SRQ-A101ZTUFI with WCDMA, LTE, WiFi and Bluetooth

A 101ZT,A102ZT Let’s Go Getting started with your device. FCC ID:SRQ-A101ZT 1 1. Prepare A valid nano-SIM card. 2 2. Install the Battery 1. Open the back cover. 2. Insert the battery. 3. Put the cover back. 3 3. Insert the nano-SIM Card 1. Insert the tip of the tray eject tool into the hole. 2. Pull out the card tray and place the nano-SIM card on the tray, as shown. Carefully slide the tray back into place. 4 4. Start Your Device Press and hold the power button until the screen lights up and then the device will connect to the Internet automatically. NOTE: If the battery is extremely low, you may be unable to power on the device. Please charge your device first. 5 5. Access the Internet  Wi-Fi: Touch the icon on the screen to get the default Wi-Fi SSID and password. Connect to the Wi-Fi network with your mobile deviceand then access the Internet.  USB Type-C cable: Connect with the computer via USB port and then access the Internet. 6 6. Change Your Device Settings You can change the device settings by logging in to the configuration web page. 1. Touch >Advanced Setting to get thedefault device manager website URLandpassword. 2. Launch the Internet browser. Enter the URL in the Address bar. 3. Click Login. 4. Input the password, click Login and then you can change the default settings. NOTE: You can also change some settings by touching the screen. 7 7. E-label You can touch the Support icon on the screen to get the E-lable information. 8 Touch Screen Icons and Interfaces 9 1. Power button Press and hold for about 2 seconds to power on your device. 2. nano-SIM card tray Insert your nano-SIM card. 3. Touch screen icons Description Signal strength Network type Wi-Fi signal strength Internet connection status New software available. Battery power level Set whether data usage is displayed on the screen and the max data amount. View the connected devices. View and delete the notification. Show the number of unread notifications. Create your Wi-Fi spot or connect to an available Wi-Fi spot. View or change the default SSID and password. 10 View or change your device settings. Use the WPS function. Show your device information. Describe the icons displayed on the screen. 4. Charging/USB Type-C jack Charge the device or connect to the USB port of a computer. 11 Troubleshooting Problem Recommended Action The connection between your device and a PC through a USB cable cannot be established automatically. If the driver of your device is abnormal, reinstall the software. You need to uninstall the software first. The connection between your device and a client through Wi- Fi cannot be established.  Ensure that the Wi-Fi function is enabled.  Refresh the network list and select the correct SSID.  Check the IP address, and ensure that your client can automatically obtain an IP address.  Enter the correct network key (Wi-Fi password) when you connect the client to your device. 12 Troubleshooting Problem Recommended Action The client connected to the device cannot access the Internet.  Ensure that your nano-SIM card is available.  Change the location and find a place with good signal.  Check the settings of the WAN connection mode.  Contact your service provider and confirm your APN settings. The configuration page cannot be visited.  Enter the correct address. Please view the label on your device to get the default Device Manager Website IP address.  Do not use any proxy server. 13 Get More Help You can get help by: •Sending an email to [email protected] • Visiting www.ztedevices.com 14 LEGAL INFORMATION Copyright © 2021 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Disclaimer Images and screenshots used in this guide may differ from the actual product. Content in this guide may differ from the actual product or software. Trademarks ZTE and the ZTE logos are trademarks of ZTE Corporation. Other trademarks and trade names are those of their respective owners. Version No.: R1.0 15 Warning and Notice To the User • If inadequately shielded, some electronic devices, for example, the electronic system of vehicles, may be affected by the electromagnetic interference caused by the device. Consult the manufacturers of such devices before using the device if necessary. • Operating the device may interfere with medical instruments such as hearing aids and pacemakers. Always keep the device more than 20 centimeters away from such medical instruments when your device is powered on. Power off the device if necessary. Consult a physician or the manufacturers of medical instruments before using the device if necessary. • Be aware of the usage limitation when using the device at places such as oil warehouses or chemical factories, where there are explosive gases or explosive products being processed. Power off the device if necessary. • Do not use electronic transmission devices in aircraft, at petrol stations or in hospitals. Observe and obey all warning signs, and power off the device in these conditions. • Do not touch the inner antenna area unless necessary. Otherwise the performance of the device may be affected. • Do not use the device in an enclosed environment or where heat dissipation is poor. Prolonged work in such space may cause excessive heat and raise ambient temperature, which may lead to automatic shutdown of the device for your safety. In the case of such an event, cool the device in a well-ventilated place before turning on for normal use. • Keep the device out of the reach of small children. The device may cause an injury if used as a toy. 16 • When the device is operating, do not touch the metallic parts. Failing to do so may cause burns.…

Text truncated - open the document above for the full version.

秘密▲ < 以上所有信息均为中兴通讯股份有限公司所有，不得外传 > 第 1 页 ZTECORPORATION ProductChangeDescription Astheapplicantofthebelowmodel,[ZTECorporation]declaresthatthe product, [A102ZT] [ZTECorporation] isthevariantoftheinitialcertifiedproduct, [A101ZT] [ZTECorporation] [ProjectNumber:21ZTE0029] SOFTWAREMODIFICATIONS: ProtocolStackchanges:NO MMS/STKchanges:NO 秘密▲ < 以上所有信息均为中兴通讯股份有限公司所有，不得外传 > 第 2 页 JAVAchanges:NO Otherchangesdetailed:NO HARDWAREMODIFICATION: Bandchanges:NO PowerAmplifierchanges:NO Antennachanges:NO PCBLayoutchanges:NO ComponentsonPCBchanges:NO LCDchanges:NO Speakerchanges:NO Camerachanges:NO Vibratorchanges:NO Bluetoothchanges:NO FMchanges:NO Otherchanges:NO MECHANICALMODIFICATIONS: Usenewmetalfront/backcoverorkeypad:NO Mechanicalshellchanges:NO Otherchangesdetailed:NO ACCESSORYMODIFICATIONS: 秘密▲ < 以上所有信息均为中兴通讯股份有限公司所有，不得外传 > 第 3 页 Batterychanges: ACAdaptorchanges: Earphonechanges: APPROVEDBY: ProjectManager:Caihonghong Date:2021-5-7 Company:ZTECorporation Address:B109,#889,BiboRd,ZhangjiangHi-TechPark,Shanghai,China Tel:+86-21-68896840 Fax:+86-21-68896835

ZTE Corporation. ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Authorization Letter FCC ID: SRQ-A101ZT Date: 2021-4-14 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_centerTesting Center (SRTC) to act on our behalf, as our agent, in the followingmatters related to the FCC approval of our product: Product Name: UFI Product Model: A101ZT,A102ZT FCC ID: SRQ-A101ZT Report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by The State Radio_monitoring_center TestingCenter (SRTC) within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Thank you. Sin cerely, ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

Ersteller:D.BrandhorstRevision:00 Erstelldatum:20.06.2011Datum:00.00.00Seite1von1 UNIIDeclarationLetter WehavedeclaredbelowfeaturedforFCCequipmentauthorization,deviceFCCID:SRQ-A101ZT (1)DFSDevice--Master,ClientwithRadardetectioncapability, Clientwithoutradardetectioncapability,N/A (2)Active/PassiveScanning,adhocmodeaccesspointcapability FrequencyBand (MHz) ActiveScanning (thedevicecan transmitaprobe (beacon)) passivescanning (wherethedevice is canlistenonly withno probes) AdHocMode capability Accesspoint capability 2412–2462MHzYes,NoYes,NoYes,NoYes,No 2422–2452MHzYes,NoYes,NoYes,NoYes,No 5745–5825MHzYes,NoYes,NoYes,NoYes,No 5755–5795MHzYes,NoYes,NoYes,NoYes,No 5180–5240MHzYes,NoYes,NoYes,NoYes,No 5190–5230MHzYes,NoYes,NoYes,NoYes,No 5260–5320MHzYes,NoYes,NoYes,NoYes,No 5270–5310MHzYes,NoYes,NoYes,NoYes,No 5500–5700MHzYes,NoYes,NoYes,NoYes,No 5510–5670MHzYes,NoYes,NoYes,NoYes,No (3)Countrycodeselectionability-Yes,No Ifno,plsexplainhowwasimplemented:useMicrosoftnetworkutility (4)Meet15.202requirement-Yes,No, plscheckbelow: Amasterdeviceisdefinedasadeviceoperatinginamodeinwhichithasthecapabilityto transmitwithoutreceivinganenablingsignal.Inthismodeitisabletoselectachannelandinitiatea networkbysendingenablingsignalstootherdevices Aclientdeviceisdefinedasadeviceoperatinginamodeinwhichthetransmissionsofthedevice areundercontrolofthemaster.Adeviceinclientmodeisnotabletoinitiateanetwork. (5)Forclientdevicesthathavesoftwareconfigurationcontroltooperateindifferentmodes(active scanninginsomeandpassivescanninginothers)indifferentbands(deviceswithmultipleequipment classesorthosethatoperateonnon-DFSfrequencies)ormodulardeviceswhichconfigurethemodes ofoperationsthroughsoftware,theapplicationmustprovidesoftwareandoperationsdescriptionon howthesoftwareand/orhardwareisimplementedtoensurethatproperoperationsmodescannot bemodifiedbyenduseroraninstaller. Apply,NoApply , (Ifapply,plshelptoprovideexplanationonhowitwasimplement(Byhardwareorsoftware,andhowsoftwarewascontrolled) Applicant:ZTECorporation Address:ZTEPlaza,#55KejiRoadSouth,Hi-Tech,IndustrialPark,NanshanDistrict,Guangdong Signature:April14，2021 Name:GongYu JobTitle:CertificationManager

Date: 22 April 2021 ZTE Corporation PHOENIX TESTLAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Subject: Declaration Operating Channel Limitation Product Name: UFI Product Model: A101ZT,A102ZT FCC ID: SRQ-A101ZT To Whom it may concern, The operating channels in 802.11 b/g/n mode for the device marketed to the US/Canada are firmware limited to channel 1 ~ 11 (2412 ~ 2462 MHz). The end-user has no possibility to select any other operating channels. If you have any questions, please feel free to contact me. Thank you. Si ncerely, Certification Manager ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

ZTE Corporation. ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of i nformation accompanying of following product: Product Name: UFI Product Model: A101ZT,A102ZT FCC ID: SRQ-A101ZT The following information should be held confidential: All Schematics/block diagrams/BOM All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397
