SS3-TP14061504DJI MATRICE 100

SZ DJI TECHNOLOGY CO., LTD
DJI MATRICE 100 - FCC ID SS3-TP14061504 - SZ DJI TECHNOLOGY CO., LTD
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jun 04, 2015
Application Purpose
Original Equipment
Date of Application
Jun 04, 2015
Equipment Note
DJI MATRICE 100
Frequency Range
2406.50000000 - 2476.50000000
Company
SZ DJI TECHNOLOGY CO., LTD
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

©2015 DJI. All Rights Reserved. 1 DJI Matrix 100 User Manual V 1.0 2015.5 www.dji.com ©2015 DJI. All Rights Reserved. 2 Using this manual Legend Warning Important Hints and Tips Reference Before Flight The following tutorials and manuals have been produced to ensure you to make full use of your M100. 1. Safety Guidelines and Disclaimer 2. M100 User Manual 3. In the Box 4. Intelligent Flight Battery Safety Guidelines Reading the Safety Guidelines and Disclaimer before flight is recommended. Refer to this manual for more comprehensive information. Download the DJI Pilot app Download and install the DJI Pilot app before use. Scan the QR code or visit “http://m.dji.net/djipilot” to download the app. For the best experience, use mobile device with Android V 4.1.2 or above. Requires iOS 8.0 or later. ©2015 DJI. All Rights Reserved. 3 Warnings When flying, the rotating propellers may cause serious damage and injury. Please fly safely at all times. Assembly Warnings (1) Ensure that all parts are installed before inserting the Intelligent Flight Battery. (2) Use a bracket to mount the GPS module onto the center frame to avoid interference with the power board. (3) Ensure frame arms are mounted correctly. (4) Do not remove any glued-in screws. (5) Screws that already have blue glue can be used once without thread locker. On other occasions, apply appropriate thread locker first. Flight Warnings (1) ESCs are not waterproof, please do not fly in rain or snow. (2) Ensure all parts are in good condition before each flight. Do not fly with worn or broken parts. (3) Ensure propellers and motors are installed correctly before flying. (4) Ensure all cables are secure before every flight. (5) When flying, maintain a safe distance away from people, buildings, high voltage power lines, tall trees, water and other hazards. (6) Use only DJI TB47D/TB48D Intelligent Flight Batteries as the power supply. (7) Do not overload the system. (8) Do not get close to or touch motors or propellers when they are spinning, as this can cause serious injury. (9) Disconnect the battery and remove the camera during transportation to avoid damage or injury. (10) Only use compatible DJI parts. If you encounter any problems or if you have any questions, please contact your local DJI authorized dealer or DJI Support. DJI Support Website: www.dji.com/support ©2015 DJI. All Rights Reserved. 4 Contents Using this manual ......................................................................................................................................................................................................... 2 Legend .................................................................................................................................................................................................................... 2 Before Flight ........................................................................................................................................................................................................ 2 Download the DJI Pilot app .......................................................................................................................................................................... 2 Warnings .......................................................................................................................................................................................................................... 3 Contents .......................................................................................................................................................................................................................... 4 Profile ................................................................................................................................................................................................................................ 6 In The Box ....................................................................................................................................................................................................................... 7 Checking Frame Arms (with the Landing Gear) ............................................................................................................................................ 11 Checking the Center Frame ................................................................................................................................................................................... 11 Mounting Frame Arms .............................................................................................................................................................................................. 13 Mounting the Battery Compartment and Wiring ......................................................................................................................................... 16 Recommended Mounting Position (under the center frame) ....................................................................................................... 16 Optional Mounting Position (on the center frame) ........................................................................................................................... 18 Wiring .................................................................................................................................................................................................................... 19 Mounting Expansion Bays ...................................................................................................................................................................................... 22 Mounting the GPS Module ................................................................................................................................................................................... 24 Reserved Ports Description ................…

Text truncated - open the document above for the full version.

External Photos

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – All View (Adapter Model: A14-100P1A) EUT – All View (Adapter Model: ADE018) EUT –Top View EUT –Bottom View EUT – Side View EUT – Side View EUT –Uncover View EUT –Uncover View EUT –Uncover View EUT –Adapter Top View (Adapter Model: A14-100P1A) EUT –Adapter Bottom View (Adapter Model: A14-100P1A) EUT –Adapter Label View (Adapter Model: A14-100P1A) EUT –Adapter Top View (Adapter Model: ADE018) EUT –Adapter Bottom View (Adapter Model: ADE018) EUT –Adapter Label View (Adapter Model: ADE018) EUT – Battery Top View EUT –Battery Bottom View EUT – Battery Label View

ID Label/Location Info

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label Here

Internal Photos

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Uncover View EUT –Main Board Top View EUT –Main Board Bottom View EUT –Turbo Top View EUT –Turbo Bottom View EUT –Turbo Label View EUT – RF Module Uncover View EUT – RF Module Uncover View EUT – RF Board Top View EUT – RF Board Bottom View EUT – RF Circuit View EUT –Control Board Top View EUT –Control Board Bottom View EUT – Power Box Uncover View EUT – Power Board Top View EUT – Power Board Bottom View EUT –Light Module Uncover View EUT –Light Board Top View EUT –Light Board Bottom View EUT –GPS View EUT – GPS Uncover View EUT – GPS Top View EUT – GPS Top Uncover View EUT –GPS Bottom View EUT –GPS Module View EUT – Antenna View EUT – Antenna Top View EUT – Antenna Bottom View

RF Exposure Info

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG150422002-00A FCC Part 15.247 Page 8 of 48 FCC §15.247 (i) & §1.1307 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247(i) and subpart §1.1307, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Calculated Data: Frequency (MHz) Antenna Gain Conducted Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm)(mW) 2436.5 3.00 2.00 27.80 602.56 20.00 0.24 1.0 Result: The device meet FCC MPE at 20 cm distance

Test Report

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.247 TEST REPORT For SZ DJI TECHNOLOGY CO., LTD 14th floor, West Wing, Skyworth Semiconductor Design Building NO.18 Gaoxin South 4th Ave, Nanshan, Shenzhen, Guangdong, China Report Type: Original Report Product Type: DJI MATRICE 100 Test En gineer: Allen Qiao Re port Number: RDG150422002-00A Re port Date: 2015-04-29 Reviewed B y: Sula Huang RF Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn FCC ID: SS3-TP14061504 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG150422002-00A FCC Part 15.247 Page 2 of 47 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 5 SUMMARY OF TEST RESULTS ............................................................................................................................... 6 FCC §15.247 (i) & §1.1307 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ......................................... 7 APPLICABLE STANDARD .............................................................................................................................................. 7 FCC §15.203 - ANTENNA REQUIREMENT ............................................................................................................. 8 APPLICABLE STANDARD .............................................................................................................................................. 8 ANTENNA CONNECTOR CONSTRUCTION ...................................................................................................................... 8 FCC §15.209, §15.205 & §15.247(d) - SPURIOUS EMISSIONS ............................................................................... 9 APPLICABLE STANDARD .............................................................................................................................................. 9 MEASUREMENT UNCERTAINTY .................................................................................................................................... 9 EUT SETUP .................................................................................................................................................................. 9 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 10 TEST PROCEDURE ...................................................................................................................................................... 10 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 11 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 11 TEST RESULTS SUMMARY .......................................................................................................................................... 11 TEST DATA ................................................................................................................................................................ 11 FCC §15.247(a) (2) – 6dB BANDWIDTH.................................................................................................................. 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST PROCEDURE ...................................................................................................................................................... 19 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 19 TEST DATA ................................................................................................................................................................ 19 FCC …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Gary Zeng(PM)
[email protected]+8675586152250Fax: +86 755 86965903

Test Firm

Bay Area Compliance Laboratories Corp. (Dongguan)John Chan
[email protected]86-769-86858888

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.48 GHz603.00 mW
Confidentiality
Long Term
Grant Notes
Output power listed is combined conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
