SRQ-MC7010CAWLAN Router (5G NR/LTE/WCDMA/BT BLE)

1 MC7010CA Quick Start Guide 2 View this label to get the default Password . ┌ Scan this QR code to download the Install Helper application. 3 LEGAL INFORMATION Copyright © 2021 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Disclaimer Images and screenshots used in this guide may differ from the actual product. Content in this guide may differ from the actual product or software. Trademarks ZTE and the ZTE logos are trademarks of ZTE Corporation. Other trademarks and trade names are those of their respective owners. Version No.: R1.0 4 Unpacking and Preparations Before installing the device, make sure that all items listed in the packing list are present. If something is missing or damaged, pleasecontact ZTE technical support. Packing List The MC7010CA ODU CPE The Quick Start Guide 1 Cover plate kit: Anti-theft screw*2,Screw anti-theft removal wrench*1, one CAT5E Network cable(for connecting the device and the POE adapter) Mounting Kit:Metal bracket, Backplane, Metal clamp, M6 expansion bolts & M6 expansion spigots*4,M3 crosshead screws*5 1 POE adapter and AC Power cord 1 RJ-45 Network cable (for connecting the POE adapter and PC/Router) 5 Prepare the following accessories(not included):  Crosshead screwdriver  Flat head screwdriver  Hammer drill  Marker pens Installation Precautions  Do not install the device in the following directions: Do not install the device with the interface side facing upwards. Do not install the device horizontally. Do not install the device tilted. WARNING! The device must be installed downwards and vertically. It is not recommended to install the device in other directions(including but not limited to the above scenarios). ZTE is not liable for any problem caused by the installation in other incorrect directions.  Do not install the device at a high position (lightning area).  The device must be placed in a well-ventilated environment for use. If possible, install the device in a place with less direct sunlight, for example, in the shade. The device must not be installed at the outlet of the exhaust pipe, or installed in a place where water passes through, for example, a rain shed.  The device shall be installed in the position of the site survey design drawings and within the protection range of 45° of the lightning rod. In high mountains and areas with heavy lightning (the number of thunderstorm days per year exceeds 180), ensure that the device is within the protection range of 30°of the lightning rod.  When the device is mounted on the wall, it should better be more than 1 m away from the grounding cable of the lightning rod and more than 20 cm away from the lightning protection 6 zone.  When installing the device against a pole, do not install a lightning rod on the pole. It is recommended that an independent lightning rod be installed near the pole. If a lightning rod is installed on the pole, it is recommended that the lightning rod be led out and grounded directly.  The mounting pole must be firm, cannot be shaken and must meet the wind-resistant requirements (not less than level-10 wind speed).  The mounting pole should be vertical, and the vertical error should be less than ±2°. Installation Modes You can install the device in either of the following ways: Install the device on a wall. Install the device against a pole. Requirements of Installation Space 7 Recommended Installation Locations 8 1.Installing the nano-SIM Card Insert the nano-SIM card to the SIM card slot as shown. WARNING! Your device does not support(U)SIM cards,micro-SIM cards or any other non-standard SIM cards. To avoid damage to the device, do not use those cards or any card holders. 9 2.Installing the Network Cable 1. Connect the RJ45 to the network port on the MC7010CA while the two screws are also inserted into the holes at the bottom of the device. 2. Push the cover plate upwards until it is secured, and use a screw anti-theft removal wrench to install the cover plate on the device. 3. Reserve enough length of the network cable,and crimp the RJ45. 10 3.Using Install Helper Application to Detect Position Before installingthe MC7010CA, you can install the Install Helper applicationon your mobile phone and connect to the device to detect the signal strength and help you detect and locate the installation location. NOTE: View the label on this guide to get the link or QR cord to download the Install Helper application. Powering on the MC7010CA 1. Connect the CAT5Enetwork cable which is from the MC7010CA to the network port(RJ45-2) on the POE adapter. 2. Connect the power connector on the POE adapter to the socket. Connecting to the MC7010CA Before connecting to the device, make sure that you have installed the Install Helper application and turn Bluetooth ® on of your phone. 1. Open the app list and touchInstall Helper. 2. Touch CONNECT TO DEVICE and select MC7010CA.The Bluetooth of the device will turn on automatically, and your phone automatically scans for and displays the IDs of all available Bluetooth devices in range. 3. Touch the device you want to pair with. 4. Touch PAIR& CONNECT >PAIRto accept the connection. 5. Enter the password and touch OK to manage the device. NOTE: View the label onthis guideto get the default password. Detecting and AdjustingInstallation Position 1. Move the device around the mounting wall/pole or try different positions and touch DETECT POSITION. 2. Follow the on-screen instructions to attach the device to your target position, and slowly move it until it provides feedback. NOTE: The device does not support elevation angle adjustment. It only supports horizontal 180° adjustment. 3. Th…

Text truncated - open the document above for the full version.

ZTE Corporation Date: 2021/2/22 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The ZTE Corporation, the undersigned, hereby authorizes Mrs. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the ZTE Corporation solely in matters relating to the application for an FCC equipment authorization for FCC ID: SRQ-MC7010CA including the signing of documents in connection with this Application. Necessary acts carried out Shenzhen Morlab Communications Technology Co., Ltd. on our behalf of the ZTE Corporation in connection with the Application shall have the same effect as acts of the ZTE Corporation. ZTE Corporation also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Name: Gong Yu Job Title: Certification Manager Telephone Number: +86-21-68895397 Fax Number: +86-21-50801070 Email: [email protected]

ZTE Corporation Date: 2021/2/22 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re:ZTE Corporation FCC ID: SRQ-MC7010CA Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. ZTE Corporation requests that the following documents regarding this submission for FCC ID:SRQ-MC7010CA be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematic.pdf Operational Description Operational description.pdf Part list BOM.pdf Those documents contain detailed system and equipment description and related information about the product which ZTE Corporation considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, ZTE Corporation considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours Sincerely, Name: Gong Yu Job Title: Certification Manager Telephone Number: +86-21-68895397 Fax Number: +86-21-50801070 Email: [email protected]

FCC ID:SRQ-MC7010CA, IC:5200E-MC7010CA External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

1. Label 2. Label location

FCC ID:SRQ-MC7010CA, IC:5200E-MC7010CA Internal Photos 1. EUT uncover view 2. Antenna view WCDMA/LTE/NR Antenna LTE B2/4/7/25/30/66 P RX MIMO Antenna NR N2/7/66 PRX MIMO Antenna WCDMA/LTE/NR Antenna WCDMA/LTE/NR Antenna

NOTE: This document is issued by MORLAB, the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 76 REPORT No.：SZ21010176S01 RF EXPOSURE EVALUATION REPORT APPLICANT : ZTE Corporation PRODUCT NAME : WLAN Router MODEL NAME : MC7010CA BRAND NAME : ZTE FCC ID : SRQ-MC7010CA STANDARD(S) : 47CFR 2.1091 KDB 447498 RECEIPT DATE : 2021-01-15 TEST DATE : 2021-01-30 to 2021-02-05 ISSUE DATE : 2021-03-03 Edited by: Gan Yueming (Rapporteur) Approved by: Peng Huarui (Supervisor) MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ21010176S01 Page 2 of 76 DIRECTORY 1. Technical Information········································································································ 3 1.1 Applicant and Manufacturer Information ····································································· 3 1.2 Equipment under Test (EUT) Description ···································································· 3 1.3 Applied Reference Documents ····················································································· 5 2. Device Category and RF Exposure Limit ······································································· 6 3. Test Equipment List ··········································································································· 7 4. RF Output Power ··············································································································· 8 5. RF Exposure Assessment ······························································································ 74 Annex A General Information ······························································································· 76 Change History Version Date Reason for Change 1.0 2021-03-03 First edition MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ21010176S01 Page 3 of 76 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: ZTE Corporation Applicant Address: ZTE Plaza, Keji Road South, Shenzhen, China. Manufacturer: ZTE Corporation Manufacturer Address: ZTE Plaza, Keji Road South, Shenzhen, China. 1.2 Equipment under Test (EUT) Description Product Name: WLAN Router Hardware Version: MC7010CAHW1.0 Software Version: MC7010CAV1.1 Frequency Bands: WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band IV: 1710 MHz ~ 1755 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 7: 2500 MHz ~ 2570 MHz LTE Band 12: 699 MHz ~ 716 MHz LTE Band 13: 777 MHz ~ 787 MHz LTE Band 17: 704 MHz ~ 716 MHz LTE Band 25: 1850 MHz ~ 1915 MHz LTE Band 26: 814 MHz ~ 849 MHz LTE Band 29: 717 MHz ~ 728 MHz (RX Only) LTE Band 30: 2305 MHz ~ 2315 MHz LTE Band 66: 1710 MHz ~ 1780 MHz 5G NR n66: 1710 MHz ~ 1780 MHz 5G NR n71: 663 MHz ~ 698 MHz Bluetooth: 2402 MHz ~ 2480 MHz Modulation Mode: WCDMA: QPSK, 16QAM LTE: QPSK, 16QAM, 64QAM 5G NR: CP-OFDM/DFT-s-OFDM, PI/2 BPSK QPSK, 16QAM, 64QAM, 256QAM Bluetooth : GFSK(1Mbps) EN-DC Combination: DC_2A_n66A, DC_5A_n66A, DC_7A_n66A, DC_12A_n66A, MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ21010176S01 Page 4 of 76 DC_13A_n66A，DC_30A_n66A, DC_2A_n71A, DC_7A_n71A, DC_66A_n71A Antenna Type: Fixed Internal Antenna Antenna Gain: WCDMA Band II/IV: 1.7 dBi WCDMA Band V: 0.8 dBi LTE Band 5/12/13/26/29: 1.0 dBi LTE Band 2/4/7/25/30/66: 1.7 dBi 5G NR n66: 1.8 dBi 5G NR n71: 0.6 dBi Note: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% risk level. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ21010176S01 Page 5 of 76 1.3 Applied Reference Documents Leading reference documents for testing: No. Identity Document Title Method determination /Remark 1 47 CFR§2.1091 Radio Frequency Radiation Exposure Assessment: mobile devices No deviation 2 KDB 447498 D01v06 General RF Exposure Guidance No deviation Note 1: The test item is not applicable. Note 2: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ21010176S01 Page 6 of 76 2. Device Category and RF Exposure Limit Per …

Text truncated - open the document above for the full version.

NOTE: This document is issued by MORLAB, the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 41 REPORT No.：SZ21010176W01 TEST REPORT APPLICANT : ZTE Corporation PRODUCT NAME : WLAN Router MODEL NAME :MC7010CA BRAND NAME : ZTE FCC ID : SRQ-MC7010CA STANDARD(S) : 47 CFR Part 15 Subpart C RECEIPT DATE : 2021-01-15 TEST DATE :2021-01-21 to 2021-02-18 ISSUE DATE :2021-03-04 Edited by: Zeng Xiaoying (Rapporteur) Approved by: Peng Huarui (Supervisor) MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 41 REPORT No.：SZ21010176W01 DIRECTORY 1. Technical Information ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 3 1.1. Applicant and Manufacturer Information ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 3 1.2. Equipment Under Test (EUT) Description ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 3 1.3. The Channel Number and Frequency ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 4 1.4. Test Standards and Results ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 5 1.5. Environmental Conditions ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 6 2. 47 CFR Part 15C Requirements ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 7 2.1. Antenna Requirement ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 7 2.2. Duty Cycle of Test Signal ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 8 2.3. Maximum Peak Conducted Output Power ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 9 2.4. Maximum Average Conducted Output Power ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 12 2.5. 6 dB Bandwidth ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 13 2.6. Conducted Spurious Emissions and Band Edge ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 16 2.7. Power Spectral Density (PSD) ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 20 2.8. Conducted Emission ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 23 2.9. Restricted Frequency Bands ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 27 2.10. Radiated Emission ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 31 Annex A Test Uncertainty ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 38 Annex B Testing Laboratory Information ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 39 Change History Version Date Reason for change 1.0 2021-03-04 First edition MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 41 REPORT No.：SZ21010176W01 1. Technical Information Note: Provide by applicant. 1.1. Applicant and Manufacturer Information Applicant: ZTE Corporation Applicant Address: ZTE Plaza, Keji Road South, Shenzhen, China. Manufacturer: ZTE Corporation Manufacturer Address: ZTE Plaza, Keji Road South, Shenzhen, China. 1.2. Equipment Under Test (EUT) Description Product Name: WLAN Router Serial No.: (N/A, marked #1 by test site) Hardware Version: MC7010CAHW1.0 Software Version: MC7010CAV1.1 Equipment Type: Bluetooth LE Bluetooth Version: 5.0 Modulation Type: GFSK Data Rate: 1Mbps Operating Frequency Range: 2402MHz-2480MHz Antenna Type: Fixed Internal Antenna Antenna Gain: 1.5dBi Accessory Information: AC Adapter Brand Name: ZTE Model No.: POE-A4803 Serial No.: (N/A, marked #1 by test site) Rated Output: 48V0.31A Rated Input: 100-240V 50/60Hz, 0.5A Manufacturer: ZTE Corporation Note 1: We use the dedicated software to control the EUT continuous transmission. Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 41 REPORT No.：SZ21010176W01 1.3. The Channel Number and Frequency Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 10 2422 20 2442 30 2462 1 2404 11 2424 21 2444 31 2464 2 2406 12 2426 22 2446 32 2466 3 2408 13 2428 23 2448 33 2468 4 2410 14 2430 24 2450 34 2470 5 2412 15 2432 25 2452 35 2472 6 2414 16 2434 26 2454 36 2474 7 2416 17 2436 27 2456 37 2476 8 2418 18 2438 28 2458 38 2478 9 2420 19 2440 29 2460 39 2480 Note 1: The black bold channels were selected for test. MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 5 of 41 REPORT No.：SZ21010176W01 1.4. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 …

Text truncated - open the document above for the full version.

FCC ID:SRQ-MC7010CA, IC:5200E-MC7010CA Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (9KHz-30MHz) 4. Radiated emission (30MHz-1GHz) 5. Radiated emission (above 1GHz) 6. RF measurement setup (Bluetooth LE)
