SGG-IBOBBERiBobber is a castable bluetooth fishfinder that syncs with iOS and Anfroid phone/tablet platforms

Product Information Guide 1 Welcome to iBobber™. This guide will show you how to use the iBobber to make shing more fun than it's ever been. Please read this guide completely before using iBobber, and retain this guide for future reference. Follow all instructions. For a downloadable pdf version of this guide, please go to ReelSonar.com. iBobber USB Charger Carry Pouch iBobber App Redemption Instructions If you have any questions, or any items are damaged or missing, please email [email protected]. PRODUCT INFORMATION GUIDE INCLUDED IN PACKAGE Fishfinder Table of Contents 3 App Redemption 4 Charging the iBobber 6 Quick Overview 9 Settings 10 Personal 11 Syncing iBobber 14 Home 15 Sonar 16 Waterbed Mapping 18 Weather 19 Calendar 20 Trip Log / GPS Tag 22 Sonar Status Dashboard 23 Troubleshooting 25 Firmware Update 26 Warranty 27 Important Safety and Care Information 29 All Other Important Stu Fishfinder 2 The iBobber is available for, and syncs with iPhone 4S, 5, 5C, 5S, iPad 2, 3, Mini and Air. Note: iBobber is not currently available for Android phones and tablets. From your desktop or iOS device, go to the Apple App store and search for iBobber or ReelSonar. Once you've found it, download and install the iBobber App. Install the app on to your iOS device, and launch the app. App Redemption iPhone / iPad: Fishfinder 3 4 (image 1)(image 2) Before you rst use the iBobber you'll need to charge it. It's very simple — just align the "bumps" on the white side of the iBobber (image 1) with the grooves in the charger cradle (image 2). Go to page 5. bump grooves charging tip charging pins Charging the iBobber (1 of 2) Fishfinder (image 3)(image 4) Gently push down the bobber into the charger (image 3) and gently twist the bobber clockwise so the "bumps" slide horizontally through the grooves. Plug the charging cable into your computer USB port, or using a USB adapter into a standard household outlet (U.S.) and charging will start, indicated by a blue light along the circumference of the iBobber (image 4). The light will remain on until fully charged, and then will ash indicating a full charge. Note: When fully charged, the iBobber turns on when disconnected from the charger and remains on for 10 minutes. This is for when you need to update the rmware (page 25). Please check for rmware update through the App when intially charging the iBobber, and update if necessary. 5 bump groove blue light = charging Charging the iBobber (2 of 2) bumps enter grooves Fishfinder push down gently gently twist clockwise to lock unlock gently twist counter clockwise 6 A B C D E F G H I J K - Active Indicator (current screen) - Sonar Screen Icon • Tap for Sonar - Sonar Status & iBobber Status / Orange means iBobber is active, Tap for iBobber status - Waterbed Mapping Icon • Tap for Waterbed - Home Dasboard - Sonar Screen - Waterbed - Weather - Calendar - Settings - Trip Log Quick Overview • iBobber App Dashboards / Screens Fishfinder 7 L M N O P - iBobber Battery - Water Temperature - Strike Alarm (o/on/adjustable) - Fish Alarm (o/on) - iBobber LED Light (o/on) Quick Overview • iBobber App Dashboards / Screens Fishfinder 8 Home This is the rst screen you'll see. And before you can use iBobber you'll need to register it. If you've avoided the initial Registration Screen, tap "Settings." More on Home Screen and features to follow. Quick Overview • iBobber App Dashboards / Screens Fishfinder (image 5) 3 App Redemption 4 Charging the iBobber 6 Quick Overview 9 Settings 10 Personal 11 Syncing iBobber 14 Home 15 Sonar 16 Waterbed Mapping 18 Weather 19 Calendar 20 Trip Log / GPS Tag 22 Sonar Status Dashboard 23 Troubleshooting 25 Firmware Update 26 Warranty 27 Important Safety and Care Information 29 All Other Important Stu 9 Settings This is the rst screen of Settings, and the only one you need to register. Choose your measurement preference (tap a circle): Imperial in the U.S., Metric in the rest of the world. Now tap Personal. (image 6) Fishfinder From your desktop or iOS device, go to the Apple App store and search for iBobber or ReelSonar. Once you've found it, download and install the iBobber App. Install the app on to your iOS device, and launch the app. 10 Personal Tap the nickname eld and a keyboard will open (image 8). Input a nick name by which you'd like your bobber to be known, then touch email and enter your email address (image 8). Tap "Favorite Fish" and tag all your favorite sh (image 8). Tap Save and you're registered. Now tap "Back" button. (image 7)(image 8) Fishfinder 11 Syncing iBobber (1 of 3) On the settings screen is where you sync your iOS device and the iBobber. The iBobber turns on when it's in the water, so you'll want to be prepared to sh when you sync it. Here's what you'll need to do when you're ready to use the iBobber. (image 9) 1) Attach the iBobber to your shing line by attaching your line through the higher of the two attach- ment points. We suggest you use a swivel and make sure it's locked so the iBobber doesn't become separated from the line. The lower attachment point is used to attach a lure when shing for small pan sh. 2) Place the iBobber into the water nearby. The water will activate the iBobber, turning it on. You're now ready to sync. Go to page 12. Attach point Attach point Fishfinder Syncing iBobber (2 of 3) (image 10)(image 11)(image 12) 3) Tap Bluetooth Sync (image 10). 4) The iBobber will appear on your device, listed by its nickname. Tap the circle next to your iBobber nickname (image 11). When the connection is made, the Sonar icon in the top navigation between the sh and waterbed sihouettes will turn orange (image 12). You're now ready to nd sh up to 100' away. Note: Bluetooth ball continues to spin. 12 Fishfinder Syncing iBobber (3 of 3) Note 1: The rst time you use the iBobber you'll pair the iBobber (nickname) with your phone. If you and a bunch of friends are syncing for the rst time, you'll need to do it separately — cast yours into the wate…

Text truncated - open the document above for the full version.

3/18/2014 To Whom It May Concern: We hereby delegate CKC Certification Services, LLC (CKC CS) power of attorney to act on our behalf in matters pertaining to certification of products. The actions of CKC CS shall be considered the same as our own. Sincerely, Alexander Lebedev CEO

3/21/2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Reelsonar, Inc. would like the following documents regarding this submission for FCC ID: FCC ID: SGG- IBOBBER to be kept confidential. • Schematics • Operational/Functional Description with Block Diagrams • Parts List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Reelsonar Alexander Lebedev CEO ReelSonar Inc Tel. 206-313-4678

This report contains a total of 27 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. ReelSonar ADDENDUM TO TEST REPORT 94243-5 Bluetooth Ultrasonic Fish Finder Model: iBobber Tested To The Following Standards: FCC Part 15 Subpart C § 15.249 Report No.: 94243-5A Date of issue: April 28, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 27 Report No.: 94243-5A TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C .................................................................................................................................................... 7 15.249(a) Maximum Power Output ........................................................................................................................... 7 15.215(c) Occupied Bandwidth ............................................................................................................................... 11 15.249(d) Field Strength of Spurious Emissions and Band Edge ............................................................................. 16 Supplemental Information .......................................................................................................................................... 26 Measurement Uncertainty ...................................................................................................................................... 26 Emissions Test Details .............................................................................................................................................. 26 Page 3 of 27 Report No.: 94243-5A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: ReelSonar 2316 Eastlake Ave E Seattle, WA 98102 Morgan Tramontin CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Chris Doughty Project Number: 94243 Customer Reference Number: 14-004 DATE OF EQUIPMENT RECEIPT: February 24, 2014 DATE(S) OF TESTING: February 24-March 4, 2014 April 18, 2014 Revision History Original: Testing of the Bluetooth Ultrasonic Fish Finder, iBobber to FCC 15.249. Addendum A: To replace data sheet and test plots in section 15.215(c) Occupied Bandwidth. To replace data sheet and test plots in section 15.249(a) Maximum Power Output. Replace data in Field Strength Spurious emissions and Band Edge section 15.249(d). Add Y and Z Axis photos to all test sections. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 27 Report No.: 94243-5A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 22116 23rd Drive S.E., Suite A Bothell, WA 98021-4413 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Bothell US0081 SL2-IN-E-1145R 3082C-1 318736 A-0148 Page 5 of 27 Report No.: 94243-5A…
