SKH-SCV123WCDMA/GSM Module

SEW290 WCDMA Module Strong Rising SEW290 Module Technical User Guide Version：V1.0 Dec, 15th, 2012 Shenzhen Strong Rising Electronics Co.,Ltd www.strongrising.com 1 Strong Rising SEW290 Module Copyright Statement Copyright © 2012 by Strong Rising. www.strongrising.com The copyright of this User Manual belongs to Strong Rising Elctronics and under the protection of Copyright Law of the People’s Republic of China and other relative laws. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means (electronic or mechanical, including photocopying and microfilm) without prior written permission from Strong Rising Elctronics. The information in the document is subject to change without notice. At the same time we reserve the right to revise or recall the User Manual. If there is anything unclear in this manual, please contact us or our agent or seller. 2 Strong Rising SEW290 Module Technical Support Shenzhen Strong Rising Electronics Co.,Ltd. was establised in January 2004.We mainly engage in the research and development, production and sales of communications terminal products,is the earliest into wireless data card in the field of one of the professional manufacturers. We can provide WCDMA/EDGE/cdma2000 module customers technical support through website,telephone,IM,E-Mail etc,and also onsite supports. The Strong Rising website www.strongrising.com provides the relevant industry information and module technical documentation. If you have more requirements, you could send an E-mail to [email protected] . You can also call us at hotline 400-0690-009 for more supports. EU Regulatory Conformance Hereby，Shenzhen Strong Rising Electronics Co., Ltd. Declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. SEW290 WCDMA Module 3 Preface Summary This manual is applicable for SEW290 module. This manual takes SEW290 for example to instruct the users how to design the hardware and how to quickly and conveniently design different kinds of wireless terminals based on the modules. Target Readers  System designing engineers  Mechanical engineers  Hardware engineers  Software engineers  Test engineers Brief Introduction The manual contains 5 chapters, shown as below: Chapter Contents  DESCRIPTION Introduces SEW290 module’s technical specs and relevant documents and abbreviations.  SEW290 MODULE INTRODUCTION Introduces SEW290 module’s principle diagram and relevant standards.  PIN DEFINITIONS Introduces SEW290 module’s PIN names and function.  DESCRIPTIONS OF HARDWARE INTERFACES Introduces SEW290 module’s hardware interfaces.  MECHANICAL DESIGN Introduces SEW290 module’s appearance, assembly diagram and antenna connector’s mechanical specifications. Update History Document Reversion V1.0 (2012-11-1) The first version released。 SEW290 WCDMA Module 4 CONTENTS Copyright Statement ......................................................................................................................................... 1 Technical Support .............................................................................................................................................. 2 Preface ............................................................................................................................................................... 3 Summary ................................................................................................................................................... 3 Target Readers .......................................................................................................................................... 3 Brief Introduction ...................................................................................................................................... 3 Update History .......................................................................................................................................... 3 1 Description ................................................................................................................................................. 6 1.1 Technical Specification ................................................................................................................... 6 1.1.1 Descriptions of specs. ......................................................................................................... 6 1.1.2 Basic Functions .................................................................................................................... 6 1.1.3 Module Interfaces ............................................................................................................... 6 1.1.4 Technical Parameters .......................................................................................................... 7 1.2Ambient Temperature Parameters ...................................................................................................... 8 1.2 Abbreviations ................................................................................................................................. 8 2 Module Introduction.................................................................................................................................. 9 3 PIN Definitions ......................................................................................................................................... 11 4 Descriptions of Hardware Interfaces ....................................................................................................... 13 4.1 Description ................................................................................................................................... 13 4.2 Power and Reset ........................................................................................................................... 13 4.2.1 Power Design ...........................…

Text truncated - open the document above for the full version.

External Photos of the EUT

Label and Label Location

Internal Photos of the EUT

Report No. :SET2013-01318 CCIC-SET/T (00) Page 1 of 9 RF Exposure Evaluation Report Report No.: SET2013-01318 Product: WCDMA/GSM Module FCC ID: SKH-SCV123 Brand Name: N/A Applicant: Shenzhen Strong Rising Electronics Co.,Ltd Address： Room 610-611, Building 13, Shangsha Creative Science&Tech Park, Futian District, Shenzhen, China Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 9 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No. :SET2013-01318 CCIC-SET/T (00) Page 3 of 9 Table of Contents Test Report ................................................................................................................................. 2 1 .General Information ................................................................................................................. 4 1.1 Description of EUT ............................................................................................................... 4 1.2 Test specifications ................................................................................................................. 5 2 RF Exposure Limit Introduction ........................................................................................... 5 3 Conducted RF Output Power（Unit：dBm） ..................................................................... 7 4. RF Exposure Evaluation ...................................................................................................... 8 Report No. :SET2013-01318 CCIC-SET/T (00) Page 4 of 9 1 .General Information 1.1 Description of EUT Product Feature & Specification DUT Type WCDMA/GSM Module Model Name SEW290,SPW270,SPW290,STW290,PCI270,PCI290,SEV550, SEV750,SEV850,MU270,MU290,MC550,MC750,MC850,SEW270, SEW291,SEW702,STV680 FCC ID SKH-SCV123 Tx Frequency GSM850: 824.2 MHz ~ 848.8 MHz GSM1900: 1850.2 MHz ~ 1909.8MHz WCDMA Band V: 826.4 MHz ~ 846.6 MHz Rx Frequency GSM850: 869.2 MHz ~ 893.8 MHz GSM1900: 1930.2 MHz ~ 1989.8 MHz WCDMA Band V: 871.4 MHz ~ 891.6 MHz Antenna Type Refer to Remark 2 and 3 HW Version SPW9S-V4 SW Version wup_2.00.008 Test of Modulation GMSK/8PSK/QPSK Remark 1: The above DUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Remark 2: The external antenna must be matched properly to achieve best performance regarding radiated power, DC-power consumption, modulation accuracy and harmonic suppression. Antenna matching networks are not included on the SEW290 Module PCB and should be placed in the host application. Remark 3: An antenna was used via a UHL Type Connector, whose maximum antenna gain was 2dBi for Band 850 and 2dBi for Band 1900. Report No. :SET2013-01318 CCIC-SET/T (00) Page 5 of 9 1.2 Test specifications ANSI Std C95.1-1992 Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3KHz-300GHz.(IEEE Std C95.1-1992) RSS-102 Radio Frequency Exposure Compliance of Radiocommunication Apparatus （All Frequency Bands （Issue 4 of March 2010）） KDB 447498 D01V05 General RF Exposure Guidance 2 RF Exposure Limit Introduction An estimation of MPE in this application for product is used to ensure if it complies to the rules of the standard in the regulation list above. Maximum permissible exposure (MPE) refers to the RF energy that is acceptable for human exposure. It is broken down into two categories, Occupational/controlled and General population/uncontrolled. Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. We analysis if it comply with the limits for General population/uncontrolled exposure. The FCC’s MPE limits for field strength and power density are given in 47CFR 1.1310(Table below).These limits are generally based on recommended exposure guidelines published by the National Council on Radiation Protection and Measurements (NCRP), and also partly based on guidelines recommended by the American National Standards Institute (ANSI) in Section 4.1 of ANSI/IEEE C95.1. Report No. :SET2013-01318 CCIC-SET/T (00) Page 6 of 9 Table：Limits For Maximum Permissible Exposure(MPE) (A) Limits for Occupational/controlled Exposure Frequency Range(MHz) Electric Field Strength （E）（V/m） Magnetic Field Strength（H） （A/m） Power Density(S) （mW/cm2） Averaging Time （minute）|E|2,|H|2 or s 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f2)* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 （B）Limits for General Population/uncontrolled Exposure Frequency Range(MHz) Electric Field Strength （E）（V/m） Magnetic Field Strength（H） （A/m） Power Density(S) （mW/cm2） Averaging Time （minute）|E|2,|H|2 or s 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f …

Text truncated - open the document above for the full version.

Report No.：SET2013-01317 CCIC-SET/T（00） Page 1 of 119 RF TEST REPORT Report No.： SET2013-01317 Product： WCDMA/GSM Module FCC ID: SKH-SCV123 Applicant： Shenzhen Strong Rising Electronics Co.,Ltd Address： Room 610-611, Building 13, Shangsha Creative Science&Tech Park, Futian District, Shenzhen, China Issued by： CCIC-SET Lab Location： Electronic Testing Building, Shahe Road，Xili, Nanshan District, Shenzh China Tel：86 755 26627338 Fax：86 755 26627238 This test report consists of 119 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.：SET2013-01317 CCIC-SET/T（00） Page 3 of 119 Table of Contents 1. GENERAL INFORMATION .................................................................................................... 4 1.1 EUT Description ......................................................................................................................... 4 1.2 Test Standards and Results ........................................................................................................ 6 1.3 Facilities and Accreditations ...................................................................................................... 7 2. 47 CFR PART 2, PART 22H & 24E REQUIREMENTS ........................................................ 8 2.1 Conducted RF Output Power .................................................................................................... 8 2.2 Peak to Average Radio .............................................................................................................. 20 2.3 99% Occupied Bandwidth ....................................................................................................... 24 2.4 Frequency Stability ................................................................................................................... 39 2.5 Conducted Out of Band Emissions ......................................................................................... 45 2.6 Band Edge ................................................................................................................................. 74 2.7 Transmitter Radiated Power (EIRP/ERP) ............................................................................. 84 2.8 Radiated Out of Band Emissions ............................................................................................ 91 Report No.：SET2013-01317 CCIC-SET/T（00） Page 4 of 119 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ............................. : WCDMA/GSM Module Serial No. .............................. : FCC ID ................................. : (n.a, marked #1 by test site) SKH-SCV123 Hardware Version ................. : SPW9S-V4 Software Version ................... wup_2.00.008 Frequency Range .................. : GSM 850MHz: Tx: 824.20 - 848.80MHz (at intervals of 200kHz); Rx: 869.20 - 893.80MHz (at intervals of 200kHz) GSM 1900MHz: Tx: 1850.20 - 1909.80MHz (at intervals of 200kHz); Rx: 1930.20 - 1989.80MHz (at intervals of 200kHz) WCDMA 850MHz Tx: 826.4 - 846.6MHz (at intervals of 200kHz); Rx: 871.4 - 891.6MHz (at intervals of 200kHz) Modulation Type................... : GPRS/GSM Mode with GMSK Modulation EDGE Mode with 8PSK Modulation WCDMA Mode with QPSK Modulation HSDPA Mode with QPSKModulation HSUPA Mode with QPSK Modulation Multislot Class ...................... : GPRS: Multislot Class12,EGPRS: Class12 Antenna Type ........................ : Refer to Note 6 and 7 Emission Designators ........... : GSM850:247KGXW, GSM1900:250KGXW, GPRS850:250KGXW,GPRS1900:248KGXW EGPRS850:246KG7W, EGPRS1900:247KG7W, WCDMA850:4M19F9W,HSDPA850:4M21F9W, HSUPA850:4M19F9W, Note 1: The transmitter (Tx) frequency arrangement of the Cellular 850MHz band used by the EUT can be represented with the formula F(nq)=824.2+0.2*(n-128), 128<=n<=251; the lowest, middle, highest channel numbers (ARFCHs) used and tested in this report are separately 128 (824.2MHz), 190 (836.6MHz) and 251 (848.8MHz). Note 2: The transmitter (Tx) frequency arrangement of the PCS 1900MHz band used by the EUT can be represented with the formula F(n)=1850.2+0.2*(n-512), 512<=n<=810; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 512 (1850.2MHz), 661 (1880.0MHz) and 810 (1909.8MHz). Note 3: The transmitter (Tx) frequency arrangement of the WCDMA 850MHz band used by the EUT can be represented with the formula F(n)=826.4+0.2*(n-4132), 4132<=n<=4233; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately Report No.：SET2013-01317 CCIC-SET/T（00） Page 5 of 119 4132 (826.4MHz), 4175(835MHz) and 4233 (846.6MHz). Note 4: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 5: According to the designer, Shenzhen Strong Rising Electronics Co.,Ltd., we hereby declare that there’s no difference between the model SPW270, SPW290, STW290, PCI270, PCI290, SEV550, SEV750, SEV850、MU270, MU290, MC550, MC750, MC850, SEW270, SEW291, SEW702, STV680 and SEW290 are accordant in both hardware and software. Note 6: The external antenna must be matched properly to achieve best performance regarding radiated power, DC-power consumption, modulation accuracy and harmonic suppression. Antenna matching networks are not included on the SEW290 Module PCB and should be placed in the host application. Note 7: During the spurious emission and ERP/EIRP tests, an antenna was used v…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
