SI5WCB210AWireless 802.11g Cardbus Card

802.11g/b Wireless CardBus Card User's Guide Version 1.0 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This device complies with FCC RF Exposure limits set forth for an uncontrolled environment, under 47 CFR 2.1093 paragraph (d)(2). This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device was tested for typical by stander conditions that may occur during use. To comply with FCC RF exposure requirements a minimum separation distance of 1.6cm must be maintained between the user’s body and the device, including the antenna. U-MEDIA declares that WCB-210A, ( FCC ID: SI5WCB210A ) is limited in CH1~CH11 for 2.4 GHz by specified firmware controlled in U.S.A. 2 Table of Contents Federal Communications Commission Interference statement .......................................... 1 Chapter 1 Getting Started .......................................................................................... 4 1.1 About Your 802.11g/b WLAN CardBus Card................................................................ .4 1.2 Card Hardware and Utility Installation.................................................................................. 4 1.3 Using the Utility to Configure Your Network........................................................................... 4 1.3.1 Network .............................................................................................................................. 6 1.3.2 Profile ................................................................................................................................. 7 1.3.3 Site Survey......................................................................................................................... 19 1.3.4 Options............................................................................................................................... 22 1.3.5 Version............................................................................................................................... 24 Chapter 2 - Configuring Wireless Security ................................................................................. 25 4.1 Configuring Security.............................................................................................................. 25 4.2 Configuring WEP .................................................................................................................. 25 4.3 Configuring WPA-P SK...........................................................................................................27 4.4 Configuring WPA............................................................................................................... ... 28 4.5 Configuring 802.1x ............................................................................................................ ... 28 4.5.1 Configuring 802.1x – EAP-MD5 ......................................................................................... 29 4.5.2 Configuring 802.1x – EAP-LEAP......................................................................................... 29 4.5.3 Configuring 802.1x – EAP-PEAP......................................................................................... 29 4.5.4 Configuring 802.1x – EAP-TLS ........................................................................................... 31 4.5.5 Configuring 802.1x – EAP-TTLS.......................................................................................... 33 3 Chapter 1 - Getting Started This chapter introduces the Card and prepares you to use the Wireless Utility. 1.1 About Your 802.11g/b WLAN CardBus Card The Card is an IEEE 802.11b, and 802.11g compliant wireless LAN adapter. With the Card, you can enjoy wireless mobility within almost any wireless networking environment. The following lists the main features of your Card. 9 Your Card can communicate with other IEEE 802.11b/g compliant wireless devices. 9 Automatic rate selection. 9 Standard data transmission rates up to 54 Mbps. 9 Proprietary Atheros transmission rates of 108 Mbps 9 Offers 64-bit, 128-bit and 152-bit WEP (Wired Equivalent Privacy) data encryption for network security. 9 Supports IEEE802.1x and WPA (Wi-Fi Protected Access). 9 Low CPU utilization allowing more computer system resources for other programs. 9 A built-in antenna. 9 Driver support for Windows XP/2000/ME/98SE 1.2 Card Hardware and Utility Inst…

Text truncated - open the document above for the full version.

-----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Friday, March 25, 2005 12:49 AM To: steve.cheng Cc: [email protected] Subject: 回信: Re: TCB Review Comments for (SI5WCB210A, 940310L13) Dear Steve We revised the user's manual and uploaded the correct manual to ftp now. Please see our reply as below: Question #1: User’s manual: p25, show 802.11g function in the manual please clarify if this device contains 802.11a function? Answer: No, this device has no 11g function build in. we have removed the 802.11a function from the manual. Question #2: P2 of User’s manual: SAR tested separation distance is 1.6 not 1.5cm Please revise user’s manual to agree with test setup. Answer: we correct the SAR tested separation distance on the manual. Please check. Thanks for your assistance! Best Regards Wendy Liao Wendy Liao (廖意紋)/ ADT Corp. TEL: 03-318-3232 EXT 1625 FAX: 03-318-5050 Email: [email protected] 地址:桃園縣龜山鄉文化村華亞二路１９號

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

FCC ID Label Location (FCC ID: SI5WCB210A)

FCC ID: SI5WCB210A WCB-210A Bottom Label 802.11g/b Wireless LAN CardBus Card Model: WCB-210A 64 mm 40 mm

Page 4 Page 5 Page 6

FCC ID: SI5WCB210A Report No.RF940310L13 Technical Description This device is a 2.4GHz Wireless 802.11g Cardbus Card which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna used in this product is Printed antenna without connector. The other instruction, please have a look at the users manual.

D3: 3G DOSIMETRIC E-FIELD PROBE

D4: 2450MHz SYSTEM VALIDATION DIPOLE SN: 716

D4: DAE SN: 510

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

FCC ID: SI5WCB210A Report No.: RF940310L131Report Format Version 2.0.2 FCC TEST REPORT REPORT NO.: RF940310L13 MODEL NO.: WCB-210A RECEIVED: Mar. 10, 2005 TESTED: Mar. 10 ~ Mar. 12, 2005 ISSUED: Mar. 15, 2005 APPLICANT: U-MEDIA Communications, Inc. ADDRESS: 9F, No. 1, Jin-shan 7 th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 62 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: SI5WCB210A Report No.: RF940310L132Report Format Version 2.0.2 Table of Contents 1.CERTIFICATION ......................................................................................................4 2.SUMMARY OF TEST RESULTS ..............................................................................5 2.1MEASUREMENT UNCERTAINTY ...........................................................................5 3.GENERAL INFORMATION.......................................................................................6 3.1GENERAL DESCRIPTION OF EUT.........................................................................6 3.2DESCRIPTION OF TEST MODES...........................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ...................................................... 7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL: .......................... 8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................10 3.4DESCRIPTION OF SUPPORT UNITS ...................................................................10 4.TEST TYPES AND RESULTS ................................................................................ 11 4.1CONDUCTED EMISSION MEASUREMENT ......................................................... 11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 11 4.1.2 TEST INSTRUMENTS............................................................................................ 11 4.1.3 TEST PROCEDURES ............................................................................................ 12 4.1.4 DEVIATION FROM TEST STANDARD .................................................................. 12 4.1.5 TEST SETUP ......................................................................................................... 13 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 13 4.1.7 TEST RESULTS ..................................................................................................... 14 4.2RADIATED EMISSION MEASUREMENT ..............................................................20 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................ 20 4.2.2 TEST INSTRUMENTS............................................................................................ 21 4.2.3 TEST PROCEDURES ............................................................................................ 22 4.2.4 DEVIATION FROM TEST STANDARD .................................................................. 22 4.2.5 TEST SETUP ......................................................................................................... 23 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 23 4.2.7 TEST RESULTS ..................................................................................................... 24 4.36dB BANDWIDTH MEASUREMENT .....................................................................32 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................... 32 4.3.2 TEST INSTRUMENTS............................................................................................ 32 4.3.3 TEST PROCEDURE............................................................................................... 32 4.3.4 DEVIATION FROM TEST STANDARD .................................................................. 32 4.3.5 TEST SETUP ......................................................................................................... 32 4.3.6 EUT OPERATING CONDITIONS ........................................................................... 32 4.3.7 TEST RESULTS ..................................................................................................... 33 4.4MAXIMUM PEAK OUTPUT POWER .....................................................................39 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...................... 39 4.4.2 INSTRUMENTS...................................................................................................... 39 4.4.3 TEST PROCEDURES ............................................................................................ 40 4.4.4 DEVIATION FROM TEST STANDARD .................................................................. 40 4.4.5 TEST SETUP ......................................................................................................... 40 4.4.6 EUT OPERATING CONDITIONS ........................................................................... 40 4.4.7 TEST RESULTS ..................................................................................................... 41 FCC ID: SI5WCB210A Report No.: RF940310L133Report Format Version 2.0.2 4.5POWER SPECTRAL DENSITY MEASUREMENT.................................................42 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT .............................. 42 4.5.…

Text truncated - open the document above for the full version.

A - 1 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION Bottom Position of EUT The Bottom of the EUT to the flat phantom distance 16 mm A - 2 EUT Photo A - 3 Liquid Level Photo MSL 2450MHz D=150mm A - 4 Date/Time: 03/16/05 09:25:06 Test Laboratory: Advance Data Technology WCB-210A-Mode 1 11b Bottom DUT: WCB-210A ; Type: PCMCIA Card ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Low Channel 1/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.160 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.34 V/m Peak SAR (extrapolated) = 0.311 W/kg SAR(1 g) = 0.153 mW/g; SAR(10 g) = 0.082 mW/g Maximum value of SAR (measured) = 0.166 mW/g A - 5 A - 6 Date/Time: 03/16/05 09:58:20 Test Laboratory: Advance Data Technology WCB-210A-Mode 1 11b Bottom DUT: WCB-210A ; Type: PCMCIA Card ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.98 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Mid Channel 4/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.141 mW/g Mid Channel 4/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.72 V/m Peak SAR (extrapolated) = 0.296 W/kg SAR(1 g) = 0.144 mW/g; SAR(10 g) = 0.077 mW/g Maximum value of SAR (measured) = 0.156 mW/g A - 7 Date/Time: 03/16/05 10:23:42 Test Laboratory: Advance Data Technology WCB-210A-Mode 1 11b DUT: WCB-210A ; Type: PCMCIA Card ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used (interpolated): f = 2462 MHz; σ = 2.05 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Mid Channel 7/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.128 mW/g Mid Channel 7/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.86 V/m Peak SAR (extrapolated) = 0.276 W/kg SAR(1 g) = 0.131 mW/g; SAR(10 g) = 0.069 mW/g Maximum value of SAR (measured) = 0.141 mW/g A - 8 Date/Time: 03/16/05 10:45:11 Test Laboratory: Advance Data Technology WCB-210A-Mode 2 11g Bottom DUT: WCB-210A ; Type: PCMCIA Card ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Low Channel 1/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.075 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.48 V/m Peak SAR (extrapolated) = 0.944 W/kg SAR(1 g) = 0.079 mW/g; SAR(10 g) = 0.040 mW/g Maximum value of SAR (measured) = 0.086 mW/g A - 9 Date/Time: 03/16/05 11:08:53 Test Laboratory: Advance Data Technology WCB-210A-Mode 2 11g Bottom DUT: WCB-210A ; Type: PCMCIA Card ; Test Frequency: 2437 MHz Communication System: 802.11g ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.98 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detectio…

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION

FCC ID: SI5WCB210A Report No.: SA940310L131Report Format Version 2.0.1 SAR TEST REPORT REPORT NO.: SA940310L13 MODEL NO.: WCB-210A RECEIVED: Mar. 10, 2005 TESTED: Mar. 16, 2005 ISSUED: Mar. 18, 2005 APPLICANT: U-MEDIA Communications, Inc. ADDRESS: 9F, No. 1, Jin-shan 7 th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 30 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: SI5WCB210A Report No.: SA940310L132Report Format Version 2.0.1 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM .............................................. ....5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................13 4.DESCRIPTION OF SUPPORT UNITS ......................................................................14 5.TEST RESULTS ........................................................................................................15 5.1 TEST PROCEDURES ...............................................................................................15 5.2 MEASURED SAR RESULT .......................................................................................16 5.3 SAR LIMITS...............................................................................................................17 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................17 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................19 6.SYSTEM VALIDATION ..............................................................................................20 6.1 TEST EQUIPMENT ...................................................................................................20 6.2 TEST PROCEDURE .................................................................................................20 6.3 VALIDATION RESULT...............................................................................................22 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................23 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................24 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................24 7.2 ISOTROPY UNCERTAINTY......................................................................................24 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................25 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................25 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................25 7.6 RESPONSE TIME UNCERTAINTY...........................................................................26 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................27 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................27 7.9 PROBE POSITIONING .............................................................................................28 7.10 PHANTOM UNCERTAINTY ......................................................................................28 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................29 8.INFORMATION ON THE TESTING LABORATORIES ..............................................30 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: SI5WCB210A Report No.: SA940310L133Report Format Version 2.0.1 1. CERTIFICATION PRODUCT : Wireless 802.11g Cardbus Card MODEL NO. : WCB-210A BRAND NAME : U-MEDIA APPLICANT : U-MEDIA Communications, Inc. TESTED : Mar. 16, 2005 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Mar. 18, 2005 ( Andrea Hsia ) TECHNICAL ACCEPTANCE :, DATE:Mar. 18, 2005 Responsible for RF ( Ansen Lei ) APPROVED BY:, DATE:Mar. 18, 2005 ( Cody Chang, Deputy Manager ) FCC ID: SI5WCB210A Report No.: SA940310L134Report Format Version 2.0.1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless 802.11g Cardbus Card MODEL NO. WCB-210A POWER SUPPLY 3.3Vdc from host equipment CLASSIFICATION Portable device, production unit MODULATION TYPE CCK, DQPSK, DBPSK for DSSS, 64QAM, 16QAM, QPSK, BPSK for OFDM RADIO TECHNOLOGY DSSS, OFDM TRANSFER RATE 802.11b: 11/5.5/2/1Mbps 802.11g: 54…

Text truncated - open the document above for the full version.

FCC ID: SI5WCB210A Report No.: RF940310L1360Report Format Version 2.0.2 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: SI5WCB210A Report No.: RF940310L1361Report Format Version 2.0.2 RADIATED EMISSION TEST
