SRQ-EB64GZTE True Wireless In-Ear Headphone with BT

First Time Use If the battery level of the Earphones and the charging case are low when the package is opened for the first time, please charge for 10 minutes. Product Illustrations Type C Charging Cable Front of Earphone Charging Case Back of Earphone Bluetooth Connection When the charging case is opened and connection is made for the first time, the Earphones will automatically turn on and enter the pairing mode with the device; click "ZTE Buds" in the device list to connect. If the Earphones have been paired with a device previously, it will automatically connect to the last connected device after the case is opened. Disconnect Bluetooth After the two Earphones are placed into the charging case, the Bluetooth connection to the device is disconnected after the charging case is closed. Charge the Earphones Place the Earphones in the charging case. The Bluetooth connection disconnects and the charging of the Earphones starts. Operation Functions Clearing Connection Records Place the two Earphones in the charging case and simultaneously press and hold the buttons on both Earphones for more than 10 seconds to clear the pairing records. Charge the Charging Case The Charging Case can be charged using a Type C charging cable. The battery level and charging status can be confirmed by the battery indicator. Notes:Please charge by connecting to an adapter with an output voltage (compatible) of 5 V by using a Type C charging cable. *If the output voltage of the adapter is higher than 5 V, it may cause charging failure or even damage to the product. LED Indicator After the Earphones are placed in the case: The case is fully charged: The white light on the case turns on for 4 seconds and turns off. Battery level of the case is low: The white light on the case flashes for 4 seconds and turns off. Charging the Charging Case: Charging: The white light on the case flashes. Fully charged: The white light on the case stays on. The charging cable is unplugged: The light on the case turns off. 5.Do not wear Earphones continuously for long periods of time (more than 6 hours), especially listening at maximum volume; 6.Do not wear Earphones when riding or driving. Such behavior is illegal in some countries; 7.This product contains a lithium battery. Disassembly, collision, crushing or exposure to fire is prohibited. Do not use swollen batteries. Do not place in high-temperature environments. Please dispose the battery in accordance with local regulations and do not treat it as household waste. Environmental protection support Name and content of hazardous substances in the product Package Content True Wireless Stereo (TWS) Bluetooth Earphones x1 Charging Case x1 Type C Charging Cable x1 User Guide x1 Technical Specifications Warning 1.Do not disassemble, repair or modify the product for any reason, as this may cause fire, electronic breakdown or even completely destroy the product; 2.Do not wipe this product with oil or other volatile liquids; 3.Do not leave the device in environments where the temperature is too high or too low (above 75 degrees or below minus 40 degrees) for an extended period of time. 4.Do not use the device during thunderstorms. Thunderstorms can cause the device to malfunction and increase the risk of electric shocks. L for the left Earphone Play/Pause Previous Next Volume+ Volume- Answer / hang up the phone Reject a call Voice Assistant R for the right Earphone Click for 3 timesClick for 3 times Hold the left Earphone for 2s Touch the left Earphone Hold the right Earphone for 2s Touch the right Earphone Hold the Earphone for 2sHold the Earphone for 2s Click for 2 timesClick for 2 times Click for 2 timesClick for 2 times 53 x 44 x 23 EarphoneCharging Case Bluetooth version Charging time Talk time Music playtime Frequency range Battery capacity Weight (one side) Dimensions (mm) Earphone impedance 5.0 1.5 H 3.7 H Capacity Type C charging time Weight of the whole device 500 mAh 1.5 H 37.6 g5 H 20 Hz-20 KHz 43 mAh 3.4 g 32 Ω Part Name Circuit BoardpbHgCd CrVIPBDE Plastic Parts Metal Parts Speaker Cable Battery Accessories Hazardous Substances PBB This form is prepared in accordance with the provisions of S1/T11364. : Indicates that this hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in GB/T26572. : Indicates that this hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in GB/T26572. For the part marked with " " in the table, the hazardous substance cannot be replaced due to limitations of the global level of technical development. WEEE Electrical and electronic equipment, parts and batteries marked with this symbol must not be disposed of with normal household wastage, it must be collected and disposed of separately to protect the environment. Your EB64G retailer will advise you of the correct way of disposal in your country. FCC The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types EB64G (FCC ID: SRQ-EB64G) has also been tested against this SAR limit. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment. Such modifications or changes could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the i…

Text truncated - open the document above for the full version.

ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: ZTE True Wireless In-Ear Headphone Product Model: EB64G FCC ID: SRQ- EB64G The following information should be held confidential: All Schematics/block diagrams All Parts list for the above schematic diagram Operational description and technical overview of product Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Certification Manager: 2021/8/4 ZTE Corporation Address: ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Fax:+86-21-50801070

ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Authorization Letter Date: August 4, 2021 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_center Testing Center (SRTC) to act on our behalf, as our agent, in the following matters related to the FCC approval, IC certification approval of our product: Product Name: ZTE True Wireless In-Ear Headphone Product Model: EB64G FCC ID: SRQ- EB64G Report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by The State Radio_monitoring_center Testing Center (SRTC) within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Thank you. ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Fax:+86-21-50801070

SRQ-EB64G External Photos 1 / 9 FCC ID : SRQ‐EB64G SRQ-EB64G External Photos 2 / 9 FCC ID : SRQ‐EB64G the right headphone the right headphone SRQ-EB64G External Photos 3 / 9 FCC ID : SRQ‐EB64G the right headphone the right headphone SRQ-EB64G External Photos 4 / 9 FCC ID : SRQ‐EB64G the left headphone the left headphone SRQ-EB64G External Photos 5 / 9 FCC ID : SRQ‐EB64G the left headphone the left headphone SRQ-EB64G External Photos 6 / 9 FCC ID : SRQ‐EB64G The charger View 1 The charger View 2 SRQ-EB64G External Photos 7 / 9 FCC ID : SRQ‐EB64G The charger View 3 The charger View 4 SRQ-EB64G External Photos 8 / 9 FCC ID : SRQ‐EB64G The charger View 5 The USB Cabel SRQ-EB64G External Photos 9 / 9 FCC ID : SRQ‐EB64G The USB Cabel

左腔字符：9.95mm X7.9mm 字符镭雕 PANTONE 423C 右腔字符：10.8mm X 7mm 字符镭雕 PANTONE 423C 充电仓上盖内壳 镭雕方案 7.9mm 7.9mm 3.6mm 3.6mm 6.95mm 型号/Model:EB64G 输入/Input:5V 1A 输出/Output:5V 1A 中兴通讯股份有限公司 500mAh ZTE Corporation 中国制造/Made In China CMIIT ID:XXXXXXXXXX FCC ID:SRQ-EB64G 5.45mm 6.95mm 5.45mm 型号/Model:EB64G 输入/Input:5V 1A 输出/Output:5V 1A 中兴通讯股份有限公司 500mAh ZTE Corporation 中国制造/Made In China CMIIT ID:XXXXXXXXXX FCC ID:SRQ-EB64G I nner shell of upper cover of charging compartment

SRQ-EB64G Internal Photos 1 / 11 FCC ID : SRQ‐EB64G SRQ-EB64G Internal Photos 2 / 11 FCC ID : SRQ‐EB64G Battery Photo 1 Battery Photo 2 SRQ-EB64G Internal Photos 3 / 11 FCC ID : SRQ‐EB64G IC Details 1 IC Details 2 SRQ-EB64G Internal Photos 4 / 11 FCC ID : SRQ‐EB64G IC Details 3 IC Details 4 SRQ-EB64G Internal Photos 5 / 11 FCC ID : SRQ‐EB64G Charger internal photos SRQ-EB64G Internal Photos 6 / 11 FCC ID : SRQ‐EB64G Charger internal photos Charger internal photos SRQ-EB64G Internal Photos 7 / 11 FCC ID : SRQ‐EB64G Charger internal photos Charger internal photos SRQ-EB64G Internal Photos 8 / 11 FCC ID : SRQ‐EB64G Charger internal photos SRQ-EB64G Internal Photos 9 / 11 FCC ID : SRQ‐EB64G Charger internal photos SRQ-EB64G Internal Photos 10 / 11 FCC ID : SRQ‐EB64G Charger internal photos SRQ-EB64G Internal Photos 11 / 11 FCC ID : SRQ‐EB64G

TEST REPORT Report No.: SRTC2021-9003(F)-0022 Product Name: ZTE True Wireless In-Ear Headphone Mode Name: EB64G Applicant: ZTE Corporation Manufacturer: ZTE Corporation Specification: FCC Part15B (Certification) (2020 edition) ANSI C63.4-2014 FCC ID: SRQ-EB64G The State Radio_monitoring_center Testing Center (SRTC) 15th Building, No.30 Shixing Street, Shijingshan District, Beijing, China Tel: 86-10-57996183 Fax: 86-10-57996388 No.: SRTC2021-9003(F)-0022 FCC ID: SRQ-EB64G The State Radio_monitoring_centerTesting Center (SRTC) Page number:2 of 14 Tel: 86-10-57996183 Fax:86-10-57996388 Copyright © SRTC CONTENTS 1. General information ...................................................................................................... 3 1.1 Notes of the test report ............................................................................................................................. 3 1.2 Information about the testing laboratory ................................................................................................ 3 1.3 Applicant’s details ...................................................................................................................................... 3 1.4 Manufacturer’s details .............................................................................................................................. 3 1.5 Application details ...................................................................................................................................... 3 1.6 Reference specification ............................................................................................................................ 4 1.7 Information of EUT .................................................................................................................................... 4 1.7.1 General information ....................................................................................................................... 4 1.7.2 EUT details ...................................................................................................................................... 5 1.7.3 Auxiliary equipment details ........................................................................................................... 5 2. Test information ............................................................................................................ 6 2.1 Summary of the test results ..................................................................................................................... 6 2.2 Test result ................................................................................................................................................... 7 2.2.1 Conducted Emissions-FCC Part15.107 ...................................................................................... 7 2.2.2 Radiated Emissions-FCC Part15.109 ....................................................................................... 10 2.3. List of test equipments .......................................................................................................................... 14 No.: SRTC2021-9003(F)-0022 FCC ID: SRQ-EB64G The State Radio_monitoring_centerTesting Center (SRTC) Page number:3 of 14 Tel: 86-10-57996183 Fax:86-10-57996388 Copyright © SRTC 1. General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC). The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio_monitoring_center Testing Center (SRTC) Address: 15th Building, No.30 Shixing Street, Shijingshan District Testing location： No.80, Zhaojiachang, BeizangCun, Daxing District, Beijing, China. City: Beijing Country or Region: China Contacted person: Liu Jia Te l: +86 10 57996183 Fax: +86 10 57996388 Email: [email protected] 1.3 Applicant’s details Company: Address: City: Country or Region: Contacted person: Te l: Email: ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District, Shenzhen, Guangdong Province 518057, P. R. China Shenzhen China Wenge Wang +86 15999501007 [email protected] 1.4 Manufacturer’s details Company: Address: City: Country or Region: Contacted person: Te l: Email: ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District, Shenzhen, Guangdong Province 518057, P. R. China Shenzhen China Wenge Wang +86 15999501007 [email protected] 1.5 Application details Date of reception of test sample: 19 th Jul. 2021 Date of test: 19 th Jul. 2021 to 4 th Aug. 2021 No.: SRTC2021-9003(F)-0022 FCC ID: SRQ-EB64G The State Radio_monitoring_centerTesting Center (SRTC) Page number:4 of 14 Tel: 86-10-57996183 Fax:86-10-57996388 Copyright © SRTC 1.6 Reference specification FCC Part 15B, 2020 (Certification) 1. 7 Information of EUT 1.7.1 General information Product Name of EUT ZTE True Wireless In-Ear Headphone Mode Name EB64G FCC ID SRQ-EB64G Frequency Range Bluetooth: 2.4~2.4835GHz Power Supply Battery Nominal Voltage 3.8V Extreme Temperature Lowest: -10°C Highest: +45°C Extreme Voltage Minimum: 3.1V Maximum: 4.2V HW Version V2 SW Version 1.0.1.0 No.: SRTC2021-9003(F)-0022 FCC ID: SRQ-EB64G The State Radio_monitoring_centerTesting Center (SRTC) Page number:5 of 14 Tel: 86-10-57996183 Fax:86-10-57996388 Copyright © SRTC 1.7.2 EUT details No. Product Name Mode Name IMEI EUT ZTE True Wireless In-Ear Headphone EB64G --- 1.7.3 Auxiliary equipment details AE (Auxiliary Equipment) 1#: Battery Manufacturer JUHEYUAN SCIENCE & TECHNOLOGY CO., LTD. Model Number JHY1054 AE (Auxiliary Equipment) 2#: Battery Manufacturer JUHEYUAN SCIENCE & TECHNOLOGY CO., LTD. Model Number JHY902030 Note: The AE1 is the Battery for the HeadPhone while the AE2 is the Battery for the cha…

Text truncated - open the document above for the full version.

No.: SRTC2021-9003(F)-0022 FCC ID: SRQ-EB64G The State Radio_monitoring_center Testing Center (SRTC) Page number: 1of 2 Te l : 86-10-57996183 Fax: 86-10-57996388 Copyright © SRTC Appendix1 Test Setup EUT+Laptop: Radiated Emissions Test Setup（30-1000MHz） Radiated Emissions Test Setup（above1GHz） No.: SRTC2021-9003(F)-0022 FCC ID: SRQ-EB64G The State Radio_monitoring_center Testing Center (SRTC) Page number: 2of 3 Te l : 86-10-57996183 Fax: 86-10-57996388 Copyright © SRTC Conducted Emissions Test Setup
