SRQ-ZTE7540N5G NR Multi model smart phone

1 ZTE 7540N Quick Start Guide 2 LEGAL INFORMATION Copyright © 2022 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. We offer self-service for our smart terminal device users. Please visit the ZTE official website (at www.ztedevices.com) for more information on user manual, self-service and supported product models. Information on the website takes precedence. Disclaimer ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized modifications of the software. Images and screenshots used in this guide may differ from the actual product. Content in this guide may differ from the actual product or software. Trademarks ZTE and the ZTE logos are trademarks of ZTE Corporation. Android™ is a trademark of Google LLC. The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by ZTE Corporation is under license. microSDXC Logo is a trademark of SD-3C, LLC. Other trademarks and trade names are those of their respective owners. 3 Getting to Know Your Phone Your phone supports 2.4 GHz and 5 GHz Wi-Fi. Front camera Touch screen Earpiece Volume key Power key/ Fingerprint sensor Charging/USB Type-C jack Headset jack Back cameras and flash Speaker Indicator light nano-SIM/ microSDXC card tray Proximity & light sensor 4 Setting Up Your Phone The nano-SIM card(s) can be installed or removed while the phone is turned on. WARNING! To avoid damage to the phone, do not use any other kind of SIM cards, or any non-standard nano-SIM card cut from a SIM card. You can get a standard nano-SIM card from your service provider. 1. Insert the tip of the tray eject tool into the hole on the card tray. CAUTION: Never replace the included tray eject tool with sharp objects. Ensure that the tray eject tool is perpendicular to the hole. Otherwise, the phone may be damaged. 5 2. Pull out the card tray. You can place a nano-SIM card on the right card slot, and place a nano-SIM card or a microSDXC card (optional) on the left card slot, as shown. Carefully slide the tray back into place. NOTE: The two card slots support 5G/4G/3G/2G networks. Charging the Phone Your phone’s battery should have enough power for the phone to turn on, find a signal, and make a few calls. You should fully charge the battery as soon as possible. WARNING! Use only ZTE-approved chargers and USB Type-C cables. The use of unapproved accessories could damage your phone or cause the battery to explode. WARNING! Do not remove the back cover. The battery is not removable. Removal may cause fire or explosion. 1. Connect the adapter to the charging jack. 6 2. Connect the charger to a standard AC power outlet. 3. Disconnect the charger when the battery is fully charged. NOTE: If the battery is extremely low, you may be unable to power on the phone even when it is being charged. In this case, try again after charging the phone for at least 20 minutes. Contact the customer service if you still cannot power on the phone after prolonged charging. Powering On/Off Your Phone Make sure the battery is charged before powering on.  Press and hold the Power key to turn on your phone.  To power off, press and hold the Power key to open the options menu, and touch > . NOTE: If the screen freezes or takes too long to respond, try pressing and holding the Power key for over 10 seconds to restart the phone. 7 Product Safety Information Don’t make or receive phone calls while driving. Never text while driving. Keep your phone at least 5 mm away from your body while making calls. Small parts may cause choking. Your phone can produce a loud sound. To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use. Avoid contact with anything magnetic. Keep away from pacemakers and other electronic medical devices. Turn off when asked to in hospitals and medical facilities. Turn off when told to on aircraft and at airports. Turn off when near explosive materials or liquids. Don’t use at gas stations. Your phone may produce a bright or flashing light. Don’t dispose of your phone in fire. Avoid extreme temperatures. Avoid contact with liquids. Keep your phone dry. Do not attempt to disassemble your phone. 8 Only use approved accessories. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible. Don’t rely on your phone as a primary device for emergency communications. Specific Absorption Rate (SAR) Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health. The guidelines use a unit of measurement known as Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg and the highest SAR value for this device when tested at the head was 1.169 W/kg*, and when tested at the body was 0.589 W/kg* with 15 mm distance. As mobile devices offer a range of functions, they can be used in other positions, such as on the body as described in the user manual**. As SAR is measured utilizing the device’s highest transmitting power, the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum power required to communicate with the network. * The tests are carried…

Text truncated - open the document above for the full version.

ZTE Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022/05/31 Subject; Request for Confidentiality FCC ID: SRQ-ZTE7540N To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM List Tune up procedure Software Security Info In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chaijue Ding Title: Test Manager

Letter of Authorization Company: ZTE Corporation Address: ZTE Plaza, #55 Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, China Product Name: 5G NR Multi model smart phone Model Number: ZTE 7540N We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Chaijue Ding Date: 2022/05/31 Title: Test Manager Signature of applicant:

Device label：PET 078761002408 078761003730 彩盒标贴彩盒标贴 60mm 078761000527 彩盒标贴 60mm 35mm ZTE Blade A72 5G Model : ZTE 7540N IMEI1: XXXXXXXXXXXXXXX IMEI2: XXXXXXXXXXXXXXX EAN: x xxxxxx xxxxxx The device is restricted to indoor use only when operating in the 5150 to 5250 MHz frequency range. Prolonged use of this music player at full volume may damage your hearing Made in China by ZTE Corporation 19mm 35mm ZTE Blade A72 5G Model : ZTE 7540N IMEI1: XXXXXXXXXXXXXXX IMEI2: XXXXXXXXXXXXXXX EAN: x xxxxxx xxxxxx The device is restricted to indoor use only when operating in the 5150 to 5250 MHz frequency range. Prolonged use of this music player at full volume may damage your hearing Made in China by ZTE Corporation master box label: Pallet label: CODE： Carton No.: ZTE Blade A72 5G Model : ZTE 7540N IMEI1：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX FCC ID : SRQ-ZTE7540N Made in China by ZTE Corporation Notes: Do not remove the rear cover. The battery is not removable. You may press and hold power button for over 10 seconds to force restart the device. Charge the battery for 20 minutes if the phone cannot be powered on the first time. X XXXXXX XXXXXX Weight:xxxxg Colour: XXXX Made in China by ZTE Corporation Weight: xxxkg IMEI1：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX IMEI1：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX EAN： IMEI1：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX IMEI1 ：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX ZTE Blade A72 5G Model : ZTE 7540N EAN： QTY: XX IMEI1：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX IMEI1：XXXXXXXXXXXXXXX IMEI2：XXXXXXXXXXXXXXX ZTE Blade A72 5G Model : ZTE 7540N Pallet ID:XXXXXXXXX XX/XXX X XXXXXX XXXXXX Made in China by ZTE Corporation Delivery Date/Time: DD.MM.YYYY QTY:XX Colour Colour UK(NI) UK(NI)

Ant0:LB TXR Ant7:MB TRX Ant5 Ant6:HB TRX:B7 Ant4:LB DIV: B7(TRX2)+DRX Ant2:WIFI Ant Ant3:MHB DIV Ant1:DRX2 Ant8:DRX2

秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第1页 General Technical Description Model: ZTE 7540N Date: 2022-01-27 Band: GSM/CDMA/WCDMA/LTE/SUB6G/ WLAN 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第2页 1. Scope This document is shown and provided the more detail information about the platform used in. The basic description for the Baseband and RF section are also included. 2. Detail Block Diagram Fig. 1 Detail Block Diagram The modem support the GSM/WCDMA/HSDPA/HSPA+/HSUPA/LTE/SUB6G. But this FCC project only can support LTE Band 7, CA 7C, 2.4G&5G WIFI, NFC, BT. 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第3页 More detailed Frequency information as following: A、UMTS Band：B1/B8 GSM Band: B3/B8 B、Max. transmitter power： UMTS 2100/900: Power Class 3 (+24dBm +1/-3dBm) LTE：B1/B3/B7/B8/B20/B28/B38:+23dBm(Power Class 3) C、WCDMA WCDMA PS: UL 384kbps/DL 384kbps； D、HSDPA/HSUPA/HSPA+ HSDPA: DL14.4Mb/s；HSUPA: UL 5.76Mb/s；HSPA+: DL21Mb/s；DC-HSPA+: DL 42Mb/s； E、LTE: DL 1600Mb/s UL 200Mb/s F、SUB6：n1/n3/n28/n78 3. Baseband Baseband architecture is based on highly integrated solution and comprise mainly 7 chips: MT6190M、RR88643-81 、 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第4页 RR98077-11、RR98028-21、MXD83K5A、HFQRXRKJB-512、 RR88920-21. Detailed function description of chips. MT6190M： MT6190M is a multi-mode multi-band highly integrated tansciever in 12 nm FinFET CMOS. Key Features:  Full multi-mode RF solution (GGE/C2K/WCDMA/TD-SCDMA/LTE/NR SA/NR NSA) Multi-band NR sub6G/LTE/WCDMA/TD-SCDMA/C2K/GGE 256 QAM UL/256 QAM DL (HSPA+/LTE) C2K/2G/3G/4G/5G co-banding Supports RxD  Direct conversion transmitter (NR/LTE/3G/8-PSK) and DFM for 2G GMSK Dedicated power detection circuits for power control over specific power range 2LB+2MHB+1MHB/CB TX0 output port 1LB+1MHB+2CB TX1_MIMO0 output port 1MHB+2CB TX1_MIMO1 output port  Hybrid direct-conversion(5G/4G/3G/C2K)/low-IF(GGE,DC-HS DPA)receiver 26 RX input ports Digital output interface 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第5页  External LNA at RxP and RxD are required  Supports 2G DRx and 3G/4G/5G TDD SAWless RX  Low supply current and operation directly from DC-DC converters  Supports RF calibration features for key RX and TX specifications (image rejection,LO feed-through,IIP2, DC offset,RC corner  Temperature measurement sub-system  LTE carrier aggregation Supports 2UL+3DL inter-band CA MAX.CCA BW up to 100MHz  Supports RX 2*2 MIMO for LB,4*4 for MHB/CB  Supports TX 2*2 MIMO for MHB/CB  NR carrier aggregation Supports 2UL+2DL inter-band CA Max.CCA BW up to 200 MHz  LTE+NR dual connectivity supports 2UL+3DL inter-band ENDC  Supports NSA/SA+LTE DR-DSDS  Supports Power Class 2 high-power UE(HPUE)in HB/CB 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第6页 Fig. 2 MT6190M functional block diagram and example application RR88643-81： RadRock RR88643-81 is a multimode multiband (MMMB) Power Amplifier Module (PAM) that supports 3G/4G/5G_N41 handsets and operates efficiently in CDMA, WCDMA, TD-SCDMA,and LTE modes. The module is fully programmable through a Mobile Industry Processor Interface (MIPI®). The PAM consists of a WCDMA / LTE block for low, mid, and high bands, a Multi-Function Control 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第7页 (MFC) block, and RF input/output ports internally matched to 50 Ω (reduces the number of external components). A CMOS integrated circuit provides the internal MFC interface and operation using standard MIPI controls. Varying the input power level provides output power control. VCC is adjusted using a DCDC converter to maximize efficiency for each power level and modulation type. Key features:  LTE Power Class 2 High Power User Equipment (HPUE)  5G N1/N3 Power Class 3 up to 30MHz Bandwidth with max 3.8V Vcc  Two T/R (RX) ports and 14 outputs  Industry-leading PAE for 3G/4G  Dual Low Band RF inputs, supporting separate transceiver outputs  Optimized for APT DCDC operation  Support MIPI RFFE  Compact Low Profile Package Dimension - 4.0 x 6.8 x 0.75 mm - 42-pad configuration 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第8页 Fig. 3 RR88643-81 functional block diagram RR98077-11： RadRock RR98077-11 is a highly integrated Sub-6GHz LPAMiD compliant to 5G-NR standards focused on Best-in-class 5G performance targeting advanced RF, including flagship/premium smartphones and data devices. The module consists of a N77 PA, N77 LNA, Filter, directional coupler and TRx Switch for TDD operation. The RR98077-11 supports Average Power Tracking (APT) Power Class 2 power targets at 3.4 Vcc. Key features: 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第9页 • Fully Baseband Agnostic Design • UHB S-PAD covering B42, B43, B48, n77, n78 • MIPI® v2.1 compliant 52 MHz RFFE bus • Two LNA cores • Support n77 receiving simultaneous in dual Rx path • Support Fast SRS Hopping timing requirements • ASM switch with two selectable ANT ports and 3 AUX ports for seamless SRS Hopping support • Switchable LAA input • Forward and Reverse Coupler • Full Power APT support without DPD - LTE Power Class 2 High Power User Equipment (HPUE) - Optimized for APT DCDC operation, ET compatible with VCC Capacitor Switch • MIPI v2.1 compliant 52 MHz RFFE bus • Support DFT-S-OFDM/CP-OFDM waveform up to 100 MHz • Support 2X2 UL-MIMO using two TX placements • Support Fast SRS Hopping timing requirements • Small, low profile package - 4.5 mm x 5.5 mm x 0.75 mm (Max.) - 42-pad configuration 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第10页 Fig. 4 RR98077-11 functional block diagram RR98028-21 The RR98028-21 is a highly integratedLNA filter module that enables users tosupport new 5G New Radio (NR) bands inthe 3.3 to 4.2 GHz frequency range. It utilizes the latest advanced SOI process technologies to achieve leading high-bandwidth, low noise figure (NF) LNA performance in a small package footprint.It also integrates all the required filtering to attenuate unwanted out-of-band blockers in adjacent and far-out frequency bands while maintaining very low insertion loss(IL) performance in the pass-band frequencies. 秘密▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> 第11页 The RR98028-21 is packaged in a small 2.8mm x 2.6mm x 0.…

Text truncated - open the document above for the full version.

Report No.: SET2022-04460 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 1 of 20 EMC TEST REPORT Report No.: SET2022-04460 Product Name: 5G NR Multi model smart phone FCC ID: SRQ-ZTE7540N Model No. : ZTE 7540N Applicant: ZTE CORPORATION. Address: ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park,Nanshan District,Shenzhen,Guangdong,P.R.China Dates of Testing: 2022.04.07-2022.04.22 Issued by: CCIC Southern Testing Co., Ltd. Lab Location: Electronic Testing Building, No. 43 Shahe Road, Xili Street, Nanshan District, Shenzhen, Guangdong, China. Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 20 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2022-04460 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 2 of 20 Test Report Product Name ...................... 5G NR Multi model smart phone Model No. ........................... ZTE 7540N Trade name ............................ ZTE Brand name ............................ ZTE Applicant .............................. ZTE CORPORATION Applicant Address ............... ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park,Nanshan District,Shenzhen,Guangdong,P.R.China Manufacturer ........................ ZTE CORPORATION Manufacturer Address ........ ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park,Nanshan District,Shenzhen,Guangdong,P.R.China Test Standards ..................... 47 CFR Part 15 Subpart B Test Result ........................... PASS Tested by ............................ Ruihong Xie Test Engineer 2022.04.22 Reviewed by ......................... Chris You Senior Engineer 2022.04.22 Approved by ........................ 2022.04.22 Shuangwen Zhang, Manager Report No.: SET2022-04460 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 3 of 20 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 4 1.1 EUT Description ......................................................................................................................... 4 1.2 Test Standards and Results ........................................................................................................ 5 1.3 Facilities and Accreditations ...................................................................................................... 6 1.3.1 Facilities .................................................................................................................................... 6 1.3.2 Test Environment Conditions .................................................................................................... 6 1.3.3 Measurement Uncertainty ......................................................................................................... 6 2. TEST CONDITIONS SETTING .............................................................................................. 7 2.1 Test Peripherals .......................................................................................................................... 7 2.2 Use of Software Checklist .......................................................................................................... 7 2.3 Test Mode .................................................................................................................................... 7 2.4 Test Setup and Equipments List ................................................................................................ 8 2.4.1 Conducted Emission ................................................................................................................. 8 2.4.2 Radiated Emission..................................................................................................................... 8 3. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 3.1 Conducted Emission ................................................................................................................. 11 3.1.1 Requirement ............................................................................................................................ 11 3.1.2 Test Description ...................................................................................................................... 11 3.1.3 Test Result ............................................................................................................................... 11 Radiated Emission............................................................................................................................... 14 3.1.4 Requirement ............................................................................................................................ 14 3.1.5 Test Description ...................................................................................................................... 14 3.1.6 Test Result ............................................................................................................................... 15 Change History Issue Date Reason for change 1.0 2022.04.22 First edition Report No.: SET2022-04460 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 4 of 20 1. GENERAL INFORMATION 1.1 EUT Description EUT Name .......................... .: 5G NR Multi model smart phone Trade Name.....................: ZTE Brand Name.....................: ZTE Hardware Version............ : zs9A Software Version .................. : MyOS11.0.1_7540N_VFPT Power supply ........................ : …
