SRQ-V765MMobile phone

第1页 User Manual The manual is applicable for the ZTE V765M mobile phone. Copyright © 2013 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice. Google, Android, Android Market, Google Mail are trademarks of Google, Inc. Other trademarks and trade names are the property of their respective owners. Third-party Software Statement When you install the software from a third-party, the phone might be restarted repeatedly or the software might not be used normally due to the incompatibility of the software itself. It is not the fault of the phone itself. Version 1.0 in july 2013 -1- 第1页 Using your phone Thanks for choosing the ZTE V765M, It’s a WCDMA Digital Mobile Phone, which will refer to as ‘phone’ from now on. Powered by Android TM , thne phone supports 3G high-speed Internet access, which brings you brand new experiences. Don’t worry if the pictures we use to demostrate your phone’s functions look a little different from what you see on the screen. It’s the functions that matter. For more information about how to use your phone, refer to the User manual on the phone. To read the user manual, do as follows: 1. Hold the Power key to turn on your phone. 2. Touch the icon to open the All Apps screen, select Settings > About phone > User manual. -2- Before getting started Inserting and removing the SIM 1. Switch off your phone and disconnect any external power. 2. Remove the back cover and then the battery. 3. Hold your SIM on the cut corner, and slide it face down into the card holder. 4. Insert the battery. 5. Replace the back cover. Inserting a memory card 1. Remove the back cover. 2. Push tightly until the card is installed in the correct position and replace the back cover. -3- 第3页 Using the battery Inserting the battery 1. Open the battery cover on the back of your phone. 2. Align the battery's contact points with those of the phone and gently press the battery down into place. 3. Replace the battery cover clicking it back into position. Removing the battery 1. Switch off your phone. 2. Open the battery cover. 3. Lift the battery up and out of your phone. -4- Charging the battery The battery is not fully charged when you unpack it for the first time. Please exhaust the capacity of the battery before you recharge it for the first time.To ensure the battery is always in its best condition, please charge the battery 8 hours for the first time and recharge it later at least 2 hours each time. 1. Connect the charger to the phone, and insert the charger to the standard power socket. 2. Please disconnect the charger from the power socket after the charging is completed. Tips:  To charge the battery, you can also connect the phone to the PC through the USB cable.  During charging, the phone and charger may normally become hot. -5- 第5页 Touch screen Back key Home k Menu key Earpiec Camer a Power key Volume keys Headset Front camera Microphon Speak er USB t Getting to know your phone -6- Descriptions of Keys Keys Functions Menu key Touch it to open a menu with items that affect the current screen or application. Home key Touch it to open the home screen. If you’re viewing the left or right extended home screen, Press it to open the central home screen. Back key Touch it to open the previous screen you were working in. If the onscreen keyboard is open, touch it to close the keyboard. Power key Press it to turn on/off the display. Long press it to open a menu with options for Airplane mode, for Silent mode, for Vibration mode, and for powering off and for rebooting the phone. Volume keys Adjust the volume. Long press it to quickly adjust the ring tone volume to maximum or minimum. -7- 第7页 Onscreen icons Icon s Descriptions Icon s Descriptions Signal strength Full battery Charging Missed calls You have an unread message. Music playing New calendar reminder Airplane mode Connected to a PC Alarm clock on Vibration mode Silent mode Wi-Fi function on Bluetooth function is on -8- Power on/off Powering on Long press the Power key until the power-on animation appears. Powering off Long press the Power key to display the phone options and select Power off. -9- 第9页 Basic Operation Screen control You can control your phone through a series of operations on the screen.  Touch: you can touch the items on the screen to select them, to open the applications, or using the keyboard to input characters.  Swipe or slide: Quickly move your finger across the surface of the screen, without pausing when you first touch (so you don't drag something instead).  Touch & hold: you can touch & hold som e item s to get the item ’s available menu.  Drag: you can drag some items on the screen to realize some operations.  Switch between landscape mode and portrait mode: you can switch to the landscape mode by rotating your phone. The landscape mode is only valid under some interfaces, such as text input interface, message viewing interface, etc.  Pinch: In some apps (such as Maps, Browser, and Gallery), you can zoom in and out by placing two fingers on the screen at once and pinching them together (to zoom out) or spreading them apart (to zoom in). -10- Home screen Arrange & work with apps To see all your apps, touch the All Apps Icon on any Home screen. After opening the All Apps, press an icon to enter the corresponding application. Touch the Back key to return to the previous screen. Touch the Home key to return to the home screen. Favorites tray Status bar Shows the signal strength, battery status, etc. Notification bar Drag the notification bar down from the top of the screen to open the notifications panel. -11- 第11页 From All Apps, you can: • Explore your widgets: Touch the widgets …

Text truncated - open the document above for the full version.

Ad-HocCountry Code Cover Letter We, ZTE Corporation, declare that this EUT (FCC ID: SRQ-V765M) doesn’t have Ad Hoc Mode function on “non-US/Canada frequencies”. In addition, the frequency selection feature is disabled by firmware for device marketed to the US/Canada. For DTS part of this device, only channel 1~11 will be used in North America. Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Zhang Min ZTE Corporation Certification Manager Te l : +86-21-68897541 Fax: +86-21-50801070 Email: [email protected]

ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R.China Tel: +86-755-86360379 ; Fax: +86-755-86360298 Date: September 11, 2013 Power of Attorney To whom it may concern, Please be notified that I, Zhang Min, have designated Ivy.Zhu in Shenzhen Morlab Communications Technology Co., Ltd. and David Gong in ZTE CORPORATION as the persons being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Ivy Zhu in Shenzhen Morlab Communications Technology Co., Ltd., and David Gong in ZTE CORPORATION on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: SRQ-V765M If you have any acknowledgement and response, please send it to Shenzhen Morlab Communications Technology Co., Ltd. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Contact Person: Min Zhang Company: ZTE CORPORATION TEL: +86-21-68897541 FAX: +86-21-68891070 E-mail: [email protected]

Rev. 1/1/03 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R.China Tel: +86-755-86360379 ; Fax: +86-755-86360298 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: SRQ-V765M Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Parts List Operation Description Tune Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Yours Sincerely, Zhang Min ZTE product approval manager

External Photos 1. EUT full view with accessories 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view

FCC label and label location 1. Label 2. Label location SRQ-V765M WCDMA Digital Mobile Phone Label location

In ternal Photos 1. EUT uncover view 2. Mainboard front view with shielding 3. Mainboard rear view with shielding 4. Mainboard front view without shielding 5. Mainboard rear view without shielding 6. GSM/WCDMA chip view 7. CPU chip view 8. BT/WIFI chip view 9. GSM/WCDMA antenna view 10. BT/WIFI antenna view 11. GPS antenna view

SZ13080159S01 Page 2 of 150 DIRECTORY 1. TESTING LABORATORY ......................................................................................................... 4 1.1. Identification of the Responsible Testing Location .............................................................. 4 1.2. Accreditation Certificate ........................................................................................................ 4 1.3. List of Test Equipments .......................................................................................................... 4 2. TECHNICAL INFORMATION ............................................................................................... 5 2.1. Identification of Applicant ..................................................................................................... 5 2.2. Identification of Manufacturer .............................................................................................. 5 2.3. Equipment Under Test (EUT) ................................................................................................ 5 2.3.1. Photographs of the EUT .................................................................................................. 5 2.3.2. Identification of all used EUT ......................................................................................... 6 2.4. Applied Reference Documents ............................................................................................... 6 2.5. Device Category and SAR Limits .......................................................................................... 6 2.6. Test Environment/Conditions ................................................................................................ 7 3. SPECIFIC ABSORPTION RATE (SAR) ................................................................................ 8 3.1. Introduction ............................................................................................................................. 8 3.2. SAR Definition......................................................................................................................... 8 4. SAR MEASUREMENT SETUP ............................................................................................... 9 4.1. The Measurement System ...................................................................................................... 9 4.2. Probe ........................................................................................................................................ 9 4.3. Probe Calibration Process .................................................................................................... 11 4.3.1 Dosimetric Assessment Procedure ........................................................................................ 11 4.3.2 Free Space Assessment Procedure ........................................................................................ 11 4.3.2 Temperature Assessment Procedure..................................................................................... 11 4.4. Phantom ................................................................................................................................. 12 4.5. Device Holder ........................................................................................................................ 12 5. TISSUE SIMULATING LIQUIDS ......................................................................................... 13 6. UNCERTAINTY ASSESSMENT ........................................................................................... 15 6.1. UNCERTAINTY EVALUATION FOR EUT SAR TEST ................................................. 15 6.2. UNCERTAINTY FOR SYSTEM PERFORMANCE CHECK ........................................ 16 7. SAR MEASUREMENT EVALUATION ............................................................................... 18 7.1. System Setup .......................................................................................................................... 18 SZ13080159S01 Page 3 of 150 7.2. Validation Results .................................................................................................................. 19 8. OPERATIONAL CONDITIONS DURING TEST ................................................................ 20 8.1. Information on the testing .................................................................................................... 20 8.2. Body-worn Configurations ................................................................................................... 21 8.3. Measurement procedure ....................................................................................................... 21 8.4. Description of interpolation/extrapolation scheme ............................................................ 21 9. MEASUREMENT OF CONDUCTED PEAK OUTPUT POWER ..................................... 23 10. TEST RESULTS LIST .............................................................................................................. 26 11. HOTSPOT MODE EVALUATION PROCEDURE .............................................................. 30 12. MULTIPLE TRANSMITTERS EVALUATION ................................................................ 31 ANNEX A GRAPH TEST RESULTS ............................................................................................ 34 Change History Issue Date Reason for change 1.0 Sep. 13, 2013 First edition 1.0 Sep. 17, 2013 Second edition SZ13080159S01 Page 4 of 150 1. Testing Laboratory 1.1. Identification of the Responsible Testing Location Name: Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory Address: FL.3, Building A, FeiYang Science Park, No.8 LongChang Road, Block 67, BaoAn District, ShenZhen, GuangDong Province, P. R. China 518101 1.2. Accreditation Certificate Accredited Testing Laboratory: No. CNAS L3572 1.3. List of Test Equipments No. Instrument Type Cal. Date Cal. Due 1 PC Dell (Pe…

Text truncated - open the document above for the full version.

SZ13080159W03 Page 2 of 36 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 6 2.1. Antenna requirement ................................................................................................................. 6 2.2. Peak Output Power.................................................................................................................... 6 2.3. Average power .......................................................................................................................... 9 2.4. 6dB & 99%Bandwidth ............................................................................................................ 10 2.5. Conducted Spurious Emissions and Band Edge ..................................................................... 13 2.6. Power spectral density (PSD) ................................................................................................. 17 2.7. Restricted Frequency Bands.................................................................................................... 20 2.8. Conducted Emission ............................................................................................................... 24 2.9. Radiated Emission................................................................................................................... 27 2.10. RF exposure evaluation ........................................................................................................... 36 Change History Issue Date Reason for change 1.0 September 12, 2013 First edition SZ13080159W03 Page 3 of 36 1. General Information 1.1. EUT Description EUT Type ............................. : WCDMA Digital Mobile Phone Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : V765M_V1BMB_B Software Version .................. : Applicant .............................. : Manufacturer ........................ : V765M_Z7_6SOOI14300F010 ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R. China ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R. China Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (40 channels, at intervals of 2MHz); Modulation Type .................. : GFSK Antenna Type ........................ : PIFA Antenna Antenna Gain ........................ : -2.0dBi Note 1: The EUT is WCDMA Digital Mobile Phone, it contain Bluetooth 4.0 LE Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth 4.0 LE is F(MHz)=2402+2*n (0<=n<=39). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 19 (2440MHz) and 39 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. SZ13080159W03 Page 4 of 36 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC Certification: No. Identity Document Title 1 47 CFR Part 15 (10-1-12 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section in CFR 47 Description Result 1 15.203 Antenna Requirement PA S S 2 15.247(b) Peak Output Power PASS 3 15.247(b) Average power PASS 4 15.247(a) 6dB Bandwidth PASS 5 15.247(a) 99% Bandwidth PASS 8 15.247(d) Conducted Spurious Emission and Band Edge PA S S 9 15.247(d) Restricted Frequency Bands PASS 10 15.207 Conducted Emission PASS 11 15.209 15.247(d) Radiated Emission PASS 12 15.247(e) Power spectral density (PSD) PASS 10 15.247(i). §1.1307&2.1093 RF exposure evaluation PASS The tests of Conducted Emission and Radiated Emission were performed according to the method of measurements prescribed in ANSI C63.4 2009. These RF tests were performed according to the method of measurements prescribed in KDB558074 D01 V03 (04/09/2013). SZ13080159W03 Page 5 of 36 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at FL.1, Building A, FeiYang Science Park, Block 67, BaoAn District, Shenzhen, 518101 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.10 2009, ANSI C63.4 2009 and CISPR Publication 22; the FCC registration number is 695796. The IC registration number is 7183A-2. 1.3.2. Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 SZ13080159W03 Page 6 of 36 2. 47 CFR Part 15C Requirements 2.1. Antenna requirement 2.1.1. Applicable Standard According to FCC 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentiona…

Text truncated - open the document above for the full version.

SZ13080159W04 Page 2 of 77 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 6 2.1. Antenna requirement ................................................................................................................. 6 2.2. Peak Output Power.................................................................................................................... 6 2.3. Bandwidth ................................................................................................................................. 8 2.4. Conducted Spurious Emissions ............................................................................................... 17 2.5. Power spectral density (PSD) ................................................................................................. 29 2.6. Restricted Frequency Bands.................................................................................................... 38 2.7. Conducted Emission ............................................................................................................... 50 2.8. Radiated Emission................................................................................................................... 53 2.9. RF exposure evaluation ........................................................................................................... 77 Change History Issue Date Reason for change 1.0 September 12, 2013 First edition SZ13080159W04 Page 3 of 77 1. General Information 1.1. EUT Description EUT Type ............................. : WCDMA Digital Mobile Phone Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : V765M_V1BMB_B Software Version .................. : Applicant .............................. : Manufacturer ........................ : V765M_Z7_6SOOI14300F010 ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R. China ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R. China Frequency Range .................. : 802.11b/g/n-20MHz: 2.412GHz - 2.462GHz 802.11n-40MHz: 2.422GHz- 2.452GHz Channel Number................... : 802.11b/g/n-20MHz: 11 802.11n-40MHz: 7 Modulation Type .................. : DSSS (802.11b), OFDM (802.11g/n) Antenna Type ........................ : PIFA Antenna Antenna Gain ........................ : -2.0dBi Note 1: The EUT is WCDMA Digital Mobile Phone, it contains WIFI Module operating at 2.4GHz ISM band; it supports 802.11b, 802.11g, 802.11n and they are all tested in this report. Note 2: For 802.11b/g/n-20MHz, the frequencies allocated is F (MHz) =2412+5*(n-1) (1<=n<=11). The lowest, middle, highest channel numbers of the EUT used and tested in this report are separately 1 (2412MHz), 6 (2437MHz) and 11 (2462MHz). For 802.11n-40MHz, the frequencies allocated is F (MHz) =2412+5*(n-1) (3<=n<=9). The lowest, middle, highest channel numbers of the EUT used and tested in this report are separately 3 (2422MHz), 6 (2437MHz) and 9 (2452MHz). Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 4: The antenna connector of EUT is designed with permanent attachment and no consideration of replacement. SZ13080159W04 Page 4 of 77 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Wi-Fi, 2.4GHz ISM band radiators) for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 15 (10-1-12 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.203 Antenna Requirement PA S S 2 15.247(b) Peak Output Power PASS 3 15.247(a) Bandwidth PASS 4 15.247(d) Conducted Spurious Emission PASS 5 15.247(d) Restricted Frequency Bands PASS 6 15.207 Conducted Emission PASS 7 15.209 ,15.247(d) Radiated Emission PASS 8 15.247(e) Power spectral density (PSD) PASS 9 15.247(i), 1.1307&2.1093 RF exposure evaluation PA S S The tests of Conducted Emission and Radiated Emission were performed according to the method of measurements prescribed in ANSI C63.4 2009. These RF tests were performed according to the method of measurements prescribed in KDB558074 D01 V03 (04/09/2013). SZ13080159W04 Page 5 of 77 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at FL.1, Building A, FeiYang Science Park, Block 67, BaoAn District, Shenzhen, 518101 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.10 2009, ANSI C63.4 2009 and CISPR Publication 22; the FCC registration number is 695796. 1.3.2. Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 SZ13080159W04 Page 6 of 77 2. 47 CFR Part 15C Requirements 2.1. Antenna requirement 2.1.1. Applicable Standard According to FCC 15.203, an intentional r…

Text truncated - open the document above for the full version.

FCC ID: SRQ- V765M 1 EUT Right Head Touch Cheek Position 2 EUT Right Head Tilt15 Position FCC ID: SRQ- V765M 3 EUT Left Head Touch Cheek Position 4 EUT Left Head Tilt15 Position FCC ID: SRQ- V765M 5 Side Position with earphone 6 Side Position 10mm 10mm FCC ID: SRQ- V765M 7. Edge A 8. Edge B 10mm 10mm FCC ID: SRQ- V765M 9. Edge C Liquid Level Photo Head Liquid Liquid depth: 15.1cm 10mm FCC ID: SRQ- V765M Liquid Level Photo Body Liquid Liquid depth :15.5cm

Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (9KHz-30MHz) 4. Radiated emission (30MHz-1GHz) 5. Radiated emission (above 1GHz) 6. Conducted emission antenna’s port
