SI5WRT372U2.4GHz Wireless 802.11n(DRAFT) Router

2.4GHz Wireless 802.11n(DRAFT) Router WRT-372U Rev 0.95 User Manual 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. U-MEDIA declares that US model of WRT-372U ( FCC ID: SI5WRT372U ) is limited in CH1-CH11 for 2.4G band by specific firmware controlled by the manufacturer and is not user changeable. Copyright This publication, including all photographs, illustrations and software, is protected under interna- tional copyright laws, with all rights reserved. Neither this manual, nor any of the material con- tained herein, may be reproduced without written consent of the author. Copyright 2006 Trademark recognition All product names used in this manual are the properties of their respective owners and are acknowledged. 2 Table of Contents Getting Started with the WRT-372U 3 Package Contents 4 Minimum System Requirements 4 Wireless LAN Networking 5 Introduction 9 Features 9 Hardware Overview 10 Rear Panel 10 LEDs 11 Installation Considerations 12 Getting Started 12 Using the Configuration Menu 13 Basic 14 Advanced 24 Tools 53 Status 70 Glossary 79 3 Getting Started with the WRT-372U Congratulations on purchasing the WRT-372U! This manual provides information for setting up and configuring the WRT-372U. This manual is intended for both home users and professionals. The following conventions are used in this manual: THE NOTE SYMBOL INDICATES ADDITIONAL INFORMATION ON THE TOPIC AT HAND. THE TIP SYMBOL INDICATES HELPFULL INFORMATION AND TIPS TO IMPROVE YOUR NETWORK EXPERIENCE. THE CAUTION SYMBOL ALERTS YOU TO SITUATIONS THAT MAY DEGRADE YOUR NETWORKING EXPERIENCE OR COMPROMISE LIKE NOTES AND TIPS, THE IMPORTANT SYMBOL INDICATES INFORMATION THAT CAN IMPROVE NETWORKING. THIS INFORMATION SHOULD NOT BE OVERLOOKED. 4 Package Contents z WRT-372U 11n(Draft) Wireless Router z CAT-5 Ethernet Cable (All the WRT-372U’s Ethernet ports are Auto-MDIX) z Power Adapter (5.0V, 2.5A) z CD-ROM with Software and Manual z Quick Installation Guide Using a power supply with a different voltage than the one included with your product will cause damage and void the warranty for this product. Minimum System Requirements z Ethernet-Based Cable or DSL Modem z Computers with Windows, Macintosh, or Linux-based operating systems with an installed Ethernet adapter and CD-ROM Drive z Internet Explorer Version 6.0 or Netscape Navigator Version 7.0 and Above 5 Wireless LAN Networking This section provides background information on wireless LAN networking technology. Consult the Glossary for definitions of the terminology used in this section. T HE INFORMATION IN THIS SECTION IS FOR YOUR REFERENCE. CHANGING NETWORK SETTINGS AND PARTICULARLY SECURITY SETTTINGS SHOULD ONLY BE DONE BY AN AUTHORIZED ADMINISTRATOR. Transmission Rate (Transfer Rate) The WRT-372U provides various transmission (data) rate options for you to select. In most networking scenarios, the factory default Best (automatic) setting proves the most efficient. This setting allows your WRT-372U to operate at the maximum transmission (data) rate. When the communication quality drops below a certain level, the WRT-372U automatically switches to a lower transmission (data) rate. Transmission at lower data speeds is usually more reliable. However, when the communication quality improves again, the WRT-372U gradually increases the transmission (data) rate again until it reaches the highest available transmission rate. Types of Wireless Networks Wireless LAN networking works in either of the two modes: ad-hoc and infrastructure. In infra- structure mode, wireless devices communicate to a wired LAN via access points. Each access point and its wireless devices are known as a Basic Service Set (BSS). An Extended Service Set (ESS) is two or more BSSs in the same subnet. In ad hoc mode (also known as peer-to-peer mode), wireless devices communicate with each other directly and do not use an access point. This is an Independent BSS (IBSS). To connect to a wired network within a coverage area using access points, set the operation mode to Infrastructure (BSS). To set up an independent wireless workgroup without an access point, use Ad-ho…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

FCC ID .: SI5WRT372U Label Location

WRT-372U Bottom Label FCC ID : SI5WRT372U WRT-372U This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference. (2) this device must accept any interference received, including interference that may cause undesired operations. 2.4GHz Wireless 802.11n(DRAFT) Router

Page 4 Page 5 Page 6 Page 7

FCC ID: SI5WRT372U Report No.: RF950616L04 OPERATIONAL DESCRIPTION This device is a 2.4GHz Wireless 802.11n(DRAFT) Router, which operates in the 2.4GHz frequency spectrum with throughput of up to 300Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is po wered by AC adapter. The antenna is dipole antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

FCC ID: SI5WRT372U Report No: SA950616L04 1 RF EXPOSURE REPORT REPORT NO.: SA950616L04 MODEL NO.: WRT-372U ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:U-MEDIA Communications, Inc. ADDRESS:9F, No. 1, Jin-shan 7th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB ADDRESS:No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION:No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: SI5WRT372U Report No: SA950616L04 2 RF EXPOSURE MEASUREMENT (MOBILE DEVICE) 1. INTRODUCTION In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF EXPOSURE LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) (A)LIMITS FOR OCCUPATIONAL / CONTROL EXPOSURES 300-1500......F/3006 1500-100,000......56 (B)LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: SI5WRT372U Report No: SA950616L04 3 3. FRIIS FORMULA Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT OPERATING CONDITION The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: SI5WRT372U Report No: SA950616L04 4 6. TEST RESULTS 6.1 ANTENNA GAIN The maximum Gain measured in Fully Anechoic Chamber is 4dBi or 2.512 numeric. 6.2 OUTPUT POWER INTO ANTENNA & RF EXPOSURE VALUE AT DISTANCE 20cm: 802.11b DSSS MODULATION – SINGLE TX: CHANNEL CHANNEL FREQUENCY (MHz) TOTAL OUTPUT POWER TO ANTENNA (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1241263.9730.0321.0 6243764.5650.0321.0 11246264.4170.0321.0 802.11g OFDM MODULATION – DUAL TX: CHANNEL CHANNEL FREQUENCY (MHz) TOTAL OUTPUT POWER TO ANTENNA (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1241275.9690.0381.0 6243780.6370.0401.0 11246280.8230.0401.0 DRAFT 802.11n (20MHz) OFDM MODULATION – DUAL TX: CHANNEL CHANNEL FREQUENCY (MHz) TOTAL OUTPUT POWER TO ANTENNA (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1241275.8960.0381.0 6243780.8220.0401.0 11246280.8220.0401.0 FCC ID: SI5WRT372U Report No: SA950616L04 5 DRAFT 802.11n (40MHz) OFDM MODULATION – DUAL TX: CHANNEL CHANNEL FREQUENCY (MHz) TOTAL OUTPUT POWER TO ANTENNA (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1242250.6450.0251.0 4243750.7620.0251.0 7245250.7030.0251.0

Report No.: RF950616L041Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950616L04 MODEL NO.: WRT-372U RECEIVED: Jun. 16, 2006 TESTED: Jun. 20 ~ Jul. 03, 2006 ISSUED: Jul. 11, 2006 APPLICANT:U-MEDIA Communications, Inc. ADDRESS:9F, No. 1, Jin-shan 7th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB ADDRESS:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION:No. 19, Hwa Ya 2 nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 110 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report No.: RF950616L042Report Format Version 2.0.4 TABLE OF CONTENTS 1.CERTIFICATION ...................................................................................................................... 4 2.SUMMARY OF TEST RESULTS.............................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY ........................................................................................... 5 3.GENERAL INFORMATION ...................................................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ........................................................................................ 6 3.2DESCRIPTION OF TEST MODES .......................................................................................... 8 3.2.1CONFIGURATION OF SYSTEM UNDER TEST ..................................................................... 9 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................................ 10 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................... 13 3.4DESCRIPTION OF SUPPORT UNITS................................................................................... 13 4.TEST TYPES AND RESULTS................................................................................................ 14 4.1CONDUCTED EMISSION MEASUREMENT......................................................................... 14 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 14 4.1.2TEST INSTRUMENTS ...........................................................................................................14 4.1.3TEST PROCEDURES ............................................................................................................15 4.1.4DEVIATION FROM TEST STANDARD .................................................................................. 15 4.1.5TEST SETUP ......................................................................................................................... 16 4.1.6EUT OPERATING CONDITIONS........................................................................................... 16 4.1.7TEST RESULTS ..................................................................................................................... 17 4.2RADIATED EMISSION MEASUREMENT.............................................................................. 35 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ........................................................... 35 4.2.2TEST INSTRUMENTS ...........................................................................................................36 4.2.3TEST PROCEDURES ............................................................................................................37 4.2.4DEVIATION FROM TEST STANDARD .................................................................................. 37 4.2.5TEST SETUP ......................................................................................................................... 38 4.2.6EUT OPERATING CONDITIONS........................................................................................... 38 4.2.7TEST RESULTS ..................................................................................................................... 39 4.3 BANDWIDTH MEASUREMENT ..................................................................................... 54 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................................. 54 4.3.2TEST INSTRUMENTS ...........................................................................................................54 4.3.3TEST PROCEDURE .............................................................................................................. 54 4.3.4DEVIATION FROM TEST STANDARD .................................................................................. 54 4.3.5TEST SETUP ......................................................................................................................... 55 4.3.6EUT OPERATING CONDITIONS........................................................................................... 55 4.3.7TEST RESULTS ..................................................................................................................... 56 4.4MAXIMUM PEAK OUTPUT POWER ..................................................................................... 70 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ..................................... 70 4.4.2INSTRUMENTS ..................................................................................................................... 70 4.4.3TEST PROCEDURES ............................................................................................................70 6dB Report No.: RF950616L043Report Format Version 2.0.4 4.4.4DEVIATION FROM TEST STANDARD .................................................................................. 70 4.4.5TEST SETUP .......................................…

Text truncated - open the document above for the full version.

Report No.: RF950616L0481Report Format Version 2.0.4 CH 11 Report No.: RF950616L0482Report Format Version 2.0.4 DRAFT 802.11n (20MHz) OFDM MODULATION – DUAL TX: MODULATION TYPE BPSK TRANSFER RATE 7.2Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg.C, 72% RH, 991hPa TEST MODEBTESTED BY Lori Chiu RF POWER LEVEL IN 3kHz BW (mW) RF POWER LEVEL IN 3kHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0CHAIN 1CHAIN 0CHAIN 1 TOTAL POWER DENSITY (mW) TOTAL POWER DENSITY (dBm) MAX. LIMIT (dBm) PASS / FAIL 124120.0400.038-14.02-14.210.078-11.088PASS 624370.0360.039-14.38-14.070.075-11.258PASS 1124620.0380.039-14.22-14.070.077-11.148PASS FOR CHAIN 0: CH 1 Report No.: RF950616L0483Report Format Version 2.0.4 CH 6 CH 11 Report No.: RF950616L0484Report Format Version 2.0.4 FOR CHAIN 1: CH 1 CH 6 Report No.: RF950616L0485Report Format Version 2.0.4 CH 11 Report No.: RF950616L0486Report Format Version 2.0.4 DRAFT 802.11n (40MHz) OFDM MODULATION – DUAL TX: MODULATION TYPE BPSK TRANSFER RATE 15.0Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg.C, 72% RH, 991hPa TEST MODEBTESTED BY Lori Chiu RF POWER LEVEL IN 3kHz BW (mW) RF POWER LEVEL IN 3kHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0CHAIN 1CHAIN 0CHAIN 1 TOTAL POWER DENSITY (mW) TOTAL POWER DENSITY (dBm) MAX. LIMIT (dBm) PASS / FAIL 124220.0180.017-17.52-17.650.035-14.568PASS 424370.0190.018-17.29-17.510.037-14.328PASS 724520.0190.018-17.25-17.490.037-14.328PASS FOR CHAIN 0: CH 1 Report No.: RF950616L0487Report Format Version 2.0.4 CH 4 CH 7 Report No.: RF950616L0488Report Format Version 2.0.4 FOR CHAIN 1: CH 1 CH 4 Report No.: RF950616L0489Report Format Version 2.0.4 CH 7 Report No.: RF950616L0490Report Format Version 2.0.4 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100kHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS DESCRIPTION & MANUFACTURER MODEL NO.SERIAL NO.CALIBRATED UNTIL R&S SPECTRUM ANALYZER FSEK30100049Aug. 14, 2006 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. Report No.: RF950616L0491Report Format Version 2.0.4 4.6.3 TEST PROCEDURE For Single TX: The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100kHz with suitable frequency span including 10Hz bandwidth from band edge. The band edges was measured and recorded. The spectrum plots (Peak RBW = VBW = 100kHz; Average RBW = 1MHz, VBW = 10Hz) are attached on the following pages. For Dual TX: a. The EUT was placed on the top of a rotating table 0.8 meters above the ground at a 3 meter semi-anechoic chamber. The table was rotated 360 degrees to determine the position of the highest radiation. b. The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top of a variable-height antenna tower. c. The antenna is a broadband antenna, and its height is varied from one meter to four meters above the ground to determine the maximum value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the measurement. d. For each suspected emission, the EUT was arranged to its worst case and then the antenna was tuned to heights from 1 meter to 4 meters and the rotatable table was turned from 0 degrees to 360 degrees to find the maximum reading. e. Set both RBW and VBW of spectrum analyzer to 100kHz with suitable frequency span including 100MHz bandwidth from band edge. The band edges was measured and recorded. The spectrum plots (Peak RBW = VBW = 100kHz; Average RBW = 1MHz, VBW = 10Hz) NOTE: The resolution bandwidth of test receiver/spectrum analyzer is 1 MHz and the video bandwidth is 10Hz for Average detection (AV) at frequency above 1GHz. 4.6.4 DEVIATION FROM TEST STANDARD No deviation Report No.: RF950616L0492Report Format Version 2.0.4 4.6.5 EUT OPERATING CONDITION Same as Item 4.3.6 4.6.6 TEST RESULTS The spectrum plots are attached on the following 24 images. D1 line indicates the highest level, and D2 line indicates the 20dB offset below D1. It shows compliance with the requirement in part 15.247(d). 802.11b DSSS MODULATION – SINGLE TX: NOTE 1: The band edge emission plot of DSSS technique on the next page shows 50.59dBc between carrier maximum power and local maximum emission in restrict band (2.38620GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.7 is 111.15dBuV/m (Peak), so the maximum field strength in restrict band is 111.15 – 50.59 = 60.56dBuV/m which is under 74dBuV/m limit. The band edge emission plot of DSSS technique on the next page shows 54.61dBc between carrier maximum power and local maximum emission in restrict band (2.38640GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.7 is 107.54dBuV/m (Average), so the maximum field strength in restrict band is 107.54 – 54.61 = 52.93dBuV/m which is under 54dBuV/m limit. NOTE 2: The band edge emission plot of DSSS technique on the next second page shows 51.82dBc between carrier maximum power and local maximum emission in restrict band (2.48670GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.7 is 111.41dBuV/m (Peak), so the maximum field strength in restrict band is 111.41 – 51.82 = 59.59dBuV/m which is under 74dBuV/m limit. The band edge emission plot of DSSS technique on the next third page shows 54.18dBc between carrier maximum power and local maximum emission in restrict band (2.48820GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.7 is 107.18dBuV/m (Average), so the maximum field strength in restrict band is 107.18 – 54.18 = 53.00dBuV/m which is under 54dBuV/m limit. Report No.: RF950616L0493Report Format Version 2.0.4 Report No.: RF950616L0494Report Format Version 2.0.4 Report No.: RF950616L0495Report…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST _ TEST MODE A 3 RADIATED EMISSION TEST _ TEST MODE B
