SQO814401XBox Wireless Headset (Dongle)

Subject: FW: (URGENT & IMPORTANT) FW: Ever Sparkle Technologies Ltd., FCC ID: SQO81440, Assessment NO.: AN05T4600 4/13/2005 Hello Eric, I checked the revised test report, I still have the following questions: 1) Operation description (datasheet of the RF transceiver chipset) indicates "+2dBm typical peak output transmission power", but the maximum conducted power output on the revised test report is -23.31dBm. Please explain. 2 ) Please provide fundamental radiated emission measurement. We need to compare with the spurious emission test data. Based on conducted spurious emission plots provided in the test report, the EUT actually failed since the spurious data is not attenuated to 20dB down from the peak value of fundamental (mark 1). Please provide new conducted spurious emission plots. 3) The plots in the test report do not match each other. For example, the 6dB bandwidth plot (span: 20MHz) looks quite different from the plot of restricted bandedge test plots (span: 180MHz). Please explain how you made the EUT a continuous transmitter, how to tune to 2440MHz. It seems sometimes the fundamental signal is not activated. 4) Peak Power Spectral Density. Please note RBW=3KHz=Span/Sweep time. Span is 300KHz, the sweep time should be 100ms, please provide new plots with correct sweep time. -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Monday, February 28, 2005 3:41 PM To: Helen Zhao Subject: Ever Sparkle Technologies Ltd., FCC ID: SQO814401, Assessment NO.: AN05T4601, Notice#1 Question #1: Please confirm what is the EUT of this project. Is it Headset or Dongle? If it is Dongle, please revise the form 731 and the test report, please also update user manual. If it is Headset, please update EUT photos. (Eric: This project belongs to the dongle in fact, and this the composite filing with its earphone. - For your request about the revised Form 731, please let me know how to getting it revised? The product name should be the same as the associated project with the FCC ID: SQO81400 (ie They are packed into a single packing, share the same product and model# but with individual FCC ID.) - For the issue about the resend of the test report, please refer to the revised test report upon your following issue (Q2~3) attached, thanks.) Question #2: The support equipment shown on setup photos does not match that listed on the test report. Please update. (Eric: Please refer to the revised test report attached, thanks.) Question #3: The test report does not contain test data for radiated emisssion above 1GHz. Please provide the test data. (Eric: Please refer to the revised test report attached, thanks.) Question #4: Please provide additional internal photos to show the PCB board, two sides. (Eric: Please refer to the additional internal photo inserted into the original exhibit attached, thanks.) Question #5: Please add RF exposure statement into the user manual. Since you claimed this is mobile device in MPE calculation, the possible RF exposure statement could be: "The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter." (Eric: Please refer to the revised user manual attached, thanks.) Question #6: The Block diagram is for the Headset, not for the Dongle. Please resubmit the block diagram for the Dongle. (Eric: Please refer to the revised block diagram attached, thanks.) Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 4/13/2005

Compliance Certification Services (Kunshan) Inc. Report No: 04E0083 Date of Issue: February 25, 2005

Compliance Certification Services (Kunshan) Inc. Report No: 04E0083 Date of Issue: February 25, 2005 Label Location

Compliance Certification Services (Kunshan) Inc. Report No: 04E0083 Date of Issue: February 25, 2005 INTERNAL PHOTOGRPHS OF EUT

Compliance Certification Services (Kunshan) Inc. Report No: 04E0083-RP (Dongle) FCC ID: SQO814401 Date of Issue: March 28, 2005 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Ever Sparkle Technologies Ltd. X-Box Wireless Head Set Model: 81440 Tra d e Na me: N YK O Prepared for Ever Sparkle Technologies Ltd. Unit B, 6/F., Kingswell Comm. Tower, 171-173 Lockhart Road, Wanchai, HongKong. Prepared by COMPLIANCE CERTIFICATION SERVICES (KUNSHAN) INC. 10#Weiye Rd, Innovation Park Eco. & Tec. Development Zone Lab. Code: 200581-0 Kunshan City JiangSu, (215300) CHINA TEL: 86-512-57355888 FAX: 86-512-57370818 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 35 Compliance Certification Services (Kunshan) Inc. Report No: 04E0083-RP (Dongle) FCC ID: SQO814401 Date of Issue: March 28, 2005 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.............................................................................................3 2. EUT DESCRIPTION....................................................................................................................4 3. TEST METHODOLOGY.............................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION.................................................................................................7 5. FACILITIES AND ACCREDITATIONS...................................................................................8 5.1 FACILITIES 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST................................................................................10 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................10 6.2 SUPPORT EQUIPMENT...............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS......................................................................................11 7.1 6DB BANDWIDTH.............................................................................................................................11 7.2 PEAK POWER...............................................................................................................................13 7.3 BAND EDGES MEASUREMENT................................................................................................15 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................20 7.5 RADIO FREQUENCY EXPOSURE........................................................................................................22 7.6 SPURIOUS EMISSIONS.................................................................................................................25 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................32 APPENDIX 1 PHOTOGRPHS OF TEST SETUP..........................................................................34 Page 2 Compliance Certification Services (Kunshan) Inc. Report No: 04E0083-RP (Dongle) FCC ID: SQO814401 Date of Issue: March 28, 2005 1. TEST RESULT CERTIFICATION Applicant: Ever Sparkle Technologies Ltd. Unit B 6/F., Kingswell Comm. Tower, 171-173 Lockhart Road, Wanchai, HongKong. Equipment Under Test: X-Box Wireless Head Set Tra d e N a m e : NYKO Model: 81440 Date of Test: March23~ 28, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Page 3 Compliance Certification Services (Kunshan) Inc. Report No: 04E0083-RP (Dongle) FCC ID: SQO814401 Date of Issue: March 28, 2005 2. EUT DESCRIPTION Product X-Box Wireless Head Set Trade Name NYTO Model Number 81440 Model Discrepancy N/A Power Supply Powered from power adapter (Rating: 120V / 200mA / 2.5W) Frequency Range 2440MHz Number of Channels 1 Channel Antenna Specification Chip Antenna Gain: 2 dBi (Max) Note: This submittal(s) (test report) is intended for FCC ID: SQO814401 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Page 4 Compliance Certification Services …
