SI4-MBDC212CBluetooth USB Adapter

Bluetooth USB Adapter User Guider Unwire your life V1.4.2- 920928y 1 Index INTRODUCTION 3 CHAPTER 1 Bluetooth profile support 3 Drivers support 3 Setup for Mac 3 CHAPTER 2 Application note for Windows 98SE/ME/2000/XP 5 Icons used for Bluetooth devices and services 5 Network sharing setting for Windows 8 File transfer setting for Windows 16 Dial-up networking setting for Windows 18 FAX setting 21 PIM Item Transfer setting 22 PIM Synchronization setting 23 Serial Port setting 24 ActiveSync setting 25 Audio Gateway setting for windows 27 Personal area network setting for Windows 29 How to setup an Ad-hoc Network 30 How to setup with Bluetooth Network Access Point 32 2 Introduction Bluetooth is an open specification for a cutting-edge technology that enables short-range wireless connections between desktop and laptop computers, personal digital assistants, cellular phones, printers, scanners, digital cameras and even home appliances — on aglobally available band (2.4GHz) for worldwide compatibility. In a nutshell, Bluetooth unplugs your digital peripherals and makes cable clutter a thing of the past. Now you can connect your PDA or PC to Bluetooth™ enabled mobile phone with this Bluetooth™ adapter. You can access e-mail & Internet no matter where you are with just a little help from your Bluetooth™ mobile phone. Plus, when you are back in the office, you can hook yourself up to your office network as well as communicate with other Bluetooth™-enabled devices. 3 Chapter 1 1.1 Bluetooth profile support includes: Generic Access Profile (GAP), Serial Port Profile (SPP), Service Discovery Application Profile (SDAP), Generic Object Exchange Profile (GOEP), Object Push Profile (OPP), File Transfer Profile (FTP), Dial-up Network Profile (DUN), LAN Access Profile (LAP), Fax Profile (FAX), Synchronization Profile, Headset Profile, Audio GatewayProfile(AG) Personal Area Network (PAN) Human Interface Device (HID) Hardcopy Cable Replacement Profile (HCRP) 1.2 Drivers support USB Bluetooth: Windows 98SE, Me, 2000, XP, Linux O.S., Mac O.S. X v10.1.2 and higher... 1.3 Mac O.S.X v10.1.2 Mac O.S. X v1.2 has build-in Bluetooth software for USB Bluetooth adapters, therefore no additional Bluetooth software is required. Simply plug in the USB Bluetooth adapter and a Bluetooth icon will appear in the System folder. Open the Bluetooth applet to configure the Bluetooth functions on your Mac system 4 Chapter 2 Application note for Windows 98SE/ME/2000/XP 2.1 Icons used for Bluetooth devices and services Bluetooth icons provide at-a-glance feedback about a device or service's status by changing appearance. The Bluetooth icon in the Windows system tray provides feedback about Bluetooth status. Basic Bluetooth Icon Device Icons for Windows 98SE, Me and 2K 5 Service Icons for Windows 98SE, Me and 2K Device Icons for Windows XP 6 Service Icons for Windows XP NOTE: Only available services are displayed in the menus 7 2.2. Network sharing setting for Windows The Network Access service permits a Bluetooth enabled PC (client) to access the Internet via another Bluetooth enabled PC (Server) that already has an Ethernet connection. Windows network sharing setting PC to PC (Windows 2000 or Windows XP) 1. To enable Internet Connection Sharing on the server PC 2. Click on Start menu-->Settings -->Network and Dial-up Connections and find your Local Area Connection (LAN) that is connected to the Internet. 3. Right click the active LAN connection to open the "Properties" dialog box. 8 4. Click on "Advanced" tab and select the "Internet Connection Sharing" checkbox to enable Internet sharing. 9 5. Click on "Settings..." button and select the services you wish to provide other Bluetooth devices. Click "OK" to save the changes. 6. Go back to the "Network and Dial-up Connections" window, right click the "Bluetooth LAN Access Server Driver" and select "Properties". 10 7. Under "General" tab, click on "Internet Protocol (TCP/IP)" and "Properties". 11 8. Under "General" tab, assign a virtual IP as shown in the picture below. Then click "OK" to save the changes. 9. This allows the server PC to act as a DHCP server towards the client PCs. NOTE: For Win98SE and WinMe, please download and install WinRoute (or similar program) on the Server PC to allow DHCP service. 10. On the client PC, launch the Bluetooth software stack by clicking the "My Bluetooth Places" icon located on the desktop. 11. Double click the "Entire Bluetooth Neighborhood" icon to search for other Bluetooth devices nearby. 12 12. After searching is completed, locate the computer name of the server PC and double click it to discover the Bluetooth services it has to offer. (i.e. Bluetooth Serial Port, Dial-up Networking, File Transfer, Network Access, etc.). 13. Click on the "Network Access" icon to connect to the shared Internet connection on the server PC. 14. Click OK without entering any username or password. If one is already present, click OK anyway and it will still connect. 15. Now you can access the Internet via Bluetooth. Note: If your PC accesses the Internet via a proxy server, remember to configure the proxy setting of you browser program in the client PC. Consult your MIS personnel if you're not sure what to set. 13 Proxy setup 1. To set up proxy, right click "Internet Explorer", select "Properties", select "Connections" tab. Select "BluetoothNull Connection" and click on "Settings...". 14 2. Select the "Proxy server" checkbox and enter the proxy address of you company and Port number. Then click “OK” to save the changes. 15 2.3. File transfer setting for Windows The File Transfer service allows one Bluetooth device to perform file operations on the default File Transfer directory (and the folders and files it contains) of another Bluetooth device. File transfer setting for Windows PC to PC 1. After successful USB adapter setup on two PCs, launch the Bluetooth software stack on both PCs by clicking the "My Bluetooth Places" icon located on the desktop. 2. On one PC …

Text truncated - open the document above for the full version.

Mavin Technology Inc. 3F, NO 35, Hsin Taid Rd. Chupei City, Hsinchu County, 302, Taiwan, R.O.C. Date: 11/18/2005 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Taiwan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS TW as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation,including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

Mavin Technology Inc. 3F, NO 35, Hsin Taid Rd. Chupei City, Hsinchu County, 302, Taiwan, R.O.C. Confidentiality Request FCC ID : SI4-MBDC212C Product : Bluetooth USB Adapter Model : MBD-C2.1-2C Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours,

Chris Harvey From: daphne.liang [[email protected]] Sent: Thursday, December 08, 2005 8:51 PM To: Compliance Certification Services Cc: [email protected]; lucy.tsai Subject: Re : Mavin Technology Inc. , FCC ID: SI4-MBDC212C , Assessment NO.: AN05T5303, Notice#2---Updated file (1209) Page 1 of 2 12/9/2005 Dear sir: Thank you for your e-mail. Please find the attached file for Compliance Letter by our client which declaration with the Bluetooth Specification. And if still have any problems,please connect with me.Thank you very much! BEST REGARDS Daphne Liang / ±ç౦p 12/09/2005 Certification Team Leader / R&D and Certification Dept. ============================================= Compliance Certification Services Inc. Rm.258, Bldg.17, No.195, Sec.4, Chung Hsing Rd.,Chutung,Hsinchu,Taiwan,R.O.C. Tel: 886-3-5910068 EXT: 502 Fax: 886-3-5825720 E-mail: [email protected] URL: http://www.ccsemc.com.tw Daphne, I have had a chance to review the associated exhibits submitted for this TCB Certification application. There are several FCC requirements that are not yet declared as being compliant in the application referenced above. These requirements are automatically deemed compliant if the device meets the Bluetooth Specification 1.2. The device is called a Bluetooth adapter; however there is no statement that the adapter complies with the Bluetooth Specification. Please either provide a declaration with the Bluetooth Specification (please include version) or provide individual declarations of compliance with the following items needed for FCC 15.247 compliance: a. Is the hopping sequence pseudorandom, based on the technical description? b. Is each channel used equally on average, based on the technical description? "Compliance Certification Services" <charvey- [email protected]> 2005/12/03 04:07 ¦¬¥ó¤H¡G <[email protected]> °Æ¥»§Û°e¡G <[email protected]> ¥D¦®¡G Mavin Technology Inc. , FCC ID: SI4-MBDC212C , Assessment NO.: AN05T5303, Notice#2 c. Does the associated system receiver have a compliant input bandwidth, based on the measured 20 dB emission bandwidth? d. Does the associated system receiver have the ability to hop in synchronization with the transmitter, based on the technical description? e. Does the design of the frequency hopping system allow it to comply with all pertinent requirements when presented with a lengthy data stream? f. Does the frequency hopping system comply with the non-coordination requirement? Please provide the documetation of compliance with the above items (or a standard Bluetooth Declaration document) so the review can be completed. Best regards, Chris Harvey [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Page 2 of 2 12/9/2005

Mavin Technology Inc. 3F, NO 35, Hsin Taid Rd. Chupei City, Hsinchu County, 302, Taiwan, R.O.C. Statement of Compliance Letter FCC ID : SI4-MBDC212C Product : Bluetooth USB Adapter Model : MBD-C2.1-2C To whom it may concern: We, the undersigned, hereby certify that we responsible to comply with the relevant provisions of the Bluetooth 1.2 specification and certificate program as bellows: a. Comply with the Bluetooth 1.2 technical description of the hopping sequence pseudorandom. b. Comply with the Bluetooth 1.2 technical description of each channel used equally on average. c. Comply with the Bluetooth 1.2 technical description ,the associated system receiver have a compliant input bandwidth, based on the measured 20 dB emission bandwidth. d. Comply with the Bluetooth 1.2 technical description ,the associated system receiver have the ability to hop in synchronization with the transmitter. e. The design of the frequency hopping system allow it to comply with all pertinent requirements when presented with a lengthy data stream. f. The frequency hopping system comply with the non-coordination requirement. Sincerely yours,

Compliance Certification Services Inc. Report No.：51102303 Page 1 of 10 External Photo (1) Compliance Certification Services Inc. Report No.：51102303 Page 2 of 10 Compliance Certification Services Inc. Report No.：51102303 Page 3 of 10 External Photo (2) Compliance Certification Services Inc. Report No.：51102303 Page 4 of 10 Compliance Certification Services Inc. Report No.：51102303 Page 5 of 10 External Photo (3) Compliance Certification Services Inc. Report No.：51102303 Page 6 of 10

Company : Mavin Technology Inc. Model : MBD-C2.1-2C Product : Bluetooth USB Adapter Bluetooth USB Adapter Model No: MBD-C2.1-2C FCC IDSI4-MBDC212C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N Made in Taiwan Label Here

Compliance Certification Services Inc. Report No.：51102303 Page 7 of 10 Internal Photo (1) Compliance Certification Services Inc. Report No.：51102303 Page 8 of 10 Compliance Certification Services Inc. Report No.：51102303 Page 9 of 10 Internal Photo (2) Compliance Certification Services Inc. Report No.：51102303 Page 10 of 10 Internal Photo (3)

Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 1 of 50 FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4 : 2003 TEST REPORT For Bluetooth USB Adapter Model : MBD-C2.1-2C Issued for Mavin Technology Inc. 3F, NO 35, Hsin Taid Rd. Chupei City, Hsinchu County, 302, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. Hsinchu Lab. Rm. 258, Bldg. 17, NO.195, Sec.4 Chung HsingRd., ChuTung Chen, Hsinchu, Taiwan 310, R.O.C TEL: (03) 591-0068 FAX: (03) 582-5720 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 2 of 50 TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION........................................................................................... 3 2. EUT DESCRIPTION.................................................................................................................. 4 2.1 DESCRIPTION OF EUT & POWER.................................................................................... 4 3. TEST METHODOLOGY............................................................................................................4 4. FACILITIES AND ACCREDITATIONS .................................................................................. 5 4.1 FACILITIES .......................................................................................................................... 5 4.2 EQUIPMENT ........................................................................................................................ 5 4.3 LABORATORY ACCREDITATIONS LISTINGS................................................................... 5 4.4 TABLE OF ACCREDITATIONS AND LISTINGS ................................................................ 6 5. CALIBRATION AND UNCERTAINTY .................................................................................... 7 5.1 MEASURING INSTRUMENT CALIBRATION ..................................................................... 7 5.2 MEASUREMENT UNCERTAINTY....................................................................................... 7 6. DESCRIPTION OF TEST MODES .......................................................................................... 7 7. SETUP OF EQUIPMENT UNDER TEST................................................................................ 8 8. APPLICABLE LIMITS AND TEST RESULTS ....................................................................... 9 8.1 20dB BANDWIDTH FOR HOPPING................................................................................... 9-11 8.2 MAXIMUM PEAK OUTPUT POWER ................................................................................. 12-14 8.3 HOPPING CHANNEL SEPARATION.................................................................................. 15-16 8.4 NUMBER OF HOPPING FREQUENCY USED .................................................................. 17-18 8.5 DWELL TIME ON EACH CHANNEL .................................................................................. 19-22 8.6 POWER SPECTRAL DENSITY MEASUREMENT............................................................... 23-25 8.7 CONDUCTED SPURIOUS EMISSION................................................................................ 26-29 8.8 RADIATED EMISSIONS ...................................................................................................... 30 8.8.1 TRANSMITTER RADIATED SUPURIOUS EMSSIONS............................................. 30-33 8.8.2 WORST-CASE RADIATED EMISSION BELOW 1 GHz ............................................ 34 8.8.3 TRANSMITTER RADIATED EMISSION ABOVE 1 GHz ........................................... 35-37 8.8.4 RESTRICTED BAND EDGES..................................................................................... 38-41 8.9 POWERLINE CONDUCTED EMISSIONS .......................................................................... 42-45 9. ANTENNA REQUIREMENT .................................................................................................... 46 9.1 STANDARD APPLICABLE................................................................................................... 46 9.2 ANTENNA CONNECTED CONSTRUCTION ...................................................................... 46 APPENDIX SETUP PHOTOS....................................................................................................... 47-50 Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 3 of 50 1. TEST REPORT CERTIFICATION Applicant ： Mavin Technology Inc. Address ： 3F, NO 35, Hsin Taid Rd. Chupei City, Hsinchu County 302, Taiwan, R.O.C. Equipment Under Test ： Bluetooth USB Adapter Model ： MBD-C2.1-2C Tested Date ： November 02 ~ 10, 2005 APPLICABLE STANDARD STANDARD TEST RESULT FCC Part 15 Subpart C: 2004 AND ANSI C63.4:2003 No non-compliance noted WE HEREBY CERTIFY THAT: The measurements shown in the attachment were made in accordance with the procedures indicated, and the energy emitted by the equipment was found to be within the limits applicable. We assume full responsibility for the accuracy and completeness of these measurements and vouch for the qualifications of all persons taking them. Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 4 of 50 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product Name Bluetooth USB Adapter Model Number MBD-C2.1-2C Frequency Range 2402MHz to 2480MHz f = 2402 + nMHz, n = 0, .....78 Transmit Power 4dBm Channel Spacing 1MHz Channel Number 79 Air Data Rate 721kbps Type of Modulation Frequency Hopping Spread Spectrum Frequency Selection by software / firmware Transmitter Classification portable device A…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 47 of 50 APPENDIX SETUP PHOTOS RADIATED RF MEASUREMENT SETUP Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 48 of 50 Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 49 of 50 RF Port Counted Measure Setup Compliance Certification Services Inc. FCC ID : SI4-MBDC212C Report No.：51102303-RP1 Page 50 of 50 POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP
