SQO83057R07PS3 Wireless Guitar

User munual

PS3-007 2008-03-11 EVER SPARKLE TECHNOLOGIES LTD A 1 HANSON <Code> B <Scale> 1 1 REV: SIZE: CODE: DRAWN: DATED: DATED: CHECKED:QUALITY CONTROL: DATED:DATED: RELEASED: COMPANY:TITLE: DRAWING NO: SHEET: OF SCALE: REVISION RECORD APPROVED: ECO NO: ABD DATE: 1 2 3 4 5 6 DCAB C LTR CRYSTAL 26MHZ PCB-ANTENNA RF-MODULE CC2500 MCU-ET44R10-TX Buttons Conrtroller side PS3- USB MCU-ET44R110-RX RF-MODULE CC2500 PCB-ANTENNA CRYSTAL 26MHZ POWER 3.0V Host side 6MHZ Crystal DATA DATA Joystick 3*AASIZEBttery 3.0V Regulator 6MHZ Crystal

EUT EXTERIOR PHOTO Applicant: EVER SPARKLE TECHNOLOGIES LTD. FCC ID: SQO83057R07

Applicant: EVER SPARKLE TECHNOLOGIES LTD. FCC ID: SQO83057R07 This device complies with part 15 the FCC rules. Operation is subject to the following two condition: (1). This device may not case harmful interference, (2).This device must accept any interference received, including interference that may cause undesired operation Proposed Label Location On EUT EUT Bottom View/Proposed FCC ID LABEL location FCC ID: SQO83057R07

EUT INSIDE PHOTO Applicant: EVER SPARKLE TECHNOLOGIES LTD. FCC ID: SQO83057R07

FCC ID: SQO83057R07 Applicant: EVER SAPARKLE TECHNOLOGIES LTD. Working Principle CC2500 is the transceiver of PS3 Wireless Guitar.The CC2500 is a low cost true single chip 2.4GHz transceiver designed for very low power wireless application .The circuit is intended for the ISM (Industrial,Scientific and Medical) and SRD(Short Range Device) frequency band at 2400-2483.5MHz. The RF transceiver is integrated with a highly configurable baseband modem.The modem supports various modulation formats and has a configurable data rate between 1.2-500 kbps. The communication range can be increased by enabling a Forward Error Correction option,which is integrated in the modem. CC2500 provides extensive hardware support for packet handling, data buffering,burst transmissions, clear channel assessment, link quality indication and wake-on-radio. The main operating parameters and the 64-byte transmit/receive FIFOs of CC2500 can be controlled via an SPI interface.In a typical system, the CC2500 will be used together with a microcontroller and a few additional passive components. CC2500 is based on Chipcon’s SmartRF 04 technology in 0.18 um CMOS.

08-16 EVER SPARKLE TECHNOLOGIES LTD hanson <Code> B a <Scale> 6 6 REV: SIZE: CODE: DRAWN: DATED: DATED: CHECKED:QUALITY CONTROL: DATED:DATED: RELEASED: COMPANY:TITLE: DRAWING NO: SHEET: OF SCALE: REVISION RECORD APPROVED: ECO NO: ABD DATE: 1 2 3 4 5 6 DCAB C LTR RF-MODEL 2.4GHZ Antenna (50 Ohm) Folded dipole PCB antenna (no external components needed0 C81 15P C101 18P C51 100N C121 100p C131 100p X1 26M R171 56k L131 1.2nH L121 1.2nH L122 1.2nH ANT C124 1.5P C132 1p C123 1.8P C151 100N C141 100N C181 1u C122 1p 1 SCLK 2 SO 3 GDO2 4 DVDD 5 DCOUPL 6 GDO0 7 CSN 8 XOSC_Q1 9 AVDD 10 XOSC_Q2 11 AVDD 12 RF_P 13 RF_N 14 AVDD 15 AVDD 16 GND 17 RBIAS 18 DGUARD 19 GND 20 SI U8 CC2500A C111 100n C20 10P 8 CS 7 GDO0 6 GND 5 GDO2 4 SO 3 SCLK 2 SI 1 VCC 9 OSC0 CO*1 9PIN2.0MMA

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 21-Feb-2008 Sheet of File: C:\Do cu men ts and Set ti ngs \han son \ 桌面 \SCH fo r Pro du ct V8\Backup of PS3-00 7 Do ngl e(V8).DD B Drawn By: VDD CS 1 GDO0 2 GND 3 GDO2 4 SO 5 SCLK 6 SI 7 VCC 8 GND 9 U1CC2500_INT VDD SISCLKSOGDO0CS PS3-007 Dongle SCH V8 Ben Zhang SDA SCL A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U3AT24C01 C4 104 VDD SCLSDA VDD 1 D- 2 D+ 3 VSS 4 J1USB 5V USB_D+USB_D- Vin 1 GND 2 Vout 3 T1BL8503-3.3V C1147uF C12 47uF C2104 VDD R1210K R1310K D1Link R1220 S1 Link LED5 橙 LED4 蓝 LED2 红 LED1 绿 LED3 黄 R2220 R3220 R4220 R1122 R5220 C10 5P VDD R91M Guitar HeroRockBand R10 1M PA0 1 PA1 2 PA2 3 PA3 4 PA4 5 PA5 6 PA6 7 PA7 8 PE7 9 PE6 10 PE5 11 PE4 12 Vref_ADC 13 VDD 14 PE3 15 PE2 16 PF2 49 VUSB_3.3V 50 VDD_5V 51 NC 52 VSS 53 DP3_PWR 54 DP2_PWR 55 DP3_DET 56 DP2_DET 57 DP3_D+ 58 DP3_D- 59 DP2_D+ 60 DP2_D- 61 UPRT_D+ 62 UPRT_D- 63 VDD 64 VSS 33 PC0 34 PC1 35 PC2 36 PC3 37 RST 38 PLCC 39 VDD 40 OSCI 41 OSCO 42 VSS 43 RCI 44 PC4 45 PC5 46 PF0 47 PF1 48 VSS 17 PE1 18 PE0 19 PD7 20 PD6 21 PD5 22 PD4 23 VDD 24 PB0 25 PB1 26 PB2 27 PB3 28 PB4 29 PB5 30 PB6 31 PB7 32 U2ET44R110 Y1 6M R7 1M C627 C7 27 SO CS R6330K C1104 C5104 VDD VDD R81M C3 104 C8 102 SO SI SCLK GDO0 USB_D-USB_D+ R141.5K 5V VDD VDD VDD S2 Game Sel VDD C31104 C32 104

Note: This report shall not be reproduced except in full, without the written approval of Sintek Laboratory CO., Ltd. This document may be altered or revised by Sintek Laboratory Co., Ltd. personnel only, and shall be noted in the revision section of the document. Page 1 of23 FCC 47 CFR PART 15 SUBPART C TEST REPORT For EVER SPARKLE TECHNOLOGIES LTD. PS3 Wireless Guitar Model: 83057, 83056 Trade Name: NYKO Prepared for EVER SPARKLE TECHNOLOGIES LTD. Unit B, 6/F., Kingswell Commercial Tower, 171~173 lockhart Road, Wanchai,HONG Kong Prepared by SINTEK LABORATORY CO., LTD. No. 7, XINSHIDAI INDUSTRIAL, GUANTIAN VILLAGE, SHIYAN TOWN, BAOAN DISTRICT, SHENZHEN, GUANGDONG, P.R.C. TEL: 86-755-27604866 FAX: 86-755-27608359 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION...................................................................................................................5 3.2 EUT EXERCISE...............................................................................................................................5 3.3 GENERAL TEST PROCEDURES........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS....................................................6 3.5 DESCRIPTION OF TEST MODES......................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES ..................................................................................................................................8 5.2 EQUIPMENT...................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING.............................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT....................................................................................................9 6.2 SUPPORT EQUIPMENT ............................................................................................................9 7. FCC PART 15.249 REQUIREMENTS...................................................................................... 10 7.1 BAND EDGES MEASUREMENT ...........................................................................................10 7.2 RADIATED EMISSIONS................................................................................................................14 7.3 POWER LINE CONDUCTED EMISSIONS........................................................................................21 8. APPENDIX 1 PHOTOGRPHS OF TEST SETUP ................................................................... 24 Page 3 1. TEST RESULT CERTIFICATION Applicant: EVER SPARKLE TECHNOLOGIES LTD. Unit B, 6/F., Kingswell Commercial Tower, 171~173 Lockhart Road, Wanchai, Hong Kong Equipment Under Test: PS3 Wireless Guitar Tra de Na me : NYKO Model: 83057, 83056 Date of Test: Mar 18~20, 2008 Report No. : ST0803019 FCC ID : SQO83057R07 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by SINTEK LABORATORY CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2001 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.249. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Page 4 2. EUT DESCRIPTION Product PS3 Wireless Guitar Tra de Name NYKO Model Number 83057, 83056 Model Discrepancy N/A Power Supply DC 3.3V Frequency Range 2410 ~ 2470 MHz Antenna Specification The EUT’S antenna is integrated on the main PCB Number of Channels 61 Channels Note: This submittal(s) (test report) is intended for FCC ID: SQO83057R07 filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, and 15.249. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.249 under the FCC Rules Part 15 Subpart C. 3.3 GENERAL TEST PROCEDURES Conducted Emissions The EUT is placed on the turntable, which is 0.8 m above ground plane. According to the requirements in Section 13.1.4.1 of ANSI C63.4: 2001, Conducted emissions from the EUT measured in the frequency range between 0.15 MHz and 30MHz using CISPR Quasi-peak and average detector modes. Radiated Emissions The EUT is placed on a turn table, which is 0.8 m above ground plane. The turntable shall rotate 360 degrees to determine the position of maximum …

Text truncated - open the document above for the full version.

TEST SETUP PHOTO Applicant: EVER SPARKLE TECHNOLOGIES LTD. FCC ID: SQO83057R07
