1 ZTE Blade A51 Quick Start Guide FCC ID :SRQ-ZTEA51 2 LEGAL INFORMATION Copyright © 2021 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. We offer self-service for our smart terminal device users. Please visit the ZTE official website (atwww.ztedevices.mx) for more information on self-service and supported product models. Information on the website takes precedence. Visit https://ztedevices.mx/soporte/ to download the user manual. Disclaimer ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized modifications of the software. Images and screenshots used in this guide may differ from the actual product. Content in this guide may differ from the actual product or software. Trademarks ZTE and the ZTE logos are trademarks of ZTE Corporation. Android™ is a trademark of Google LLC. The Bluetooth®word mark and logos are registeredtrademarks owned by the Bluetooth SIG, Inc. and any use of such marks by ZTE Corporation is under license. microSDXC Logo is a trademark of SD-3C, LLC. Other trademarks and trade names are those of their respective owners. Version No.: R1.0 Edition Time :August 25, 2020 ManualNo.: 3 Getting to Know Your Phone Front camera Touch screen Earpiece Proximity & light sensor Volume key Power key Headset jack Dual-lens camera Speaker Indicator light nano-SIM/ microSDXC card tray Flash Fingerprint sensor Charging/USB Typ e-C jack 4 Setting Up Your Phone The nano-SIM card can be installed or removed while the phone is turned on. WARNING! To avoid damage to the phone, do not use any other kind of SIM cards, or any non-standard nano-SIM card cut from a SIM card. You can get a standard nano-SIM card from your service provider. 1. Insert the tip of the tray eject tool into the hole on the card tray. CAUTION: Never replace the included tray eject tool with sharp objects. Ensure that the tray eject tool is perpendicular to the hole. Otherwise, the phone may be damaged. 5 2. Pull out the card tray and place the nano-SIM card and the microSDXC card (optional) on the tray, as shown. Carefully slide the tray back into place. Charging the Phone Yo u r phone’s battery should have enough power for the phone to turn on, find a signal, and make a few calls. You should fully charge the battery as soon as possible. WARNING! Use only ZTE-approved chargers and USB Type-C cables. The use of unapproved accessories could damage your phone or cause the battery to explode. WARNING! Do not remove the back cover. The battery is not removable. Removal may cause fire or explosion. nano-SIM card microSDXC card 6 1. Connect the adapter to the charging jack. 2. Connect the charger to a standard AC power outlet. 3. Disconnect the charger when the battery is fully charged. NOTE: If the battery is extremely low, you may be unable to power on the phone even when it is being charged. In this case, try again after charging the phone for at least 20 minutes. Contact the customer service if you still cannot power on the phone after prolonged charging. Powering On/Off Your Phone Make sure the battery is charged before powering on. • Press and hold the Power key to turn on your phone. • To power off, press and hold the Power key to open the options menu, and touch . NOTE: If the screen freezes or takes too long to respond, try pressing and holding the Power keyfor over 10 seconds to restart the phone. 7 FM Radio Scanning for Channels 1. Plug in a wired headset and open FM Radio. 2. Touc h > Scan. Your phone scans for all available channels and saves them to thechannel list. Listening to FM Radio 1. Open FM Radio while the headset is connected. 2. Touc h > All channels and select a channel. You can also drag the red line along the frequency panel or touch or to switch to other channels, or touch or to adjust the current channel frequency. NOTES: • Touc h to add the channel to favorites. • Touc h to listen to the radio through the phone speaker. • The FM radio feature does not require an Internet connection. 8 Product Safety Information Don’t make or receive phone calls while driving. Never text while driving. Keep your phone at least 10 mm away from your body while making calls. Small parts may cause choking. Your phone can produce a loud sound. To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use. Avoid contact with anything magnetic. Keep away from pacemakers and other electronic medical devices. Turn off when asked to in hospitals and medical facilities. Turn off when told to on aircraft and at airports. Turn off when near explosive materials or liquids. Don’t use at gas stations. Your phone may produce a bright or flashing light. Don’t dispose of your phone in fire. Avoid extreme temperatures. Avoid contact with liquids. Keep your phone dry. Do not attempt to disassemble your phone. 9 Only use approved accessories. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible. Don’t rely on your phone as a primary device for emergency communications. FCC RF Exposure Information (SAR) This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the United States. During SAR testing, this device was set to transmit at its highest certified power level in all tested frequency bands, and placed in positions that simulate RF exposure in usage against the head with no separation, and near the body with the separation of 10 mm. Although the SAR is determined at…

Text truncated - open the document above for the full version.

ZTECorporation. ZTEPlaza,#55KejiRoadSouth,Hi-Tech,IndustrialPark,Nanshan District,Guangdong Tel:+86-21-68895397 AuthorizationLetter FCCID:SRQ-ZTEA51 Date:2020-10-29 Towhomitmayconcern: We,theundersigned,herebyauthorizeTheStateRadio_monitoring_centerTestingCenter(SRTC)to actonourbehalf,asouragent,inthefollowingmattersrelatedtotheFCCapprovalofourproduct: ProductName:LTE/WCDMA/GSM(GPRS)Multi-ModeDigitalMobilePhone ProductModel:ZTEBladeA51 FCCID:SRQ-ZTEA51 Reportsubmittal,relatedcorrespondence,thesigningofalldocumentsrelatingtothesematters, andanyotherlawfulactivitynecessarytoobtainsuchcertification.AnyactcarriedoutbyTheState Radio_monitoring_centerTestingCenter(SRTC)withinthescopeofthisauthorizationshallhavethe sameeffectsasourown. Thisauthorizationshallexpire2monthsfromoriginaldate.Ifyouhaveanyquestionregardingthe authorization,pleasedon’thesitatetocontactwithme. Thankyou. Sincerely, ZTECorporation ZTEPlaza,#55KejiRoadSouth,Hi-Tech,IndustrialPark,NanshanDistrict,Guangdong Telephone:+86-21-68895397

ZTECorporation. ZTEPlaza,#55KejiRoadSouth,Hi-Tech,IndustrialPark,Nanshan District,Guangdong Tel:+86-21-68895397 RequestofConfidentiality FederalCommunicationsCommissionAuthorizationandEvaluationDivision PursuanttoSections0.457and0.459oftheCommission’sRules,theApplicant herebyrequestsconfidentialtreatmentofinformationaccompanyingoffollowing product: ProductName:LTE/WCDMA/GSM(GPRS)Multi-ModeDigitalMobilePhone ProductModel:ZTEBladeA51 FCCID:SRQ-ZTEA51 Thefollowinginformationshouldbeheldconfidential: AllSchematics/blockdiagrams/BOM AllPartslistfortheaboveschematicdiagram Tune-UpProcedure Operationaldescriptionandtechnicaloverviewofproduct Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesemattersmightbeharmfultothe applicantandprovideunjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoRule0.457,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethe dateoftheGrantforthisapplication. Sincerely, ZTECorporation ZTEPlaza,#55KejiRoadSouth,Hi-Tech,IndustrialPark,NanshanDistrict,Guangdong Telephone:+86-21-68895397

CompanyAddress ： No.55,Hi-techRoadSouth,Shenzhen,P.R.China PHOENIXTESTLABGmbHDate:7November2020 ProductCertification Königswinkel10 D32825Blomberg Subject:DeclarationOperatingChannelLimitation ProductName:LTE/WCDMA/GSM(GPRS)Multi-ModeDigitalMobilePhone ProductModel:ZTEBladeA51 FCCID:SRQ-ZTEA51 ToWhomitmayconcern, Theoperatingchannelsin802.11b/g/nmodeforthedevicemarketedtotheUS/Canadaare firmwarelimitedtochannel1~11(2412~2462MHz).Theend-userhasnopossibilityto selectanyotheroperatingchannels. Ifyouhaveanyquestions,pleasefeelfreetocontactme. Thankyou. Sincerely,CertificationManager CompanyName:ZTECorporation Address:No.55,Hi-techRoadSouth,Shenzhen,P.R.China Tel:+86-755-26770000

External Photos FCC ID: SRQ-ZTEA51 1 / 14 External Photos FCC ID: SRQ-ZTEA51 2 / 14 External Photos FCC ID: SRQ-ZTEA51 3 / 14 External Photos FCC ID: SRQ-ZTEA51 4 / 14 Charger View (Model: STC-A51D-Z made by Ruijing) Charger View (Model: STC-A51D-Z made by Ruijing) External Photos FCC ID: SRQ-ZTEA51 5 / 14 Charger View (Model: STC-A51D-Z made by Ruijing) Charger View (Model: STC-A51D-Z made by Ruijing) External Photos FCC ID: SRQ-ZTEA51 6 / 14 Charger View (Model: STC-A51D-Z made by Ruijing) Charger View (Model: STC-A51D-Z made by Ruijing) External Photos FCC ID: SRQ-ZTEA51 7 / 14 Charger View (Model: STC-A51D-Z made by Ruijing) Charger View (Model: STC-A51D-Z made by Ruijing) External Photos FCC ID: SRQ-ZTEA51 8 / 14 Charger View (Model: STC-A51D-Z made by Ruijing) Charger View (Model: STC-A51D-Z made by AoHai) External Photos FCC ID: SRQ-ZTEA51 9 / 14 Charger View (Model: STC-A51D-Z made by AoHai) Charger View (Model: STC-A51D-Z made by AoHai) External Photos FCC ID: SRQ-ZTEA51 10 / 14 Charger View (Model: STC-A51D-Z made by AoHai) Charger View (Model: STC-A51D-Z made by AoHai) External Photos FCC ID: SRQ-ZTEA51 11 / 14 Charger View (Model: STC-A51D-Z made by AoHai) Charger View (Model: STC-A51D-Z made by AoHai) External Photos FCC ID: SRQ-ZTEA51 12 / 14 Charger View (Model: STC-A51D-Z made by AoHai) Charger View (Model: STC-A51D-Z made by AoHai) External Photos FCC ID: SRQ-ZTEA51 13 / 14 USB Cable made by kingpower (Model number: USB-TC20-W-100-M-L) USB Cable made by luxshare (Model number: USB-TC20-W-100-M-L) External Photos FCC ID: SRQ-ZTEA51 14 / 14 Handset made by JUWEI ELECTRONICS CO.,LTD (Model number: JWEP1036-Z01R) Handset made by ShenZhen FDC Electronic Co.,Ltd (Model number: DEM-66)

External Photos FCC ID: SRQ-ZTEA51 1 / 9 IC Details 1 IC Details2 External Photos FCC ID: SRQ-ZTEA51 2 / 9 IC Details 3 IC Details 4 External Photos FCC ID: SRQ-ZTEA51 3 / 9 IC Details 5 External Photos FCC ID: SRQ-ZTEA51 4 / 9 IC Details 6 External Photos FCC ID: SRQ-ZTEA51 5 / 9 IC Details 7 External Photos FCC ID: SRQ-ZTEA51 6 / 9 IC Details 8 External Photos FCC ID: SRQ-ZTEA51 7 / 9 IC Details 9 External Photos FCC ID: SRQ-ZTEA51 8 / 9 Battery View 1 External Photos FCC ID: SRQ-ZTEA51 9 / 9 Battery View 2

No.: SRTC2020-9004(F)-20092401 (H) FCC ID: SRQ-ZTEA51 The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 105 of 135 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 TEST PLOTS System check 835MHz Communication System: UID 0, CW (0); Frequency: 835 MHz Medium parameters used (interpolated): f = 835 MHz; σ = 0.911 S/m; ε r = 40.266 ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: ES3DV3 - SN3127; ConvF(6.16, 6.16, 6.16) @ 836 MHz; Calibrated: 9/1/2020 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 3mm (Mechanical Surface Detection) • Electronics: DAE4 Sn720; Calibrated: 9/30/2020 • Phantom: Twin-SAM 1559; Type: QD 000 P40 CD; Serial: xxxx • Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7450) Configuration 835/835/Area Scan (8x15x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.72 W/kg Configuration 835/835/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51.67 V/m; Power Drift = 0.08 dB Peak SAR (extrapolated) = 3.58 W/kg SAR(1 g) = 2.39 W/kg; SAR(10 g) = 1.51 W/kg Maximum value of SAR (measured) = 2.75 W/kg No.: SRTC2020-9004(F)-20092401 (H) FCC ID: SRQ-ZTEA51 The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 106 of 135 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 System check 1800MHz Communication System: UID 0, CW (0); Frequency: 1800 MHz; Duty cycle:1:1 Medium parameters used: f = 1800 MHz; σ = 1.418 S/m; ε r = 40.688; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: ES3DV3 - SN3127; ConvF(5.12, 5.12, 5.12) @ 1800 MHz; Calibrated: 9/1/2020 • Sensor-Surface: 3mm (Mechanical Surface Detection) • Electronics: DAE4 Sn720; Calibrated: 9/30/2020 • Phantom: Twin-SAM 1559; Type: QD 000 P40 CD; Serial: xxxx • Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7450) Configuration 1800/1800/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 8.31 W/kg Configuration 1800/1800/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 76.60 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 17.5 W/kg SAR(1 g) = 9.49 W/kg; SAR(10 g) = 4.97 W/kg Maximum value of SAR (measured) = 12.1 W/kg No.: SRTC2020-9004(F)-20092401 (H) FCC ID: SRQ-ZTEA51 The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 107 of 135 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 System check 2450MHz Communication System: UID 0, CW (0); Frequency: 2450 MHz; Duty cycle:1:1 Medium parameters used: f = 2450 MHz; σ = 1.866 S/m; ε r = 38.343; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: ES3DV3 - SN3127; ConvF(4.58, 4.58, 4.58) @ 2450 MHz; Calibrated: 9/1/2020 • Sensor-Surface: 3mm (Mechanical Surface Detection) • Electronics: DAE4 Sn720; Calibrated: 9/30/2020 • Phantom: Twin-SAM 1559; Type: QD 000 P40 CD; Serial: xxxx • Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7450) System Performance Check at Frequencies 2450 MHz/2450/Area Scan (8x11x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 21.2 W/kg System Performance Check at Frequencies 2450 MHz/2450/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 108.3 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 28.2 W/kg SAR(1 g) = 13.5 W/kg; SAR(10 g) = 6.14 W/kg Maximum value of SAR (measured) = 22.6 W/kg No.: SRTC2020-9004(F)-20092401 (H) FCC ID: SRQ-ZTEA51 The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 108 of 135 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 Note: for LTE Band7 high range System check 2600MHz Communication System: UID 0, CW (0); Frequency: 2600 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2600 MHz; σ = 1.951 S/m; ε r = 39.672; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: ES3DV3 - SN3127; ConvF(4.37, 4.37, 4.37) @ 2600 MHz; Calibrated: 9/1/2020 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 3mm (Mechanical Surface Detection) • Electronics: DAE4 Sn720; Calibrated: 9/30/2020 • Phantom: Twin-SAM 1559; Type: QD 000 P40 CD; Serial: xxxx • Measurement SW: DASY52, Version 52.10 (2); SEMCAD X Version 14.6.12 (7450) SYSTEM CHECK 2600/Area Scan (5x11x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 22.7 W/kg SYSTEM CHECK 2600/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 102.2 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 33.7 W/kg SAR(1 g) = 14.1 W/kg; SAR(10 g) = 6.52 W/kg Maximum value of SAR (measured) = 26.6 W/kg No.: SRTC2020-9004(F)-20092401 (H) FCC ID: SRQ-ZTEA51 The State Radio_monitoring_centerTestingCenter (SRTC) Page number: 109 of 135 Tel:86-10-5799618 Fax:86-10-57996388 V3.0.0 Main supply GSM850 Head Left cheek Communication System: UID 0, Generic GSM (0); Frequency: 836.6 MHz;Duty Cycle: 2:8.30042 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.905 S/m; ε r = 41.528; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration: • Probe: ES3DV3 - SN3127; ConvF(6.16, 6.16, 6.16) @ 836.6 MHz; Calibrated: 9/1/2020 • Sensor-Surface: 3mm (Mechanical Surface Detection) • Electronics: DAE4 Sn720; Calibrated: 9/30/2020 • Phantom: Twin-SAM 1559; Type: QD 000 P40 CD; Serial: xxxx • Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) LEFT HEAD 15_15/LC GSM850/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.139 W/kg LEFT HEAD 15_15/LC GSM850/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.191 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.169 W/kg SAR(1 g) = 0.133 W/kg; SAR(10 g) = 0.099 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid Ratio of SAR at M2 to SAR at M1 = 79% Maximum value of SAR (measured) = 0.146 W/kg No.: SRTC2020-9004(F)-20092401 (H) FCC…
