SS3-MT3PD22DJI Mini 3

SZ DJI TECHNOLOGY CO., LTD
DJI Mini 3 - FCC ID SS3-MT3PD22 - SZ DJI TECHNOLOGY CO., LTD
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Nov 21, 2022
Application Purpose
Original Equipment
Date of Application
Nov 21, 2022
Equipment Note
DJI Mini 3
Frequency Range
2410.50000000 - 2472.50000000
Company
SZ DJI TECHNOLOGY CO., LTD
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗
↗
↗
↗
↗

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MT3PD Quick Start Guide Aircraft 1. Gimbal Camera 2. Infrared Sensing System 3. Downward Vision System 4. Antennas 5. Front LEDs 6. Battery Buckles 7. Power Button and Battery Level LEDs 8. USB-C Port 9. microSD Card Slot Remote Controller RM330 1. Control Sticks 2. Flight Pause/Return to Home (RTH) Button 3. Flight Mode Switch 4. Power Button 5. Battery Level LEDs 6. Record Button 7. Gimbal Dial 8. Shutter Button 9. Zoom Dial 10. Control Sticks Storage Slot 11. Customizable Buttons 12. 4G Dongle Port(USB-C) 13. microSD Card Slot 14. Power Connector(USB-C) Download the DJI Fly App and watch the tutorial videos Charge to activate Check Battery Level, Power on/off Check battery level: press once. Power on/off: press then press and hold. Prepare the aircraft Prepare the remote controller Ready to fly Power on the remote controller and the aircraft, then launch the DJI Fly App. Fly Auto take-off/land: Touch and hold the following icon from DJI Fly App to take off or land. Take off Land Manually take-off/land: Start/stop the motors: Take off: Slowly push the throttle stick up. Land: Slowly push the throttle stick down until the aircraft lands on ground. Hold the stick down until the motors stop. Flight control Specifications Aircraft (MT3PD) Operating Temperature -1 0° to 40° C (14° to 104° F) O2 Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE) Wi-Fi Protocol 802.11a/b/g/n/ac Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz Transmitter Power (EIRP) 2.4 GHz: <19 dBm (FCC/CE/SRRC/MIC) 5.8 GHz: <20 dBm (FCC/SRRC), <14 dBm (CE) Bluetooth 5.2 Operating Frequency 2.4000-2.4835 GHz Transmitter Power (EIRP) < 8 dBm Remote Controller (Model: RM330) Operating Temperature -10° to 40° C (14° to 104° F) O2 Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC) , <14 dBm (CE), <23 dBm (SRRC) Wi-Fi Protocol 802.11a/b/g/n Operating Frequency 2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz Transmitter Power (EIRP) 2.4 GHz: <23 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.1 GHz: <23 dBm (FCC/CE/SRRC/MIC) 5.8 GHz: <23 dBm (FCC/SRRC), <14 dBm (CE) Bluetooth 4.2 Operating Frequency 2.4000-2.4835 GHz Transmitter Power (EIRP) <8 dBm Intelligent Flight Battery (BWX162-2453-7.38) Charging Temperature 5° to 40° C (41° to 104° F) Capacity 2453 mAh Battery Type Li-ion Chemical System LiNiMnCoO2 Max Charging Power 37 W Standard Voltage 7.38 V Support Charger DJI 30W USB-C Charger Or other USB Power Delivery charger Compliance Info FCC Compliance Notice Supplier’s Declaration of Conformity Product name: DJI MINI 3 Model Number: MT3PD Responsible Party: DJI Technology, Inc. Responsible Party Address: 201 S. Victory Blvd., Burbank, CA 91502 Website: www.dji.com We, DJI Technology, Inc., being the responsible party, declares that the above mentioned model was tested to demonstrate complying with all applicable FCC rules and regulations. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF Exposure Information The aircraft complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm during normal operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This remote controller complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for use when properly worn on the body. ISED Compliance Notice This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1)This device may not cause interference.(2)This device must accept any interference, including interference that may cause undesired operation o…

Text truncated - open the document above for the full version.

Cover Letter(s)

TCB Authority to Act as Agent Number: MS-0045317 Revision: 0 Effective date: Oct 8, 2021 Page 1 of 1 SZ DJI TECHNOLOGY CO.,LTD. Authority to Act as Agent Date: 2022-10-24 TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint TUV Rheinland (Shenzhen) Co., Ltd. and TUV Engineer to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with SZ DJI TECHNOLOGY CO.,LTD. 14th floor, West Wing, Skyworth Semiconductor Design Building NO.18 Gaoxin South 4th Ave, Nanshan, Shenzhen, Guangdong, China For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: _2022-10-24__ Agreement is valid for 12 months from the above date. By: _____________ ____Gary Zeng__ (Signature) (Print name) _Certification Manager +86 755 26656677 (Title) (Telephone) On behalf of: SZ DJI TECHNOLOGY CO.,LTD. (Company Name)

Cover Letter(s)

Request for Confidentiality Letter Number: MS0044715 Revision: 1 Effective date: Sep 12, 2022 Author: William Graff Owner: William Graff MS-0044715 Page 1 of 1 Revision 1 Legal Scope: Global Business Scope: Cross Business Process Scope: Cross Process The following is a sample Confidentiality Request letter, which must be completed on Applicant company letterhead, signed by the Applicant or their authorized Agent, and submitted to TÜV Rheinland. Date: 24 Oct 2022 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Confidentiality Request for FCC ID: SS3-MT3PD22 Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term n/a External Photo Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Short Term Permanent Test Setup*** Short Term Permanent Tune-Up Procedure Short Term Permanent User’s Manual*** Short Term Permanent Part List/ Antenna Construction SZ DJI TECHNOLOGY CO.,LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** Exceptional case for Permanent Confidentiality for these Exhibits by PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: _______________________________________ _______Gary Zeng ____________ (Signature/Title) (Print name) Tel: +86 755 26656677 Email: [email protected]

External Photos

Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 1: External view 1 Figure 2: External view 2 Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 3: External view 3 Figure 4: External view 4 Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 5: External view 5

ID Label/Location Info

Label information: Label location:

Internal Photos

Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 6: Internal view 1 Figure 7: Internal view 2 Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 8: Internal view 3 Figure 9: Internal view 4 Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 10: Internal view 5 Figure 11: Internal view 6 Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 12: Internal view 7 Figure 13: Internal view 8 Product: Aircraft (DJI Mini 3) Type Designation: MT3PD Figure 14: Battery view 1 Figure 15: Battery view 2

Operational Description

1 DJI Antenna Datasheet ___WM163 antenna____ __ 2022-07-29 Revision history Version Change notes Modificator Date V1.0 First draft. Freeman.D eng 2022.07.29 1 DJI Antenna Datasheet 1、 Basic Specifications No. Specification Descriptions Notes 1 Antenna Name WM163 Ant 2 Brand DJI 3 Operation Frequency 2.4~2.483GHz; 5.725~5.85GHz 4 Connector Type Ipex-4 5 Impedance 50ohm 6 Gain [email protected] [email protected] 7 Efficiency ≥45% 8 VSWR ≤2 9 Polarization type Linear 10 3dB Beamwidth Omnidirectional horizon 11 Weight 12 Antenna type Dipole 2、 Antenna Return Loss/VSWR 2.1 Ant return loss 3、 Antenna Gain 3.1 Wifi antenna Frequency Efficiency Gain(dBi) 2400MHz 48% 1.50 2420MHz 53% 1.46 2440MHz 52% 1.45 2460MHz 47% 1.49 2480MHz 44% 1.45 Frequency Efficiency Gain(dBi) 5725MHz 47% 1.02 5750MHz 47% 0.83 5775MHz 49% 0.70 5800MHz 52% 0.88 5825MHz 57% 1.0 5850MHz 56% 0.97 4、 Radiation Pattern 4.1 Ant0 2.4G radiation pattern 4.2 Ant1 2.4G radiation pattern 4.3 Ant0 5.8G radiation pattern 4.4 Ant1 5.8G radiation pattern 5、 Structure drawing

RF Exposure Info

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN22JIUF 004 Auftrags-Nr.: Order no.: 168384966 Seite 1 von 10 Page 1 of 10 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2022-09-21 Auftraggeber: Client: SZ DJI TECHNOLOGY CO., LTD. 14th Floor, West Wing, Skyworth Semiconductor Design Building No.18 Gaoxin South 4th Ave Nanshan District, Shenzhen, P.R. China Prüfgegenstand: Test item: DJI Mini 3 Bezeichnung / Typ-Nr.: Identification / Type no.: MT3PD (Trademark: DJI) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: 47 CFR FCC Part 2.1091 Wareneingangsdatum: Date of sample receipt: 2022-09-22 Please refer to Photo Document Prüfmuster-Nr.: Test sample no: A003338845-005~008, 024~027 Prüfzeitraum: Testing period: 2022-09-22 to 2022-10-17 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: genehmigt von: authorized by: Datum: Date: 2022-10-19 Ausstellungsdatum: Issue date: 2022-10-19 Stellung / Position: Project Manager Stellung / Position: Reviewer Sonstiges / Other: FCC ID: SS3-MT3PD22 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com jjj Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22JIUF 004 Seite 2 von 10 Page 2 of10 TEST SUMMARY 3.1.1 RF EXPOSURE COMPLIANCE RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22JIUF 004 Seite 3 von 10 Page 3 of 10 CONTENTS 1. TEST SITES ....................................................................................................................... 4 1.1 TEST FACILITIES ............................................................................................................... 4 1.2 TRACEABILITY .................................................................................................................. 4 1.3 CALIBRATION .................................................................................................................... 4 1.4 LOCATION OF ORIGINAL DATA ........................................................................................... 4 1.5 STATUS OF FACILITY USED FOR TESTING ........................................................................... 4 2. GENERAL PRODUCT INFORMATION .................................................................................... 5 2.1 GENERAL DESCRIPTION .................................................................................................... 5 2.2 RATING AND SYSTEM DETAILS ........................................................................................... 5 3. TEST RESULTS ................................................................................................................. 8 3.1 TRANSMITTER REQUIREMENTS & TEST SUITES ................................................................... 8 3.1.1 RF Exposure Compliance ............................................................................................................ 8 3.1.1.1 FCC Part 1.1310, Part 2.1091 ........................................................................................ 9 4. LIST OF TABLES .............................................................................................................. 10 Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22JIUF 004 Seite 4 von 10 Page 4 of 10 1. TEST SITES 1.1 TEST FACILITIES TÜV Rheinland (Shenzhen) Co., Ltd. Address: No. 362 Huanguan Road Middle, Longhua District, Shenzhen 518110, P.R. China FCC Registration No.: 694916 ISED Wireless Device Testing Laboratory: 25069 1.2 Traceability All measurement equipment calibrations are traceable to NIST or where calibration is performed outside the United States, to equivalent nationally recognized standards organizations. 1.3 Calibration Equipment requiring calibration is calibrated periodically by the manufacturer or according to manufacturer’s specifications. Additionally all equipment is verified for proper performance on a regular basics using in house standards or comparisons. 1.4 Location of Original Data The original copies of all test data taken during actual testing were attached at Appendixes of this report and delivered to the applicant. A copy has been retained in the TÜV Rheinland (Shenzhen) file for certification follow-up purposes. 1.5 Status of Facility Used for Testing The TÜV Rheinland (Shenzhen) Co., Ltd. facility located at No. 362 Huanguan Road Middle, Longhua District, Shenzhen 518110, P.R. China is listed on the US Federal Communications Commission list of facilities approved to perform measurements. Prüfbericht - Produkte Test Report -…

Text truncated - open the document above for the full version.

Test Report

Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 1 of 37 Appendix A: Test Results of Bluetooth LE APPENDIX A: TEST RESULTS OF BLUETOOTH LE ............................................................................................................. 1 APPENDIX A.1: TEST RESULTS OF CONDUCTED POWER SPECTRAL DENSITY ..................................................................................... 2 APPENDIX A.2: TEST RESULTS OF 6DB BANDWIDTH ................................................................................................................... 5 APPENDIX A.3: TEST RESULTS OF 99% BANDWIDTH ................................................................................................................... 8 APPENDIX A.4: TEST RESULTS OF CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH ...................................... 11 Conducted Spurious Emission ..................................................................................................................................... 11 Band Edge ................................................................................................................................................................... 18 APPENDIX A.5: TEST RESULTS OF RADIATED SPURIOUS EMISSIONS ............................................................................................. 20 30 MHz to 1GHz .......................................................................................................................................................... 20 1GHz-18GHz ................................................................................................................................................................ 22 APPENDIX A.6: TEST RESULTS OF RADIATED EMISSIONS IN RESTRICTED BANDS ............................................................................. 34 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 2 of 37 Appendix A.1: Test Results of Conducted Power Spectral Density TestMode Antenna Channel Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -10.26 ≤8 PASS 2440 -9.67 ≤8 PASS 2480 -10.15 ≤8 PASS BLE_2M Ant1 2402 -15.01 ≤8 PASS 2440 -14.62 ≤8 PASS 2480 -14.99 ≤8 PASS Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 3 of 37 BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 4 of 37 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 BLE_2M_Ant1_2480 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 5 of 37 Appendix A.2: Test Results of 6dB Bandwidth TestMode Antenna Channel DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.648 2401.676 2402.324 0.5 PASS 2440 0.644 2439.692 2440.336 0.5 PASS 2480 0.532 2479.680 2480.212 0.5 PASS BLE_2M Ant1 2402 0.996 2401.524 2402.520 0.5 PASS 2440 1.008 2439.524 2440.532 0.5 PASS 2480 1.044 2479.460 2480.504 0.5 PASS Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 6 of 37 BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 7 of 37 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 BLE_2M_Ant1_2480 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 8 of 37 Appendix A.3: Test Results of 99% Bandwidth TestMode Antenna Channel OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 1.0690 2401.4825 2402.5515 --- PASS 2440 1.0646 2439.4918 2440.5564 --- PASS 2480 1.0655 2479.4930 2480.5585 --- PASS BLE_2M Ant1 2402 2.0774 2400.9821 2403.0595 --- PASS 2440 2.0860 2438.9894 2441.0754 --- PASS 2480 2.0819 2478.9968 2481.0787 --- PASS Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 9 of 37 BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 10 of 37 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 BLE_2M_Ant1_2480 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 11 of 37 Appendix A.4: Test Results of Conducted Spurious Emissions Measured in 100 kHz Bandwidth Conducted Spurious Emission TestMode Antenna Channel FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 Reference 5.85 5.85 --- PASS 30~1000 5.85 -47.25 ≤-14.15 PASS 1000~26500 5.85 -39.25 ≤-14.15 PASS 2440 Reference 6.26 6.26 --- PASS 30~1000 6.26 -48.12 ≤-13.74 PASS 1000~26500 6.26 -39.5 ≤-13.74 PASS 2480 Reference 5.78 5.78 --- PASS 30~1000 5.78 -49.13 ≤-14.22 PASS 1000~26500 5.78 -39.27 ≤-14.22 PASS BLE_2M Ant1 2402 Reference 4.80 4.80 --- PASS 30~1000 4.80 -48.18 ≤-15.2 PASS 1000~26500 4.80 -38.22 ≤-15.2 PASS 2440 Reference 5.19 5.19 --- PASS 30~1000 5.19 -48.39 ≤-14.81 PASS 1000~26500 5.19 -38.91 ≤-14.81 PASS 2480 Reference 4.81 4.81 --- PASS 30~1000 4.81 -48.47 ≤-15.19 PASS 1000~26500 4.81 -39.07 ≤-15.19 PASS Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 12 of 37 BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 13 of 37 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 BLE_1M_Ant1_2440_1000~26500 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 14 of 37 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 BLE_1M_Ant1_2480_1000~26500 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 15 of 37 BLE_2M_Ant1_2402_0~Reference BLE_2M_Ant1_2402_30~1000 BLE_2M_Ant1_2402_1000~26500 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 16 of 37 BLE_2M_Ant1_2440_0~Reference BLE_2M_Ant1_2440_30~1000 BLE_2M_Ant1_2440_1000~26500 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 17 of 37 BLE_2M_Ant1_2480_0~Reference BLE_2M_Ant1_2480_30~1000 BLE_2M_Ant1_2480_1000~26500 Prüfbericht - Produkte Test Report - Products Appendix A CN22JIUF 002 Page 18 of 37 Band Edge TestMode Antenna ChNam…

Text truncated - open the document above for the full version.

Test Report

Prüfbericht - Produkte Test Report - Products Appendix B CN22JIUF 002 Page 1 of 108 Appendix B: Test Results of 2.4GHz SDR APPENDIX B: TEST RESULTS OF 2.4GHZ SDR .................................................................................................................. 1 APPENDIX B.1: TEST RESULTS OF CONDUCTED POWER SPECTRAL DENSITY ..................................................................................... 2 2.4GHz SDR, 1.4MHz BW .............................................................................................................................................. 2 2.4GHz SDR, 1.4MHz BW CA mode .............................................................................................................................. 3 2.4GHz SDR, 3MHz BW ................................................................................................................................................. 4 2.4GHz SDR, 10MHz BW ............................................................................................................................................... 5 2.4GHz SDR, 20MHz BW ............................................................................................................................................... 6 APPENDIX B.2: TEST RESULTS OF 6DB BANDWIDTH .................................................................................................................... 7 2.4GHz SDR, 1.4MHz BW .............................................................................................................................................. 7 2.4GHz SDR, 1.4MHz BW CA mode .............................................................................................................................. 8 2.4GHz SDR, 3MHz BW ................................................................................................................................................. 9 2.4GHz SDR, 10MHz BW ............................................................................................................................................. 10 2.4GHz SDR, 20MHz BW ............................................................................................................................................. 11 APPENDIX B.3: TEST RESULTS OF 99% BANDWIDTH ................................................................................................................. 12 2.4GHz SDR, 1.4MHz BW ............................................................................................................................................ 12 2.4GHz SDR, 1.4MHz BW CA mode ............................................................................................................................ 13 2.4GHz SDR, 3MHz BW ............................................................................................................................................... 14 2.4GHz SDR, 10MHz BW ............................................................................................................................................. 15 2.4GHz SDR, 20MHz BW ............................................................................................................................................. 16 APPENDIX B.4: TEST RESULTS OF CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH ....................................... 17 2.4GHz SDR, 1.4MHz BW ............................................................................................................................................ 17 2.4GHz SDR, 1.4MHz BW CA mode ............................................................................................................................ 21 2.4GHz SDR, 3MHz BW ............................................................................................................................................... 25 2.4GHz SDR, 10MHz BW ............................................................................................................................................. 29 2.4GHz SDR, 20MHz BW ............................................................................................................................................. 33 2.4GHz SDR, 1.4MHz BW Bandedge .......................................................................................................................... 37 2.4GHz SDR, 1.4MHz BW CA mode Bandedge .......................................................................................................... 38 2.4GHz SDR, 3MHz BW Bandedge ............................................................................................................................. 39 2.4GHz SDR, 10MHz BW Bandedge ........................................................................................................................... 40 2.4GHz SDR, 20MHz BW Bandedge ........................................................................................................................... 41 APPENDIX B.5: TEST RESULTS OF RADIATED SPURIOUS EMISSIONS ............................................................................................. 42 30MHz - 1GHz (Worst case) ....................................................................................................................................... 42 1GHz - 18GHz .............................................................................................................................................................. 44 Prüfbericht - Produkte Test Report - Products Appendix B CN22JIUF 002 Page 2 of 108 Appendix B.1: Test Results of Conducted Power Spectral Density Both Ant ports tested, only the wor…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Gary Zeng(PM)
[email protected]+8675586152250Fax: +86 755 86965903

Technical Contact

SZ DJI TECHNOLOGY CO.,LTDGary Zeng
[email protected]

14th floor, West Wing, Skyworth Semiconductor · Shenzhen · China

Test Firm

TUV Rheinland (Shenzhen) Co., Ltd.Gina Yang
[email protected]86 755 8268 1497

Technical Specifications

#Rule PartsFrequency RangePower Output
815C2.41 GHz - 2.47 GHz137.40 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance
