SRQ-ZTEBLADEL6Phone

ZTE Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Oct 29, 2015
Application Purpose: Original Equipment
Date of Application: Oct 28, 2015
Equipment Note: Phone
Frequency Range: 2412.00000000 - 2462.00000000
Company: ZTE Corporation
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 ZTE Blade L6 User Manual 2 About This Manual Thank you for choose this ZTE mobile device. In order to keep your device in its best condition, please read this manual and keep it for future reference. Copyright Copyright © 2015 ZTE CORPORATION All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. Notice ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. This manual has been designed with the utmost care to ensure the accuracy of its content. However, all statements, information and recommendations contained therein do not constitute a warranty of any kind, either expressed or implied. Please refer to chapter For Your Safety to be sure to use your phone properly and safely. We offer self-service for our smart terminal device users. Please visit the ZTE official website (at www.ztedevice.com ) for more information on self-service and supported product models. Information on the website takes precedence. 3 Disclaimer ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized modifications of the software. Images and screenshots used in this manual may differ from the actual product. Content in this manual may differ from the actual product or software. Trademarks ZTE and the ZTE logos are trademarks of ZTE Corporation. Google and Android are trademarks of Google, Inc. The Bluetooth ® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such trademarks by ZTE Corporation is under license. microSDHC Logo is a trademark of SD-3C, LLC. Other trademarks and trade names are the property of their respective owners. Version No.: R1.0 Edition Time : 2015.07.29 4 Contents Getting Started ......................................................... 9 Getting to Know Your Phone ............................................... 9 Knowing the Keys .............................................................. 11 Installing the microSDHC™ Card (Not Included) ............... 13 Charging the Battery.......................................................... 14 Extending the Battery Life ................................................. 15 Powering On/Off ................................................................ 16 Setting Up for the First Time .............................................. 16 Locking/Unlocking the Screen and Keys ........................... 16 Using the Touch Screen .................................................... 17 Getting to Know the Home Screen .................................... 18 Personalizing .......................................................... 20 Changing the System Language ....................................... 20 Setting the Date and Time ................................................. 20 Changing Ringtone and Notification Sound ....................... 20 Adjusting Volume ............................................................... 21 Applying New Wallpapers .................................................. 21 Changing Screen Brightness ............................................. 21 Protecting Your Phone With Screen Locks ........................ 22 Protecting Your Phone With Encryption ............................. 23 Knowing the Basics ............................................... 25 Monitoring the Phone Status ............................................. 25 Managing Notifications ...................................................... 25 5 Managing Shortcuts and Widgets ...................................... 26 Rearranging the Favorites Tray ......................................... 27 Entering Text ...................................................................... 28 Connecting to Networks and Devices .................. 31 Connecting to Mobile Networks ......................................... 31 Connecting to Wi-Fi ® ......................................................... 33 Connecting to Bluetooth ® Devices ..................................... 36 Connecting to Your Computer via USB .............................. 39 Sharing Your Mobile Data Connection ............................... 41 Connecting to Virtual Private Networks.............................. 44 Phone Calls ............................................................ 46 Placing and Ending Calls ................................................... 46 Answering or Rejecting Calls ............................................. 47 Working With the Call Log ................................................. 47 Calling Your Contacts ......................................................... 48 Checking Voicemail ........................................................... 48 Using Options During a Call............................................... 49 Managing Multi-party Calls ................................................ 50 Adjusting Your Call Settings ............................................... 51 People ..................................................................... 55 Checking Contact Details ................................................... 55 Adding a New Contact ....................................................... 55 Setting Up Your Own Profile .............................................. 56 Importing, Exporting, and Sharing Contacts ...................... 56 6 Searching for a Contact ..................................................... 58 Editing Contacts ................................................................ 58 Messaging .............................................................. 59 Opening the Messaging Screen ........................................ 59 Sending a Message ........................................................... 59 Replying to a Message ...................................................... 60 Forwarding a M…

Text truncated - open the document above for the full version.

Users Manual

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 ZTE Corporation 2015/10/21 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ZTE Corporation hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product: WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model: ZTE Blade L6 FCC ID: SRQ-ZTEBLADEL6 Sincerely, Client’s signature Client’s name / title Certification Manager Contact information / address ZTE Plaza, Keji Road South Shenzhen China

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 ZTE Corporation 2015/10/21 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: SRQ-ZTEBLADEL6 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name & title : Certification Manager Contact information / address: ZTE Plaza, Keji Road South Shenzhen China

External Photos

External Photo

Internal Photos

Internal Photo WWAN ANT WIFI/BT ANT

RF Exposure Info

Report No. SET2015-13425 CCIC-SET/T-I (00) Page 1 of 119 FCC SAR TEST REPORT Report No.： SET2015-13425 Product： WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Brand Name: ZTE Model No.： ZTE Blade L6 FCC ID： SRQ-ZTEBLADEL6 Applicant： ZTE Corporation Address： ZTE Plaza, Keji Road South, Shenzhen, China Issued by： CCIC-SET Lab Location： Electronic Testing Building, Shahe Road，Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel： 86 755 26627338 Fax：86 755 26627238 Mail： [email protected] Website：http://www.ccic-set.com This test report consists of 119 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No. SET2015-13425 CCIC-SET/T-I (00) Page 2 of 119 Test Report Product. ...................: WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model No. .................: ZTE Blade L6 Brand Name..............: ZTE FCC ID.......................: SRQ-ZTEBLADEL6 Applicant....................: ZTE Corporation Applicant Address.......: ZTE Plaza, Keji Road South, Shenzhen, China Manufacturer............: ZTE Corporation Manufacturer Address: ZTE Plaza, Keji Road South, Shenzhen, China Test Standards..........: 47CFR §2.1093- Radiofrequency Radiation Exposure Evaluation: Portable Devices; ANSI C95.1–1992: Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz – 300 GHz.( IEEE Std C95.1-1991) IEEE 1528–2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques; Test Result...............: Pass Tested by ..............: 2015-09-30 Chun Mei, Test Engineer Reviewed by.............: 2015-09-30 Shuangwen Zhang,Senior Egineer Approved by...............: 2015-09-30 Wu Li’an , Manager Report No. SET2015-13425 CCIC-SET/T-I (00) Page 3 of 119 Contents 1. GENERAL CONDITIONS-----------------------------------------------------------------4 2. ADMINISTRATIVE DATA-----------------------------------------------------------------5 2.1. Identification of the Responsible Testing Laboratory--------------------------------5 2.2. Identification of the Responsible Testing Location(s)--------------------------------5 2.3. Organization Item-------------------------------------------------------------------------5 2.4. Identification of Applicant---------------------------------------------------------------5 2.5. Identification of Manufacture-----------------------------------------------------------5 3. EQUIPMENT UNDER TEST (EUT)-----------------------------------------------------6 4. SAR SUMMAY--------------------------------------------------------------------------------7 5. Specific Absorption Rate(SAR)------------------------------------------------------------8 5.1. Introduction--------------------------------------------------------------------------------8 5.2. SAR Definition----------------------------------------------------------------------------8 5.3. Phantoms-----------------------------------------------------------------------------------9 5.4. Device Holder-----------------------------------------------------------------------------9 5.5. Probe Specification----------------------------------------------------------------------10 6. OPERATIONAL CONDITIONS DURING TEST------------------------------------11 6.1. Schematic Test Configuration---------------------------------------------------------11 6.2. SAR Measurement System--------------------------------------------------------------11 6.3. Equipments and results of validation testing------------------------------------------14 6.4. SAR measurement procedure-----------------------------------------------------------16 6.5. Antennas position and test position----------------------------------------------------17 7. CHARACTERISTICS OF THE TEST--------------------------------------------------18 7.1. Applicable Limit Regulations----------------------------------------------------------18 7.2. Applicable Measurement Standards---------------------------------------------------18 8. LABORATORY ENVIRONMENT-------------------------------------------------------19 9. CONDUCTED RF OUTPUT POWER---------------------------------------------------19 10. TEST RESULTS------------------------------------------------------------------------------27 11. MEASUREMENT UNCERTAINTY-----------------------------------------------------31 12. MAIN TEST INSTRUMENTS------------------------------------------------------------32 This Test Report consists of the following Annexes: Annex A: Test Layout ---------------------------------------------------------------------35 Annex B: Sample Photographs----------------------------------------------------------42 Annex C: System Performance Check Data and Highest SAR Plots------------44 Annex D: Calibration Certificate of Probe and Dipoles----------------------------71 Report No. SET2015-13425 CCIC-SET/T-I (00) Page 4 of 119 1．GENERAL CONDITIONS 1.1 This report only refers to the item that has undergone the test. 1.2 This report standalone does not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. 1.3 This document is only valid if complete; no partial reproduction can be made without written approval of CCIC-SET 1.4 This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of CCIC-SET and the Accreditation Bodies…

Text truncated - open the document above for the full version.

Test Report

Report No.: SET2015-13202 CCIC-SET/T（00） Page 1 of 33 RF TEST REPORT Report No.: SET2015-13202 Product Name: WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone FCC ID: SRQ-ZTEBLADEL6 Model No. : ZTE Blade L6 Applicant: ZTE Corporation Address: ZTE Plaza, Keji Road South, Shenzhen, China Dates of Testing: 09/07/2015 — 09/24/2015 Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 33 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2015-13202 CCIC-SET/T（00） Page 2 of 33 Test Report Product Name ...................... : WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Brand Name ......................... : ZTE Trade Name .......................... : ZTE Applicant .............................. : ZTE Corporation Applicant Address ............... : ZTE Plaza, Keji Road South, Shenzhen, China Manufacturer ........................ : ZTE Corporation Manufacturer Address ........ : ZTE Plaza, Keji Road South, Shenzhen, China Test Standards ..................... : 47 CFR Part 15 Subpart C：Radio Frequency Devices ANSI C63.10-2009：American National Standard for Testing Unlicensed Wireless Devices KDB 558074D01 v03r03 Test Result ........................... : PASS Tested by ............................ : 2015.09.25 Lu Lei, Test Engineer Reviewed by ......................... : 2015.09.25 Zhu Qi, Senior Egineer Approved by ........................ : 2015.09.25 Wu Li’an, Manager Report No.: SET2015-13202 CCIC-SET/T（00） Page 3 of 33 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................. 4 1.1. EUT Description .................................................................................................................... 4 1.2. Test Standards and Results ..................................................................................................... 5 1.3. Facilities and Accreditations .................................................................................................. 7 2. 47 CFR PART 15C REQUIREMENTS ................................................................................. 8 2.1. Antenna requirement .............................................................................................................. 8 2.2. Peak Output Power................................................................................................................. 9 2.3. 6dB Bandwidth .................................................................................................................... 10 2.4. Conducted Band Edges and Spurious Emissions ................................................................. 13 2.5. Power spectral density (PSD) .............................................................................................. 18 2.6. Radiated Band Edge and Spurious Emission ....................................................................... 21 2.7. Conducted Emission ............................................................................................................ 29 3. LIST OF MEASURING EQUIPMENT .............................................................................. 33 Change History Issue Date Reason for change 1.0 2015-09-25 First edition Report No.: SET2015-13202 Page 4 of 33 1. General Information 1.1. EUT Description EUT Type WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Hardware Version WMCY Software Version ZTE_CN_QB25D_P680A10V1.0.0 EUT supports Radios application GSM/GPRS/WCDMA/HSPA WLAN2.4GHz 802.11b/g/n (HT20/HT40) Bluetooth V3.0+EDR / Bluetooth V4.0LE Frequency Range Bluetooth LE 4.0 2402MHz~2480MHz Channel Number Bluetooth LE 4.0 40 Bit Rate of Transmitter Bluetooth LE 4.0 1Mbps Modulation Type Bluetooth LE 4.0 GFSK Antenna Type PIFA antenna Antenna Gain 1.02dBi Note 1: The EUT is a mobile phone, it contain Bluetooth 4.0 LTE Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth 4.0 LTE is F(MHz)=2402+2*n (0<=n<=39). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 20(2442MHz) and 39 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: The EUT was programmed to be in continuously transmitting mode and the transmit duty cycle is not less than 98%. Report No.: SET2015-13202 Page 5 of 33 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC Certification: No. Identity Document Title 1 47 CFR Part 15 Subpart C 2013 Radio Frequency Devices 2 ANSI C63.10-2009 American National Standard for Testing Unlicensed Wireless Devices Test detailed items/section required by FCC rules and results are as below: No. Section in CFR 47 Description Result 1 15.203 Antenna Requirement PASS 2 15.247(b) Peak Output Power PASS 3 15.247(a) Bandwidth PASS 4 15.247(d) Conducted Band Edges and Spurious Emission PASS 5 15.247(e) Power spectral density (PSD) PASS 6 15.207 Conducted Emission PASS 7 15.209 15.247(d) Radiated Band Edges and Spurious Emission PASS The tests of Conducted Emission and Radiated Emission were performed according to the method of measurements prescribed in AN…

Text truncated - open the document above for the full version.

Test Report

Report No.: SET2015-13200 CCIC-SET/T（00） Page 1 of 64 RF TEST REPORT Report No.: SET2015-13200 Product Name: WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone FCC ID: SRQ-ZTEBLADEL6 Model No. : ZTE Blade L6 Applicant: ZTE Corporation Address: ZTE Plaza, Keji Road South, Shenzhen, China Dates of Testing: 09/07/2015 — 09/24/2015 Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 64 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2015-13200 CCIC-SET/T（00） Page 2 of 64 Test Report Product Name ...................... : WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Brand Name ......................... : ZTE Trade Name .......................... : ZTE Applicant .............................. : ZTE Corporation Applicant Address ............... : ZTE Plaza, Keji Road South, Shenzhen, China Manufacturer ........................ : ZTE Corporation Manufacturer Address ........ : ZTE Plaza, Keji Road South, Shenzhen, China Test Standards ..................... : 47 CFR Part 15 Subpart C：Radio Frequency Devices ANSI C63.10 2009：American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v03r03 Test Result ........................... : PASS Tested by ............................ : 2015.09.25 Lu Lei, Test Engineer Reviewed by ......................... : 2015.09.25 Zhu Qi, Senior Egineer Approved by ........................ : 2015.09.25 Wu Li’an, Manager Report No.: SET2015-13200 CCIC-SET/T（00） Page 3 of 64 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................. 4 1.1. EUT Description .................................................................................................................... 4 1.2. Test Standards and Results ..................................................................................................... 5 1.3. Table for Supporting Units ..................................................................................................... 6 1.4. Facilities and Accreditations .................................................................................................. 6 2. 47 CFR PART 15C REQUIREMENTS ................................................................................. 7 2.1. Antenna requirement .............................................................................................................. 7 2.2. Peak Output Power.....................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Chaijue Ding(Certification Manager)

[email protected]+86-13764330709Fax: +86-21-50801070

Test Firm

CCIC-SETQi Zhu

[email protected]86075526626067Fax: 86075526627238

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	56.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum conducted output power. The device has 20MHz and 40MHz bandwidth. This device contains functions that are not operational in U.S. Territories. This filing is only applicable for U.S. operations. For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 10 mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. Highest reported SAR for Head, Body-worn accessory, product specific (wireless router), Simultaneous Transmission are: 0.71 W/kg, 0.22 W/kg, 0.22 W/kg, 1.09 W/kg.
