SS3-T7402206INSPIRE 3

T740 Quick Start Guide Aircraft You are able to shoot multi-angle and high specification photos and create great content with the aircraft. Overview 1. Power Button 2. Battery 3. SSD Slot 4. Gimbal Connector 1. Gimbal Release Button 2. Gimbal Lock 3. USB-C Port (for data transmission) 4. Screw Socket 5. Earphone Jack 6. Auxiliary Bottom Light 7. USB-C Port (for LiDAR module) 8. USB-C Port (for 4G dongle) Aircraft Modes Remote Controller The DJI RC Plus remote controller can transmit a live HD view from the camera of an aircraft to display on the touchscreen. 1. External RC Antennas 2. Touchscreen 3. Indicator Button 4. Control Sticks 5. Internal Wi-Fi Antennas 6. Back/Function Button 7. L1/L2/L3/R1/R2/R3 Buttons 8. Return to Home (RTH) Button 9. Microphones 10. Status LED 11. Battery Level LEDs 12. Internal GNSS Antennas 13. Power Button 14. 5D Button 15. Flight Pause Button 16. C3 Button (customizable) 17. Left Dial 18. Record Button 19. Flight Mode Switch 20. Internal RC Antennas 21. microSD Card Slot 22. USB-A Port 23. HDMI Port 24. USB-C Port 25. Focus/Shutter Button 26. Right Dial 27. Scroll Wheel 28. Handle 29. Speaker 30. Air Vent 31. Reserved Mounting Holes 32. C1 Button (customizable) 33. C2 Button (customizable) 34. Rear Cover 35. Battery Release Button 36. WB37 Intelligent Battery 37. Rear Cover Release Button 38. Alarm 39. Air Intake 40. Dongle Compartment 41. Remote Controller Strap Bracket Preparing the Remote Controller Check battery level: press once. Power on/off: press and then press and hold. The remote controller needs to be activated before using for the first time. Follow the prompts to activate. Preparing the Aircraft a. Insert the batteries; b. Press the power button a minimum of five times. The aircraft will be transformed to the Landing Mode. Mount the Gimbal and Camera a. Press and hold the release button and rotate the gimbal lock counter-clockwise to remove the gimbal connector cover. b. Align the white and red dots and insert the gimbal. c. Rotate the gimbal lock to the locked position. Installing the SSD Getting Ready for Takeoff Linking a. Power on the remote controller and the aircraft. b. Open DJI Pilot and follow the on-screen instructions. Attaching the Propellers Attach the propellers with marks to the motors with marks and the unmarked propellers to the motors without marks. Press each propeller down onto the motor and turn until it is secure. Flight Control Stick Mode The default control stick mode is Mode 2. The left control stick controls the altitude and heading of the aircraft while the right control stick controls the forward, backward, and sideward movements. Manual Takeoff/Landing 1. Start/stop motors: perform combination stick command. 2. Takeoff: slowly push the left control stick (Mode 2) up to take off. 3. Landing: slowly push the left control stick (Mode 2) down until the aircraft lands. Hold for three seconds to stop the motors. Specifications Aircraft (Model: T740) Operating Temperature -20°C to 40°C O3 Pro Operating Frequency 2.400-2.4835 GHz, 5.150-5.250GHz， 5.725-5.850 GHz Battery (Model: BWX630-4280-23.1) Capacity 4280 mAh Standard Voltage 23.1 V Charging Temperature 5°C to 40°C Max Power Rate 203 W Battery Safety Notice • DO NOT allow liquid to come into contact with the batteries. DO NOT leave batteries covered in moisture or out in the rain. DO NOT drop the batteries into water. Otherwise, an explosion or fire may occur. • DO NOT use non-DJI batteries. It is recommended to use DJI chargers. • DO NOT use swollen, leaking, or damaged batteries. In such situations, contact DJI or a DJI authorized dealer. • The batteries should be used at a temperature between -10° and 40° C (14° and 104° F). A high temperature can cause an explosion or fire. A low temperature will reduce the performance of a battery. • DO NOT disassemble or pierce the battery in any way. • The electrolytes in the battery are highly corrosive. If any electrolytes come into contact with your skin or eyes, immediately wash the affected area with water and seek medical support. • Keep batteries out of the reach of children and animals. • DO NOT use a battery if it is involved in a crash or heavy impact. • Extinguish any battery fire using water, sand, or a dry powder fire extinguisher. • DO NOT charge the battery immediately after flight. The battery temperature may be too high and may cause serious damage to the battery. Allow the battery to cool down to close to room temperature before charging. Charge the battery at a temperature range of 5° to 40° C (41° to 104° F). The ideal charging temperature range is 22° to 28° C (72° to 82° F). Charging at the ideal temperature range can prolong battery life. • DO NOT leave the battery near heat sources such as a furnace or heater. DO NOT leave the battery inside a vehicle on hot days. • DO NOT store the battery for an extended period after fully discharging. Otherwise, the battery may over-discharge and cause irreparable damage to the battery cell. • If a battery with a low power level has been stored for an extended period, the battery will enter deep hibernation mode. Recharge the battery to bring it out of hibernation. FCC Compliance Notice Supplier’s Declaration of Conformity Product name: INSPIRE 3 Model Number: T740 Responsible Party: DJI Technology, Inc. Responsible Party Address: 201 S. Victory Blvd., Burbank, CA 91502 Website: www.dji.com We, DJI Technology, Inc., being the responsible party, declares that the above mentioned model was tested to demonstrate complying with all applicable FCC rules and regulations. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate…

Text truncated - open the document above for the full version.

SZ DJI TECHNOLOGY CO., LTD. Certification Designating a US Agent for Service of Process To: Federal Communications Commission Date: 4/12/2023 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: SS3-T7402206 SZ DJI TECHNOLOGY CO., LTD. (“the applicant”) certifies that as of the date of the filing of the application, DJI Research LLC (“the agent”) is our designated U.S. agent. We acknowledge the applicant’s consent and the designated agent for service of process’s obligation to accept service of process. The applicant accepts to maintain an agent for service of process for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. APPLICANT Company Name: SZ DJI TECHNOLOGY CO., LTD. Contact Person: Gary Zeng Address: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Tel.: 86 755 26656677 Email: [email protected] FCC FRN: 0022596753 U.S. Agent Company Name: DJI Research LLC Contact Name: Jinyu Guo Address: 435 Portage Ave, Palo Alto, CA 94306 Phone No.: 530-574-9905 Email Address: [email protected] FCC FRN: 0033569757 Sincerely yours, The Applicant The Agent Company Name SZ DJI TECHNOLOGY CO., LTD. DJI Research LLC Contact Person Gary Zeng Jinyu Guo Signature

SZ DJI TECHNOLOGY CO., LTD. Attestation Statements Not Covered Entity Applicant To: Federal Communications Commission Date: 4/12/2023 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(ii) filing FCC ID: SS3-T7402206 [SZ DJI TECHNOLOGY CO., LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely yours, Applicant Signature Printed Name: Gary Zeng Title: Compliance Manager Address: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Tel.: 86 755 26656677 Email: [email protected]

SZ DJI TECHNOLOGY CO., LTD. Attestation Statements Not Covered Equipment To: Federal Communications Commission Date: 4/12/2023 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) filing FCC ID: SS3-T7402206 [SZ DJI TECHNOLOGY CO., LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Gary Zeng Title: Compliance Manager Address: Lobby of T2, DJI Sky City, No. 53 Xianyuan Road, Xili Community, Xili Street, Nanshan District, Shenzhen, China. Tel.: 86 755 26656677 Email: [email protected]

TCB Authority to Act as Agent Number: MS-0045317 Revision: 0 Effective date: Oct 8, 2021 Page 1 of 1 Authority to Act as Agent Date: 9 Januar 2023 TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint TUV Rheinland (Shenzhen) Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with SZ DJI TECHNOLOGY CO., LTD. / 14th Floor, West Wing, Skyworth Semiconductor Design Building No.18 Gaoxin South 4th Ave Nanshan District, Shenzhen, P.R. China For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: 12 Months Agreement is valid for 12 months from the above date. By: __________________________ Gary Zeng (Signature) (Print name) Certification Manager Tel:+8675586152250 (Title) (Telephone) On behalf of: SZ DJI TECHNOLOGY CO., LTD. (Company Name)

第 1 页 共 12 页 WM630 SDR Ant Datasheet ANT Engineer： Freeman.deng(SDR) 第 2 页 共 12 页 Antenna Datasheet 1 Basic Specifications No. Specification Descriptions Notes 1 Antenna Name WM630 SDR Ant Only sale for DJI 2 Brand DJI 3 Operation Frequency 2.4~2.483GHz; 5.15~5.25GHz; 5.725~5.85GHz; 4 Connector Type SMA 5 Impedance 50ohm 6 Gain [email protected]~2.483GHz 2dBi @5.15~5.25GHz; 2.5dBi @5.725~5.85GHz 7 Efficiency ≥50% 8 VSWR ≤2.5 9 Polarization type Linear 10 3dB Beamwidth Omnidirectional 11 Manufacturer Shenzhen ZTX Communication Technology Co., LT D . 2 Antenna Return Loss/VSWR No.34 Shilong Road, Bao'an District, Shenzhen, China 第 3 页 共 12 页 3 Antenna Gain Frequency Efficiency Gain(dBi) 2400MHz 58% 1.92143 2410MHz 59% 2.01237 2420MHz 54% 1.86028 2450MHz 59% 1.90777 2470MHz 52% 1.96167 2480MHz 53% 1.87167 Frequency Efficiency Gain(dBi) 5145MHz 33% 1.72534 5175MHz 35% 1.84122 5205MHz 32% 2.04267 5235MHz 28% 1.54286 5265MHz 31% 1.60078 Frequency Efficiency Gain(dBi) 5725MHz 57% 2.55116 5775MHz 59% 2.49269 5800MHz 56% 2.43893 5825MHz 59% 2.42121 5850MHz 54% 2.43672 4 Radiation Pattern Frequency Tangent Direction 2450MHz Ant0 (Phi90deg) 第 4 页 共 12 页 Ant1(Phi90d eg) Ant2(Phi90d eg) Ant3(Phi90d eg) 第 5 页 共 12 页 Ant0 (Phi0deg) Ant1 (Phi0deg) 第 6 页 共 12 页 Ant2 (Phi0deg) 2450MHz Ant3 (Phi0deg) 5800MHz Ant0 (Phi90deg) 第 7 页 共 12 页 Ant1(Phi90 deg) Ant2(Phi90 deg) Ant3(Phi90 deg) 第 8 页 共 12 页 Ant0(Phi0d eg) Ant1(Phi0d eg) 第 9 页 共 12 页 Ant2(Phi0d eg) 5800MHz Ant3(Phi0d eg) 第 10 页 共 12 页 5200MHz Ant0 Ant1 第 11 页 共 12 页 Ant2 Ant3

Standard Form Request for Confidentiality Letter MS-0044715 Page 1 of 1 Revision 0 SZ DJI TECHNOLOGY CO., LTD. Confidentiality Letter Date: 13 January 2023 Subject: Confidentiality Request for FCC ID: SS3-T7402206 and IC: 11805A-T7402206 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Antenna datasheet Short Term Permanent Schematics/Parts list Short Term Permanent User’s Manual Short Term n/a Test Setup Short Term n/a External Photos SZ DJI TECHNOLOGY CO., LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: _________________________________ _______ Gary Zeng (Certification Manager)_________ (Signature/Title) (Print name)

ANT

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN224PNQ 004 Auftrags-Nr.: Order no.: 168371699 Seite 1 von 10 Page 1 of 10 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2022-05-11 Auftraggeber: Client: SZ DJI TECHNOLOGY CO., LTD. 14th Floor, West Wing, Skyworth Semiconductor Design Building No.18 Gaoxin South 4th Ave Nanshan District, Shenzhen, P.R. China Prüfgegenstand: Test item: INSPIRE 3 Bezeichnung / Typ-Nr.: Identification / Type no.: T740 (Trademark: DJI) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: FCC Part 2: Section 2.1091 Wareneingangsdatum: Date of sample receipt: 2022-05-19 Please refer to photo documents Prüfmuster-Nr.: Test sample no: A003258804-005~008 A003330976-003~006 Prüfzeitraum: Testing period: 2022-05-19 to 2022-09-19 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Breeze Jiang genehmigt von: authorized by: X Signed by: Lin Lin Datum: Date: 2022-11-21 Ausstellungsdatum: Issue date: 2022-11-21 Stellung / Position: Assistant Project Manager Stellung / Position: Reviewer Sonstiges / Other: FCC ID: SS3-T7402206 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com jjj Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN224PNQ 004 Seite 2 von 10 Page 2 of 10 TEST SUMMARY 3.1.1 RF EXPOSURE COMPLIANCE RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN224PNQ 004 Seite 3 von 10 Page 3 of 10 CONTENTS 1. TEST SITES ....................................................................................................................... 4 1.1 TEST FACILITIES ............................................................................................................... 4 1.2 TRACEABILITY .................................................................................................................. 4 1.3 CALIBRATION .................................................................................................................... 4 1.4 LOCATION OF ORIGINAL DATA ........................................................................................... 4 1.5 STATUS OF FACILITY USED FOR TESTING ........................................................................... 4 2. GENERAL PRODUCT INFORMATION .................................................................................... 5 2.1 GENERAL DESCRIPTION .................................................................................................... 5 2.2 RATING AND SYSTEM DETAILS ........................................................................................... 5 3. TEST RESULTS ................................................................................................................. 8 3.1 TRANSMITTER REQUIREMENTS & TEST SUITES ................................................................... 8 3.1.1 RF Exposure Compliance ............................................................................................................ 8 3.1.1.1 Radio Frequency Exposure Limit ................................................................................... 8 3.1.1.2 Radio Frequency Exposure Calculation Formula ........................................................... 9 3.1.1.3 Simultaneous transmission MPE .................................................................................... 9 3.1.1.4 Conclusion ...................................................................................................................... 9 4. LIST OF TABLES .............................................................................................................. 10 Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN224PNQ 004 Seite 4 von 10 Page 4 of 10 1. TEST SITES 1.1 TEST FACILITIES TÜV Rheinland (Shenzhen) Co., Ltd. 362 Huanguan Road Middle Longhua District, Shenzhen 518110 People’s Republic of China FCC Registration No.: 694916 ISED wireless device testing laboratory: 25069 A2LA Certificate Number: 5162.01 1.2 Traceability All measurement equipment calibrations are traceable to NIST or where calibration is performed outside the United States, to equivalent nationally recognized standards organizations. 1.3 Calibration Equipment requiring calibration is calibrated periodically by the manufacturer or according to manufacturer’s specifications. Additionally all equipment is verified for proper performance on a regular basics using in house standards or comparisons. 1.4 Location of Original Data The original copies of all test data taken during actual testing were attac…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN224PNQ 009 Auftrags-Nr.: Order no.: 168371699 Seite 1 von 19 Page 1 of 19 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2022-05-11 Auftraggeber: Client: SZ DJI TECHNOLOGY CO., LTD. 14th Floor, West Wing, Skyworth Semiconductor Design Building No.18 Gaoxin South 4th Ave Nanshan District, Shenzhen, P.R. China Prüfgegenstand: Test item: INSPIRE 3 Bezeichnung / Typ-Nr.: Identification / Type no.: T740 (Trademark: DJI) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart E Section 15.407 Wareneingangsdatum: Date of sample receipt: 2022-09-06 Please refer to photo documents Prüfmuster-Nr.: Test sample no: A003330976-003~006 Prüfzeitraum: Testing period: 2022-09-13 to 2022-09-19 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Breeze Jiang genehmigt von: authorized by: X Signed by: Lin Lin Datum: Date: 2022-11-21 Ausstellungsdatum: Issue date: 2022-11-21 Stellung / Position: Assistants Project Manager Stellung / Position: Reviewer Sonstiges / Other: FCC ID: SS3-T7402206 This report is for 5.2GHz SDR. Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com jjj Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN224PNQ 009 Seite 2 von 19 Page 2 of 19 TEST SUMMARY 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 MAXIMUM OUTPUT POWER RESULT: Pass 5.1.3 POWER SPECTRAL DENSITY RESULT: Pass 5.1.4 FREQUENCY STABILITY RESULT: Pass 5.1.5 26DB BANDWIDTH AND 99% BANDWIDTH RESULT: Pass 5.1.6 RADIATED SPURIOUS EMISSION RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN224PNQ 009 Seite 3 von 19 Page 3 of 19 TABLE OF CONTENTS 1. GENERAL REMARKS ......................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS .......................................................................................... 4 2. TEST SITES ...................................................................................................................... 5 2.1 TEST FACILITIES ............................................................................................................... 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS ............................................................... 5 2.3 TRACEABILITY .................................................................................................................. 6 2.4 CALIBRATION ................................................................................................................... 6 2.5 UNCERTAINTY OF MEASUREMENT ...................................................................................... 6 2.6 LOCATION OF ORIGINAL DATA ........................................................................................... 6 2.7 STATUS OF FACILITY USED FOR TESTING ........................................................................... 6 3. GENERAL PRODUCT INFORMATION .................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE ........................................................................... 7 3.2 RATINGS AND SYSTEM DETAILS ........................................................................................ 7 3.3 INDEPENDENT OPERATION MODES .................................................................................... 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ....................................................... 9 3.5 SUBMITTED DOCUMENTS .................................................................................................. 9 4. TEST SET-UP AND OPERATION MODES ............................................................................ 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION ...................................................................... 10 4.2 TEST OPERATION ........................................................................................................... 10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ........................................................ 10 4.4 COUNTERMEASURES TO ACHIEVE ERM COMPLIANCE ...................................................... 10 4.5 TEST SETUP DIAGRAM .................................................................................................... 11 5. TEST RESULTS ............................................................................................................... 12 5.1 RADIO TEST REQUIREMENT & TEST SUITES (5GHZ BANDS) .........................…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 1 of 75 Appendix A: Test Results of 5.2G SDR APPENDIX A: TEST RESULTS OF 5.2G SDR ...................................................................................................................... 1 APPENDIX A.1: TEST RESULTS OF CONDUCTED POWER SPECTRAL DENSITY ..................................................................................... 2 APPENDIX A.2: TEST RESULTS OF FREQUENCY STABILITY ............................................................................................................. 9 APPENDIX A.3: TEST RESULTS OF 26DB BANDWIDTH ............................................................................................................... 10 APPENDIX A.4: TEST RESULTS OF 99% BANDWIDTH ................................................................................................................. 14 APPENDIX A.5: TEST RESULTS OF RADIATED SPURIOUS EMISSIONS ............................................................................................. 18 30MHz - 1GHz (Worst case) ....................................................................................................................................... 18 1GHz - 18GHz .............................................................................................................................................................. 20 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 2 of 75 Note: All testing were carried out on SISO mode and MIMO mode, but only the worst case was presented in this report. Appendix A.1: Test Results of Conducted Power Spectral Density TestMode Antenna Channel Result[dBm/1MHz] Limit[dBm/1MHz] Verdict 10M 5157 Ant0 7.04 ≤11 PASS Ant3 6.80 ≤11 PASS Total 9.93 ≤11 PASS 5201 Ant0 6.63 ≤11 PASS Ant3 6.97 ≤11 PASS Total 9.81 ≤11 PASS 5245 Ant0 7.04 ≤11 PASS Ant3 6.80 ≤11 PASS Total 9.93 ≤11 PASS TestMode Antenna Channel Result [dBm/MHz] Limit[dBm/MHz] Verdict 20M Ant0 5161 4.39 ≤11.00 PASS Ant3 5161 4.15 ≤11.00 PASS total 5161 7.28 ≤11.00 PASS Ant0 5200 4.20 ≤11.00 PASS Ant3 5200 3.97 ≤11.00 PASS total 5200 7.10 ≤11.00 PASS Ant0 5240 4.06 ≤11.00 PASS Ant3 5240 3.40 ≤11.00 PASS total 5240 6.75 ≤11.00 PASS 40M Ant0 5170 1.16 ≤11.00 PASS Ant3 5170 0.99 ≤11.00 PASS total 5170 4.09 ≤11.00 PASS Ant0 5200 1.14 ≤11.00 PASS Ant3 5200 1.05 ≤11.00 PASS total 5200 4.11 ≤11.00 PASS Ant0 5230 1.36 ≤11.00 PASS Ant3 5230 0.69 ≤11.00 PASS total 5230 4.05 ≤11.00 PASS Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 3 of 75 10M_Ant0_5157 10M_Ant3_5157 10M_Ant0_5201 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 4 of 75 10M_Ant3_5201 10M_Ant0_5245 10M_Ant3_5245 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 5 of 75 20M_MIMO_Ant0_5161 20M_MIMO_Ant3_5161 20M_MIMO_Ant0_5200 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 6 of 75 20M_MIMO_Ant3_5200 20M_MIMO_Ant0_5240 20M_MIMO_Ant3_5240 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 7 of 75 40M_MIMO_Ant0_5170 40M_MIMO_Ant3_5170 40M_MIMO_Ant0_5200 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 8 of 75 40M_MIMO_Ant3_5200 40M_MIMO_Ant0_5230 40M_MIMO_Ant3_5230 Prüfbericht - Produkte Test Report - Products Appendix A CN224PNQ 009 Page 9 of 75 Appendix A.2: Test Results of Frequency Stability Voltage TestMode Antenna Channel Voltage [Vdc] Temperature (°C) Dev…
