SRQ-MF993CLTE UFi (LTE, WCDMA, WIFI)

MF993C User Manual IC ID:5200E-MF993C FCC ID:SRQ-MF993C LEGAL INFORMATION Copyright © 2021 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice. This manual has been designed with the utmost care to ensure the accuracy of its content. However, all statements, information and recommendations contained therein do not constitute a warranty of any kind, either expressed or implied. Contents Getting Started ................................................................. 1 Introduction .............................................................................................. 1 Installing the Battery ................................................................................ 2 Installing the nano-SIM Card .................................................................... 2 Charging Your Device .............................................................................. 3 Powering On/Off Your Device .................................................................. 4 Locking/Unlocking the Screen .................................................................. 4 Touch Screen and Icons .......................................................................... 5 Connection Scenario ................................................................................ 6 Connecting to the MF993C ............................................. 7 Connecting via Wi-Fi ................................................................................ 7 Using the Wi-Fi Protected Setup (WPS) ................................................... 7 Connecting via a USB Type-C Cable ....................................................... 8 Configuring Your PC (Verifying IP Address and DNS) ............................. 9 Accessing the LTE Hotspot Configuration Web Page ............................ 10 Navigating the LTE Hotspot Configuration Web Pages ........................................................................................ 13 Phonebook and Text Messaging .................................. 15 Managing the Phonebook ...................................................................... 15 Managing Text Messages ...................................................................... 16 Managing Data Usage ................................................... 18 Access Controls ............................................................ 19 Managing Settings ......................................................... 20 Cellular Settings ..................................................................................... 20 Wi-Fi Settings......................................................................................... 21 Touch Screen Settings ........................................................................... 23 Advanced Settings ................................................................................. 24 1 For Your Safety .............................................................. 25 To the User ............................................................................................ 25 Battery Safety ........................................................................................ 27 Limited Warranty .................................................................................... 28 Limitation of Liability ............................................................................... 29 Radio Frequency (RF) Exposure ............................................................ 29 FCC Compliance .................................................................................... 30 IC Notice ................................................................................................ 31 IC Radiation Exposure Statement .......................................................... 31 Troubleshooting ............................................................ 33 2 Getting Started Introduction ZTE MF993C is a 4G LTE mobile hotspot, which works on the 4G and 3G networks to provide you data service via a USB cable or Wi-Fi ® . The following figure shows the appearance of the device. It is only for your reference. The actual device may be different. 1 Power button Press and hold for about 3 seconds to power on or off. Press to turn on or off the touch screen. 2 Touch screen Control the functions and settings of your device. 3 nano-SIM card tray Pop out the tray with the eject tool to install the nano-SIM card. 4 Charging/USB Type-C jack Charge the device or connect to the USB port of a computer to provide Internet service to it. 1 Installing the Battery Power off the MF993C before removing or replacing the battery. 1. Open the back cover from the slot at one of its corner. 2. Insert the battery, making sure the connectors align. 3. Replace the back cover. Installing the nano-SIM Card The nano-SIM card can be installed or removed while the MF993C is turned on. WARNING! To avoid damage to the device, do not use any other kind of SIM cards, or any non-standard nano-SIM card cut from a SIM card. You can get a standard nano-SIM card from your service provider. 1. Insert the tip of the tray eject tool into the hole on the nano-SIM card tray. 2 2. Pull out the card tray and place the nano-SIM card on the tray, as shown. Carefully slide the tray back into place. Charging Your Device You can charge your device by using the USB Type-C cable or adapter. Please charge your device for more than two hours when you use it the first time or when you haven’t used it for a long time. • Use the USB Type-C cable to connect your device and PC directly. 3 • Use the adapter and the USB Type-C cable to connect an AC power outlet and your devi…

Text truncated - open the document above for the full version.

ZTE Corporation. ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Authorization Letter FCC ID: SRQ-MF993C Date: 2021-1-6 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_centerTesting Center (SRTC) to act on our behalf, as our agent, in the followingmatters related to the FCC approval of our product: Product Name: LTE uFi Product Model: MF993C FCC ID: SRQ-MF993C Report submittal, related correspondence, the signing of all documents relatingto these matters, and any other lawful activity necessary to obtain suchcertification. Any act carried out by The State Radio_monitoring_center TestingCenter (SRTC) within the scope of this authorization shall have the sameeffects as our own. This authorization shall expire 2 months from original date. If you have anyquestion regarding the authorization, please don’t hesitate to contact with me. Thank you. Sincerely, ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

ZTE Corporation. ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: LTE uFi Product Model: MF993C FCC ID: SRQ-MF993C The following information should be held confidential: All Schematics/block diagrams/BOM All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

COMPANY NAME Company Address Tel: ZTE Corporation +86-755-26770000 PHOENIX TESTLAB GmbH Date: 7 January 2021 Product Certification Königswinkel 10 D 32825 Blomberg Subject: Declaration Operating Channel Limitation Product Name: LTE uFi Product Model: MF993C FCC ID: SRQ-MF993C To Whom it may concern, The operating channels in 802.11 b/g/n mode for the device marketed to the US/Canada are firmware limited to channel 1 ~ 11 (2412 ~ 2462 MHz). The end-user has no possibility to select any other operating channels. If you have any questions, please feel free to contact me. Thank you. Sincerely, Certification Manager Company Name : ZTE Corporation Address: No. 55, Hi-tech Road South, Shenzhen, P.R.China Tel: +86-755-26770000

UNII Declaration Letter We have declared below featured for FCC equipment authorization, device FCC ID: SRQ-MF993C (1) DFS Device -- Master, Client with Radar detection capability , Client without radar detection capability, N/A (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 2412 – 2462 MHz Yes, No Yes, No Yes, No Yes, No 2422 – 2452 MHz Yes, No Yes, No Yes, No Yes, No 5745 – 5825 MHz Yes, No Yes, No Yes, No Yes, No 5755 – 5795 MHz Yes, No Yes, No Yes, No Yes, No 5180 – 5240 MHz Yes, No Yes, No Yes, No Yes, No 5190 – 5230 MHz Yes, No Yes, No Yes, No Yes, No 5260 – 5320 MHz Yes, No Yes, No Yes, No Yes, No 5270 – 5310 MHz Yes, No Yes, No Yes, No Yes, No 5500 – 5700 MHz Yes, No Yes, No Yes, No Yes, No 5510 – 5670 MHz Yes, No Yes, No Yes, No Yes, No (3) Country code selection ability - Yes , No If no, pls explain how was implemented : use Microsoft network utility (4) Meet 15.202 requirement - Yes , No , pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply , No Apply , (If apply , pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) Applicant: ZTE Corporation Address: ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Signature: January 22，2021 Name:Gong Yu Job Title: Certification Manager Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 20.06.2011 Datum: 00.00.00 Seite 1 von 1

External Photos IC ID: 5200E-MF993C 1 / 13 External Photos IC ID: 5200E-MF993C 2 / 13 External Photos IC ID: 5200E-MF993C 3 / 13 External Photos IC ID: 5200E-MF993C 4 / 13 External Photos IC ID: 5200E-MF993C 5 / 13 External Photos IC ID: 5200E-MF993C 6 / 13 External Photos IC ID: 5200E-MF993C 7 / 13 External Photos IC ID: 5200E-MF993C 8 / 13 External Photos IC ID: 5200E-MF993C 9 / 13 External Photos IC ID: 5200E-MF993C 10 / 13 External Photos IC ID: 5200E-MF993C 11 / 13 External Photos IC ID: 5200E-MF993C 12 / 13 External Photos IC ID: 5200E-MF993C 13 / 13

75#亚银PET； MF993 ZX656.96JA-01/42 Fabriqué en Chine Model:MF993C IMEI:XXXXXXXXXXXXXXX S/N:XXXXXXXXXXXX Made in China IC:5200E-MF993C SKU: XXXXXXXX H/W:MF993CHW1.0 FCC ID:SRQ-MF993C WLAN SSID 1KEY1XXXXXXXXXX WLAN SSID 2KEY2XXXXXXXXXX Device Manager Website http://192.168.0.1 Password:XXXXXXXX

秘密▲ < 以上所有信息均为中兴通讯股份有限公司所有，不得外传 > 第 1 页 标贴位置

In ternal Photos IC ID: 5200E-MF993C 1 / 8 In ternal Photos IC ID: 5200E-MF993C 2 / 8 In ternal Photos IC ID: 5200E-MF993C 3 / 8 In ternal Photos IC ID: 5200E-MF993C 4 / 8 In ternal Photos IC ID: 5200E-MF993C 5 / 8 In ternal Photos IC ID: 5200E-MF993C 6 / 8 In ternal Photos IC ID: 5200E-MF993C 7 / 8 In ternal Photos IC ID: 5200E-MF993C 8 / 8

No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 156 of 191 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 ANNEX A – TEST PLOTS System check 750MHz Communication System: UID 0, CW (0) Frequency: 750 MHz; Duty cycle:1:1 Medium parameters used: f = 750 MHz; σ = 0.89 S/m; ε r = 43.56; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: • Probe: EX3DV4 - SN3708; ConvF(9.75, 9.75, 9.75); Calibrated: 2020/10/30 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), • Electronics: DAE4 Sn720; Calibrated: 2020/9/30 • Phantom: Twin-SAM 1659; Type: QD 000 P40 CD; Serial: 1659 • Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7373) System Performance Check at Frequencies 750MHz/d=15mm, Pin=250 mW, dist=3.0mm (ES-Probe)/Area Scan (8x15x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.31 W/kg System Performance Check at Frequencies 750MHz/d=15mm, Pin=250 mW, dist=3.0mm (ES-Probe)/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 41.00 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 3.23 W/kg SAR(1 g) = 2.19 W/kg; SAR(10 g) = 1.40 W/kg Maximum value of SAR (measured) = 2.48 W/kg SRTC performed system check by using 250mw at antenna port No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 157 of 191 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 System check 835MHz Communication System: UID 0, CW (0); Frequency: 835 MHz Duty cycle:1:1 Medium parameters used (interpolated): f = 835 MHz; σ = 0.92 S/m; ε r = 40.41 ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN3708; ConvF(9.39, 9.39, 9.39); Calibrated: 2020/10/30 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), • Electronics: DAE4 Sn720; Calibrated: 2020/9/30 • Phantom: Twin-SAM 1659; Type: QD 000 P40 CD; Serial: 1659 • Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7373) Configuration 835/835/Area Scan (8x15x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.72 W/kg Configuration 835/835/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51.67 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 3.56 W/kg SAR(1 g) = 2.26 W/kg; SAR(10 g) = 1.61 W/kg Maximum value of SAR (measured) = 2.76 W/kg SRTC performed system check by using 250mw at antenna port No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 158 of 191 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 System check 1800MHz Communication System: UID 0, CW (0); Frequency: 1800 MHz; Duty cycle:1:1 Medium parameters used: f = 1800 MHz; σ = 1.33 S/m; ε r = 41.24; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN3708; ConvF(8.27, 8.27, 8.27); Calibrated: 2020/10/30 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), • Electronics: DAE4 Sn720; Calibrated: 2020/9/30 • Phantom: Twin-SAM 1659; Type: QD 000 P40 CD; Serial: 1659 • Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7373) Configuration 1800/1800/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.31 W/kg Configuration 1800/1800/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 76.76 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 17.5 W/kg SAR(1 g) = 10.08 W/kg; SAR(10 g) = 4.95 W/kg Maximum value of SAR (measured) = 12.1 W/kg SRTC performed system check by using 250mw at antenna port No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 159 of 191 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 System check 2000MHz Communication System: UID 0, CW (0); Frequency: 2000 MHz; Duty cycle:1:1 Medium parameters used: f = 2000 MHz; σ = 1.38 S/m; ε r = 41.65; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN3708; ConvF(7.94, 7.94, 7.94); Calibrated: 2020/10/30 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), • Electronics: DAE4 Sn720; Calibrated: 2020/9/30 • Phantom: Twin-SAM 1659; Type: QD 000 P40 CD; Serial: 1659 • Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7373) Configuration 2000/2000/Area Scan (7x10x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 11.40 W/kg Configuration 2000/2000/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 76.22 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 18.7 W/kg SAR(1 g) = 10.59 W/kg; SAR(10 g) = 4.99 W/kg Maximum value of SAR (measured) = 12.9 W/kg SRTC performed system check by using 250mw at antenna port No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 160 of 191 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 System check 2450MHz Communication System: UID 0, CW (0); Frequency: 2450 MHz; Duty cycle:1:1 Medium parameters used: f = 2450 MHz; σ = 1.87 S/m; ε r = 39.02; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN3708; ConvF(7.48, 7.48, 7.48); Calibrated: 2020/10/30 • Sensor-Surface: 1.4mm (Mechanical Surface Detection), • Electronics: DAE4 Sn720; Calibrated: 2020/9/30 • Phantom: Twin-SAM 1659; Type: QD 000 P40 CD; Serial: 1659 • Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7373) System Performance Check at Frequencies 2450 MHz/2450/Area Scan (8x11x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 21.2 W/kg System Performance Check at Frequencies 2450 MHz/2450/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 108.3 V/m; Power Drift = 0.18 dB Peak SAR (extrapolated) = 28.2 W/kg SAR(1 g) = 13.37 W/kg; SAR(10 g) = 6.34 W/kg Maximum value of SAR (measured) = …

Text truncated - open the document above for the full version.

Certificate Number: 5055.02 TEST REPORT FOR SAR TESTING Report No.: SRTC2020-9004(F)-20112401 (H) Product Name: LTE uFi Product Model: MF993C Applicant: ZTE Corporation Manufacturer: ZTE Corporation Specification: Part 2.1093 IEEE Std 1528 KDB Procedures FCC ID: SRQ-MF993C The State Radio_monitoring_center Testing Center (SRTC) 15th Building, No.30 Shixing Street, Shijingshan District, Beijing, P.R. China Tel: 86-10-57996183 Fax: 86-10-57996388 No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_center Testing Center (SRTC) Page number: 1 of 191 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 Contents 1. GENERAL INFORMATION ......................................................................................................................................... 2 1.1 NOTES OF THE TEST REPORT ......................................................................................................................................... 2 1.2 INFORMATION ABOUT THE TESTING LABORATORY ........................................................................................................ 2 1.3 APPLICANT’S DETAILS ................................................................................................................................................... 2 1.4 MANUFACTURER’S DETAILS .......................................................................................................................................... 2 1.5 TEST ENVIRONMENT ...................................................................................................................................................... 3 2. DESCRIPTION OF THE DEVICE UNDER TEST ..................................................................................................... 3 2.1 FINAL EQUIPMENT BUILD STATUS ................................................................................................................................ 3 2.2 SUPPORT EQUIPMENT .................................................................................................................................................... 4 3. REFERENCE SPECIFICATION.................................................................................................................................. 5 4. TEST CONDITIONS ...................................................................................................................................................... 6 4.1 PICTURE TO DEMONSTRATE THE REQUIRED LIQUID DEPTH .......................................................................................... 6 4.2 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER ..................................................................................................... 6 4.3 SAR MEASUREMENT SET-UP ........................................................................................................................................ 6 4.4 PHANTOMS ..................................................................................................................................................................... 7 4.5 TISSUE SIMULANTS ........................................................................................................................................................ 7 4.6 DESCRIPTION OF THE TEST PROCEDURE ........................................................................................................ 8 5 RESULT SUMMARY ................................................................................................................................................... 11 6 TEST RESULT .............................................................................................................................................................. 14 6.1 MANUFACTURING TOLERANCE .................................................................................................................................... 14 6.2 WCDMA MEASUREMENT RESULT .............................................................................................................................. 28 6.3 LTE MEASUREMENT RESULT ...................................................................................................................................... 38 6.4 WI-FI MEASUREMENT RESULT .................................................................................................................................. 110 6.5 STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ........................................................................................ 112 6.6 RF EXPOSURE CONDITIONS ....................................................................................................................................... 114 6.7 SYSTEM CHECKING .................................................................................................................................................... 116 6.8 SAR TEST RESULT ................................................................................................................................................ 118 6.9 SAR MEASUREMENT VARIABILITY ............................................................................................................................ 147 6.10 SIMULTANEOUS TRANSMISSION SAR ANALYSIS ................................................................................................... 148 7 MEASUREMENT UNCERTAINTY .......................................................................................................................... 149 8 TEST EQUIPMENTS ................................................................................................................................................. 152 ANNEX – TEST PLOTS ............................................................................................................................................... 155 No.: SRTC2020-9004(F)-20112401(H) FCC ID: SRQ-MF993C The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 191 Tel: 86-10-57…

Text truncated - open the document above for the full version.

Certificate Number: 5055.02 TEST REPORT FOR WCDMA TESTING Report No.: SRTC2020-9004(F)-20112401(B) Product Name: LTE uFi Product Model: MF993C Applicant: ZTE Corporation Manufacturer: ZTE Corporation Specification: FCC Part 24E, Part 22H, Part 2, Part 27 (2019) FCC ID: SRQ-MF993C The State Radio_monitoring_center Testing Center (SRTC) 15th Building, No.30 Shixing Street, Shijingshan District, Beijing, P.R.China Tel: 86-10-57996183 Fax: 86-10-57996388 No.: SRTC2020-9004(F)-20112401(B) FCC ID: SRQ-MF993C The State Radio_monitoring_center Testing Center (SRTC) Page number: 1 of 112 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 CONTENTS 1. GENERAL INFORMATION .................................................................................................................... 2 1.1 Notes of the test report .................................................................................................................. 2 1.2 Information about the testing laboratory ........................................................................................ 2 1.3 Applicant’s details ......................................................................................................................... 2 1.4 Manufacturer’s details ................................................................................................................... 2 1.5 Test Environment .......................................................................................................................... 3 2 DESCRIPTION OF THE DEVICE UNDER TEST .................................................................................... 4 2.1Final Equipment Build Status ......................................................................................................... 4 2.2 Support Equipment........................................................................................................................ 5 2.3 Summary table. ............................................................................................................................. 5 3 REFERENCE SPECIFICATION .............................................................................................................. 6 4 KEY TO NOTES AND RESULT CODES ................................................................................................ 6 5 RESULT SUMMARY .............................................................................................................................. 7 6 TEST RESULT ........................................................................................................................................ 8 6.1 RF Power Output ................................................................................................................... 8 6.2 Effective Radiated Power and Effective Isotropic Radiated Power ........................................ 9 6.3 Occupied Bandwidth ............................................................................................................ 10 6.4 Emission Bandwidth ............................................................................................................. 11 6.5 Spurious Emissions at antenna terminal .............................................................................. 12 6.6 Band Edges Compliance ...................................................................................................... 13 6.7 Frequency Stability ............................................................................................................... 14 6.8 Radiated Spurious Emissions .............................................................................................. 15 6.9 Peak-Average Ratio ............................................................................................................. 17 7 MEASUREMENT UNCERTAINTIES .................................................................................................... 18 8 TEST EQUIPMENTS ............................................................................................................................ 19 APPENDIX A – TEST DATA OF CONDUCTED EMISSION .................................................................... 20 APPENDIX B – TEST DATA OF RADIATED EMISSION ........................................................................ 78 No.: SRTC2020-9004(F)-20112401(B) FCC ID: SRQ-MF993C The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 112 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 1. GENERAL INFORMATION 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC).The test results relate only to individual items of the samples which have been tested. The certification and accreditation identifiers used in this report shall not be applicable to the tested or calibrated samples thereof. The manufacturer shall not mark the tested samples or items (or a separate part of the item) with the identifiers of certification and accreditation to mis…

Text truncated - open the document above for the full version.
