R-AN2400-1901RS FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 6 of 7 ANTENNA- M/N: R-AN2400-5801RS FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 7 of 7 ANTENNA- M/N: AN2400-3306RS

FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright Ⓒ 2010, LTA Co., Ltd. SAMPLE LABEL & LOCATION

FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 2 Internal photo Module FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 2 MainBoard - Front MainBoard - Rear

FCC ID: S7APARANISD1000U ATTACHMENT ** MPE Calculations ** The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 13.3dBm + 8.92dBi EIRP = 22.22 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 π) S = (21.38* 7.80) / (4 * 20 2 * π) S = 0.0332 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density does not exceed the 1 mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. Estimated safe separation: R = √(PG / 4π) R = √(21.38 * 7.80/ 4π) R = 3.64Cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (8.92 / 10) G = 7.80

Ref. No.: LR500191011A Copyright ̺ c 2010, LTA Co., Ltd. Page 1 of 43G 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com G Dates of Tests: Oct 25~Nov 02, 2010 Test Report S/N: LR500191011A Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. IC APPLICANT Equipment Class : Part 15 Spread Spectrum Transmitter (DSS) Manufacturing Description : Bluetooth USB-Serial Adapter Manufacturer : Sena Technologies, Inc. Model name : Parani-SD1000U Test Device Serial No.: : Identical prototype Rule Part(s): FCC Part 15.247 Subpart C; ANSI C-63.4-2003 RSS-210 and ISSUE No.: 7 Date: 2007 Frequency Range : 2402 ~ 2480MHz RF power : 13.3 dBm - Conducted Data of issue : November 2, 2010 G G G G This test report is issued under the authority of: The test was supervised by: G G G G Kyung-Taek LEE, Technical Manager Hyun-Chae You, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. Ϳ·ͽͲ΁͑ͽͲͳ͑ʹΠΕΖͫ͑ͣͨͣͤ͟͡͡͞͡ S7APARANISD1000U 8154A-SD1000U Sena Technologies, Inc. Ref. No.: LR500191011A Copyright ̺ c 2010, LTA Co., Ltd. Page 2 of 43G G G TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 TTANSMITTER OUTPUT POWER ---------------------------------------------------------- 3.2.6 BAND – EDGE & SPURIOUS ----------------------------------------------------------------- 3.2.7 FIELD STRENGTH OF HARMONICS -Transmitter ---------------------------------------- 3.2.8 FIELD STRENGTH OF HARMONICS -Receiver ------------------------------------------ 3.2.9 AC CONDUCTED EMISSIONS --------------------------------------------------------------- G APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 8 10 17 22 26 32 36 39 42 Ref. No.: LR500191011A Copyright ̺ c 2010, LTA Co., Ltd. Page 3 of 43G 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: AgencyCountryAccreditation No. ValidityReference NVLAP U.S.A 200723-0 2011-09-30 ECT accredited Lab. RRL KOREA KR0049 2011-06-20 EMC accredited Lab. FCC U.S.A 610755 2011-04-22 FCC filing VCCI JAPAN R2133, C2307 2011-06-21 VCCI registration IC CANADA IC5799 2012-05-14 IC filing Ref. No.: LR500191011A Copyright ̺ c 2010, LTA Co., Ltd. Page 4 of 43G 2. Information’s about test item 2-1 Applicant & Manufacturer Company name : Sena Technologies, Inc. Address : 210 Yangjae-dong Seocho-gu Seoul 137-130 Korea Tel / Fax : +82-2-571-8283/ +82-2-573-7710 2-2 Equipment Under Test (EUT) Trade name : Bluetooth USB-Serial Adapter FCC ID : S7APARANISD1000U Model name : Parani-SD1000U Serial number : Identical prototype Date of receipt : October 25, 2010 EUT condition : Pre-production, not damaged Patch Antenna (M/N: HIF-2400) Max Gain 8.92 dBi Dipole Antenna (M/N: R-AN2400-1901RS) Max Gain 5.37 dBi Dipole Antenna (M/N: R-AN2400-5801RS) Max Gain 3.27 dBi Antenna type : Dipole Antenna (M/N: AN2400-3306RS) Max Gain 1.40 dBi Frequency Range : 2402 ~ 2480MHz RF output power : Maximum 13.3 dBm Number of channels : 79 Channel spacing : 1MHz Channel Access Protocol : Frequency Hopping Spread Spectrum (FHSS) Type of Modulation : Basic Mode(GFSK), EDR Mode(Pi/4 DQPSK, 8DPSK) Power Source : DC 5.0V By PC USB 2-3 Tested frequency LOWMIDHIGH Frequency (MHz) 2402 2441 2480 2-4 Ancillary Equipment EquipmentModel No. Serial No. Manufacturer Notebook PP37L 8V5RBN1 DELL PRINTER STYLUS C65 JF5Y020825 EPSON Ref. No.: LR500191011A Copyright ̺ c 2010, LTA Co., Ltd. Page 5 of 43G 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) Carrier Frequency Separation > 25 kHz C 15.247(a) Number of Hopping Frequencies > 15 hops C 15.247(a) 20 dB Bandwidth 99% Bandwidth > 1.5 MHz C 15.247 Dwell Time < 0.4 seconds C 15.247(b) Transmitter Output Power < 250 mWatt C 15.247(d) Conducted Spurious emission > 20 dBc C 15.247(d) Band Edge > 20 dBc Conducted C 15.249 / 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) C 15.109 Field Strength - Radiated C 15.207 /15.107 AC Conducted Emissions EN 55022 Line Conducted C 15.203 Antenna requirement - - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 RSS-210 and ISSUE No.: 7 Date: 2007  Antenna Requirement The Sena Technologies, Inc. Parani-SD1000U unit complies with the requirement of §15.203. The ant…

Text truncated - open the document above for the full version.

FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 2 Radiated Emission FCC ID: S7APARANISD1000U IC : 8154A-SD1000U Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 2 Conducted Emission
