SE-0119 WIRELESS DOOR ALARM W/REMOTE Magnetically Triggered Door Alarm And Remote Control PACKAGE INCLUDES: y Main Unit ... 1PC y Magnetic Sensor ... 1PC y Remote Control ... 1PC INSTALLATION: y Simply peel and stick the alarm to the door or any other place you wish to protect. y For best performance, keep the distance between the Main Unit and Magnetic Sensor no larger than half an inch. y The Magnetic Sensor can be installed on either side of the Main Unit. (see drawing below) BATTERY INSTALLATION/ REPLACEMENT: Main Unit : y Set the swtich to OFF and slide down the battery cover. y Follow the polarity instructions to insert 3 AAA Alkaline batteries (not included). y The red LED light will flash once if the batteries are installed correctly. y Put the battery cover back on. Remote Control : y Unscrew the back cover to insert or replace replace 1 fresh CR2032 battery. Follow the polarity instructions. y Press any button on the remote Control. The red LED will light if the battery is installed correctly. OPERATION: Remote Mode : y Make sure the Magnetic Sensors are aligned and batteries are installed correctly. y After installing the batteries, slide the switch to , and the red LED will flash once. y Slide down the battery cover and press the small button beside the battery compartment once. A beep will sound, and the red LED will flash for 5 seconds. The Main Unit is now waiting for the Remote Control to learn the code. y Press any button on the Remote Control and you’ll hear a Bi-Bi sound. This indicates the code has been learned successfully. y Press the ON button on the Remote Control, a Beep will sound, and the Main Unit will be armed in three seconds. The red LED will flash three times. y Press the OFF button on the Remote Control, a Bi-Bi will sound, accompanied by a flashing red LED. The device is now disarmed. y Under ARM status, once the door is opened, the alarm will go off continuously for 30 seconds. y Turn off the alarm by pressing the OFF button on the Remote Control or slide the switch to OFF on the Main Unit. Manual Mode : y Make sure the Magnetic Sensors are aligned and that the batteries are installed correctly. y Slide the switch to , and the Main Unit will be armed in three seconds and the red LED will flash three times. y Once the door is opened, the alarm will go off continuously for 30 seconds. y Turn off the alarm by sliding the switch to OFF. NOTES: y The Magnetic Sensor can be installed on either side of the Main Unit, to allow for doors that open from the left or the right. y Please replace with new batteries if the red LED on the Main Unit flashes at 10 second intervals, or the Remote Control range becomes obviously shorter. WARNING: The high pitched alarm sound may injure hearing if in close proximity to the ears. This alarm contains small parts and is not suitable for children. DISCLAIMER: All Doberman Security items are strenuously tested by our experienced R&D teams. Doberman, however, does not guarantee that this item will prevent all theft and/or attacks from occurring. This item is only meant to act as an alarm in emergency situations. LIMITED WARRANTY COVERAGE: If your product does not work properly because of a defect in materials or workmanship, Doberman will, for the length of the period as follows, which starts with the date of original purchase (“warranty period”), replace it with a new or a refurbished product. Product Parts Services All Doberman Brand Products Ninety (90) Days Mail-in During the parts warranty period, there will be no charge for Parts. You must first email acquiring a RMA number, and then mail-in your product during the warranty period. This warranty only applies to products purchased and serviced in U.S.A./CANADA The warranty is extended only to the original purchaser of a new product, which was not sold “as is”. A purchase receipt or other proof of the original purchase is required for warranty service. For assistance in U.S.A./CANADA, please visit our Website at: http://www.dobermanproducts.com or, send your request by E-Mail to: [email protected] LIMITED WARRANTY LIMITS AND EXCLUSIONS: The Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by Doberman, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, miss-adjustment of consumer controls, improper maintenance, power line surge, lighting damage, modification, rental use of the product, serviced by anyone other that a factory service center or other unauthorized service, or damage that is attributable to acts of God. THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY COVERAGE”. DOBERMAN IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING WITHOUT LIMITATION, LOSS OF GOODWILL, PROFITS OR REVENUE, LOSS OF USE OF THIS PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF SUBSTITUTE EQUIPMENT, DOWNTIME COSTS, OR CLAIMS OF ANY PARTY DEALING WITH BUYER FOR SUCH DAMAGES. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the service provider. The items listed are not exclusive, but are for illustration only.) ALL EXPRESSED AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABLITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY. Some states and/or provinces do not allow the exclusions or limitations of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the exclusions may not apply to you. This warranty gives you specific legal rights and you may also have others rights which vary from state to state and from province to p…
