S8ABCEBEEWireless Door Chime Receiver

www.tuv.com Appendix 7 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 1 von 2 Page 1 of 2 www.tuv.com Appendix 7 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 2 von 2 Page 2 of 2

www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 1 von 2 Page 1 of 2 www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 2 von 2 Page 2 of 2

www.tuv.com Appendix 4 Prüfbericht - Nr.: Test Report No. 14013998 001 FCCID: S8ABCEBEE FCCID Label and Label Location SIZE:L50MM*30MM This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Sure Win Technologies Ltd MODEL ： UA-1228 FCC ID S8ABCEBEE MADE IN CHINA

www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 1 von 3 Page 1 of 3 www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 2 von 3 Page 2 of 3 www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 3 von 3 Page 3 of 3

www.tuv.com Test Report No.: 14013998 001 Date: 11.08.2006 Page 2 of 7 Test Summary Spurious Radiated Emissions Result: Pass Conducted Emissions Result: Pass www.tuv.com Test Report No.: 14013998 001 Date: 11.08.2006 Page 3 of 7 Content List of Test and Measurement Instruments.........................................................4 General Product Information ................................................................................5 Product Function and Intended Use.............................................................................................5 Ratings and System Details ..........................................................................................................5 Independent Operation Mode........................................................................................................5 Submitted Documents ...................................................................................................................5 Test Set-up and Operation Mode..........................................................................6 Principle of Configuration Selection ............................................................................................6 Test Operation and Test Software ................................................................................................6 Special Accessories and Auxiliary Equipment ...........................................................................6 Countermeasures to achieve EMC Compliance..........................................................................6 Test Methodology ..................................................................................................7 Radiated Emission .........................................................................................................................7 Conducted Emission......................................................................................................................7 Test Results ...........................................................................................................7 Spurious Radiated Emissions Section 15.109 .........................................................................7 Conducted Emissions Section 15.107 ......................................................................................7 Appendix 1: Test Setup Appendix 2: EUT External Photo Appendix 3: EUT Internal Photo Appendix 4: FCCID Label and Label Location Appendix 5: Block Diagram and Operating Description Appendix 6: Specification of EUT Appendix 7: User Manual Appendix 8: Schematic Diagram Appendix 9: Bill of Material www.tuv.com Test Report No.: 14013998 001 Date: 11.08.2006 Page 4 of 7 List of Test and Measurement Instruments Kind of Equipment Manufacturer Type S/N Test Receiver Rohde & Schwarz ESVS30 842807/009 Biconical Antenna Rohde & Schwarz HK116 841489/015 Log.-Periodic Antenna Rohde & Schwarz HL223 841516/017 Double Ridge Horn Antenna EMCO 3115 9002-3347 Spectrum Analyzer Rohde & Schwarz FSP30 1093.4495K30 LISN Rohde & Schwarz ESH 3-Z5 849876/026 www.tuv.com Test Report No.: 14013998 001 Date: 11.08.2006 Page 5 of 7 General Product Information Product Function and Intended Use The equipment under test (EUT) is a wireless door chime receiver operating at 315MHz for generating music tone after receiving the signal from the associated door chime transmitter. Client declared that UA-1228 and UA-1229 are identical in their circuit layout and only difference in their cabinets. And UA-1228 was tested in this report. The EUT was tested with the associated door chime transmitter model TX-100A provided by the client. Ratings and System Details FCCID : S8ABCEBEE Operating frequency : 315MHz Number of channel : One ( receives different time frames from associated transmitter in one frequency channel) Modulation scheme : ASK Type of antenna : Integral antenna Power supply : AC mains, 110Volt, 60Hz Independent Operation Mode The basic operation mode: -receives data signal from the associated transmitter. For further information refer to User Manual Submitted Documents - Block diagram - User manual - Bill of material - Schematic circuit diagram www.tuv.com Test Report No.: 14013998 001 Date: 11.08.2006 Page 6 of 7 Test Set-up and Operation Mode Principle of Configuration Selection Emission: The test was performed under normal operating mode to obtain the maximum emission. Test Operation and Test Software - There was no special software to exercise the device. Special Accessories and Auxiliary Equipment The product has been tested together with the following additional accessories: - none Countermeasures to achieve EMC Compliance - none www.tuv.com Test Report No.: 14013998 001 Date: 11.08.2006 Page 7 of 7 Test Methodology Radiated Emission The radiated emission measurements were performed according to the procedures in ANSI C63.4-2003. The equipment under test (EUT) was placed at the middle of the 80 cm height turntable, and the turntable is 3 meters far from the measuring antenna. The EUT was tested in three orthogonal planes and the turntable was rotated 360ﾟ for obtaining the maximum emission. The antenna height scanned between 1m and 4m, and the antenna rotated to repeat the measurements for both the horizontal and vertical antenna polarizations. Repeat the measurement steps until the maximum emissions were obtained. Test Setup: Conducted Emission The conducted emission measurements were performed according to the procedures in ANSI C63.4-2003. Initial measurements were performed in peak and average detection modes on the live line. Any emission(s) recorded within 30dB below the relevant limit lines were re-measured using quasi-peak and average detection on the live and neutral lines with the worst case recorded in the table of results. Test Setup: EUT 3m Pre-Amplifier Measuring Receiver Turntable Ground Plane Semi-anechoic Chamber 50Ω Output Mains Input Wooden Table Ground Plane 0.8m EUT LISN EMI Receiver Screened …

Text truncated - open the document above for the full version.

www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 1 von 3 Page 1 of 3 Radiated Emission Test Radiated Emission Test www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 2 von 3 Page 2 of 3 Radiated Emission Test Radiated Emission Test www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14013998 001 Seite 3 von 3 Page 3 of 3 Conducted Emission Test
