SRQ-ZTE9030WCDMA/LTE Multi-mode Digital Mobile Phone with Bluetooth, WiFi and GSM

1 ZTE 9030 Quick Start Guide FCC ID:SRQ-ZTE9030 2 LEGAL INFORMATION Copyright © 2021 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. We offer self-service for our smart terminal device users. Please visit the ZTE official website (atwww.ztedevices.mx) for more information on self-service and supported product models. Information on the website takes precedence. Visit https://ztedevices.mx/soporte/ to download the user manual. Disclaimer ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized modifications of the software. Images and screenshots used in this guide may differ from the actual product. Content in this guide may differ from the actual product or software. Trademarks ZTE and the ZTE logos are trademarks of ZTE Corporation. Android™ is a trademark of Google LLC. The Bluetooth® word mark and logos are registeredtrademarks owned by the Bluetooth SIG, Inc. and any use of such marks by ZTE Corporation is under license. microSDXC Logo is a trademark of SD-3C, LLC. For DTS patents, see http://patents.dts.com. 3 Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together, DTS:X, the DTS:X logo, and DTS:X Ultra are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved. Other trademarks and trade names are those of their respective owners. Version No.: R1.0 Edition Time : February 25, 2021 4 Getting to Know Your Phone Front camera Touch screen Earpiece Volume key Power key/ Fingerprint Charging/USB Type-C jack Headset jack Back cameras and flash Speaker nano-SIM / microSDXC dt Proximity & light sensor 5 Setting Up Your Phone The nano-SIM card can be installed or removed while the phone is turned on. WARNING! To avoid damage to the phone, do not use any other kind of SIM cards, or any non-standard nano-SIM card cut from a SIM card. You can get a standard nano-SIM card from your service provider. 1. Insert the tip of the tray eject tool into the hole on the card tray. NOTE: Please use the tray eject tool included in the box. Otherwise the card tray may not be ejected. CAUTION: Never replace the included tray eject tool with sharp objects. Ensure that the tray eject tool is perpendicular to the hole. Otherwise, the phone may be damaged. 6 2. Pull out the card tray and place the nano-SIM card and the microSDXC card (optional) on the tray, as shown. Carefully slide the tray back into place. Charging the Phone Your phone’s battery should have enough power for the phone to turn on, find a signal, and make a few calls. You should fully charge the battery as soon as possible. WARNING! Use only ZTE-approved chargers and USB Type-C cables. The use of unapproved accessories could damage your phone or cause the battery to explode. NOTE: To achieve fast charging, you can use the original charger and USB Type-C cable when charging your phone. WARNING! Do not remove the back cover. The battery is not removable. Removal may cause fire or explosion. 1. Connect the adapter to the charging jack. microSDXC card nano-SIM card 2. Connect 3. Disconn e charged. NOTE: If the batter y power on th this case, tr y 20 minutes. cannot pow e Powering Make sure th  Press and phone.  To powe the optio NOTE: If the screen pressing an d to restart the FM Radio Scanning f 1. Plug in a 2. Touch > 7 the charger to a st ect the charger wh y is extremely low, e phone even wh e y again after chargi Contact the custo m er on the phone af g On/Off Your he battery is charg d hold the Power er off, press and ho ons menu, and tou freezes or takes to d holding the Powe e phone. o for Channels a wired headset an > Scan > OK. Your tandard AC power hen the battery is f you may be unab en it is being charg ng the phone for a mer service if you fter prolonged cha r Phone ed before powerin key to turn on you ld the Power key to uch >. oo long to respond er keyfor over 10 se nd open FM Radio r phone scans for a outlet. fully le to ged. In at least still rging. ng on. ur o open d, try econds . all available list. Listening t 1. Open FM 2. Touch > You can also or touch o or to a NOTES:  Touch  Touch speaker.  The FM connecti 8 e channels and save to FM Radio M Radio while the > All channels and drag the red line a or to switch to o adjust the current to add the cha n to listen to the radio feature does on. es them to the cha headset is connec d select a channel. along the frequency other channels, or t channel frequency nnel to favorites. radio through the not require an In t annel ted. y panel touch y. phone ternet 9 Product Safety Information Don’t make or receive phone calls while driving. Never text while driving. Keep your phone at least 10 mm away from your body while making calls. Small parts may cause choking. Your phone can produce a loud sound. To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use. Avoid contact with anything magnetic. Keep away from pacemakers and other electronic medical devices. Turn off when asked to in hospitals and medical facilities. Turn off when told to on aircraft and at airports. Turn off when near explosive materials or liquids. Don’t use at gas stations. Your phone may produce a bright or flashing light. Don’t dispose of your phone in fire. 10 Avoid extreme temperatures. Avoid contact with liquids. Keep your phone dry. Do not attempt to disassemble your phone. Only use approved accessories. For pluggable equipment, the socket-outlet shall be installed near the equipment and shal…

Text truncated - open the document above for the full version.

ZTE Corporation. ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Authorization Letter FCC ID: SRQ-ZTE9030 Date: 2021-4-14 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_centerTesting Center (SRTC) to act on our behalf, as our agent, in the followingmatters related to the FCC approval of our product: Product Name: WCDMA/LTE Multi-mode Digital Mobile Phone Product Model: ZTE 9030 FCC ID: SRQ-ZTE9030 Report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by The State Radio_monitoring_center TestingCenter (SRTC) within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Thank you. Sincerely, ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

Ersteller:D.BrandhorstRevision:00 Erstelldatum:20.06.2011Datum:00.00.00Seite1von1 UNIIDeclarationLetter WehavedeclaredbelowfeaturedforFCCequipmentauthorization,deviceFCCID:SRQ-ZTE9030 (1)DFSDevice--Master,ClientwithRadardetectioncapability, Clientwithoutradardetectioncapability,N/A (2)Active/PassiveScanning,adhocmodeaccesspointcapability FrequencyBand (MHz) ActiveScanning (thedevicecan transmitaprobe (beacon)) passivescanning (wherethedevice is canlistenonly withno probes) AdHocMode capability Accesspoint capability 2412–2462MHzYes,NoYes,NoYes,NoYes,No 2422–2452MHzYes,NoYes,NoYes,NoYes,No 5745–5825MHzYes,NoYes,NoYes,NoYes,No 5755–5795MHzYes,NoYes,NoYes,NoYes,No 5180–5240MHzYes,NoYes,NoYes,NoYes,No 5190–5230MHzYes,NoYes,NoYes,NoYes,No 5260–5320MHzYes,NoYes,NoYes,NoYes,No 5270–5310MHzYes,NoYes,NoYes,NoYes,No 5500–5700MHzYes,NoYes,NoYes,NoYes,No 5510–5670MHzYes,NoYes,NoYes,NoYes,No (3)Countrycodeselectionability-Yes,No Ifno,plsexplainhowwasimplemented:useMicrosoftnetworkutility (4)Meet15.202requirement-Yes,No, plscheckbelow: Amasterdeviceisdefinedasadeviceoperatinginamodeinwhichithasthecapabilityto transmitwithoutreceivinganenablingsignal.Inthismodeitisabletoselectachannelandinitiatea networkbysendingenablingsignalstootherdevices Aclientdeviceisdefinedasadeviceoperatinginamodeinwhichthetransmissionsofthedevice areundercontrolofthemaster.Adeviceinclientmodeisnotabletoinitiateanetwork. (5)Forclientdevicesthathavesoftwareconfigurationcontroltooperateindifferentmodes(active scanninginsomeandpassivescanninginothers)indifferentbands(deviceswithmultipleequipment classesorthosethatoperateonnon-DFSfrequencies)ormodulardeviceswhichconfigurethemodes ofoperationsthroughsoftware,theapplicationmustprovidesoftwareandoperationsdescriptionon howthesoftwareand/orhardwareisimplementedtoensurethatproperoperationsmodescannot bemodifiedbyenduseroraninstaller. Apply,NoApply, (Ifapply,plshelptoprovideexplanationonhowitwasimplement(Byhardwareorsoftware,andhowsoftwarewascontrolled) Applicant:ZTECorporation Address:ZTEPlaza,#55KejiRoadSouth,Hi-Tech,IndustrialPark,NanshanDistrict,Guangdong Signature:April26，2021 Name:GongYu JobTitle:CertificationManager

ZTE Corporation PHOENIX TESTLAB GmbH Date: 24 April 2021 Product Certification Königswinkel 10 D 32825 Blomberg Subject: Declaration Operating Channel Limitation Product Name: WCDMA/LTE Multi-mode Digital Mobile Phone Product Model: ZTE 9030 FCC ID: SRQ-ZTE9030 To Whom it may concern, The operating channels in 802.11 b/g/n mode for the device marketed to the US/Canada are firmware limited to channel 1 ~ 11 (2412 ~ 2462 MHz). The end-user has no possibility to select any other operating channels. If you have any questions, please feel free to contact me. Thank you. Sincerely, Certification Manager ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

ZTE Corporation. ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Guangdong Tel: +86-21-68895397 Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: WCDMA/LTE Multi-mode Digital Mobile Phone Product Model: ZTE 9030 FCC ID: SRQ-ZTE9030 The following information should be held confidential: All Schematics/block diagrams/BOM All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ZTE Corporation ZTE Plaza, #55 Keji Road South, Hi-Tech, Industrial Park, NanshanDistrict,Guangdong Telephone: +86-21-68895397

External Photos FCC ID: SRQ-ZTE9030 1 / 8 External Photos FCC ID: SRQ-ZTE9030 2 / 8 External Photos FCC ID: SRQ-ZTE9030 3 / 8 External Photos FCC ID: SRQ-ZTE9030 4 / 8 External Photos FCC ID: SRQ-ZTE9030 5 / 8 External Photos FCC ID: SRQ-ZTE9030 6 / 8 External Photos FCC ID: SRQ-ZTE9030 7 / 8 External Photos FCC ID: SRQ-ZTE9030 8 / 8

ZTE 9030 GSM: 850/1900 MHz UMTS:850/1900/AWS MHz LTE:B2/B4/B5/B7/B12/B13 /B17/B66/B26/B38 WIFI MAC: XXXXXXXXXXXXXXX FCC IDSRQ-ZTE9030 BT MAC: XXXXXXXXXXXXXXX IMEI: XXXXXXXXXXXXXXX 078761001887空白标贴40x50mm

In ternal Photos FCC ID: SRQ- ZTE9030 1 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 2 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 3 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 4 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 5 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 6 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 7 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 8 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 9 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 10 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 11 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 12 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 13 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 14 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 15 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 16 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 17 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 18 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 19 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 20 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 21 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 22 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 23 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 24 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 25 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 26 / 27 In ternal Photos FCC ID: SRQ- ZTE9030 27 / 27

No.:SRTC2021-9004(F)-21030803(H) FCCID:SRQ-ZTE9030 TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 186 of211 Tel:86-10-5799618 Fax:86-10-57996388V3.0.0 ANNEXA–TESTPLOTS Systemcheck750MHz CommunicationSystem:UID0,CW(0)Frequency:750MHz;Dutycycle:1:1 Mediumparametersused:f=750MHz;σ=0.923S/m;ε r =41.352;ρ=1000kg/m 3 Phantomsection:FlatSection DASYConfiguration: Probe:EX3DV4-SN3708;ConvF(9.75,9.75,9.75);Calibrated:2020/10/30 Sensor-Surface:1.4mm(MechanicalSurfaceDetection), Electronics:DAE4Sn546;Calibrated:11/11/2020 Phantom:Twin-SAM1559;Type:QD000P40CD;Serial:1559 MeasurementSW:DASY52,Version52.8(8);SEMCADXVersion14.6.10(7373) SystemPerformanceCheckatFrequencies750MHz/d=15mm,Pin=250mW, dist=3.0mm(ES-Probe)/AreaScan(8x15x1):Measurementgrid:dx=15mm, dy=15mm MaximumvalueofSAR(measured)=2.16W/kg SystemPerformanceCheckatFrequencies750MHz/d=15mm,Pin=250mW, dist=3.0mm(ES-Probe)/ZoomScan(7x7x7)(7x7x7)/Cube0:Measurementgrid: dx=5mm,dy=5mm,dz=5mm ReferenceValue=41.00V/m;PowerDrift=0.11dB PeakSAR(extrapolated)=3.23W/kg SAR(1g)=2.07W/kg;SAR(10g)=1.40W/kg MaximumvalueofSAR(measured)=2.48W/kg SRTCperformedsystemcheckbyusing250mwatantennaport No.:SRTC2021-9004(F)-21030803(H) FCCID:SRQ-ZTE9030 TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 187 of211 Tel:86-10-5799618 Fax:86-10-57996388V3.0.0 Systemcheck835MHz CommunicationSystem:UID0,CW(0);Frequency:835MHzDutycycle:1:1 Mediumparametersused(interpolated):f=835MHz;σ=0.911S/m;ε r =40.266ρ=1000 kg/m 3 Phantomsection:FlatSection DASY5Configuration: Probe:EX3DV4-SN3708;ConvF(9.39,9.39,9.39);Calibrated:2020/10/30 Sensor-Surface:1.4mm(MechanicalSurfaceDetection), Electronics:DAE4Sn546;Calibrated:11/11/2020 Phantom:Twin-SAM1559;Type:QD000P40CD;Serial:1559 MeasurementSW:DASY52,Version52.8(8);SEMCADXVersion14.6.10(7373) Configuration835/835/AreaScan(8x15x1):Measurementgrid:dx=15mm, dy=15mm MaximumvalueofSAR(measured)=2.72W/kg Configuration835/835/ZoomScan(7x7x7)(7x7x7)/Cube0:Measurementgrid: dx=5mm,dy=5mm,dz=5mm ReferenceValue=51.67V/m;PowerDrift=0.02dB PeakSAR(extrapolated)=3.56W/kg SAR(1g)=2.38W/kg;SAR(10g)=1.61W/kg MaximumvalueofSAR(measured)=2.76W/kg SRTCperformedsystemcheckbyusing250mwatantennaport No.:SRTC2021-9004(F)-21030803(H) FCCID:SRQ-ZTE9030 TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 188 of211 Tel:86-10-5799618 Fax:86-10-57996388V3.0.0 Systemcheck1800MHz CommunicationSystem:UID0,CW(0);Frequency:1800MHz;Dutycycle:1:1 Mediumparametersused:f=1800MHz;σ=1.418S/m;ε r =40.688;ρ=1000kg/m 3 Phantomsection:FlatSection DASY5Configuration: Probe:EX3DV4-SN3708;ConvF(8.27,8.27,8.27);Calibrated:2020/10/30 Sensor-Surface:1.4mm(MechanicalSurfaceDetection), Electronics:DAE4Sn546;Calibrated:11/11/2020 Phantom:Twin-SAM1559;Type:QD000P40CD;Serial:1559 MeasurementSW:DASY52,Version52.8(8);SEMCADXVersion14.6.10(7373) Configuration1800/1800/AreaScan(7x10x1):Measurementgrid:dx=15mm, dy=15mm MaximumvalueofSAR(measured)=8.31W/kg Configuration1800/1800/ZoomScan(7x7x7)/Cube0:Measurementgrid: dx=5mm,dy=5mm,dz=5mm ReferenceValue=76.76V/m;PowerDrift=0.02dB PeakSAR(extrapolated)=17.5W/kg SAR(1g)=9.48W/kg;SAR(10g)=4.95W/kg MaximumvalueofSAR(measured)=12.1W/kg SRTCperformedsystemcheckbyusing250mwatantennaport No.:SRTC2021-9004(F)-21030803(H) FCCID:SRQ-ZTE9030 TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 189 of211 Tel:86-10-5799618 Fax:86-10-57996388V3.0.0 Systemcheck2000MHz CommunicationSystem:UID0,CW(0);Frequency:2000MHz;Dutycycle:1:1 Mediumparametersused:f=2000MHz;σ=1.427S/m;ε r =39.844;ρ=1000kg/m 3 Phantomsection:FlatSection DASY5Configuration: Probe:EX3DV4-SN3708;ConvF(7.94,7.94,7.94);Calibrated:2020/10/30 Sensor-Surface:1.4mm(MechanicalSurfaceDetection), Electronics:DAE4Sn546;Calibrated:11/11/2020 Phantom:Twin-SAM1559;Type:QD000P40CD;Serial:1559 MeasurementSW:DASY52,Version52.8(8);SEMCADXVersion14.6.10(7373) Configuration2000/2000/AreaScan(7x10x1):Measurementgrid:dx=10mm, dy=10mm MaximumvalueofSAR(measured)=8.40W/kg Configuration2000/2000/ZoomScan(7x7x7)(7x7x7)/Cube0:Measurementgrid: dx=5mm,dy=5mm,dz=5mm ReferenceValue=76.22V/m;PowerDrift=0.04dB PeakSAR(extrapolated)=18.7W/kg SAR(1g)=9.83W/kg;SAR(10g)=4.99W/kg MaximumvalueofSAR(measured)=12.9W/kg SRTCperformedsystemcheckbyusing250mwatantennaport No.:SRTC2021-9004(F)-21030803(H) FCCID:SRQ-ZTE9030 TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 190 of211 Tel:86-10-5799618 Fax:86-10-57996388V3.0.0 Systemcheck2450MHz CommunicationSystem:UID0,CW(0);Frequency:2450MHz;Dutycycle:1:1 Mediumparametersused:f=2450MHz;σ=1.866S/m;ε r =38.343;ρ=1000kg/m 3 Phantomsection:FlatSection DASY5Configuration: Probe:EX3DV4-SN3708;ConvF(7.48,7.48,7.48);Calibrated:2020/10/30 Sensor-Surface:1.4mm(MechanicalSurfaceDetection), Electronics:DAE4Sn546;Calibrated:11/11/2020 Phantom:Twin-SAM1559;Type:QD000P40CD;Serial:1559 MeasurementSW:DASY52,Version52.8(8);SEMCADXVersion14.6.10(7373) SystemPerformanceCheckatFrequencies2450MHz/2450/AreaScan(8x11x1): Measurementgrid:dx=12mm,dy=12mm MaximumvalueofSAR(measured)=21.2W/kg SystemPerformanceCheckatFrequencies2450MHz/2450/ZoomScan(7x7x7) (7x7x7)/Cube0:Measurementgrid:dx=5mm,dy=5mm,dz=5mm ReferenceValue=108.3V/m;PowerDrift=0.18dB PeakSAR(extrapolated)=28.2W/kg SAR(1g)=13.4W/kg;SAR(10g)=6.34W/kg MaximumvalueofSAR(measured)=22.6W/kg SRTCperformedsystemcheckbyusing250mwatantennaport No.:SRTC2021-9004(F)-21030803(H) FCCID:SRQ-ZTE9030 TheStateRadio_monitoring_centerTestingCenter(SRTC)Pagenumber: 191 of211 Tel:86-10-5799618 Fax:86-10-57996388V3.0.0 Systemcheck2600MHz CommunicationSystem:UID0,CW(0);Frequency:2600MHz;DutyCycle:1:1 Mediumparametersused:f=2600MHz;σ=1.951S/m;ε r =39.672;ρ=1000kg/m 3 Phantomsection:FlatSection DASY5Configuration: Probe:EX3DV4-SN3708;ConvF(7.37,7.37,7.37);Calibrated:2020/10/30 Sensor-Surface:1.4mm(MechanicalSurfaceDetection), Electronics:DAE4Sn546;Calibrated:11/11/2020 Phantom:Twin-SAM1559;Type:QD000P40CD;Serial:1559 MeasurementSW:DASY52,Version52.8(8);SEMCADXVersion14.6.10(7373) SYSTEMCHECK2600/Area…
