CANTALOUPE SYSTEMS Getting started with seed February 2005 Version 1.1 cantaloupe SYSTEMS • [email protected] • www.cantaloupesys.com • 510.647.3785 CANTALOUPE SYSTEMS SEED DEVICE INSTALLATION INSTRUCTIONS PAGE 1 DEVICE & ANTENNA 1 seed device 1 Antenna HARDWARE 1 large o-ring 4 small o-rings 2 washers 2 nuts CABLES 1 MDB Y tap cable 1 DEX cable (3 pronged) with phono plug 1. Remove the backing from the Velcro patch on the back of the seed device. 2. Mount the seed device in the machine an example is illustrated in the diagram to the left. The seed device should be easily accessible. 3. Plug the phono plug end of the DEX cable into the DEX phono jack of the machine. 4. Tap the male and female connectors of the MDB Y tap cable into the existing MDB cable. Note: Ensure all the wiring is away from any moving parts of the machine. We recommend using cable ties to route the wires in an organized fashion. 1. Turn off machine 2. Mount the device 3. Mount the antenna 4. Attach cabling 5. Turn on machine 6. Call Cantaloupe Sytems to verify installation Mounting the device Overview of steps Parts cantaloupe SYSTEMS • [email protected] • www.cantaloupesys.com • 510.647.3785 CANTALOUPE SYSTEMS SEED DEVICE INSTALLATION INSTRUCTIONS NESQUIK ROYAL VENDING PAGE 2 1. Position the antenna on top of the machine. We recommend mounting it on the part of the machine where the vending machine controller is attached to. We recommend putting it as center and far forward as possible. The example to the left is mounted on the door. 2. Using a 1/4” drill bit, drill two holes downwards through the door to accomodate the two mounting bolts protruding from the antenna base. 3. Drill a larger hole inbetween and in line with the 1/4” holes to accomodate the two antenna cables. Note: This center hole must be large enough to be able to thread both cables and their connectors through the door. Plug in the cables to the seed device. Refer to the diagram on the left for reference. 1. Plug antenna cables in at (a) and (b). It does not matter which cable is plugged in to a or b. 2. Plug DEX cable into the device at (c) 3. Plug MDB cable into the device at (d) 4. Turn on the machine 5. Close the machine door 6. Call Cantaloupe Systems at 510.647.3785 to verify the installation. ab cd Mount the antenna to the machine door as illustrated in the diagram to the left: 4. Place a small o-ring around each bolt, and the large o-ring around the two antenna wires. 5. Mount the antenna on the door by threading the two bolts and the two antenna wires through the door. There should now be o-rings sandwiched between the bottom of the antenna and the top of the machine. 6. Place a small o-ring and then a washer on each bolt, and then screw in each bolt with a nut. Make sure the antenna is tightened down securely. Mounting the antenna Finishing up During or after an installation, the LED indicator lights will assist you in diagnosing the status of the device. There are two modes of the device - its resting state, and its confi guration state. The lights will differ in meaning according to what state the device is in. RESTING STATE The device is perpetually in resting state until a button is pressed. CONFIGURATION STATE Hold the Confi g button to view the confi guration state. Pressing and holding the button any longer than 10 seconds will force the device to DEX and report its data to Cantaloupe Systems (otherwise known as “forcing a DEX”). HOW TO USE THIS GUIDE There are two tables, one for resting state and confi guration state. Each table will describe the deviceʼs state ac- cording to what the LED indicators are doing. The symbols in the table represent the following: Solid light Off Blinking light CANTALOUPE SYSTEMS SEED DEVICE LED INDICATOR GUIDE StatusDEXRadioModem n/aLast DEX successfuln/aConnected to network Door openDEXing machinen/aConnecting/dialing to network Door closedLast DEX unsuccessfuln/aDisconnected from network StatusDEXRadioModem Device onLast DEX successfuln/aAble to connect to network Battery powerDEXing machinen/aModem problem Device offLast DEX unsuccessfuln/aUnable to connect to network Copyright © 2005 Cantaloupe Systems, Inc CANTALOUPE SYSTEMS SEED DOOR ADAPTER GUIDE INSTALLING THE DOOR ADAPTER Before attempting to install the adapter, please ensure that the door switch is in full working order. To install the adapter, fi rst refer to the diagram above. Note that the orientation of the adapter is crucial to indicate which cables go to which locations. Note that the smaller section of the adapter is on the bottom, which means the male spade connectors on the left go to the VMC, the female spade connectors on the right go to the door switch, and the 4 pin connector goes to the seed device. 1 CONNECT THE DOOR ADAPTER TO THE VMC Unplug the wires from the door switch. In the case of a three-pronged switch, take note of which tabs were originally connected. Plug the male spade connectors from the door adapter into the female spade connectors attached to the wires coming from the VMC. Color does not matter. If you cannot locate any connectors, you will need to splice the wire. Find the wires leading from the VMC to the door switch, and splice the male spade connector wires into these wires by cutting off the spade connectors (please remember that color does not matter). Strip the wires from the VMC and the wire from the left side of door adapter, and use wire nuts to connect the wires. 2 CONNECT THE DOOR ADAPTER TO THE DOOR SWITCH Plug the female spade connectors into the door switch, making sure to plug them into the same tabs as you noted in step (1). Again, please remember that color does not matter. If you need to splice, take the other side of the wires from step (1) (leading to the door switch), and then attach them to the wires originating from the right side of the door adapter, (labeled “To door switch” in the diagram). 3 CONNECT THE DOOR ADAPTER TO THE SEED DEVICE Plug in the 4 pin connector to the see…

Text truncated - open the document above for the full version.

2930 Shattuck Avenue Suite 206, Berkeley CA 94705 P:510.647.3785 F:510.295.2581 www.cantaloupesys.com Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 April 27, 2005 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Cantaloupe Systems requests confidentiality for the following products: FCC ID Number Product Title/Model S9D-101010 5330 For the product stated above, we request that the following information be held confidential: 1) Electrical Schematics of the Circuitry 2) Bill of Materials for the components used on Seed 3) Block Diagram detailing functionality of Seed 4) Operational Description and Manuals 5) Tune Up Procedure No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Cantaloupe Systems trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Anant Agrawal Director and President

EUT – Top & Profile view EUT – Top , profile & Back view EUT – Top, Profile & Front view

Label & Label Location

CETECOM Photographs of the equipment CETECOM Photographs of the equipment CETECOM Photographs of the equipment

EUT – Internal Top View EUT – Internal Bottom View

RF EXPOSURE INFO GSM operations at the 850 MHz Band Used limit for 850MHz fixed operation A) 0.57mW/cm2 @ 20cm=2.865W (34.57dBm) as per §1.1310 table 1B B) 1000 W ERP for Cellular Radiotelephone Service as per §1.1307 Table 1 Max. permitted Antenna gain where no routine evaluation is required: Ant. Gain = 34.57dBm – measured cond. Power = 34.57-33 = 1.57dBi – 2.14= -0.57dBD Used limit for 850MHz mobile operation: C) 0.57mW/cm2 @ 20cm=2.865W (34.57dBm) as per §1.1310 table 1B D) 1.5 W (31.76dBm )ERP for frequencies below 1.5 GHz as per §2.1091(c) Max. permitted Antenna gain where no routine evaluation is required: Ant. Gain = 31.76dBm – measured cond. Power = 31.76-33 = -1.24dBD GSM operations at the 1900 MHz Band Limit for 1900MHz fixed operation: 1mW/cm2 @ 20cm=5W (37dBm) Ant. Gain = 37dBm – measured cond. Power = 37-28.7 = 8.3dBi Limit for 1900MHz mobile operation: 2W (33dBm) EIRP Ant. Gain = 33dBm – measured cond. Power = 33-28.7 = 4.3dBi Date: 2005-05-11 Harpreet Sidhu Cetecom Inc.
