SS3-RD241608RFForward Phased Array Radar

Agras T25 Quick Start Guide v1.0 2022.12 Aircraft The Agras T25 aircraft has a truss-style body that comes with pitched arms that can be folded, making it easier to transport. The integrated spraying system can quickly transform into the spreading configuration with a spreading payload of 25 kg. The aircraft is equipped with the phased array radar system and binocular vision system, including downward and forward binocular vision, forward and rear phased array radar. The systems provide 360-degree omnidirectional obstacle sensing to ensure operational safety. The ultra HD FPV camera with a tiltable gimbal can automatically collect HD field images for local offline reconstruction to assist precise field planning. The Coaxial Dual Propeller structure brings a strong wind field. Pesticides can penetrate thick canopies to allow thorough spraying. The spraying system is equipped with the Magnetic Drive Impeller Pump, Dual Atomized Sprinkler, Anti-Drip Centrifugal Valve and solenoid valve, to ensure more efficient and precise pesticide spraying, as well as save liquid pesticide. The spraying system can be upgraded with two more sprinklers to meet different operation scenarios. Using the T25 Preparing the Intelligent Flight Battery Only use official DJI flight batteries. Check the battery level before flying and charge according to the corresponding manual document. Preparing the Aircraft 1. Propellers 2. Motors 3. ESCs 4. Aircraft Front Indicators (on two front arms) 5. Frame Arms 6. Folding Detection Sensors (built-in) 7. Spray Lance 8. Sprinklers 9. Spread Tank 10. Delivery Pumps 11. FPV PTZ camera 12. Downward Binocular Vision 13. Forward Binocular Vision 14. Spotlights 15. Forward Phased Array Radar 16. Rear Phased Array Radar 17. Landing Gear 18. Intelligent Flight Battery 19. Onboard D-RTK TM Antennas 20. Internal OCUSYNC TM Image Transmission Antennas 21. External OcuSync Image Transmission Antennas 22. Aircraft Status Indicators (on two rear arms) Unfold the M3 and M4 arms, and fasten the two arm locks. Avoid pinching fingers. Unfold the M1 and M2 arms, and fasten the two arm locks. Avoid pinching fingers. Unfold the propeller blades. Insert the Intelligent Flight Battery into the aircraft until you hear a click.  Make sure that the battery is firmly inserted into the aircraft. Only insert or remove the battery when the aircraft is powered off.  To remove the battery, press and hold the clamp and lift the battery up.  Fold the M1 and M2 arms followed by the M3 and M4 arms. Otherwise, the arms may be damaged. Getting Ready for Takeoff A. Place the aircraft on open, flat ground with the rear of the aircraft facing toward you. B. Make sure that the propellers are securely mounted, there are no foreign objects in or on the motors and propellers, the propeller blades and arms are unfolded, and the arm locks are firmly fastened. C. Make sure that the spray tank and flight battery are firmly in place. E. Power on the remote controller, make sure that the DJI Agras app is open, and power on the aircraft. Tap Start in the home screen of the app to enter Operation View. Make sure that the GNSS signals are strong and the screen shows Ready to GO (GNSS) or Ready to GO (RTK). Otherwise, the aircraft cannot take off. RTK positioning is recommended. In the app, go to Operation View, tap > RTK, and select a method for receiving RTK signals. Calibrating the Flow Meter Make sure to calibrate the flow meter in the following situations: Change liquid payload with different viscosity. The difference between the actual area and planned area is more than 15% after the first operation. Calibrating procedure A. Get Ready to Calibrate ① Fill the spray tank with approximately 2 L of water. ② Press the Spray button to start or stop spraying manually in order to exhaust air. B. Calibrating the flow meter ① In the app, go to Operation View, tap > , then tap Calibration on the right of the flow meter calibration section. ② Tap Start Calibration and calibration will start automatically. The result of the calibration will be displayed in the app when completed. ● After calibrating successfully, users can proceed with the operation. ● If calibration fails, tap the reminder to view and resolve the problem. Afterwards, recalibrate and wait for successful calibration. Flight In order for the aircraft to automatically take off and perform an operation, it is recommended to creat a plan for a field and select an operation before takeoff. Refer to the Starting Operations section for more information. For other scenarios, take off and land manually as follows. Takeoff Perform a Combination Stick Command (CSC) and push the throttle stick up to take off. Landing Push the throttle stick down until the aircraft lands. There are two methods to stop the motors after landing. Method 1: When the aircraft has landed, push and hold the throttle stick down. The motors will stop after three seconds. Method 2: When the aircraft has landed, push the throttle stick down, and perform the same CSC that was used to start the motors. Release both sticks once the motors have stopped.  Spinning propellers can be dangerous. Stay away from spinning propellers and motors. DO NOT start the motors in confined spaced or where there are people nearby.  Maintain control of the remote controller as long as the motors are running.  DO NOT stop the motors mid-flight. Otherwise, the aircraft will be crashed. Stop the motors only in an emergency situation to reduce the risk of damage or injury.  It is recommended to use Method 1 to stop the motors. When using the Method 2 to stop the motors, the aircraft may roll over if it is not completely grounded. Use Method 2 with caution. O R Throttle Stick (left stick in Mode 2)  After landing, power off the aircraft before turning off the remote controller. Starting Operations Users can perform aerial surveying for the operation area in the DJI Agras app, receive an HD map via offline reconstruction in the rem…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name SZ DJI TECHNOLOGY CO., LTD. Address Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Grantee Code SS3 FCC ID SS3-RD241608RF Authorized Contact Name Gary Zeng Contact Email [email protected] Contact Phone +8675586152250 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [SZ DJI TECHNOLOGY CO., LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [SZ DJI TECHNOLOGY CO., LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date:2023/6/12 Print Name: Gary.Zeng Title: PM *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATED AGENT LETTER Date: 2023-06-06 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: SZ DJI TECHNOLOGY CO., LTD Company Name: DJI Research LLC Grantee Code: SS3 FRN: 0033569757 Contact Name: Gary Zeng Contact Name: Jie Shen Address: Lobby of T2, DJI Sky City, No 53 Xianyuan Road, Xili Community,Xili Street,Nanshan District, Address: 435 Portage Ave, Palo Alto, CA 94306 City/Province/Zip: Shenzhen City/Province/Zip: Palo Alto/California/94306 Telephone: 8675586152250 Telephone: 530-574-9905 Fax: +86 755 86965903 Fax: Email: [email protected] Email: [email protected] ATTN: Director of Certification: We, < SZ DJI TECHNOLOGY CO., LTD > and < DJI Research LLC > understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, < SZ DJI TECHNOLOGY CO., LTD > and < DJI Research LLC > acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Gary Zeng Name (Printed): Jie Shen Title: PM Title: General Manager Signature: Signature:

SZ DJI TECHNOLOGY CO., LTD. Date: 2023/6/12 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: SS3-RD241608RF To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with << SZ DJI TECHNOLOGY CO., LTD.>>. This authorization is valid until further written notice from the applicant. Name (Printed): Gary Zeng Title: PM Signature: On behalf of Company: SZ DJI TECHNOLOGY CO., LTD. Telephone: +8675586152250

SZ DJI TECHNOLOGY CO., LTD. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: SZ DJI TECHNOLOGY CO., LTD. Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Regarding: Confidentiality Request regarding application for FCC ID: SS3-RD241608RF LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name: Gary Zeng Title: PM Company Name: SZ DJI TECHNOLOGY CO., LTD.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 External Photos for KSCR2305000771AT Test Model: RD241608RF Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4

Compliance Certification Services (Kunshan) Inc. Page: 1 of 7 Internal Photos for KSCR2305000771AT Test Model: RD241608RF Compliance Certification Services (Kunshan) Inc. Page: 2 of 7 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 7 Compliance Certification Services (Kunshan) Inc. Page: 4 of 7 Antenna for Omnidirectional radar Compliance Certification Services (Kunshan) Inc. Page: 5 of 7 Compliance Certification Services (Kunshan) Inc. Page: 6 of 7 Compliance Certification Services (Kunshan) Inc. Page: 7 of 7 Antenna for Upward radar

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077103 Page: 1 of 8 Eric Lin Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2305000771AT FCC ID: SS3-RD241608RF IC: 11805A-RD241608RF Applicant: SZ DJI TECHNOLOGY CO., LTD. Address of Applicant: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Manufacturer: SZ DJI TECHNOLOGY CO., LTD. Address of Manufacturer: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Factory: DJI Baiwang Technology Company Ltd. Address of Factory: Room 101, Building 12, Baiwangxin Industrial Park, 1002 Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Equipment Under Test (EUT): EUT Name: Forward Phased Array Radar Model No.: RD241608RF Trade Mark: DJI Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D01 interim General RF Exposure Guidance v06 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Date of Receipt: 2023-05-06 Date of Test: 2023-05-08 to 2023-05-19 Date of Issue: 2023-05-26 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077103 Page: 2 of 8 Revision Record Version Description Date Remark 00 Original 2023-05-26 / Authorized for issue by: Pawn Liu/Project Engineer Eric Lin/Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077103 Page: 3 of 8 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................ 5 3.4 TEST FACILITY .............................................................................................................................. 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 6 5 IC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ............................................................. 6 6 MEASUREMENT AND CALCULATION ............................................................................................ 7 6.1 MAXIMUM TRANSMIT POWER ......................................................................................................... 7 6.2 RF EXPOSURE CALCULATION ........................................................................................................ 8 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077103 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Power supply: DC 15V 3.2 Details of E.U.T. Operation Frequency Range: 24.05GHz to 24.25GHz Channel Number: 1 Modulation： FMCW Antenna type： Antenna for Omnidirectional radar: Linear Antenna Antenna for Upward radar: Linear Antenna Antenna Gain: Antenna Gain for Omnidirectional radar: 10dBi (Provided by the manufacturer) Antenna Gain for Upward radar:10dBi (Provided by the manufacturer) SN: 63MDL34001X8EL Firmware Version: V00.00.00.01 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077103 Page: 5 of 8 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 2324E • VCCI The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-20134, R-11600, C-11707, T-11499, G-10216 respectively. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077103 Page: 6 of 8 4 FCC Radiofrequency radiation exposure limits According to§1.1310, the limit for general population/uncontrolled exposures Frequency Power density(mW/cm 2 ) Averaging time(minutes) 300MHz~1.5GHz f/1500 30 1.5GHz~100GHz 1.0 30 5 IC Radiofrequency radiation exposure limits: According to RSS-102 section 2.5.2, RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: below 20…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077102 Page: 1 of 52 Eric Lin Laboratory Manager TEST REPORT Application No.: KSCR2305000771AT FCC ID: SS3-RD241608RF IC: 11805A-RD241608RF Applicant: SZ DJI TECHNOLOGY CO., LTD. Address of Applicant: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Manufacturer: SZ DJI TECHNOLOGY CO., LTD. Address of Manufacturer: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Factory: DJI Baiwang Technology Company Ltd. Address of Factory: Room 101, Building 12, Baiwangxin Industrial Park, 1002 Songbai Road, Sunshine Community, Xili Street, Nanshan District, Shenzhen Equipment Under Test (EUT): EUT Name: Forward Phased Array Radar Model No.: RD241608RF Trade Mark: DJI Standard(s) : 47 CFR Part 15, Subpart C 15.249 RSS-210 Issue 10 Amendment (April 2020) RSS-Gen Issue5 Amendment 2 (February 2021) Date of Receipt: 2023-05-06 Date of Test: 2023-05-08 to 2023-05-19 Date of Issue: 2023-05-26 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077102 Page: 2 of 52 Revision Record Version Description Date Remark 00 Original 2023-05-26 / Authorized for issue by: Pawn Liu/Project Engineer Eric Lin/Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077102 Page: 3 of 52 2 Test Summary Radio Spectrum Technical Requirement Item FCC Requirement IC Requirement Method Result Antenna Requirement 47 CFR Part 15, Subpart C 15.249 RSS-Gen Clause 6.8 N/A Pass N/A: Not applicable Radio Spectrum Matter Part Item FCC Requirement IC Requirement Method Result 20dB Emission bandwidth 47 CFR Part 15, Subpart C 15.249 RSS-210 Issue 10 Amendment (April 2020) Annex B 10 ANSI C63.10 (2013) Section 6.9 Pass Filed strength of fundamental 47 CFR Part 15, Subpart C 15.249 RSS-210 Issue 10 Amendment (April 2020) Annex B 10 ANSI C63.10 (2013) Section 6.6 Pass Radiation Spurious Emission 47 CFR Part 15, Subpart C 15.249 RSS-210 Issue 10 Amendment (April 2020) Annex B 10 ANSI C63.10 (2013) Section 6.6 Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.249 RSS-210 Issue 10 Amendment (April 2020) Annex B 10 ANSI C63.10 (2013) Section 6.10 Pass 99% Bandwidth N/A RSS-Gen Section 6.7 RSS-Gen Section 6.7 Pass Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077102 Page: 4 of 52 3 Contents Page 1 COVER PAGE.............................................................................................................................................. 1 2 TEST SUMMARY ......................................................................................................................................... 3 3 CONTENTS .................................................................................................................................................. 4 4 GENERAL INFORMATION ......................................................................................................................... 5 4.1 DETAILS OF E.U.T.................................................................................................................................. 5 4.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY ................................................................................................................ 5 4.4 TEST LOCATION ..................................................................................................................................... 6 4.5 TEST FACILITY ....................................................................................................................................... 6 4.6 DEVIATION FROM STANDARDS ................................................................................................................ 6 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 6 5 EQUIPMENT LIST ....................................................................................................................................... 7 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ................................................................................... 8 6.1 ANTENNA REQUIREMENT ........................................................................................................................ 8 7 RADIO SPECTRUM MATTER TEST RESULTS ........................................................................................ 9 7.1 20DB BANDWIDTH .................................................................................................................................. 9 7.2 99% BANDWIDTH ................................................................................................................................. 12 7.3 FILED STRENGTH OF FUNDAMENTAL AND RADIATION SPURIOUS EMISSION ............................................. 15 7.4 RADIATED EMISSIONS WHICH FALL IN THE RESTRICTED BANDS ................................................................ 41 8 TEST SETUP PHOTO ............................................................................................................................... 52 9 EUT CONSTRUCTIONAL DETAILS (EUT PHOTOS) .............................................................................. 52 Compliance Certification Services (Kunshan) Inc. Report No.: KSCR230500077102 Page: 5 of 52 4 General Information 4.1 Details of E.U.T. Power supply: DC 15V Test voltage: DC 15V Operation Frequency Range: 24.05GHz to 24.25GHz Channel Number: 1 Modulation： FMCW Antenna type： Antenna for Omnidirectional radar: Linear Antenna Antenna for Upward radar: Linear Antenna Antenna Gain: Antenna Gain for Omn…

Text truncated - open the document above for the full version.

Justification statement for Antenna To: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: SS3-RD241608RF Dear Sir/Madam, Only radiated measurements are used for EUT with FCC ID: SS3-RD241608RF to show compliance with FCC limits for fundamental and spurious emissions. All measurements were performed radiated and therefore additional antenna gain documentation is not required. The detailed information for antenna as below shows: Antenna for Omnidirectional radar： Design Specifications Typical Antenna Type Linear Antenna Working Frequency 24050-24250MHz Antenna for Upward radar： Design Specifications Typical Antenna Type Linear Antenna Working Frequency 24050-24250MHz

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2305000771AT Test Model No.: RD241608RF Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo RF Radiated Test Below 1GHz RF Radiated Test (1-18GHz) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 RF Radiated Test (18-40GHz) RF Radiated Test (Above 40GHz)
