Report No. 2015SAR270 Page 2 / 210 V5.0 Standards Conclusion Localized Specific Absorption Rate (SAR) of this equipment has been measured in all cases requested by the relevant standards above. Maximum localized SAR is below exposure limits as well. Applicable Limit Regulations ANSI/IEEE C95.1-2005 Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields. 3 kHz to 300 GHz ANSI/IEEE C95.3-2002 Recommended Practice For Measurements and Computations of Radio Frequency Electromagnetic Fields with Respect to Human Exposure to such Fields. 100 kHz-300 GHz Applicable Standards IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques KDB865664 D01v01r03: SAR Measurement Requirements for 100 MHz to 6 GHz KDB447498 D01v05r02: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Polices KDB248227 D01v02r01: SAR Measurement Procedures for IEEE 802.11 Wi-Fi Transmitters KDB941225 D01v03: SAR Measurement Procedures for 3G Devices KDB941225 D05v02r03: SAR Test Consideration for LTE Handsets and Data Modems KDB941225 D06v02: SAR Evaluation Procedures for Portable Devices with Wireless Router Capabilities. Report No. 2015SAR270 Page 3 / 210 V5.0 Change History Version Change Contents Author Date V1.0 First edition Chen Qiang 2015-06-30 V2.0 Add two channel testing of LTE band 41, retest wifi for MIMO mode Chen Qiang 2015-07-14 V3.0 Add evaluation for wifi with ducy cycle factor Chen Qiang 2015-07-16 V4.0 Add evaluation for LTE 50%RB worst position Chen Qiang 2015-07-17 V5.0 Update evaluation of wifi Chen Qiang 2015-07-18 Note: The last version will be invalid automatically while the new version is issued. Report No. 2015SAR270 Page 4 / 210 V5.0 CONTENTS: STANDARDS ............................................................................................................................... 2 CONCLUSION ............................................................................................................................. 2 CHANGE HISTORY..................................................................................................................... 3 1. STATEMENT OF COMPLIANCE ......................................................................................... 6 2. ADMINISTRATIVE INFORMATION ........................................................................................ 7 2.1 PROJECT INFORMATION ..................................................................................................................... 7 2.2 TEST LABORATORY INFORMATION ...................................................................................................... 7 2.3 TEST ENVIRONMENT .......................................................................................................................... 7 3. CLIENT INFORMATION .......................................................................................................... 8 3.1 APPLICANT INFORMATION .................................................................................................................. 8 3.2 MANUFACTURER INFORMATION.......................................................................................................... 8 4. EQUIPMENT UNDER TEST (EUT) AND ACCESSORY EQUIPMENT (AE) ......................... 9 4.1 INFORMATION OF EUT ....................................................................................................................... 9 4.2 IDENTIFICATION OF EUT .................................................................................................................. 11 4.3 IDENTIFICATION OF AE ..................................................................................................................... 11 5．OPERATIONAL CONDITIONS DURING TEST .................................................................. 12 5.1 GENERAL DESCRIPTION OF TEST PROCEDURES ............................................................................... 12 5.2 GSM TEST CONFIGURATION ........................................................................................................... 12 5.3 WCDMA TEST CONFIGURATION ..................................................................................................... 13 5.4 LTE TEST CONFIGURATION ............................................................................................................. 15 5.6 WI-FI TEST CONFIGURATION ........................................................................................................... 18 6. SAR MEASUREMENTS SYSTEM CONFIGURATION ........................................................ 19 6.1 SAR MEASUREMENT SET-UP ........................................................................................................... 19 6.2 DASY5 E-FIELD PROBE SYSTEM .................................................................................................... 20 6.2.1 Es3DV3 Probe Specification ................................................................................................ 20 6.2.2 E-field Probe Calibration ....................................................................................................... 21 6.3 OTHER TEST EQUIPMENT ................................................................................................................ 22 6.3.1 Device Holder for Transmitters ............................................................................................. 22 6.3.2 Phantom ................................................................................................................................. 22 6.4 SCANNING PROCEDURE ................................................................................................................... 23 6.5 DATA STORAGE AND EVALUATION ..................................................................................................…

Text truncated - open the document above for the full version.

Report No. 2015SAR270 Page 111 / 210 V5.0 Report No. 2015SAR270 Page 112 / 210 V5.0 Report No. 2015SAR270 Page 113 / 210 V5.0 Report No. 2015SAR270 Page 114 / 210 V5.0 Report No. 2015SAR270 Page 115 / 210 V5.0 Report No. 2015SAR270 Page 116 / 210 V5.0 Report No. 2015SAR270 Page 117 / 210 V5.0 Report No. 2015SAR270 Page 118 / 210 V5.0 Report No. 2015SAR270 Page 119 / 210 V5.0 Report No. 2015SAR270 Page 120 / 210 V5.0 Report No. 2015SAR270 Page 121 / 210 V5.0 Report No. 2015SAR270 Page 122 / 210 V5.0 Report No. 2015SAR270 Page 123 / 210 V5.0 Report No. 2015SAR270 Page 124 / 210 V5.0 Report No. 2015SAR270 Page 125 / 210 V5.0 Report No. 2015SAR270 Page 126 / 210 V5.0 Report No. 2015SAR270 Page 127 / 210 V5.0 Report No. 2015SAR270 Page 128 / 210 V5.0 Report No. 2015SAR270 Page 129 / 210 V5.0 Annex B.2 DAE4 Calibration Certificate Report No. 2015SAR270 Page 130 / 210 V5.0 Report No. 2015SAR270 Page 131 / 210 V5.0 Report No. 2015SAR270 Page 132 / 210 V5.0 Report No. 2015SAR270 Page 133 / 210 V5.0 Report No. 2015SAR270 Page 134 / 210 V5.0 Report No. 2015SAR270 Page 135 / 210 V5.0 Report No. 2015SAR270 Page 136 / 210 V5.0 Report No. 2015SAR270 Page 137 / 210 V5.0 Report No. 2015SAR270 Page 138 / 210 V5.0 Report No. 2015SAR270 Page 139 / 210 V5.0 Annex B.3 D835V2 Calibration Certificate Report No. 2015SAR270 Page 140 / 210 V5.0 Report No. 2015SAR270 Page 141 / 210 V5.0 Report No. 2015SAR270 Page 142 / 210 V5.0 Report No. 2015SAR270 Page 143 / 210 V5.0 Report No. 2015SAR270 Page 144 / 210 V5.0 Report No. 2015SAR270 Page 145 / 210 V5.0 Report No. 2015SAR270 Page 146 / 210 V5.0 Report No. 2015SAR270 Page 147 / 210 V5.0 Report No. 2015SAR270 Page 148 / 210 V5.0 Report No. 2015SAR270 Page 149 / 210 V5.0 Annex B.4 D1900V2 Calibration Certificate Report No. 2015SAR270 Page 150 / 210 V5.0 Report No. 2015SAR270 Page 151 / 210 V5.0 Report No. 2015SAR270 Page 152 / 210 V5.0 Report No. 2015SAR270 Page 153 / 210 V5.0 Report No. 2015SAR270 Page 154 / 210 V5.0 Report No. 2015SAR270 Page 155 / 210 V5.0 Report No. 2015SAR270 Page 156 / 210 V5.0 Report No. 2015SAR270 Page 157 / 210 V5.0 Report No. 2015SAR270 Page 158 / 210 V5.0 Report No. 2015SAR270 Page 159 / 210 V5.0 Annex B.5 D2450V2 Calibration Certificate Report No. 2015SAR270 Page 160 / 210 V5.0

Report No. 2015SAR270 Page 161 / 210 V5.0 Report No. 2015SAR270 Page 162 / 210 V5.0 Report No. 2015SAR270 Page 163 / 210 V5.0 Report No. 2015SAR270 Page 164 / 210 V5.0 Report No. 2015SAR270 Page 165 / 210 V5.0 Report No. 2015SAR270 Page 166 / 210 V5.0 Report No. 2015SAR270 Page 167 / 210 V5.0 Report No. 2015SAR270 Page 168 / 210 V5.0 Report No. 2015SAR270 Page 169 / 210 V5.0 Annex B.6 D1750V2 Calibration Certificate Report No. 2015SAR270 Page 170 / 210 V5.0 Report No. 2015SAR270 Page 171 / 210 V5.0 Report No. 2015SAR270 Page 172 / 210 V5.0 Report No. 2015SAR270 Page 173 / 210 V5.0 Report No. 2015SAR270 Page 174 / 210 V5.0 Report No. 2015SAR270 Page 175 / 210 V5.0 Report No. 2015SAR270 Page 176 / 210 V5.0 Report No. 2015SAR270 Page 177 / 210 V5.0 Report No. 2015SAR270 Page 178 / 210 V5.0 Report No. 2015SAR270 Page 179 / 210 V5.0 Annex B.7 D2600V2 Calibration Certificate Report No. 2015SAR270 Page 180 / 210 V5.0 Report No. 2015SAR270 Page 181 / 210 V5.0 Report No. 2015SAR270 Page 182 / 210 V5.0 Report No. 2015SAR270 Page 183 / 210 V5.0 Report No. 2015SAR270 Page 184 / 210 V5.0 Report No. 2015SAR270 Page 185 / 210 V5.0 Report No. 2015SAR270 Page 186 / 210 V5.0 Report No. 2015SAR270 Page 187 / 210 V5.0 Report No. 2015SAR270 Page 188 / 210 V5.0 Report No. 2015SAR270 Page 189 / 210 V5.0 Annex B.8 D5GHzV2 Calibration Certificate Report No. 2015SAR270 Page 190 / 210 V5.0 Report No. 2015SAR270 Page 191 / 210 V5.0 Report No. 2015SAR270 Page 192 / 210 V5.0 Report No. 2015SAR270 Page 193 / 210 V5.0 Report No. 2015SAR270 Page 194 / 210 V5.0 Report No. 2015SAR270 Page 195 / 210 V5.0 Report No. 2015SAR270 Page 196 / 210 V5.0 Report No. 2015SAR270 Page 197 / 210 V5.0 Report No. 2015SAR270 Page 198 / 210 V5.0 Report No. 2015SAR270 Page 199 / 210 V5.0 Report No. 2015SAR270 Page 200 / 210 V5.0 Report No. 2015SAR270 Page 201 / 210 V5.0 Report No. 2015SAR270 Page 202 / 210 V5.0 Report No. 2015SAR270 Page 203 / 210 V5.0 Report No. 2015SAR270 Page 204 / 210 V5.0 ANNEX C: Test Layout Picture C.1: Specific Absorption Rate Test Layout Picture C.2: Liquid depth in the flat Phantom (835MHz) (15.1cm deep) Report No. 2015SAR270 Page 205 / 210 V5.0 Picture C.3: Liquid depth in the head Phantom (835MHz) (15.4cm deep) Picture C.4: Liquid depth in the flat Phantom (1900 MHz) (15.3cm deep) Report No. 2015SAR270 Page 206 / 210 V5.0 Picture C.5: liquid depth in the head Phantom (1900 MHz) (15.2cm deep) Picture C.6: Liquid depth in the flat Phantom (2450 MHz) (15.1cm deep) Report No. 2015SAR270 Page 207 / 210 V5.0 Picture C.7: liquid depth in the head Phantom (2450 MHz) (15.2cm deep) Picture C.8: Liquid depth in the flat Phantom (1750 MHz) (15.2cm deep) Report No. 2015SAR270 Page 208 / 210 V5.0 Picture C.9: liquid depth in the head Phantom (1750 MHz) (15.1cm deep) Picture C.10: Liquid depth in the flat Phantom (2600 MHz) (15.2cm deep) Report No. 2015SAR270 Page 209 / 210 V5.0 Picture C.11: liquid depth in the head Phantom (2600 MHz) (15.3cm deep) Picture D 12: Liquid depth in the head Phantom (750MHz) (15.4cm deep) Report No. 2015SAR270 Page 210 / 210 V5.0 Picture D 13: Liquid depth in the flat Phantom (750MHz) (15.3cm deep) ------------------------------------------END OF REPORT----------------------------------------------------

©Copyright. All rights reserved by CTTL. FCC PART 15C TEST REPORT No. I15Z41150-SRD05 for ZTE CORPORATION LTE/WCDMA/GSM Multi-Mode Ufi Model name: MF900 With FCC ID: SRQ-MF900 Hardware Version: HO2 Software Version: BD_UROSMF900V1.0.0B04 Issued Date: 2015-07-01 Note:The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No.52, HuayuanNorth Road, Haidian District, Beijing, P. R. China 100191. Tel: +86(0)10-62304633-2512, Fax: +86(0)10-62304633-2504 Email: [email protected]. www.chinattl.com TESTING CNAS L0570 No. I15Z41150-SRD05 Page2 of 81 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LATORATORY ......................................................................................................... 6 1.1. TESTING LOCATION .............................................................................................................. 6 1.2. PROJECT DATA ..................................................................................................................... 6 1.3. SIGNATURE .......................................................................................................................... 6 2. CLIENT INFORMATION .................................................................................................... 7 2.1. APPLICANT INFORMATION ..................................................................................................... 7 2.2. MANUFACTURER INFORMATION ............................................................................................. 7 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT(AE) ...................... 8 3.1. ABOUT EUT ......................................................................................................................... 8 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................................... 8 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................................... 8 3.4. GENERAL DESCRIPTION ....................................................................................................... 8 4. REFERENCE DOCUMENTS ............................................................................................ 9 4.1. DOCUMENTS SUPPLIED BY APPLICANT ................................................................................... 9 4.2. REFERENCE DOCUMENTS FOR TESTING ................................................................................ 9 5. LABORATORY ENVIRONMENT ...................................................................................... 9 6. SUMMARY OF TEST RESULTS ..................................................................................... 10 6.1. SUMMARY OF TEST RESULTS .............................................................................................. 10 6.2. STATEMENTS...................................................................................................................... 10 6.3. TEST CONDITIONS .............................................................................................................. 10 7. TEST EQUIPMENTS UTILIZED...................................................................................... 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 A.1. MEASUREMENT METHOD ....................................................................................................... 12 A.2. MAXIMUM PEAK OUTPUT POWER ........................................................................................... 13 A.2.1 DATA RATE SELECTION ......................................................................................................... 13 A.2.2. MAXIMUM PEAK OUTPUT POWER-CONDUCTED .................................................................... 14 A.2.3. MAXIMUM AVERAGE OUTPUT POWER-CONDUCTED .............................................................. 15 A.3. PEAK POWER SPECTRAL DENSITY ......................................................................................... 16 A.4. OCCUPIED 6DB BANDWIDTH .................................................................................................. 17 FIG. 1 OCCUPIED 6DB BANDWIDTH (802.11A, CH 149) ............................................................. 18 FIG. 2 OCCUPIED 6DB BANDWIDTH (802.11A, CH 157) ............................................................. 18 FIG. 3 OCCUPIED 6DB BANDWIDTH (802.11A, CH 165) ............................................................. 19 FIG. 4 OCCUPIED 6DB BANDWIDTH (802.11N-HT20, CH 149) ................................................... 19 FIG. 5 OCCUPIED 6DB BANDWIDTH (802.11N-HT20, CH 157) ................................................... 20 FIG. 6 OCCUPIED 6DB BANDWIDTH (802.11N-HT20, CH 165) ................................................... 20 FIG. 7 OCCUPIED 6DB BANDWIDTH (802.11N-HT40, CH 151) ................................................... 21 FIG. 8 OCCUPIED 6DB BANDWIDTH (802.11N-HT40, CH 159) ................................................... 21 No. I15Z41150-SRD05 Page3 of 81 ©Copyright. All rights reserved by CTTL. A.5. TRANSMITTER SPURIOUS EMISSION ....................................................................................... 22 A.5.1 TRANSMITTER SPURIOUS EMISSION - CONDUCTED ............................................................... 22 FIG. 9 CONDUCTED SPURIOUS EMISSION (802.11A, CH149, 30 MHZ-1 GHZ) ............................ 24 FIG. 10 CONDUCTED SPURIOUS EMISSION (802.11A, CH149, 1 GHZ -12 GHZ) ........................... 25 FIG. 11 CONDUCTED SPURIOUS EMISSION (802.11A, CH149, 12 GHZ-25 GHZ) .......................... 25 FIG. 12 CONDUCTED SPURIOUS EMISSION (802.11A, CH149, 25 GHZ-40 GHZ) ...............…

Text truncated - open the document above for the full version.

No. I15Z41150-SRD05 Page41 of 81 ©Copyright. All rights reserved by CTTL. Fig. 42 Conducted Spurious Emission (802.11n-HT20, Chain1, Ch165, 1 GHz -12 GHz) Fig. 43 Conducted Spurious Emission (802.11n-HT20, Chain1, Ch165, 12 GHz-25 GHz) No. I15Z41150-SRD05 Page42 of 81 ©Copyright. All rights reserved by CTTL. Fig. 44 Conducted Spurious Emission (802.11n-HT20, Chain1, Ch165, 25 GHz-40 GHz) A Offset 22.3 dB LVL Ref 10 dBmAtt 5 dB* 97 MHz/Start30 MHzStop1 GHz *RBW 100 kHz VBW 300 kHz SWT 100 ms 3DB 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -59.76 dBm 274.054487179 MHz D1 -27 dBm Date: 19.JUN.2015 18:33:48 Fig. 45 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch151, 30 MHz-1 GHz) No. I15Z41150-SRD05 Page43 of 81 ©Copyright. All rights reserved by CTTL. Fig. 46 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch151, 1 GHz -12 GHz) Fig. 47 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch151, 12 GHz-25 GHz) No. I15Z41150-SRD05 Page44 of 81 ©Copyright. All rights reserved by CTTL. Fig. 48 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch151, 25 GHz-40 GHz) A Offset 22.3 dB LVL Ref 10 dBmAtt 5 dB* 97 MHz/Start30 MHzStop1 GHz *RBW 100 kHz VBW 300 kHz SWT 100 ms 3DB 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -58.50 dBm 438.830128205 MHz D1 -27 dBm Date: 19.JUN.2015 18:34:18 Fig. 49 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch159, 30 MHz-1 GHz) No. I15Z41150-SRD05 Page45 of 81 ©Copyright. All rights reserved by CTTL. Fig. 50 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch159, 1 GHz -12 GHz) Fig. 51 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch159, 12 GHz-25 GHz) No. I15Z41150-SRD05 Page46 of 81 ©Copyright. All rights reserved by CTTL. Fig. 52 Conducted Spurious Emission (802.11n-HT40, Chain0,Ch159, 25 GHz-40 GHz) A Offset 22.3 dB LVL Ref 10 dBmAtt 5 dB* *RBW 100 kHz VBW 300 kHz SWT 100 ms Center515 MHzSpan970 MHz97 MHz/ 3DB 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -59.59 dBm 56.426282051 MHz D1 -27 dBm Date: 19.JUN.2015 18:38:11 Fig. 53 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch151, 30 MHz-1 GHz) No. I15Z41150-SRD05 Page47 of 81 ©Copyright. All rights reserved by CTTL. Fig. 54 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch151, 1 GHz -12 GHz) Fig. 55 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch151, 12 GHz-25 GHz) No. I15Z41150-SRD05 Page48 of 81 ©Copyright. All rights reserved by CTTL. Fig. 56 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch151, 25 GHz-40 GHz) A Offset 22.3 dB LVL Ref 10 dBmAtt 5 dB* *RBW 100 kHz VBW 300 kHz SWT 100 ms Center515 MHzSpan970 MHz97 MHz/ 3DB 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -59.81 dBm 852.323717949 MHz D1 -27 dBm Date: 19.JUN.2015 18:38:44 Fig. 57 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch159, 30 MHz-1 GHz) No. I15Z41150-SRD05 Page49 of 81 ©Copyright. All rights reserved by CTTL. Fig. 58 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch159, 1 GHz -12 GHz) Fig. 59 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch159, 12 GHz-25 GHz) No. I15Z41150-SRD05 Page50 of 81 ©Copyright. All rights reserved by CTTL. Fig. 60 Conducted Spurious Emission (802.11n-HT40, Chain1,Ch159, 25 GHz-40 GHz) No. I15Z41150-SRD05 Page51 of 81 ©Copyright. All rights reserved by CTTL. A.5.2 Transmitter Spurious Emission - Radiated Measurement Uncertainty: Frequency Range Uncertainty(dB) f ≤ 1GHz 3.9 f>1GHz 4.3 Measurement Results: 802.11a mode Mode Channel Frequency Range Test Results Conclusion 802.11a 149 1 GHz ~ 3 GHz Fig.61 P 3 GHz ~ 6 GHz Fig.62 P 6 GHz ~ 18 GHz Fig.63 P 157 30 MHz ~1 GHz Fig.64 P 1 GHz ~ 3 GHz Fig.65 P 3 GHz ~ 6 GHz Fig.66 P 6 GHz ~ 18 GHz Fig.67 P 18 GHz ~ 26.5 GHz Fig.68 P 26.5 GHz~ 40 GHz Fig.69 P 165 1 GHz ~ 3 GHz Fig.70 P 3 GHz ~ 6 GHz Fig.71 P 6 GHz ~ 18 GHz Fig.72 P 802.11n-HT20 mode Mode Channel Frequency Range Test Results Conclusion 802.11n (HT20) 149 1 GHz ~ 3 GHz Fig.73 P 3 GHz ~ 6 GHz Fig.74 P 6 GHz ~ 18 GHz Fig.75 P 157 30 MHz ~1 GHz Fig.76 P 1 GHz ~ 3 GHz Fig.77 P 3 GHz ~ 6 GHz Fig.78 P 6 GHz ~ 18 GHz Fig.79 P 18 GHz ~ 26.5 GHz Fig.80 P 26.5 GHz~ 40 GHz Fig.81 P 165 1 GHz ~ 3 GHz Fig.82 P 3 GHz ~ 6 GHz Fig.83 P 6 GHz ~ 18 GHz Fig.84 P No. I15Z41150-SRD05 Page52 of 81 ©Copyright. All rights reserved by CTTL. 802.11n-HT40 mode Mode Channel Frequency Range Test Results Conclusion 802.11n (HT40) 151 30 MHz ~1 GHz Fig.85 P 1 GHz ~ 3 GHz Fig.86 P 3 GHz ~ 6 GHz Fig.87 P 6 GHz ~ 18 GHz Fig.88 P 18 GHz ~ 26.5 GHz Fig.89 P 26.5 GHz~ 40 GHz Fig.90 P 159 1 GHz ~ 3 GHz Fig.91 P 3 GHz ~ 6 GHz Fig.92 P 6 GHz ~ 18 GHz Fig.93 P Conclusion: PASS Note: A "reference path loss" is established and the A Rpl is the attenuation of “reference path loss”, and including the gain of receive antenna, the gain of the preamplifier, the cable loss. P Mea is the field strength recorded from the instrument. 802.11a Ch149 Frequency(MHz) Result (dBuV/m) Cable Loss(dB) Antenna Factor P Mea (dBuV/m) Polarization 5723.672 70.6 -33.4 34.8 69.238 V 17779.200 56.3 -23.4 41.0 38.672 V 17866.800 56.2 -23.3 41.0 38.533 V 17656.200 55.9 -23.4 41.2 38.072 V 17919.000 55.9 -23.3 41.0 38.233 V 17506.800 55.6 -23.9 41.2 38.253 H Ch157 Frequency(MHz) Result (dBuV/m) Cable Loss(dB) Antenna Factor P Mea (dBuV/m) Polarization 17554.800 56.0 -23.9 41.2 38.653 V 17997.000 55.9 -23.0 41.0 37.947 V 17949.000 55.8 -23.3 41.0 38.133 H 17641.200 55.8 -23.4 41.2 37.972 V 17189.400 55.6 -24.2 41.4 38.385 H 17911.200 55.6 -23.3 41.0 37.933 V No. I15Z41150-SRD05 Page53 of 81 ©Copyright. All rights reserved by CTTL. Ch165 Frequency(MHz) Result (dBuV/m) Cable Loss(dB) Antenna Factor P Mea (dBuV/m) Polarization 5850.000 58.1 -33.7 34.9 56.865 H 17860.800 56.9 -23.3 41.0 39.233 H 17612.400 56.3 -23.9 41.2 38.953 V 17069.400 56.1 -24.6 41.4 39.315 V 17010.600 56.1 -24.6 41.4 39.315 H 17866.200 56.0 -23.3 41.0 38.333 H 802.11n-HT20 Ch149 Frequency(MHz) Result (dBuV/m) Cable Loss(dB) Antenna Factor P Mea (dBuV/m) Polarization 5724.096 69.3 -33.4 34.8…

Text truncated - open the document above for the full version.

No. I15Z41150-SRD05 Page61 of 81 ©Copyright. All rights reserved by CTTL. 20 30 40 50 60 70 80 90 100 3 3.5 4 4.5 5 5.5 6 Leve l i n dB 礦 /m F re q u e n c y in G H z R E - 3 G H z -6 G H z F C C P a rt 1 5 P K F C C P a rt 1 5 A V Fig. 74 Radiated Spurious Emission (802.11n-HT20, Ch149, 3 GHz-6 GHz) 20 25 30 35 40 45 50 55 60 65 70 75 80 6 8 10 12 14 16 18 Leve l i n dB 礦 /m F re q u e n c y in G H z R E - 6 G H z -1 8 G H z Fig. 75 Radiated Spurious Emission (802.11n-HT20, Ch149, 6 GHz-18 GHz) No. I15Z41150-SRD05 Page62 of 81 ©Copyright. All rights reserved by CTTL. 0 5 10 15 20 25 30 35 40 45 30 M 5060 80100 M20 030 040 050 0 80 01G Leve l i n dB 礦 /m F re q u e n c y in H z N o rma l R E _ 3 0 M -1 G H z _ 1 0 m F C C P A R T 1 5 _ Q P _ 1 0 m Fig. 76 Radiated Spurious Emission (802.11n-HT20, Ch157, 30 MHz-1 GHz) 20 25 30 35 40 45 50 55 60 65 70 75 80 100 0 150 0 20 00 25 00 30 00 Leve l i n dB 礦 /m F re q u e n c y in M H z R E - 1 G H z -3 G H z F C C P a rt 1 5 P K F C C P a rt 1 5 A V Fig. 77 Radiated Spurious Emission (802.11n-HT20, Ch157, 1 GHz-3 GHz) No. I15Z41150-SRD05 Page63 of 81 ©Copyright. All rights reserved by CTTL. 20 30 40 50 60 70 80 90 100 3 3.5 4 4.5 5 5.5 6 Leve l i n dB 礦 /m F re q u e n c y in G H z R E - 3 G H z -6 G H z F C C P a rt 1 5 P K F C C P a rt 1 5 A V Fig. 78 Radiated Spurious Emission (802.11n-HT20, Ch157, 3 GHz-6 GHz) 20 25 30 35 40 45 50 55 60 65 70 75 80 6 8 10 12 14 16 18 Leve l i n dB 礦 /m F re q u e n c y in G H z R E - 6 G H z -1 8 G H z Fig. 79 Radiated Spurious Emission (802.11n-HT20, Ch157, 6 GHz-18 GHz) No. I15Z41150-SRD05 Page64 of 81 ©Copyright. All rights reserved by CTTL. 30 35 40 45 50 55 60 65 70 75 18 19 20 21 22 23 24 25 2626 .5 Leve l i n dB 礦 /m F re q u e n c y in G H z N o rma l R E _ 1 8 G -2 6 . 5 G H z F C C P A R T 1 5 _ P K F C C P A R T 1 5 _ A V G Fig. 80 Radiated Spurious Emission (802.11n-HT20, Ch157, 18 GHz-26.5 GHz) 30 35 40 45 50 55 60 65 70 75 80 85 90 26 .5 28 30 32 34 36 38 40 Leve l i n dB 礦 /m F re q u e n c y in G H z N o rma l R E _ 2 6 . 5 G -4 0 G H z F C C P A R T 1 5 _ P K _ 1 m F C C P A R T 1 5 _ A V G _ 1 m Fig. 81 Radiated emission: 802.11n, (802.11n-HT20, Ch157, 26.5 GHz - 40 GHz) No. I15Z41150-SRD05 Page65 of 81 ©Copyright. All rights reserved by CTTL. 20 25 30 35 40 45 50 55 60 65 70 75 80 100 0 150 0 20 00 25 00 30 00 Leve l i n dB 礦 /m F re q u e n c y in M H z R E - 1 G H z -3 G H z F C C P a rt 1 5 P K F C C P a rt 1 5 A V Fig. 82 Radiated Spurious Emission (802.11n-HT20, Ch165, 1 GHz-3 GHz) 20 30 40 50 60 70 80 90 100 3 3.5 4 4.5 5 5.5 6 Leve l i n dB 礦 /m F re q u e n c y in G H z R E - 3 G H z -6 G H z F C C P a rt 1 5 P K F C C P a rt 1 5 A V Fig. 83 Radiated Spurious Emission (802.11n-HT20, Ch165, 3 GHz-6 GHz) No. I15Z41150-SRD05 Page66 of 81 ©Copyright. All rights reserved by CTTL. 20 25 30 35 40 45 50 55 60 65 70 75 80 6 8 10 12 14 16 18 Leve l i n dB 礦 /m F re q u e n c y in G H z R E - 6 G H z -1 8 G H z Fig. 84 Radiated Spurious Emission (802.11n-HT20, Ch165, 6 GHz-18 GHz) 0 5 10 15 20 25 30 35 40 45 30 M 5060 80100 M20 030 040 050…

Text truncated - open the document above for the full version.
