SRQ-302ZTWCDMA/GSM(GPRS) Dual-Mode Digital Mobile Phone

302ZT HSDPA Dual Band 3G Mobile Phone User Manual PC Software Requirements Join-Me PC Software supports Microsoft Vista (only 32 bit), Windows 2000 with Service Pack 4 or Windows XP with Service Pack 2 only. 64 Bit systems are NOT supported. Warnings and Safety Notices Please read all the safety notices before using this device. Copyright©2008 ZTE Corporation All rights reserved. 1st Edition August 2008 No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE Corporation operates a policy of continuous development. ZTE Corporation reserves the right to make changes and improvements to any of the products described in this document without prior notice. Limitation of Liability ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using this product, whether or not ZTE had been advised, knew or should have known the possibility of such damages. The user should refer to the enclosed warranty card for full warranty and service information. 3 Contents 1 For Your Safety ............................................................................ 8 1.1 General Care ............................................................................................................ 8 1.2 Aircraft Safety ......................................................................................................... 10 1.3 Hospital Safety ....................................................................................................... 11 1.4 General Guidelines ................................................................................................ 11 1.5 Road Safety ........................................................................................................... 12 1.6 Vehicles Equipped with an Airbag .......................................................................... 13 1.7 Third party equipment ............................................................................................ 13 1.8 Emergency Services .............................................................................................. 14 1.9 Declaration of Conformity....................................................................................... 15 1.10 Information on the privacy ...................................................................................... 15 1.11 Copyright Notice..................................................................................................... 15 2 Introduction .............................................................................. 16 2.1 Technical parameters ............................................................................................. 16 2.2 Key definition .......................................................................................................... 17 2.3 Indicators and Icons ............................................................................................... 19 3 Set up your phone ..................................................................... 20 3.1 Battery .................................................................................................................... 20 3.1.1 Install the battery ......................................................................................... 21 3.1.2 Remove the battery ..................................................................................... 21 3.1.3 Charge the battery ...................................................................................... 21 3.2 (U)SIM card ............................................................................................................ 22 4 3.3 TFlash Card ........................................................................................................... 23 3.3.1 Insert the TFlash card ................................................................................. 23 3.3.2 Remove the TFlash card ............................................................................. 24 3.3.3 Access the TFlash card on the phone......................................................... 24 3.4 Power on/off your phone ........................................................................................ 24 3.5 Idle Screen ............................................................................................................. 25 3.6 Signal strength ....................................................................................................... 25 4 Basic Operations ...................................................................... 26 4.1 Navigate the menus ............................................................................................... 26 4.2 Make a call ............................................................................................................. 27 4.2.1 Make a Voice Call ....................................................................................... 27 4.2.2 Make a Video Call ....................................................................................... 28 4.2.3 Make an International Call .......................................................................... 28 4.2.4 Call an Extension Number .......................................................................... 28 4.2.5 Call a Number from Contacts ...................................................................... 29 4.2.6 Call a Previous Dialed Number ................................................................... 29 4.2.7 Call a Speed Dial Number ........................................................................... 29 4.3 Answer a call .......................................................................................................... 30 4.3.1 Answer a Voice Call ....................…

Text truncated - open the document above for the full version.

内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Oct.14,2014 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Tejet is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhang Min ZTE CORPORATION ： Tel021-68895196 ： Fax 021-61460600 E-Mail：[email protected]

内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 2 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Oct.14,2014 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: SRQ-302ZT To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Technical/Operational Description - BOM list/Tune-Up-Procedure The applicant requests short-term confidentiality for the following information accompanying this application and the time limit of the confidentiality should be 180 days from grant date. - External Photos - Internal Photos - Handset User Manual - Test set up photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhang Min ZTE CORPORATION Tel：021-68895196 Fax：021-61460600 E-Mail：[email protected]

No.I14Z47594-EMC01 Page 1 of 18 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. I14Z47594-EMC01 for ZTE CORPORATION WCDMA/GSM（GPRS）Dual-Mode Digital Mobile Phone Model Name: 302ZT FCC ID: SRQ-302ZT with Hardware Version: wmmB Software Version: alpha1.0 Issued Date:Sep.18 th , 2014 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel: +86(0)10-62304633-2561, Fax: +86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.I14Z47594-EMC01 Page 2 of 18 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY .............................................................................................................. 3 1.1. TESTING LOCATION .......................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................. 3 1.3. PROJECT DATA .................................................................................................................. 3 1.4. SIGNATURE ........................................................................................................................ 3 2. CLIENT INFORMATION .......................................................................................................... 4 2.1. APPLICANT INFORMATION............................................................................................... 4 2.2. MANUFACTURER INFORMATION ..................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ........................................................................................................................ 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 3.4. EUT SET-UPS ..................................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................. 7 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 7 5. LABORATORY ENVIRONMENT ............................................................................................ 8 6. SUMMARY OF TEST RESULTS ............................................................................................. 9 7. TEST EQUIPMENTS UTILIZED ............................................................................................ 10 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 11 No.I14Z47594-EMC01 Page 3 of 18 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Location A Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan Bei Road, Haidian District, Beijing, P.R. China Postal Code: 100191 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Sep. 9 th , 2014 Testing End Date: Sep. 12 th , 2014 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.I14Z47594-EMC01 Page 4 of 18 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R. China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R. China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 No.I14Z47594-EMC01 Page 5 of 18 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WCDMA/GSM（GPRS）Dual-Mode Digital Mobile Phone Model Name 302ZT FCC ID SRQ-302ZT Extreme vol. Limits 3.5VDC to 4.35VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 864183022006885 wmmB alpha1.0 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Remarks AE1 Battery / 1447594BA001 AE2 Battery / 1447594BA002 AE3 USB cable / 1447594DC001 AE4 USB cable / 1447594DC002 AE5 Travel / 1447594CH004 AE6 Travel / 1447594CH003 AE1,AE2 Model ZEBAT1 Manufacturer ZTE CORPORATION Capacitance 1100 mAh Nominal voltage 3.7 V AE3,AE4 Model / Manufacturer / Length of cable 118cm AE5,AE6 Model STC-A51A-Z Manufacturer RUIDE Length of cable / *AE ID: is used to identify the test sample in the lab internally. No.I14Z47594-EMC01 Page 6 of 18 ©Copyright. All rights reserved by TMC Beijing. 3.4. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1+ AE1+ AE3 + AE5 Charger Set.2 EUT1+ AE1+ AE3 USB No.I14Z47594-EMC01 Page 7 of 18 ©C…
