SRQ-VM6200Automotive Multi-function MiFi Terminal

VM6200 Product Safety and Warranty Information ZTEUSA.COM 1 Copyright © 2015 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Version No. : R1.0 Manual No. : 8090182200MT Table of Contents Regulatory and Safety Information .................................... 3 To the Owner ..................................................................................... 3 Using Your Device ............................................................................ 3 Radio Frequency (RF) Energy ....................................................... 4 FCC Compliance ............................................................................... 5 Warranty ................................................................................................. 6 Limited Warranty ............................................................................. 6 Limitation of Liability ..................................................................... 7 32 Regulatory and Safety Information To the Owner • Operating your device may interfere with medical devices such as hearing aids and pacemakers. Please always keep them more than 8 inches (20 cm) away from such medical devices when they are powered on. Stop using your device if necessary. Consult a physician or the manufacturer of the medical device before using your device. • Be aware of the usage limitation when using your device at places such as oil warehouses or chemical factories, where there are explosive gases or explosive products being processed. Stop using your device if required. • The use of electronic transmitting devices is forbidden in aircrafts, at gas stations, and in hospitals. Please observe and obey all warning signs and stop using your device in these conditions. • Store your device out of the reach of little children. Your device may cause injury if used as a toy. • Do not touch the metallic parts of your device. Otherwise, it will affect your device’s performance. Using Your Device • Please use original accessories or accessories that are authorized. Using any unauthorized accessories may affect your device’s performance and violate related national regulations about telecom terminals. 54 • Avoid using your device near or inside metallic structures or establishments that can emit electromagnetic waves. Otherwise, it may influence signal reception. • Your device is not waterproof. Please keep it dry and store it in a shady and cool place. • Do not use your device immediately after a sudden temperature change, which will produce dew inside and outside your device. Do not use the device until it becomes dry. • Handle your device carefully. Do not drop, bend, or strike it. Otherwise, your device will be damaged. • Do not allow non-professionals to dismantle the device. Only qualified technicians can undertake repair work. • An operating temperature range of -4°F ~ 158°F (-20°C ~ +70°C) and humidity range of 5% ~ 95% are recommended. Radio Frequency (RF) Energy This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government: FOR MOBILE DEVICE USAGE (>20 cm/low power) Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. FCC ID: SRQ-VM6200 FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accor- dance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. 76 • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Note: The country code selection is for non-U.S. models only and is not available to all U.S. models. Per FCC regulation, all Wi-Fi® products marketed in the U.S. must be fixed to U.S. operation channels only. Warranty Limited Warranty This warranty does not apply to defects or errors in the Product caused by: i. Reasonable abrasion. ii. End User’s failure to follow ZTE’s installation, operation, or maintenance instructions or procedures. iii. End User’s mishandling, misuse, negligence…

Text truncated - open the document above for the full version.

ZTE Corporation ZTE Plaza, Keji Road South Shenzhen, China Date: July 1, 2015 Declaration We, ZTE Corporation, declare that the device, FCC ID: SRQ-VM6200, Model Name: VM6200, does not support any non-US channels in all the operational mode(s). All non-US frequencies, US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours, ______________________________ Min Zhang / Certification Manager ZTE Corporation Tel: +86-21-68897541 Fax: +86-21-50801070 E-mail: [email protected]

ZTE Corporation ZTE Plaza, Keji Road South Shenzhen, China Date: July 1, 2015 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: SRQ-VM6200 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.
Schematic Diagram
Block Diagram
Parts List
Tune-up Procedure
Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, ___ Min Zhang / Certification Manager ZTE Corporation Tel: +86-21-68897541 Fax: +86-21-50801070 E-mail: [email protected]

ZTE Corporation ZTE Plaza, Keji Road South Shenzhen, China Date: July 1, 2015 Power of Attorney To whom it may concern, Please be notified that I, Min Zhang, have designated Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan on the matters relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. As defined in 47 CFR Ch. 1.2002 (b), we further certify that neither the applicant nor any party to this application is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: SRQ-VM6200 If you have any acknowledgement and response, please send it to Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan directly. Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, ___ Min Zhang / Certification Manager ZTE Corporation Tel: +86-21-68897541 Fax: +86-21-50801070 E-mail: [email protected]

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 3 Report Version 1 Reference No.: 150420N007 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 3 Report Version 1 Reference No.: 150420N007 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 3 Report Version 1 Reference No.: 150420N007

Label Location FCC ID: SRQ-VM6200 Label Location

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 4 Report Version 1 Reference No.: 150420N007 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 4 Report Version 1 Reference No.: 150420N007 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 4 Report Version 1 Reference No.: 150420N007 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 4 Report Version 1 Reference No.: 150420N007

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page1 of 19 Report Version 1 Test Report No.: SA150420N007 RF EXPOSURE REPORT Product: Automotive Multi-function MiFi Terminal Model Name: VM6200 FCC ID: SRQ-VM6200 Applicant: ZTE Corporation Address: ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R. China Manufacturer: ZTE Corporation Address: ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, Shenzhen, Guangdong, P.R. China Prepared by: Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch Lab Location: No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China TEL: +86 769 8593 5656 FAX: +86 769 8593 1080 E-MAIL: [email protected] Report No.: SA150420N007 Received Date: Apr. 20, 2015 Test Date: Apr. 21, 2015 ~ May 28, 2015 Issued Date: Jul. 03, 2015 Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by A2LA or any government agencies. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page2 of 19 Report Version 1 Test Report No.: SA150420N007 TABLE OF CONTENTS RF EXPOSURE REPORT ............................................................................................. 1 RELEASE CONTROL RECORD .................................................................................. 3 1 CERTIFICATION ..................................................................................................... 4 2 GENERAL INFORMATION ..................................................................................... 5 2.1 GENERAL DESCRIPTION OF EUT ................................................................. 5 3 RF EXPOSURE ....................................................................................................... 6 3.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) .......................... 6 3.2 MPE CALCULATION FORMULA ...................................................................... 6 3.3 CLASSIFICATION ............................................................................................ 6 3.4 CONDUCTED POWER .................................................................................... 7 3.5 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................. 19 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page3 of 19 Report Version 1 Test Report No.: SA150420N007 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA150420N007 Original release Jul. 03, 2015 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page4 of 19 Report Version 1 Test Report No.: SA150420N007 1 CERTIFICATION PRODUCT: Automotive Multi-function MiFi Terminal BRAND NAME: ZTE MODEL NAME: VM6200 APPLICANT: ZTE Corporation TESTED: Apr. 21, 2015 ~ May 28, 2015 TEST SAMPLE: Production Unit STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment has been tested by Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Jul. 03, 2015 (Yuqiang Yin / Engineer) APPROVED BY : , DATE: Jul. 03, 2015 ( Glyn He / Supervisor ) Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page5 of 19 Report Version 1 Test Report No.: SA150420N007 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Automotive Multi-function MiFi Terminal MODEL NAME VM6200 NOMINAL VOLTAGE 14Vdc (adapter or host equipment) OPERATING TEMPERATURE RANGE -10 ~ 55°C MODULATION TECHNOLOGY DSSS, OFDM MODULATION TYPE WLAN CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM WCDMA BPSK/QP…

Text truncated - open the document above for the full version.

Dear Sir, As to the FCC Comments 234896 on June/02/2016, “We are sorry to inform you that this device cannot be classified as MPE since there is no guarantee that the required distance can be maintained for all models of car. Therefore, it is under audit. However, please refer to KDB 447498 D01, section 4.3.1, "Standalone SAR test exclusion considerations" and apply the formula under 4.3.1 (a). The distance to be used in the formula will be 50mm. You must consider all frequencies intended to be used.” We have response as below: 1. In our perspective and the usage, this product seems not be able to defined as portable product, since it need to be powered by vehicle electricity and cannot be transmit when hand carry as below photo described. As you see in the picture, the top side is the interface of electricity. 2. As to considering the risk that end user may close to this device, here is a curiosity about why home wireless AP router ( w/o battery) did not need to test SAR since it has external monopole and user has big chance to be close it? 3. In order to evaluate the RF Exposure to clarify dispute, KDB 447498 formula was leveraged with distance 50mm to evaluate the SAR test threshold. The calculated results shows positive to SAR test. Thus, a pre-test of BODY SAR was made and test distance of 10mm was proposed. 4. Please advise if the test with distance 10mm is acceptable or not. Then full test will going on under your approval. Sincerely, William Chung Technical Manager Mobile Certification Bureau Veritas CPS E&E Business Line
