SBVZP002Digital Music System

Sonos Digital Music System ZonePlayer ZP80 Setup Guide Guía de configuración Installatiehandleiding Installationshandbuch Guide d'Installation Installationshandbok TM Sonos ZonePlayer ZP80 Setup Guide. For use with the Sonos Digital Music System. THIS DOCUMENT CONTAINS INFORMATION THAT IS SUBJECT TO CHANGE WITHOUT NOTICE. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including but not limited to photocopying, recording, information retrieval systems, or computer network without the written permission of Sonos, Inc. Sonos, Sonosnet, and all Sonos logos are trademarks of Sonos, Inc. Macintosh® and Mac OS® are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. Windows® XP and Windows® 2000 are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. This product includes technology owned by Microsoft Corporation and under a license from Microsoft Licensing, GP. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft Corporation and/or Microsoft Licensing, GP as applicable. MPEG Layer-3 audio decoding technology licensed from Fraunhofer IIS and Thomson. Sonos uses MSNTP software, which was developed by N.M. Maclaren at the University of Cambridge. © Copyright, N.M. Maclaren, 1996, 1997, 2000; © Copyright, University of Cambridge, 1996, 1997, 2000. All other products and services mentioned may be trademarks or service marks of their respective owners. © 2004-2006 by Sonos, Inc. All rights reserved. Version: 060101 January, 2006 TM Contents Sonos ZonePlayer ZP80 Setup Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Installationshandbuch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Installatiehandleiding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Installationshandbok . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Guide d'Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Guía de configuración . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 TM ii Regulation Information Europe This product complies with the requirements of the R&TTE Directive (1999/5/ED). A copy of the full Declaration of Conformance may be obtained at http://eu.sonos.com. Attention In France, operation is limited to indoor use within the band 2.454-2.4835 GHz. (Attention. En France, l’utilisation en intérieur est limitée à la bande de fréquences 2,454-2,4835 GHz.) USA This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is con- nected. •Consult the dealer or an experienced audio technician for help. Modifications not expressly ap- proved by the manufacturer may void the user's authority to operate the equipment under FCC rules. Canada This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Industry Canada The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s Web site www.hc-sc.gc.ca/rpb. RF Exposure Requirements To comply with FCC and EU exposure essential requirements, a minimum separation distance of 20cm (8 inches) is required between the equipment and the body of the user or nearby persons. Recycling Information This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead please deliver it to the applicable collection point for the recycling of electrical and electronic equipment. By recycling this product correctly, you will help conserve natural resources and prevent potential negative environmental consequences. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. Setup Guide Sonos ZonePlayer ZP80 Setup Guide 2 About the ZonePlayer ZP80 The ZonePlayer ZP80 is designed to be used with an external amplifier. It contains both analog and digital outputs so that you can easily connect it to your existing audio equipment. •Use a ZonePlayer ZP80 to connect your Sonos Digital Music System in a room where you already have an amplifier, such as your home theater system or the stereo system in your family room. •Use a ZonePlayer ZP80 to create a music zone in your home office where you already have a computer or a pair of powered speakers. •Use a ZonePlayer ZP80 if you have a distributed audio system that is driven from one cen- tral location with speaker wires home-run to this central location. •Use a ZonePlayer ZP80 to extend the wireless range of your Sonos Digital Music System if you want to set up a music zone in an area that lies beyond your current range. All Zone- Players, including the ZP80, can be used as wi…

Text truncated - open the document above for the full version.

tel: 650-726-1263 fax: 650-726-1252 [email protected] Thomas N. Cokenias EMC &Radio Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 Compliance Certification Services 1 December 2005 561F Monterey Road Morgan Hill, CA 95037 Attention: Application Examiner Reviewing Engineer Re: Request per 0.457 and 0.459 of FCC Rules to withhold certain documents from routine public access Applicant: Sonos Inc. Model: RedRocks FCC ID: SBVZP002 802.11g wireless music system To whom it may concern, Request is hereby submitted, on behalf of my client Sonos Inc. to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Block Diagrams Schematic Operational Description Rationale for request for confidentiality: Sonos has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. If you have questions or need further information, please contact the undersigned. Sincerely, tel: 650-726-1263 fax: 650-726-1252 [email protected] THOMAS N. COKENIAS EMC Consultant Agent for Sonos Inc.

1 Helen Zhao Subject:FW: FW: Sonos Inc., FCC ID: SBVZP002, Assessment NO.: AN05T5323, Notice#1 Revised_ReportZP8 0.pdf ZP80_Guide.pdf From: Tom Cokenias Sent: Tuesday, December 20, 2005 9:52 PM To: Helen Zhao Subject: Re: FW: Sonos Inc., FCC ID: SBVZP002, Assessment NO.: AN05T5323, Notice#1 Hi Helen, Attached please find new report with the info on the RBW and VBW, plus the user manual with the required 15.21 highlighted in yellow. best regards Tom >-----Original Message----- >From: Compliance Certification Services [mailto:[email protected]] >Sent: Monday, December 05, 2005 5:25 PM >To: Helen Zhao >Subject: Sonos Inc., FCC ID: SBVZP002, Assessment NO.: AN05T5323, >Notice#1 > > >Question #1: The user manual does not contain user information as >specified in FCC15.21. Please update the user manual. > >Question #2: The test report does not specify measurement procedure, >e.g. resolution bandwidth (RBW) and video bandwidth(VBW) setting for >radiated emission measurement above 1GHz employing peak and average >detector function. Please specify. > >Best Regards, >Helen Zhao > >The items indicated above must be submitted before processing can >continue on the above referenced application. Failure to provide the >requested information within 30 days of the original e-mail date may >result in application dismissal and forfeiture of the filing fee. >Also, please note that partial responses increase processing time >and should not be submitted. Any questions about the content of this >correspondence should be directed to the e-mail address listed below >the name of the sender.

Digital Music System ZonePlayer ZP80 TM SERIAL NUMBER 19NP AUDIO PRODUCT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RISK OF ELECTRIC SHOCK - DO NOT OPEN C AU T I O N FOR HOME OR OFFICE USE Tested To Comply with FCC Standards © 2 0 0 5 Y S T U D I O S L L C • Y S T U D I O S . C O M • Redrocks Graphics November 9, 2005 PMS 430C PMS 427C Die cut line PMS 430C BACK LABELBOTTOM LABEL VERSION 1 BUTTON ICONS outin L R ANALOG AUDIO OUT MAINS INPUTDIGITAL AUDIO OUT ~100 - 240V 100mA 50/60Hz PMS 427C PMS 430C Die cut line N1594 IC:5373A-ZP002 FCCID:SBVZP002 Digital Music System ZonePlayer ZP80 TM SERIAL NUMBER 19NP AUDIO PRODUCT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RISK OF ELECTRIC SHOCK - DO NOT OPEN C AU T I O N FOR HOME OR OFFICE USE Tested To Comply with FCC Standards PMS 427C Die cut line PMS 430C BOTTOM LABEL VERSION 2 (MY PREFERENCE) IC:5373A-ZP002 FCCID:SBVZP002 N1594

Page 1 of 28 Audix Corporation Report No.: EM-F940237A TEST REPORT OF FCC DoC On Behalf of Sonos, Inc. Zone Player (Red Rocks) Model No.: ZP80 Brand: SONOS Prepared for : Sonos, Inc. 223 DeLa Cuerra St. Santa Barbara, LA 93101, U.S.A. Prepared by : Audix Corporation Technical Division EMC Department No. 53-11, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County 24443, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax : (02) 2609-9303 File Number EM941149R1 Report Number EM-F940237A Date of Test of Revision A Dec. 15~ 16, 2005 Date of Revision A Dec. 26, 2005 Page 2 of 28 Audix Corporation Report No.: EM-F940237A TABLE OF CONTENTS Description Page Test Report For FCC Compliance Declaration......................................................................................3 1. DESCRIPTION OF VERSION.......................................................................................................4 2. GENERAL INFORMATION..........................................................................................................5 2.1. Description of Device (EUT).........................................................................................................5 2.2. Tested Supporting System Details..................................................................................................6 2.3. Description of Test Facility...........................................................................................................7 2.4. Measurement Uncertainty.............................................................................................................7 3. CONDUCTED EMISSION MEASUREMENT............................................................................8 3.1. Test Equipment............................................................................................................................8 3.2. Block Diagram of Test Setup.........................................................................................................8 3.3. Conducted Emission Limits (§15.107, Class B)..............................................................................8 3.4. Conducted Emission Measurement Results.....................................................................................9 4. RADIATED EMISSION MEASUREMENT...............................................................................12 4.1. Test Equipment..........................................................................................................................12 4.2. Block Diagram of Test Setup.......................................................................................................12 4.3. Radiated Emission Measurement Results.....................................................................................14 5. DEVIATION TO TEST SPECIFICATIONS..............................................................................21 6. PHOTOGRAPHS...........................................................................................................................22 6.1. Photos of Conducted Emission Measurement...............................................................................22 6.2. Photos of Radiated Measurement at Open Area Test Site (30-1000MHz, 10m)......................................24 6.3. Photos of Radiated Measurement at Semi-Anechoic Chamber (1-2GHz, 3m)......................................27 APPENDIX I (Photos of EUT) Page 3 of 28 Audix Corporation Report No.: EM-F940237A TEST REPORT FOR FCC COMPLIANCE DECLARATION Applicant Sonos, Inc. Manufacturer Inventec Electronics (M) Sdn Bhd EUT Description Zone Player (Red Rocks) (A) MODEL NO. ZP80 (B) SERIAL NO. N/A (C) BRAND SONOS (D) POWER SUPPLY 100-240Vac, 50/60Hz (E) TEST VOLTAGE AC 120V/60Hz Measurement Regulations and Procedure Used: FCC CFR 47 Part 15 Subpart B/Sep. 2005 and CISPR 22/1997 ANSI C63.4-2003 The device described above was tested by AUDIX Corporation to determine the maximum emission levels emanating from the device. The maximum emission levels were compared to the FCC Part 15 Sections 15.107(a) and 15.109(g) Class B limits both conducted and radiated emissions. The measurement results are contained in this test report and AUDIX Corporation is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only and which shall not be reproduced in part without written approval of AUDIX Corporation. The applicant to claim product endorsement by NVLAP or any agency of the U.S. Government must not use this report. This report is based on report of EM-F940237. Date of Revision A : Dec. 26, 2005 Date of Test of Revision A : Dec. 15 ~ 16, 2005 Date of Test of Original : Oct. 11 ~ 13, 2005 Prepared by : (Tina Huang/Assistant) Test Engineer : (Ben Cheng/SectionManager) Approved & Authorized Signer : (Leon Liu/Senior Manager) Name of the Representative of the Responsible Party : Signature : Page 4 of 28 Audix Corporation Report No.: EM-F940237A 1. DESCRIPTION OF VERSION Edition No. Date of Revision Revision Summary Report Number 0 Oct. 20, 2005 Original Report. EM-F940237 Rev. A Dec. 26, 2005 1. Changed PC Boards, circuit re-layout and component parts difference. 2. Changed Power Board. 3. Supplementary test data are recorded in this report. EM-F940237A Page 5 of 28 Audix Corporation Report No.: EM-F940237A 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Description Zone Player (Red Rocks) This device is a digital music system using a wired or wireless connection. Model Number ZP80 Serial Number N/A Brand SONOS Applicant Sonos, Inc. 223 DeLa Cuerra St. Santa Barbara, LA 93101, U.S.A. Manufacturer Inventec Electronics (M) Sdn. Bhd. Plot 102, Bayan Lepas Industrial Estate, 11900 Bayan Lepas, Penang, Malaysia. High Frequency of Used 16.0MHz20.0MHz20.0MHz20.0MHz 25.0MHz33.0MHz for Main Controller 11.289MHz for Audio Controller 40 MHz for Wir…

Text truncated - open the document above for the full version.

FCC ID. SBVZP002 Page 1 of 57 Audix Corporation Report No. EM-F940238 APPLICATION FOR CERTIFICATION On Behalf of Sonos, Inc Zone Player Model No.ZP80 FCC IDSBVZP002 Prepared for : Sonos, Inc 223 DeLa Cuerra St. Santa Barbara, LA 93101, U.S.A. Prepared by : Audix Corporation Technical Division EMC Department No. 53-11, Tin-Fu Tsun, Lin-Kou, Taipei County, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax: (02) 2609-9303 File Number EM941149 Report Number EM-F940238 Date of Test Oct. 11 ~ 13, 2005 Date of Report Oct. 20, 2005 FCC ID. SBVZP002 Page 2 of 57 Audix Corporation Report No. EM-F940238 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION.......................................................................................................4 1. GENERAL INFORMATION.......................................................................................................5 1.1. Description of Device (EUT).........................................................................................................5 1.2. Tested Supporting System Details..................................................................................................6 1.3. Description of Test Facility...........................................................................................................7 1.4. Measurement Uncertainty.............................................................................................................7 2. CONDUCTED EMISSION MEASUREMET............................................................................8 2.1. Test Equipment............................................................................................................................8 2.2. Block Diagram of Test Setup.........................................................................................................8 2.3. Conducted Emission Limits (§15.207)...........................................................................................8 2.4. Operating Condition of EUT.........................................................................................................9 2.5. Test Procedure..............................................................................................................................9 2.6. Conducted Emission Measurement Results.....................................................................................9 3. RADIATED EMISSION MEASUREMENT............................................................................12 3.1. Test Equipment..........................................................................................................................12 3.2. Test Setup..................................................................................................................................12 3.3. Radiated Emission Limits (§15.209)............................................................................................13 3.4. Operating Condition of EUT.......................................................................................................13 3.5. Test Procedure............................................................................................................................14 3.6. Radiated Emission Measurement Results.....................................................................................14 4. 6dB BANDWIDTH MEASUREMENT.....................................................................................39 4.1. Test Equipment..........................................................................................................................39 4.2. Block Diagram of Test Setup.......................................................................................................39 4.3. Specification Limits (§15.247(a)(2))............................................................................................39 4.4. Operating Condition of EUT.......................................................................................................39 4.5. Test Procedure............................................................................................................................39 4.6. Test Results................................................................................................................................40 5. MAXIMUM PEAK OUTPUT POWER MEASUREMENT...................................................42 5.1. Test Equipment..........................................................................................................................42 5.2. Block Diagram of Test Setup.......................................................................................................42 5.3. Specification Limits (§15.247(b)-(3))...........................................................................................42 5.4. Operating Condition of EUT.......................................................................................................42 5.5. Test Procedure............................................................................................................................42 5.6. Test Results................................................................................................................................42 6. EMISSION LIMITATIONS MEASUREMENT......................................................................43 6.1. Test Equipment..........................................................................................................................43 6.2. Block Diagram of Test Setup.......................................................................................................43 6.3. Specification Limits (§15.247(c))................................................................................................43 6.4. Operating Condition of EUT.......................................................................................................43 6.5. Test Procedure...................................................................…

Text truncated - open the document above for the full version.

Page 1 of 28 Audix Corporation Report No.: EM-F940237A TEST REPORT OF FCC DoC On Behalf of Sonos, Inc. Zone Player (Red Rocks) Model No.: ZP80 Brand: SONOS Prepared for : Sonos, Inc. 223 DeLa Cuerra St. Santa Barbara, LA 93101, U.S.A. Prepared by : Audix Corporation Technical Division EMC Department No. 53-11, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County 24443, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax : (02) 2609-9303 File Number EM941149R1 Report Number EM-F940237A Date of Test of Revision A Dec. 15~ 16, 2005 Date of Revision A Dec. 26, 2005 Page 2 of 28 Audix Corporation Report No.: EM-F940237A TABLE OF CONTENTS Description Page Test Report For FCC Compliance Declaration......................................................................................3 1. DESCRIPTION OF VERSION.......................................................................................................4 2. GENERAL INFORMATION..........................................................................................................5 2.1. Description of Device (EUT).........................................................................................................5 2.2. Tested Supporting System Details..................................................................................................6 2.3. Description of Test Facility...........................................................................................................7 2.4. Measurement Uncertainty.............................................................................................................7 3. CONDUCTED EMISSION MEASUREMENT............................................................................8 3.1. Test Equipment............................................................................................................................8 3.2. Block Diagram of Test Setup.........................................................................................................8 3.3. Conducted Emission Limits (§15.107, Class B)..............................................................................8 3.4. Conducted Emission Measurement Results.....................................................................................9 4. RADIATED EMISSION MEASUREMENT...............................................................................12 4.1. Test Equipment..........................................................................................................................12 4.2. Block Diagram of Test Setup.......................................................................................................12 4.3. Radiated Emission Measurement Results.....................................................................................14 5. DEVIATION TO TEST SPECIFICATIONS..............................................................................21 6. PHOTOGRAPHS...........................................................................................................................22 6.1. Photos of Conducted Emission Measurement...............................................................................22 6.2. Photos of Radiated Measurement at Open Area Test Site (30-1000MHz, 10m)......................................24 6.3. Photos of Radiated Measurement at Semi-Anechoic Chamber (1-2GHz, 3m)......................................27 APPENDIX I (Photos of EUT) Page 3 of 28 Audix Corporation Report No.: EM-F940237A TEST REPORT FOR FCC COMPLIANCE DECLARATION Applicant Sonos, Inc. Manufacturer Inventec Electronics (M) Sdn Bhd EUT Description Zone Player (Red Rocks) (A) MODEL NO. ZP80 (B) SERIAL NO. N/A (C) BRAND SONOS (D) POWER SUPPLY 100-240Vac, 50/60Hz (E) TEST VOLTAGE AC 120V/60Hz Measurement Regulations and Procedure Used: FCC CFR 47 Part 15 Subpart B/Sep. 2005 and CISPR 22/1997 ANSI C63.4-2003 The device described above was tested by AUDIX Corporation to determine the maximum emission levels emanating from the device. The maximum emission levels were compared to the FCC Part 15 Sections 15.107(a) and 15.109(g) Class B limits both conducted and radiated emissions. The measurement results are contained in this test report and AUDIX Corporation is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only and which shall not be reproduced in part without written approval of AUDIX Corporation. The applicant to claim product endorsement by NVLAP or any agency of the U.S. Government must not use this report. This report is based on report of EM-F940237. Date of Revision A : Dec. 26, 2005 Date of Test of Revision A : Dec. 15 ~ 16, 2005 Date of Test of Original : Oct. 11 ~ 13, 2005 Prepared by : (Tina Huang/Assistant) Test Engineer : (Ben Cheng/SectionManager) Approved & Authorized Signer : (Leon Liu/Senior Manager) Name of the Representative of the Responsible Party : Signature : Page 4 of 28 Audix Corporation Report No.: EM-F940237A 1. DESCRIPTION OF VERSION Edition No. Date of Revision Revision Summary Report Number 0 Oct. 20, 2005 Original Report. EM-F940237 Rev. A Dec. 26, 2005 1. Changed PC Boards, circuit re-layout and component parts difference. 2. Changed Power Board. 3. Supplementary test data are recorded in this report. EM-F940237A Page 5 of 28 Audix Corporation Report No.: EM-F940237A 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Description Zone Player (Red Rocks) This device is a digital music system using a wired or wireless connection. Model Number ZP80 Serial Number N/A Brand SONOS Applicant Sonos, Inc. 223 DeLa Cuerra St. Santa Barbara, LA 93101, U.S.A. Manufacturer Inventec Electronics (M) Sdn. Bhd. Plot 102, Bayan Lepas Industrial Estate, 11900 Bayan Lepas, Penang, Malaysia. High Frequency of Used 16.0MHz20.0MHz20.0MHz20.0MHz 25.0MHz33.0MHz for Main Controller 11.289MHz for Audio Controller 40 MHz for Wir…

Text truncated - open the document above for the full version.
