SRQ-ZM8620LTE Wireless Data Terminal

Hardware Development Guide of Module Product Welink Your Smart Version 2.3, 2014-04-15 ZM8620_V2 Hardware Development Guide of Module Product All Rights reserved, No Spreading abroad without Permission of ZTEWelink I 错误！未找到 用源。 ZM8620_V2 Legal Information By receiving the document from Shenzhen ZTEWelink Technology Co., Ltd (shortly referred to as ZTEWelink), you are deemed to have agreed to the following terms. If you don‘t agree to the following terms, please stop using the document. Copyright © 2013 Shenzhen ZTEWelink Technology Co., Ltd. All rights reserved. The document contains ZTEWelink‘s proprietary information. Without the prior written permission of ZTEWelink, no entity or individual is allowed to reproduce, transfer, distribute, use and disclose this document or any image, table, data or other information contained in this document. As the wholly-owned subsidiaries of ZTE, ZTEWelink is the professional company engaging in R&D, manufacture and sales of wireless module product. is the registered trademark of ZTEWelink. The name and logo of ZTEWelink are ZTEWelink‘s trademark or registered trademark. Meanwhile, ZTEWelink is a wholly-owned subsidiary of ZTE Corporation, and is granted to use ZTE Corporation‘s registered trademark. The other products or company names mentioned in this document are the trademark or registered trademark of their respective owner. Without the prior written permission of ZTEWelink or the third-party oblige, no one is allowed to read this document. The product meets the design requirements of environmental protection and personal security. The storage, use or disposal of products should abide by the product manual, relevant contract or the laws and regulations of relevant country. ZTEWelink reserves the right to make modifications on the product described in this document without prior notice, and keeps the right to revise or retrieve the document any time. If you have any question about the manual, please consult the company or its distributors promptly. Hardware Development Guide of Module Product All Rights reserved, No Spreading abroad without Permission of ZTEWelink II 错误！未找到 用源。 ZM8620_V2 Applicability Table Product ZM8620_V2EUD ZM8620_V2LAT Hardware Development Guide of Module Product All Rights reserved, No Spreading abroad without Permission of ZTEWelink III 错误！未找到 用源。 ZM8620_V2 Revision History Version Date Description V1.0 2013-02-22 First published V2.0 2013-03-20 Delete the part of 4.8 in the former version, and change the header, front cover, legal information and footer. V2.1 2013-08-16 1. Modify the legal information 2. Modify the part of 7.1.1 3. Modify the format of footer and header 4. Modify the figure of PIN Configuration Diagram 5. Add the figure of PIN Distribution Diagram 6. Add chapter 8 of Debugging Environment and Method 7. Modify chapter 7 of Antenna 2013-09-30 8. Modify the typical voltage of power supply to 3.8V 9. Add the support of WinCE OS 10. Update the Product Material Object Picture of Figure 2-1 11. Modify the support of GPRS Class B in Table 2-1 12. Modify the Specification of SIM interface in Table 2-1 13. Modify the pin NO. of USIM in Table 4-4 14. Modify the Figure of (U)SIM Card Signal Connection Circuit 15. Modify the support of MMS, RAS, phonebook, network lock, and USSD in Table 2-1 16. Add the Figure 4-4 of Module Serial Port & AP Application Processor 17. Add the Table 4-6 of Definition of UART Signal 18. Add 4.10 of W_DISABLE_N Signal 19. Modify chapter 5.3 of Resetting Flow 20. Delete the part of Power_on/Power_off in chapter 5.2 and chapter 4.8 21. Add Table 5-3 of Power-on/Resetting Period 22. Complete and modify Table 4-2 of PIN Interface Definition 2013-10-11 23. Add chapter 4.8 of SPI Interface 24. Add chapter 6 of Related Test & Testing Standard 2013-12-12 25. Add Contact Information 26. Modify Power-on/Resetting Period in chapter 5 27. Add the document in table List for Supported& Related Documents 28. Modify LTE TDD in Technical Standard to DL 50Mbps / UL 25Mbps (10MHz) in Table 2-1 29. Modify the RxDiv Band in Table 2-1 30. Add the power consumption in the mode of UMTS/LTE in Hardware Development Guide of Module Product All Rights reserved, No Spreading abroad without Permission of ZTEWelink IV 错误！未找到 用源。 ZM8620_V2 Version Date Description chapter 5.1 31. Modify the antenna interface to MHF-A13 of I-PEX V2.2 2014-03-06 1. Modify the typical voltage of power supply to 3.3V，and the range to 3.1-3.6V 2. Modify the the Profile Dimensions in Figure 8-1 and The PCB layout is shown in the Figure 8-2. 3. Modify the antenna interface to U.FL-R-SMT-1(80)(HRS)/ ECT818000071(ECT) 4. Modify the pins in chapter 4.1 5. Modify the chapter 4.6 of UART interface 6. Update the format and template of the document 7. Update the legal information of this document 8. Update the Product Material Object Picture in Figure 2-1 V2.3 2014-04-15 1. Update the document as the hardware development guide of module ZM8620_V2 2. Add the difference between the module ZM8620_V2 and ZM8620. 3. Update the bands information of two variants ZM8620_V2EUD and ZM8620_V2LAT 4. Modify the Figure in chapter of UART electric feature 5. Add the chapter of 10 and 11 6. Update the Overview of Major Technical Parameters in Table 2–2 Note: Because of ZTEWelink ZM8620_V2 module is still under revision to improve its performances, the present document could be subject to revisions without notice. Hardware Development Guide of Module Product All Rights reserved, No Spreading abroad without Permission of ZTEWelink V 错误！未找到 用源。 ZM8620_V2 Contact Information Post 9/F, Tower A, Hans Innovation Mansion, North Ring Rd., No.9018, Hi-Tech Industrial Park, Nanshan District, Shenzhen, P.R.China. Web www.ztewelink.com Phone +86-755-86360200-8679 E-Mail [email protected] Note: Consult our website for up-to-date product descriptions, documentation, application notes, firmware upgrades, troubleshooting tips, and press releases Besides, ZTEWelink provides various…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Date:Oct.16, 2014 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name SRQ-ZM8620 ZM8620 For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (Signed) Name:Min Zhang Company: ZTE CORPORATION Address: ZTE Plaza, Keji Road South, Shenzhen, China Phone: +86-18616587757 Fax: +86-21-50801070 Email:[email protected]

Company Letter head IC/FCC Modular Approval Statement 1 Receiver Federal Communication Commission Equipment Authorization Devision, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Certification and Engineering Bureau Industry Canada Spectrum Engineering Branch 3701 Carling Avenue, Building 94 Ottawa, Ontario K2H 8S2 Subject: Modular Approval Statement Date: Oct 20, 2014 FCC Certification Number: SRQ-ZM8620 Model Name/Number: ZM8620 TO WHOM IT MAY CONCERN Pursuant to Paragraphs RSS-GEN Issue 3 December 2010 Item 3.2.2 and CFR § 15.212, we herewith declare for our module. Modular approval requirement Yes No * (a) The radio elements must have the radio frequency circuitry be shielded. Physical/discrete and tuning capacitors may be located external to the shield, but must be on the module assembly. YES *Please provide a detailed explanation if the answer is “No.”: (b) The module shall have buffered modulation/data input(s) (if such inputs are provided) to ensure that the module will comply with the requirements set out in the applicable RSS standard under conditions of excessive data rates or over-modulation. YES *Please provide a detailed explanation if the answer is “No.”: (c) The module shall have its own power supply regulation on the module. This is to ensure that the module will comply with the requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module. YES *Please provide a detailed explanation if the answer is “No.”: (d) The module shall comply with the provisions for external power amplifiers and antennas detailed in this standard. The equipment certification submission shall contain a detailed description of the configuration of all antennas that will be used with the module. YES *Please provide a detailed explanation if the answer is “No.”: (e) The module shall be tested for compliance with the applicable standard in a stand-alone configuration, i.e. the module must not be inside another device during testing. Yes Company Letter head IC/FCC Modular Approval Statement 2 *Please provide a detailed explanation if the answer is “No.”: (f) The module shall comply with the Category I equipment labeling requirements and CFR § 15.212(a)(1)(vi). Yes *Please provide a detailed explanation if the answer is “No.”: (g) The module shall comply with applicable RSS-102 exposure requirements and any applicable FCC RF exposure requirement which are based on the intended use/configurations. Yes *Please provide a detailed explanation if the answer is “No.”: Only applicable for IC certification: (h) Is the modular device for an Industry Canada licensed exempt service? *Please provide a detailed explanation if the answer is “No.”: Only applicable for FCC certification: (i) The modular transmitter complies with all applicable FCC rules. Instructions for maintaining compliance are given in the user instructions. Yes If you have any questions, please feel free to contact us at the address shown below Best Regards, ______________________ Name of person authorized to sign Company name: ZTE CORPORATION Address :ZTE Plaza, Keji Road South, Shenzhen, China Phone No:. +86-18616587757

External Photos of The EUT

Internal Photos of The EUT

No.I14N00332-EMF Page 1 of 10 ©Copyright. All rights reserved by TMC Beijing. EMF TEST REPORT No. I14N01065-EMF For ZTE CORPORATION LTE Wireless Data Terminal ZM8620 FCC ID: SRQ-ZM8620 With Hardware Version: ZM8620-1.0.0 Software Version: BD_WELINK_ZM8620V1.0.0B06 Issued Date: 2014-10-20 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of MIIT No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2079, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com. No. I14N01065-EMF Page 2 of 10 Revision Version Report Number Revision Date Memo I14Z01065-SAR 00 2014-10-20 Initial creation of test report No. I14N01065-EMF Page 3 of 10 TABLE OF CONTENT TEST LABORATORY ...................................................................................................................... 4 1.1 TESTING LOCATION ........................................................................................................................................ 4 1.2 TESTING ENVIRONMENT ................................................................................................................................. 4 1.3 PROJECT DATA ............................................................................................................................................... 4 1.4 SIGNATURE .............................................................................................................................................. 4 2 CLIENT INFORMATION ............................................................................................................... 5 2.1 APPLICANT INFORMATION .............................................................................................................................. 5 2.2 MANUFACTURER INFORMATION ..................................................................................................................... 5 3 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................ 6 3.1 ABOUT EUT ................................................................................................................................................... 6 3.2 INTERNAL IDENTIFICATION OF EUT ............................................................................................................... 6 3.3 INTERNAL IDENTIFICATION OF AE .................................................................................................................. 6 4 REFERENCE DOCUMENTS ........................................................................................................ 7 4.1 APPLICABLE LIMIT REGULATIONS .................................................................................................................. 7 4.2 APPLICABLE MEASUREMENT STANDARDS ...................................................................................................... 7 5 RF EXPOSURE LIMIT .................................................................................................................. 7 6 FRIIS FORMULA .......................................................................................................................... 7 7 CLASSIFICATION......................................................................................................................... 8 8 TEST RESULTS ............................................................................................................................ 8 No. I14N01065-EMF Page 5 of 10 2 Client Information 2.1 Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Shenzhen, China City: Shenzhen Post Code: 518000 Country: China Contact: Min Zhang Email: [email protected] Telephone: +86 18616587757 Fax: +86 021 50801070 2.2 Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Shenzhen, China City: Shenzhen Post Code: 518000 Country: China Contact: Min Zhang Email: [email protected] Telephone: +86 18616587757 Fax: +86 021 50801070 No. I14N01065-EMF Page 6 of 10 3 Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1 About EUT Description: LTE Wireless Data Terminal Model name: ZM8620 Marketing name: ZM8620 Operating mode(s): GSM850/1900,WCDMA 850/1700/1900, LTE Band 1/2/4/5/7/8/12/17/38 Tested Tx Frequency: 824.2 – 848.8 MHz (GSM 850) 1850.2 – 1909.8 MHz (GSM 1900) 826.4 - 846.6 MHz (WCDMA 850) 1710 – 1755 MHz(WCDMA 1700) 1852.4 - 1908MHz (WCDMA 1900) 1850-1910/1930-1990 (LTE Band 2) 1710-1755/2110-2155 (LTE Band 4) 824-849/869-894 (LTE Band 5) 2500-2570/2620-2690 (LTE Band 7) 1850-1910/1930-1990 (LTE Band 12) 704-716/734-746 (LTE Band 17) GPRS class 10 GPRS capability Class: A EGPRS Multislot Class: 12 Test device Production information: Production unit Device type: Portable device Antenna type: external antenna Accessories/Body-worn configurations: / Form factor: 5.1cm × 3.0cm 3.2 Internal Identification of EUT EUT ID* SN or IMEI HW Version SW Version EUT1 / ZM8620-1.0.0 BD_WELINK_ZM8620V1.0.0B06 *EUT ID: is used to identify the test sample in the lab internally. 3.3 Internal Identification of AE AE ID* Description Model SN Manufacturer AE1 / / / / *AE ID: is used to identify the test sample in the lab internally. No. I14N01065-EMF Page 7 of 10 4 Reference Documents 4.1 Applicable Limit Regulations ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 4.2 Applicable Measurement Standards FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v05r01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310：Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091：Radiofrequency radiation exposure e…
