www.vilant.com Vilant TrackerCharger User Guide Vilant TrackerCharger 2 Version 1.0© Vilant Systems 2013 / www.vilant.com Error indicator Busy indicator Charge level indicator USB-connector On PC ordedicatedUSB power-supply 3 1) Connect to USB port © Vilant Systems 2013 / www.vilant.com Busy indicator will start blinking when connected USB connectors are marked with this sign Version 1.0 Open charginglidon trackerbeforeinserting 4 2) Inserttrackerand close © Vilant Systems 2013 / www.vilant.com The charging lid should be entirely opened insert Close & click Version 1.0 On PC ordedicatedUSB power-supply 5 3) Waitduringcharging © Vilant Systems 2013 / www.vilant.com The green indicators show charging progress. Charging is finished when the busy indicator is off and all green indicators are on Version 1.0 6 4) Takeout thetracker © Vilant Systems 2013 / www.vilant.comVersion 1.0 I have a USB-charger, can I use this to connect the Jiivacharger to? –Yes, you can use any powered USB port to charge. How long does a charging cycle take? –This depends on the USB-port and the remaining battery charge in the tracker. When I insert a tracker, all 4 green indicators are switched on, what’s happening? –The battery in the tracker is already full, the charger does not start a new charging cycle When I insert a tracker, none of the green indicators are switched on, what’s happening? –A bad contact between the tracker and the charger is likely to be the reason. Reopen the charger and close it again firmly and wait a few seconds. Normally one or more green indicators should be switched on. –If the previous doesn’t solve the problem, the spring-loaded contacts on the charger may need to be cleaned. For this purpose, use a soft cotton sick and pure alcohol. The red error indicator is blinking, what should I do? –The read indicator indicates a fatal system error. Please return the charger to your local Vilant Tracker distributor for repair or replacement if covered by warranty. 7 Questions © Vilant Systems 2013 / www.vilant.comVersion 1.0 © Vilant Systems 2013 / www.vilant.comVersion 1.0 8 Warnning FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by party responsible for compliance coulk void the user’s authority to operate the equipment. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – All View EUT – Top View EUT – BottomView EUT – Left View EUT – Right View Charger: EUT –Top View EUT –Bottom View EUT –Left Side View EUT –Right Side View

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT-Top Cover off View EUT – Bottom Cover off View EUT – Main Board Top View EUT –Main Board Bottom View EUT –Main Board without Shielding Top View EUT – GSM Antenna View EUT – RF Monitor Antenna View EUT – Battery View Charger: EUT –Uncover View EUT – Cover off View EUT – Main Board Top View EUT – Main Board Bottom View

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R1DG120807002-00A FCC Part 22H/24E Page 9 of 28 FCC §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart FCC §1.1310 and §2.1091 systems operating under the provisions of t his section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mw/cm 2 ) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Test Data Predication of MPE limit at a given distance S = PG/4πR² Where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Antenna Gain Conducted Power Mode Frequency (MHz) (dBi) (numeric)(dBm) (mW) Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) Cellular Band 836.6 -1.00 0.79 31.78 1506.6120 0.2382 0.56 PCS Band 1909.8 -1.00 0.79 29.08 809.10 20 0.1279 1.0 Result: The device meets FCC MPE limit at 20 cm distance.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). FCC PART 22H, PART 24E MEASUREMENT AND TEST REPORT For Vilant Systems Oy Tietajantie 2, 02130 ESPOO, FINLAND FCC ID: SEY-EA920 Report Type: Original Report Product Type: GSM-Tracker Test Engineer: Leon Chen Report Number: R1DG120807002-00A Report Date: 2012-08-23 Reviewed By: Ivan Cao RF Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R1DG120807002-00A FCC Part 22H/24E Page 2 of 28 TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .....................................................................................4 OBJECTIVE...................................................................................................................................................................4 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................4 TEST METHODOLOGY..................................................................................................................................................4 TEST FACILITY.............................................................................................................................................................5 SYSTEM TEST CONFIGURATION ..........................................................................................................................6 JUSTIFICATION.............................................................................................................................................................6 EQUIPMENT MODIFICATIONS.......................................................................................................................................6 SUPPORT EQUIPMENT LIST AND DETAILS....................................................................................................................6 CONFIGURATION OF TEST SETUP.................................................................................................................................6 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................7 SUMMARY OF TEST RESULTS...............................................................................................................................8 FCC §1.1307 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE).............................................................9 APPLICABLE STANDARD..............................................................................................................................................9 TEST DATA..................................................................................................................................................................9 FCC §2.1047 - MODULATION CHARACTERISTIC ............................................................................................10 FCC § 2.1046, § 22.913 (A) & § 24.232 (C) - RF OUTPUT POWER......................................................................11 APPLICABLE STANDARD............................................................................................................................................11 TEST PROCEDURE......................................................................................................................................................11 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................11 TEST DATA................................................................................................................................................................12 FCC §2.1049, §22.917, §22.905 & §24.238 - OCCUPIED BANDWIDTH ..............................................................14 APPLICABLE STANDARD............................................................................................................................................14 TEST PROCEDURE......................................................................................................................................................14 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................14 TEST DATA................................................................................................................................................................14 FCC §2.1051, §22.917(A) & §24.238(A) - SPURIOUS EMISSIONS AT ANTENNA TERMINALS ..................17 APPLICABLE STANDARD............................................................................................................................................17 TEST PROCEDURE......................................................................................................................................................17 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................17 TEST DATA................................................................................................................................................................17 FCC §2.1053, §22.917 & §24.238 - SPURIOUS RADIATED EMISSIONS ...........................................................19 APPLICABLE STANDARD...................…
