SI5WUB210Wireless 802.11g Portable USB Adapter

1 802.11g Wireless Network Adapter User's Guide Version 1.0 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: U-MEDIA declares that WUB-210Z, ( FCC ID: SI5WUB210 ) is limited in CH1~CH11 for 2.4 GHz by specified firmware controlled in U.S.A. 3 CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. This transmitter must not be co-located or operation in conjunction with any other antenna or transmitter. 4 Table of Contents Federal Communications Commission (FCC) Interference statement 2 CE Mark Warning 3 Chapter 1 - Getting Started 1.1 About Your 802.11b/g WLAN USB Adapter 5 1.2 Package Content 5 1.3 System Requirement 5 1.4 LED Definition 6 1.5 Adapter Hardware and Utility Installation 6 1.6 Using the Utility to Configure Your Network 14 Chapter 2 – Maintenance 2.1 The Version Screen 25 2.2 Uninstalling the Driver 25 2.3 Uninstall the Client Utility 25 2.3 Upgrading the Wireless Utility 25 5 Chapter 1 - Getting Started This chapter introduces the Adapter and prepares you to use the Wireless Utility. 1.1 About Your 802.11b/g WLAN USB Adapter The Adapter is an IEEE 802.11b, and 802.11g compliant wireless LAN adapter. With the Adapter, you can enjoy wireless mobility within almost any wireless networking environment. The following lists the main features of your Adapter. 9 Your Adapter can communicate with other IEEE 802.11b/g compliant wireless devices. 9 Automatic rate selection. 9 Standard data transmission rates up to 54 Mbps. 9 Proprietary Atheros transmission rates of 108 Mbps 9 Offers 64-bit, 128-bit and 152-bit WEP (Wired Equivalent Privacy) data encryption for network security. 9 Supports IEEE802.1x and WPA (Wi-Fi Protected Access). 9 Low CPU utilization allowing more computer system resources for other programs. 9 A built-in antenna. 9 Driver support for Windows XP/2000. 1.2 Package Content ¾ 802.11b/g WLAN USB Adapter ¾ Installation and Manual CD ¾ Quick Start Guide ¾ Warranty/Registration Adapter 1.3 System Requirement z Pentium class notebook computers with at least one available USB slot z Microsoft Windows XP or 2K z CD-ROM drive 6 1.4 LED Definition The following table describes the LED on the 802.11b/g WLAN USB Adapter LED COLOR STATUS DESCRIPTION OFF The Adapter has no connection Blinking SlowlyThe Adapter is connected LINK Green Blinking The Adapter is sending or receiving data 1.5 Adapter Hardware and Utility Installation NOTE: If you have connected the USB Adapter to your computer, please remove it first. Follow the instructions below to install the USB Adapter and Utility. STEP 1 Insert the Driver and Utility CD into CD drive STEP 2 If your CD Autorun is enabled, the Main Installation Menu will show. (Otherwise open your CD folder and double-click on the “setup.exe” file) 7 STEP 3 Click the button of INSTALL. The InstallShield wizard prepares for installation. STEP 4 The InstallShield Wizard prompts you for confirmation. Click Next on the following menu. 8 STEP 5 Choose to install client utility and driver or install driver only. We recommend proceeding with “Install Client Utilities and Driver” STEP 6 A warning question will pop up, click “Yes” on it. STEP 7 In the destination Folder screen you are asked to confirm the Destination Folder for the application software. If you would like, you may change the destination folder to another location. Click Next 9 STEP 8 Select a program folder and click on Next. 10 STEP 9 The installation gives you information regarding the Client Utility to be used. Click Next on it. STEP 10 Choose the client utility. Click Next. 11 STEP 11 At this moment please insert your USB Adapter to your Laptop and click OK. STEP 12 You will get the “Found News Hardware Wizard” menu; click on Cancel. 12 STEP 13 At the hardware installation menu click Continue Anyway. (Our product has been tested under Windows XP and found to be fully compatible click Continue Anyway.) 13 STEP 14 The setup configuration shows the installation progress STEP 15 Click Finish to complete the client utility installation. Your computer will be rebooted. 14 STEP 16 After rebooting, The Client Utility icon resides on the Desktop at the System Tray automatically. 1.6 Using the Utility to Configure Your Network The following are explanations on how to configure and use the Utility program. After completing the installation pr…

Text truncated - open the document above for the full version.

-----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Friday, June 24, 2005 4:25 AM To: steve.cheng Subject: 回信: TCB Review Comments for (940519L09 (WUB-210Z)- U-Media 11g USB) Dear Steve Reply your questions. <Answer Q1> for complying with 15.247, manufacture has noticed that the output power need to be limited to mentioned level and these levels (11b:50mW / 11g: 31. mW Max.) will be incorporated into the firmware limit and is not user changeable. <Answer Q2> revised manual re-uploaded. Thanks for your assistance! Best Regards Wendy Liao Wendy Liao (廖意紋)/ ADT Corp. TEL: 03-318-3232 EXT 1625 FAX: 03-318-5050 Email: [email protected] 地址:桃園縣龜山鄉文化村華亞二路１９號 "steve.cheng" <steve.cheng@nacs emc.com> 收 件人 Wendy Liao <[email protected]> 2005/06/24 下午 副本抄 送 06:14 [email protected] 主旨 TCB Review Comments for (940519L09 (WUB-210Z)- U-Media 11g USB) TCB Review Comments for (940519L09 (WUB-210Z)- U-Media 11g USB) -EMC- Question #1: Page 19 of user’s manual, indicated power level higher then tested power level 11b:50mW / 11g: 32mW. Please explain how this device cans comply with rule? Question #2: RFX statement on page 2 is not consider complete, please revise the manual to include necessary info and resubmit a copy. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best Regards Steve Cheng / Technical Reviewer TCB/FCB/NB CKC Certification Services. North American EMC Certification Services Inc. Email: [email protected] Tel: 403-241-8826

Page 1 CONSTRUCTION PHOTOS OF EUT For WLAN Function Page 2 For Finder Function Page 3

FCC ID Label Location (FCC ID: SI5WUB210) FCC ID Label Location (FCC ID: SI5WUB210)

50 +0.00-0.25 18 +0. 0 0-0 . 25 WUB-210Z_FCC Label WUB-210Z 802.11g Wireless Network Adapter FCC ID: SI5WUB210 Label Location :

Page 4 For WLAN Function Page 5 Page 6 Page 7 Page 8 For Finder Function Page 9 Page 10

FCC ID: SI5WUB210 Report No.RF940519L09 Technical Description This device is a Wireless 802.11g Portable USB Adapter which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna used in this product is Printed antenna without connector. The other instruction, please have a look at the users manual.

D3: DAE SN: 579

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

A - 1 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION Position of Horizontal EUT The Bottom of the EUT to the flat phantom distance 9 mm A - 2 Position of Horizontal EUT The Bottom of the EUT to the flat phantom distance 6 mm A - 3 Position of Vertical EUT The Bottom of the EUT to the flat phantom distance 8 mm A - 4 Position of Vertical EUT The Bottom of the EUT to the flat phantom distance 9 mm A - 5 EUT Photo A - 6 A - 7 Liquid Level Photo MSL 2450MHz D=150mm MSL 5000MHz D=150mm A - 8 Date/Time: 2005/6/2 12:05:12 Test Laboratory: Advance Data Technology White WUB-210Z Horizontal Mode 1 11b DUT: Wireless 802.11g Portable USB Adapter ; Type: WUB-210Z ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.98 mho/m; ε r = 54; ρ = 1000 kg/m 3 ; Liquid level : 150mm Phantom section: Flat Section ; Separation distance : 9 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 Low Channel 1/Area Scan (5x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.242 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.32 V/m Peak SAR (extrapolated) = 0.478 W/kg SAR(1 g) = 0.241 mW/g; SAR(10 g) = 0.127 mW/g Maximum value of SAR (measured) = 0.262 mW/g A - 9 Date/Time: 2005/6/2 12:36:06 Test Laboratory: Advance Data Technology White WUB-210Z Horizontal Mode 1 11b DUT: Wireless 802.11g Portable USB Adapter ; Type: WUB-210Z ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 2.02 mho/m; ε r = 53.9; ρ = 1000 kg/m 3 ; Liquid level : 150mm Phantom section: Flat Section ; Separation distance : 9 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 Mid Channel 6/Area Scan (5x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.272 mW/g Mid Channel 6/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.0 V/m Peak SAR (extrapolated) = 0.525 W/kg SAR(1 g) = 0.262 mW/g; SAR(10 g) = 0.136 mW/g Maximum value of SAR (measured) = 0.287 mW/g A - 10 Date/Time: 2005/6/2 13:12:11 Test Laboratory: Advance Data Technology White WUB-210Z Horizontal Mode 1 11b DUT: Wireless 802.11g Portable USB Adapter ; Type: WUB-210Z ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2462 MHz; σ = 2.04 mho/m; ε r = 53.8; ρ = 1000 kg/m 3 ; Liquid level : 150mm Phantom section: Flat Section ; Separation distance : 9 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 High Channel 11/Area Scan (5x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.289 mW/g High Channel 11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.0 V/m Peak SAR (extrapolated) = 0.569 W/kg SAR(1 g) = 0.283 mW/g; SAR(10 g) = 0.147 mW/g Maximum value of SAR (measured) = 0.310 mW/g A - 11 A - 12 Date/Time: 2005/6/2 13:31:30 Test Laboratory: Advance Data Technology White WUB-210Z Horizontal Mode 2 11g DUT: Wireless 802.11g Portable USB Adapter ; Type: WUB-210Z ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.98 mho/m; ε r = 54; ρ = 1000 kg/m 3 ; Liquid level : 150mm Phantom section: Flat Section ; Separation distance : 9 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 Low Channel 1/Area Scan (5x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.137 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.97 V/m Peak SAR (extrapolated) = 0.280 W/kg SAR(1 g) = 0.138 mW/g; SAR(10 g) = 0.072 mW/g Maximum value of SAR (measured) = 0.150 mW/g A - 13 Date/Time: 2005/6/2 13:49:27 Test Laboratory: Advance Data Technology White WUB-210Z Horizontal Mode 2 11g DUT: Wireless 802.11g Portable USB Adapter ; Type: WUB-210Z ; Test Frequency: 2437 MHz Communication System: 802.11g ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Med…

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION

FCC ID: SI5WUB210 Report No.: SA940516L09A1Report Format Version 2.0.1 Reference No.: 940519L09 SAR TEST REPORT REPORT NO.: SA940516L09A MODEL NO.: WUB-210Z RECEIVED: May 16, 2005 TESTED: Jun. 02 ~ Jun.03 2005 ISSUED: Jun. 14, 2005 APPLICANT: U-MEDIA Communications, Inc. ADDRESS: 9F, No.1, Jin-shan 7th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 36 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: SI5WUB210 Report No.: SA940516L09A2Report Format Version 2.0.1 Reference No.: 940519L09 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ...................................................5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................8 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................12 4.DESCRIPTION OF SUPPORT UNITS ......................................................................15 5.TEST RESULTS ........................................................................................................16 5.1 TEST PROCEDURES ...............................................................................................16 5.2 MEASURED SAR RESULTS ....................................................................................17 5.3 SAR LIMITS...............................................................................................................21 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................21 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................24 6.SYSTEM VALIDATION ..............................................................................................25 6.1 TEST EQUIPMENT ...................................................................................................25 6.2 BEFORE STARTING THE MEASUREMENT, ALL TEST EQUIPMENT SHALL BE WARMED UP FOR 30MIN.TEST PROCEDURE ......................................................26 6.3 VALIDATION RESULTS ............................................................................................28 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................29 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................30 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................30 7.2 ISOTROPY UNCERTAINTY......................................................................................30 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................31 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................31 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................31 7.6 RESPONSE TIME UNCERTAINTY...........................................................................32 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................33 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................33 7.9 PROBE POSITIONING .............................................................................................34 7.10 PHANTOM UNCERTAINTY ......................................................................................34 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................35 8.INFORMATION ON THE TESTING LABORATORIES ..............................................36 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: SI5WUB210 Report No.: SA940516L09A3Report Format Version 2.0.1 Reference No.: 940519L09 1. CERTIFICATION PRODUCT : Wireless 802.11g Portable USB Adapter MODEL NO. : WUB-210Z BRAND NAME : U-MEDIA APPLICANT : U-MEDIA Communications, Inc. TESTED : Jun. 02 ~ Jun. 03, 2005 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Jun. 14, 2005 ( Andrea Hsia) TECHNICAL ACCEPTANCE:, DATE:Jun. 14, 2005 Responsible for RF ( Stanely Hsu ) APPROVED BY :, DATE:Jun. 14, 2005 ( Cody Chang, Deputy Manager ) FCC ID: SI5WUB210 Report No.: SA940516L09A4Report Format Version 2.0.1 Reference No.: 940519L09 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless 802.11g Portable USB Adapter MODEL NO. WUB-210Z POWER SUPPLY 5dc from host equipment CLASSIFICATION Portable device, produc…

Text truncated - open the document above for the full version.

FCC ID: SI5WUB210 Report No.: SA940516L09A1Report Format Version 2.0.1 Reference No.: 940519L09 SAR TEST REPORT REPORT NO.: SA940516L09A MODEL NO.: WUB-210Z SERIES MODEL NO.: WHF-230 RECEIVED: May 16, 2005 TESTED: Jun. 02 ~ Jun.03 2005 ISSUED: Jun. 14, 2005 APPLICANT: U-MEDIA Communications, Inc. ADDRESS: 9F, No.1, Jin-shan 7th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 36 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: SI5WUB210 Report No.: SA940516L09A2Report Format Version 2.0.1 Reference No.: 940519L09 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ...................................................5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................8 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................12 4.DESCRIPTION OF SUPPORT UNITS ......................................................................15 5.TEST RESULTS ........................................................................................................16 5.1 TEST PROCEDURES ...............................................................................................16 5.2 MEASURED SAR RESULTS ....................................................................................17 5.3 SAR LIMITS...............................................................................................................21 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................21 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................24 6.SYSTEM VALIDATION ..............................................................................................25 6.1 TEST EQUIPMENT ...................................................................................................25 6.2 BEFORE STARTING THE MEASUREMENT, ALL TEST EQUIPMENT SHALL BE WARMED UP FOR 30MIN.TEST PROCEDURE ......................................................26 6.3 VALIDATION RESULTS ............................................................................................28 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................29 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................30 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................30 7.2 ISOTROPY UNCERTAINTY......................................................................................30 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................31 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................31 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................31 7.6 RESPONSE TIME UNCERTAINTY...........................................................................32 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................33 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................33 7.9 PROBE POSITIONING .............................................................................................34 7.10 PHANTOM UNCERTAINTY ......................................................................................34 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................35 8.INFORMATION ON THE TESTING LABORATORIES ..............................................36 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: SI5WUB210 Report No.: SA940516L09A3Report Format Version 2.0.1 Reference No.: 940519L09 1. CERTIFICATION PRODUCT: Wireless 802.11g Portable USB Adapter SERIES PRODUCT: Hotspot Finder with 802.11b/g USB 2.0 Wi-Fi Adapter BRAND NAME: U-MEDIA MODEL NO.: WUB-210Z SERIES MODEL NO.: WHF-230 APPLICANT : U-MEDIA Communications, Inc. TESTED : Jun. 02 ~ Jun. 03, 2005 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Jun. 14, 2005 ( Andrea Hsia) TECHNICAL ACCEPTANCE:, DATE:Jun. 14, 2005 Responsible for RF ( Stanely Hsu ) APPROVED BY :, DATE:Jun. 14, 2005 ( Cody Chang, Deputy Manager ) FCC ID: SI5WUB210 Report No.: SA940516L09A4Report Format Version 2.0.1 Reference No.: 940519L09 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless 802.11…

Text truncated - open the document above for the full version.

FCC ID: SI5WUB210 Report No.: RF940516L09A1Report Format Version 2.0.2 Reference No.: 940519L09 FCC TEST REPORT REPORT NO.: RF940516L09A MODEL NO.: WUB-210Z RECEIVED: May 16, 2005 TESTED: May 18 ~ May 30, 2005 ISSUED: Jun. 14, 2005 APPLICANT: U-MEDIA Communications, Inc. ADDRESS: 9F, No.1, Jin-shan 7th St., Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 71 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: SI5WUB210 Report No.: RF940516L09A2Report Format Version 2.0.2 Reference No.: 940519L09 Table of Contents 1.CERTIFICU-MEDIAON.............................................................................................4 2.SUMMARY OF TEST RESULTS ..............................................................................5 2.1 MEASUREMENT UNCERTAINTY ............................................................................5 3.GENERAL INFORMU-MEDIAON.............................................................................6 3.1GENERAL DESCRIPTION OF EUT.........................................................................6 3.2DESCRIPTION OF TEST MODES...........................................................................7 3.2.1 CONFIGURU-MEDIAON OF SYSTEM UNDER TEST ............................................ 7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL: .......................... 8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................10 3.4DESCRIPTION OF SUPPORT UNITS ...................................................................10 4.TEST TYPES AND RESULTS ................................................................................ 11 4.1CONDUCTED EMISSION MEASUREMENT ......................................................... 11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 11 4.1.2 TEST INSTRUMENTS............................................................................................ 11 4.1.3 TEST PROCEDURES ............................................................................................ 12 4.1.4 DEVIATION FROM TEST STANDARD .................................................................. 12 4.1.5 TEST SETUP ......................................................................................................... 13 4.1.6 EUT OPERATING CONDITIONS ...............................................................…

Text truncated - open the document above for the full version.
