SRQ-ZTER528GSM digital mobile phone

ZTE R528 Mobile Phone User Manual LEGAL INFORMATION Copyright © 2012 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No.: R1.0 Edition Time: 2014.07.31 3 Contents SAFETY PRECAUTIONS ..................................................................... 6 OPERATIONAL PRECAUTIONS.......................................................... 6 PRECAUTIONS WHILE DRIVING ........................................................ 7 PRECAUTIONS FOR MEDICAL DEVICES AND FACILITIES .............. 7 MOBILE PHONE .................................................................................. 8 PRECAUTIONS FOR POTENTIALLY EXPLOSIVE ATMOSPHERES . 9 PRECAUTIONS FOR ELECTRONIC DEVICES ..................................10 SAFETY AND GENERAL USE IN VEHICLES .....................................10 AIRCRAFT SAFETY ............................................................................11 BATTERY USE ....................................................................................11 KEY FUNCTIONS ................................................................................17 INTERFACE ICONS ............................................................................19 BATTERY ............................................................................................19 INSTALLING AND REMOVING THE BATTERY ................................. 20 INSERTING THE SIM/SD CARD ......................................................... 21 CHARGING THE BATTERY ............................................................... 23 POWERING YOUR PHONE ON/OFF .................................................. 24 TURNING THE TORCH ON/OFF ........................................................ 24 WRITING TEXT ................................................................................... 25 HOW TO ADD CONTACT TO THE PHONEBOOK ............................. 26 HOW TO MAKE AND RECEIVE CALLS ............................................. 26 SENDING AND RECEIVING MESSAGES .......................................... 27 HOW TO SET USER PROFILES ......................................................... 29 HOW TO SET YOUR PHONE ............................................................. 29 BLUETOOTH ...................................................................................... 30 ORGANIZER ....................................................................................... 31 FILE MANAGER ................................................................................. 32 HOW TO PLAY MUSIC ....................................................................... 32 5 HOW TO USE FM RADIO ....................................................................33 SERVICES ..........................................................................................33 6 Security  To protect your mobile phone from illegal use, take the security measures as follows:  Set PIN codes of the SIM card.  Set handset lock code.  Set call restrictions. Safety Precautions This section includes some important information on safe and efficient operation. Please read this information before using the phone. Operational Precautions  Please use your phone properly. When making or receiving a call, please hold your phone as holding a wireline telephone. Make sure that the phone is at least one inch (about two point five centimeters) from your body when transmitting.  Do not touch the antenna when the phone is in use. Touching the antenna area affects call quality and may cause the phone to operate at a higher power level than needed.  Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when watching television or playing 7 video games. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing- light feature on your phone. (The flashing-light feature is not available on all products.)  Keep the phone out of the reach of small children. The phone may cause injury if used as a toy. Precautions While Driving  Please pay attention to the traffic safety. Check the laws and regulations on the use of your phone in the area where you drive. Always obey them.  Use hands-free function of the phone, if available.  Pull off the road and park before making or answering a call if conditions require. Precautions for Medical Devices and Facilities  When using your phone near pacemakers, please always keep the phone more than eight inches (about twenty centimeters) from the pacemaker when the phone is switched on. Do not carry the phone in the breast pocket. Use the ear opposite the pacemaker to minimize the potential for interference. Switch off the phone immediately if 8 necessary.  Some phones may interfere with some hearing aids. In the event of such interference, you may consult your hearing aids manufacturer to discuss alternatives.  If you use any other personal medical device, please consult the manufacturer of your device to determine if it is adequately shielded from RF (radio frequency) energy.  In those facilities with special demand, such as hospital or health care facilities, please pay attention to the restriction on the use of mobile phone. Switch off your phone if required. Mobile Phone  Please use original accessories or accessories approved by the phone manufacturer. Using any unauthorized accessories may affect your mobile phone‟s performance, damage your phone or even cause danger to your body and violate related local regulations about telecom terminals.  Turn off your ph…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 ZTE Corporation 05/09/2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ ZTE Corporation _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): GSM digital mobile phone, ZTE R528 SRQ-ZTER528 Sincerely, Client’s signature Client’s name / title Min Zhang / Manager Contact information / address: ZTE Plaza, Keji Road South, Nanshan District, Shenzhen, China FCC ID :

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 05/09/2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: SRQ-ZTER528 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Min Zhang / Manager Contact information / address: ZTE Plaza, Keji Road South, Nanshan District, Shenzhen, China SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 05/09/2014 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: SRQ-ZTER528 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - User Manual - Internal Photo - External Photo - Setup Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title: Min Zhang / Manager Contact information / address: ZTE Plaza, Keji Road South, Nanshan District, Shenzhen, China

External Photos EUT EUT External Photos EUT EUT Micro USB External Photos EUT EUT External Photos EUT EUT External Photos EUT

Internal Photos EUT EUT Internal Photos EUT EUT Internal Photos EUT EUT Internal Photos EUT EUT Internal Photos EUT EUT EUT Internal Photos EUT

No.I14N00904-SAR Page 1 of 81 ©Copyright. All rights reserved by TMC Beijing. SAR TEST REPORT No.I14N00904-SAR for ZTE Corporation GSM（GPRS） Dual-Mode Digital Mobile Phone ZTE R528 with Hardware Version: GMBF Software Version: ZTE-EN-8D-P153A40V0.0.1 FCC ID: SRQ-ZTER528 Issued Date: 2014-09-09 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of MIIT No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2079, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No. I14N00904-SAR Page 2 of 81 Revision Version Report Number Revision Date Memo I14N00904-SAR 00 2014-09-09 Initial creation of test report No. I14N00904-SAR Page 3 of 81 TABLE OF CONTENT 1 TEST LABORATORY .................................................................................................................... 5 1.1 TESTING LOCATION ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT ................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE .................................................................................................. 6 3 CLIENT INFORMATION ................................................................................................................ 7 3.1 APPLICANT INFORMATION .............................................................................................................................. 7 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 7 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................. 8 4.1 ABOUT EUT ................................................................................................................................................... 8 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................................... 8 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................................ 8 5 TEST METHODOLOGY ................................................................................................................ 9 5.1 APPLICABLE LIMIT REGULATIONS .................................................................................................................. 9 5.2 APPLICABLE MEASUREMENT STANDARDS ...................................................................................................... 9 6 SPECIFIC ABSORPTION RATE (SAR) ...................................................................................... 10 6.1 INTRODUCTION ............................................................................................................................................. 10 6.2 SAR DEFINITION .......................................................................................................................................... 10 7 TISSUE SIMULATING LIQUIDS ................................................................................................. 11 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 11 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 11 8 SYSTEM VERIFICATION ............................................................................................................ 14 8.1 SYSTEM SETUP ............................................................................................................................................. 14 8.2 SYSTEM VERIFICATION ................................................................................................................................. 15 8.3 JUSTIFICATION FOR EXTENDED SAR DIPOLE CALIBRATIONS ....................................................................... 16 9 MEASUREMENT PROCEDURES .............................................................................................. 17 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 17 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 19 9.3 BLUETOOTH MEASUREMENT PROCEDURES FOR SAR .................................................................................. 20 9.4 POWER DRIFT ............................................................................................................................................... 20 10 CONDUCTED OUTPUT POWER.............................................................................................. 21 10.1 MANUFACTURING TOLERANCE ................................................................................................................... 21 3.5 .................................................................................................................................................... 21 10.2 GSM MEASUREMENT RESULT .................................................................................................................... 22 No. I14N00904-SAR Page 4 of 81 10.3 BT MEAS…

Text truncated - open the document above for the full version.

No.I14N00904-2G Page 1 of 69 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. I14N00904-2G for ZTE Corporation GSM （GPRS） Dual-Mode Digital Mobile Phone Model Name: ZTE R528 Marketing Name: ZTE R528 FCC ID: SRQ-ZTER528 with Hardware Version: GMBF Software Version: ZTE-EN-8D-P153A40V0.0.1 Issued Date: 2014-08-26 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Shenzhen. Test Laboratory: FCC 2.948 Listed: No.310359 IC O.A.T.S listed: No.6629C-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Te l : +86(0)10-62304633-2678, Fax: +86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No. I14N00904-2G Page 2 of 69 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMAT ION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. NORMAL ACCESSORY SETTING ............................................................................................... 6 3.5. GENERAL DESCRIPTION ............................................................................................................ 6 4. REFERENCE DOCUMENTS ............................................................................................................. 7 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 7 5. LABORATORY ENVIRONMENT ..................................................................................................... 8 6. SUMMARY OF TEST RESULT S ....................................................................................................... 9 7. TEST EQUIPMENTS UTILIZED .................................................................................................... 10 ANNEX A: MEASUREMENT RESULTS ................................................................................................. 11 A.1 OUTPUT POWER ............................................................................................................................11 A.2 EMISSION LIMIT ........................................................................................................................... 17 A.3 CONDUCTED EMISSION ............................................................................................................. 23 A.4 FREQUENCY STABILITY ............................................................................................................ 26 A.5 OCCUPIED BANDWIDTH ............................................................................................................ 28 A.6 EMISSION BANDWIDTH ............................................................................................................. 36 A.7 BAND EDGE COMPLIANCE ........................................................................................................ 44 A.8 CONDUCTED SPURIOUS EMISSION ......................................................................................... 48 A.9 PEAK-TO-AVERAGE POWER R AT I O ......................................................................................... 69 No. I14N00904-2G Page 4 of 69 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: ZTE Plaza, Keji Road South , Shenzhen,China City: ShenZhen Postal Code: 518000 Country: China 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: ZTE Plaza, Keji Road South , Shenzhen,China City: ShenZhen Postal Code: 518000 Country: China No. I14N00904-2G Page 5 of 69 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name ZTE R528 Marketing Name ZTE R528 FCC ID SRQ-ZTER528 Frequency GSM850; PCS1900; Antenna Integrated Power supply Battery or Charger (AC Adaptor) Output power 27.97dBm maximum EIRP measured for 1900MHz Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. Note: 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI N01 86550102…

Text truncated - open the document above for the full version.

Test setup photos 1. Part 22/24 radiated spurious emission below 3GHz 2. Part22/24 radiated spurious emission above 3 GHz

SAR TEST REPORT No.I14N00904-SAR for ZTE Corporation GSM（GPRS） Dual-Mode Digital Mobile Phone ZTE R528 with Hardware Version: GMBF Software Version: ZTE-EN-8D-P153A40V0.0.1 FCC ID: SRQ-ZTER528 Issued Date: 2014-09-09 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of MIIT No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2079, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com Picture 1: front side of the sample Picture 2: back side of the sample Picture 3: Left Hand Touch Cheek Position Picture 4: Left Hand Tilt 15° Position Picture 5: Right Hand Touch Cheek Position Picture 6: Right Hand Tilt 15° Position Test positions for body: The Body SAR is tested at the following 2 test positions all with the distance =10mm between the EUT and the phantom bottom: Picture 7: Toward Phantom Picture 8: Toward Ground
