Agras T25 Quick Start Guide v1.0 2022.12 Aircraft The Agras T25 aircraft has a truss-style body that comes with pitched arms that can be folded, making it easier to transport. The integrated spraying system can quickly transform into the spreading configuration with a spreading payload of 25 kg. The aircraft is equipped with the phased array radar system and binocular vision system, including downward and forward binocular vision, forward and rear phased array radar. The systems provide 360-degree omnidirectional obstacle sensing to ensure operational safety. The ultra HD FPV camera with a tiltable gimbal can automatically collect HD field images for local offline reconstruction to assist precise field planning. The Coaxial Dual Propeller structure brings a strong wind field. Pesticides can penetrate thick canopies to allow thorough spraying. The spraying system is equipped with the Magnetic Drive Impeller Pump, Dual Atomized Sprinkler, Anti-Drip Centrifugal Valve and solenoid valve, to ensure more efficient and precise pesticide spraying, as well as save liquid pesticide. The spraying system can be upgraded with two more sprinklers to meet different operation scenarios. Using the T25 Preparing the Intelligent Flight Battery Only use official DJI flight batteries. Check the battery level before flying and charge according to the corresponding manual document. Preparing the Aircraft 1. Propellers 2. Motors 3. ESCs 4. Aircraft Front Indicators (on two front arms) 5. Frame Arms 6. Folding Detection Sensors (built-in) 7. Spray Lance 8. Sprinklers 9. Spread Tank 10. Delivery Pumps 11. FPV PTZ camera 12. Downward Binocular Vision 13. Forward Binocular Vision 14. Spotlights 15. Forward Phased Array Radar 16. Rear Phased Array Radar 17. Landing Gear 18. Intelligent Flight Battery 19. Onboard D-RTK TM Antennas 20. Internal OCUSYNC TM Image Transmission Antennas 21. External OcuSync Image Transmission Antennas 22. Aircraft Status Indicators (on two rear arms) Unfold the M3 and M4 arms, and fasten the two arm locks. Avoid pinching fingers. Unfold the M1 and M2 arms, and fasten the two arm locks. Avoid pinching fingers. Unfold the propeller blades. Insert the Intelligent Flight Battery into the aircraft until you hear a click.  Make sure that the battery is firmly inserted into the aircraft. Only insert or remove the battery when the aircraft is powered off.  To remove the battery, press and hold the clamp and lift the battery up.  Fold the M1 and M2 arms followed by the M3 and M4 arms. Otherwise, the arms may be damaged. Getting Ready for Takeoff A. Place the aircraft on open, flat ground with the rear of the aircraft facing toward you. B. Make sure that the propellers are securely mounted, there are no foreign objects in or on the motors and propellers, the propeller blades and arms are unfolded, and the arm locks are firmly fastened. C. Make sure that the spray tank and flight battery are firmly in place. E. Power on the remote controller, make sure that the DJI Agras app is open, and power on the aircraft. Tap Start in the home screen of the app to enter Operation View. Make sure that the GNSS signals are strong and the screen shows Ready to GO (GNSS) or Ready to GO (RTK). Otherwise, the aircraft cannot take off. RTK positioning is recommended. In the app, go to Operation View, tap > RTK, and select a method for receiving RTK signals. Calibrating the Flow Meter Make sure to calibrate the flow meter in the following situations: Change liquid payload with different viscosity. The difference between the actual area and planned area is more than 15% after the first operation. Calibrating procedure A. Get Ready to Calibrate ① Fill the spray tank with approximately 2 L of water. ② Press the Spray button to start or stop spraying manually in order to exhaust air. B. Calibrating the flow meter ① In the app, go to Operation View, tap > , then tap Calibration on the right of the flow meter calibration section. ② Tap Start Calibration and calibration will start automatically. The result of the calibration will be displayed in the app when completed. ● After calibrating successfully, users can proceed with the operation. ● If calibration fails, tap the reminder to view and resolve the problem. Afterwards, recalibrate and wait for successful calibration. Flight In order for the aircraft to automatically take off and perform an operation, it is recommended to creat a plan for a field and select an operation before takeoff. Refer to the Starting Operations section for more information. For other scenarios, take off and land manually as follows. Takeoff Perform a Combination Stick Command (CSC) and push the throttle stick up to take off. Landing Push the throttle stick down until the aircraft lands. There are two methods to stop the motors after landing. Method 1: When the aircraft has landed, push and hold the throttle stick down. The motors will stop after three seconds. Method 2: When the aircraft has landed, push the throttle stick down, and perform the same CSC that was used to start the motors. Release both sticks once the motors have stopped.  Spinning propellers can be dangerous. Stay away from spinning propellers and motors. DO NOT start the motors in confined spaced or where there are people nearby.  Maintain control of the remote controller as long as the motors are running.  DO NOT stop the motors mid-flight. Otherwise, the aircraft will be crashed. Stop the motors only in an emergency situation to reduce the risk of damage or injury.  It is recommended to use Method 1 to stop the motors. When using the Method 2 to stop the motors, the aircraft may roll over if it is not completely grounded. Use Method 2 with caution. O R Throttle Stick (left stick in Mode 2)  After landing, power off the aircraft before turning off the remote controller. Starting Operations Users can perform aerial surveying for the operation area in the DJI Agras app, receive an HD map via offline reconstruction in the rem…

Text truncated - open the document above for the full version.

Agras T50 Quick Start Guide v1.0 2022.12 Aircraft The Agras T50 aircraft has an anti-torsion structure, offering reliable operations. The integrated spraying system can quickly transform into the spreading configuration with a spreading payload of up to 50 kg. The aircraft is equipped with the phased array radar system and binocular vision system, including downward and forward binocular vision, forward and rear phased array radar. The systems provide 360-degree omnidirectional obstacle sensing to ensure operational safety. The ultra HD FPV camera with a tiltable gimbal can automatically collect HD field images for local offline reconstruction to assist precise field planning. The Coaxial Dual Propeller structure brings a strong wind field. Pesticides can penetrate thick canopies to allow thorough spraying. The spraying system is equipped with the Magnetic Drive Impeller Pump, Dual Atomized Sprinkler, Anti-Drip Centrifugal Valve and solenoid valve, to ensure more efficient and precise pesticide spraying, as well as save liquid pesticide. The spraying system can be upgraded with two more sprinklers to meet different operation scenarios. Using the T50 Preparing the Intelligent Flight Battery Only use official DJI flight batteries. Check the battery level before flying and charge according to the corresponding manual document. Preparing the Aircraft 1. Propellers 2. Motors 3. ESCs 4. Aircraft Front Indicators (on two front arms) 5. Frame Arms 6. Folding Detection Sensors (built-in) 7. Spray Lance 8. Sprinklers 9. Spread Tank 10. Delivery Pumps 11. FPV PTZ camera 12. Downward Binocular Vision 13. Forward Binocular Vision 14. Spotlights 15. Forward Phased Array Radar 16. Rear Phased Array Radar 17. Landing Gear 18. Intelligent Flight Battery 19. Onboard D-RTK TM Antennas 20. Internal OCUSYNC TM Image Transmission Antennas 21. External OcuSync Image Transmission Antennas 22. Aircraft Status Indicators (on two rear arms) Unfold the M3 and M4 arms, and fasten the two arm locks. Avoid pinching fingers. Unfold the M1 and M2 arms, and fasten the two arm locks. Avoid pinching fingers. Unfold the propeller blades. Insert the Intelligent Flight Battery into the aircraft until you hear a click.  Make sure that the battery is firmly inserted into the aircraft. Only insert or remove the battery when the aircraft is powered off.  To remove the battery, press and hold the clamp and lift the battery up.  Fold the M1 and M2 arms followed by the M3 and M4 arms. Otherwise, the arms may be damaged. Getting Ready for Takeoff A. Place the aircraft on open, flat ground with the rear of the aircraft facing toward you. B. Make sure that the propellers are securely mounted, there are no foreign objects in or on the motors and propellers, the propeller blades and arms are unfolded, and the arm locks are firmly fastened. C. Make sure that the spray tank and flight battery are firmly in place. E. Power on the remote controller, make sure that the DJI Agras app is open, and power on the aircraft. Tap Start in the home screen of the app to enter Operation View. Make sure that the GNSS signals are strong and the screen shows Ready to GO (GNSS) or Ready to GO (RTK). Otherwise, the aircraft cannot take off. RTK positioning is recommended. In the app, go to Operation View, tap > RTK, and select a method for receiving RTK signals. Calibrating the Flow Meter Make sure to calibrate the flow meter in the following situations: Change liquid payload with different viscosity. The difference between the actual area and planned area is more than 15% after the first operation. Calibrating procedure A. Get Ready to Calibrate ① Fill the spray tank with approximately 2 L of water. ② Press the Spray button to start or stop spraying manually in order to exhaust air. B. Calibrating the flow meter ① In the app, go to Operation View, tap > , then tap Calibration on the right of the flow meter calibration section. ② Tap Start Calibration and calibration will start automatically. The result of the calibration will be displayed in the app when completed. ● After calibrating successfully, users can proceed with the operation. ● If calibration fails, tap the reminder to view and resolve the problem. Afterwards, recalibrate and wait for successful calibration. Flight In order for the aircraft to automatically take off and perform an operation, it is recommended to creat a plan for a field and select an operation before takeoff. Refer to the Starting Operations section for more information. For other scenarios, take off and land manually as follows. Takeoff Perform a Combination Stick Command (CSC) and push the throttle stick up to take off. Landing Push the throttle stick down until the aircraft lands. There are two methods to stop the motors after landing. Method 1: When the aircraft has landed, push and hold the throttle stick down. The motors will stop after three seconds. Method 2: When the aircraft has landed, push the throttle stick down, and perform the same CSC that was used to start the motors. Release both sticks once the motors have stopped.  Spinning propellers can be dangerous. Stay away from spinning propellers and motors. DO NOT start the motors in confined spaced or where there are people nearby.  Maintain control of the remote controller as long as the motors are running.  DO NOT stop the motors mid-flight. Otherwise, the aircraft will be crashed. Stop the motors only in an emergency situation to reduce the risk of damage or injury.  It is recommended to use Method 1 to stop the motors. When using the Method 2 to stop the motors, the O R Throttle Stick (left stick in Mode 2) aircraft may roll over if it is not completely grounded. Use Method 2 with caution.  After landing, power off the aircraft before turning off the remote controller. Starting Operations Users can perform aerial surveying for the operation area in the DJI Agras app, receive an HD map via offline reconstruction in the remote controller. Field planning and i…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name SZ DJI TECHNOLOGY CO., LTD Address Lobby of T2, DJI Sky City, No 53 Xianyuan Road, Xili Community,Xili Street,Nanshan District,Shenzhen, China Grantee Code SS3 FCC ID SS3-T50A2303 Authorized Contact Name Gary Zeng Contact Email [email protected] Contact Phone 8675586152250 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [SZ DJI TECHNOLOGY CO., LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [SZ DJI TECHNOLOGY CO., LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date:2023-06-29 Print Name: Gary Zeng Title: PM *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATED AGENT LETTER Date: 2023-06-06 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: SZ DJI TECHNOLOGY CO., LTD Company Name: DJI Research LLC Grantee Code: SS3 FRN: 0033569757 Contact Name: Gary Zeng Contact Name: Jie Shen Address: Lobby of T2, DJI Sky City, No 53 Xianyuan Road, Xili Community,Xili Street,Nanshan District, Address: 435 Portage Ave, Palo Alto, CA 94306 City/Province/Zip: Shenzhen City/Province/Zip: Palo Alto/California/94306 Telephone: 8675586152250 Telephone: 530-574-9905 Fax: +86 755 86965903 Fax: Email: [email protected] Email: [email protected] ATTN: Director of Certification: We, < SZ DJI TECHNOLOGY CO., LTD > and < DJI Research LLC > understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, < SZ DJI TECHNOLOGY CO., LTD > and < DJI Research LLC > acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Gary Zeng Name (Printed): Jie Shen Title: PM Title: General Manager Signature: Signature:

SZ DJI TECHNOLOGY CO., LTD Date: 2023-07-10 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: SS3-T50A2303 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) and Keny Xu in SGS- CSTC Standards Technical Services Co., Ltd. (SGS) to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own.. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with SZ DJI TECHNOLOGY CO., LTD. This authorization is valid until further written notice from the applicant. Print Name: Gary Zeng Title: PM Signature: On behalf of Company: SZ DJI TECHNOLOGY CO., LTD Telephone: +8675586152250 E-mail: [email protected]

SZ DJI TECHNOLOGY CO., LTD TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: SS3-T50A2303 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions BOM List Software Security Description The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Print Name: Gary Zeng Title: PM Signature: On behalf of Company: SZ DJI TECHNOLOGY CO., LTD Telephone: +8675586152250 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 22 External Photos for SZCR2304001225AT FCC ID: SS3-T50A2303 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 22 EUT Constructional Details (EUT Photos) 3WWDZ-40B SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 22 3WWDZ-20B SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 6 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 7 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 8 of 22 BAX702-30000mAh-52.22V SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 9 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 10 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 11 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 12 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 13 of 22 BAX702-15500mAh-52.22V SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 14 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 15 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 16 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 17 of 22 24G Radar: Forward Phased Array Radar (RD241608RF) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 18 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 19 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 20 of 22 24G Radar: Rear Phased Array Radar (RD241608RB) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 21 of 22 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 22 of 22 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 26 Internal Photos for SZCR2304001225AT FCC ID: SS3-T50A2303 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 26 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 5 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 6 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 7 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 8 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 9 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 10 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 11 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 12 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 13 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 14 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 15 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 16 of 26 Antenna Location SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 17 of 26 24G Radar: Forward Phased Array Radar (RD241608RF) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 18 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 19 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 20 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 21 of 26 Antenna for Omnidirectional radar SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 22 of 26 Antenna for Single board radar SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 23 of 26 24G Radar: Rear Phased Array Radar (RD241608RB) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 24 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 25 of 26 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 26 of 26 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230400122504 Page: 1 of 12 Keny Xu EMC Laboratory Manager 1 Cover Page Test Report Application No.: SZCR2304001225AT Applicant: SZ DJI TECHNOLOGY CO., LTD. Address of Applicant: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Manufacturer: SZ DJI TECHNOLOGY CO., LTD. Address of Manufacturer: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Equipment Under Test (EUT): EUT Name: Agras T50/Agras T25 Model No.: 3WWDZ-40B, 3WWDZ-20B   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: DJI FCC ID: SS3-T50A2303 Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-04-26 Date of Test: 2023-05-06 to 2023-06-26 Date of Issue: 2023-06-28 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230400122504 Page: 2 of 12 Revision Record Version Chapter Date Modifier Remark 01 2023-06-28 Original Authorized for issue by: Darren Yuan/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230400122504 Page: 3 of 12 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 TEST LOCATION .......................................................................................................................... 10 3.4 TEST FACILITY ............................................................................................................................ 10 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS ........................................................ 11 5 MEASUREMENT AND CALCULATION .......................................................................................... 12 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230400122504 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: Powered by Lithium-Ion Polymer Rechargeable Battery Battery Information for 3WWDZ-40B Model: BAX702-30000mAh-52.22V Nominal Voltage: 52.22V Rated Capacity: 30000mAh, 1566.6Wh Battery Information for 3WWDZ-20B Model: BAX702-15500mAh-52.22V Nominal Voltage: 52.22V Rated Capacity: 15500mAh, 809.4Wh SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230400122504 Page: 5 of 12 2.4G SDR Operation Frequency: 1.4MHz: 2403.5MHz-2469.5MHz 1.4MHz CA: 2405.12MHz-2471.12MHz 3MHz: 2405.5MHz-2468.5MHz 3MHz CA: 2408.2MHz-2471.2MHz 10MHz: 2407.5MHz-2467.5MHz 20MHz: 2412.5MHz-2462.5MHz 40MHz: 2422.5MHz-2452.5MHz Modulation Type: OFDM Channel Spacing: 1.4MHz: 2MHz 1.4MHz CA: 2MHz 3MHz: 3MHz 3MHz CA: 3MHz 10MHz: 1MHz 20MHz: 1MHz 40MHz: 1MHz Number of Channels: 1.4MHz: 34 1.4MHz CA: 34 3MHz: 22 3MHz CA: 22 10MHz: 61 20MHz: 51 40MHz: 31 Antenna Type: Dipole Antenna Antenna Gain: ANT0&ANT1&ANT2&ANT3: 2.5dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230400122504 Page: 6 of 12 5.8G SDR Operation Frequency: 1.4MHz: 5728.5MHz-5846.5MHz 1.4MHz CA: 5730.12MHz-5848.12MHz 3MHz: 5727.5MHz-5844.5MHz 3MHz CA: 5730.2MHz-5847.2MHz 10MHz: 5730.5MHz-5844.5MHz 20MHz: 5735.5MHz-5839.5MHz 40MHz: 5745.5MHz-5829.5MHz Modulation Type: OFDM Channel Spacing: 1.4MHz: 2MHz 1.4MHz CA: 2MHz 3MHz: 3MHz 3MHz CA: 3MHz 10MHz: 1MHz 20MHz: 1MHz 40MHz: 1MHz Number of Channels: 1.4MHz: 60 1.4MHz CA: 60 3MHz: 40 3MHz CA: 40 10MHz: 115 20MHz: 105 40MHz: 85 Antenna Type: Dipole Antenna Antenna Gain: ANT0&ANT1&ANT2&ANT3: 2dBi SGS-CSTC Standards Technical Services Co., Ltd. Shen…
