SS4ST102Smart Rugged Tablet Computer

user manual ST102 BLUEBIRD version 1.0 This user manual is protected by copyright. Copyright © 1995-2018 Bluebird Inc. All rights reserved. Bluebird Inc. is the designer and manufacturer of Bluebird handheld mobiles. This manual and the programs in this device are protected under international copyright laws, and may not be copied, distributed, translated, or removed by any means. Registered Trademark BLUEBIRD is an emerging global brand, striving to lead the market in performance and mobility. Their products represent reliability, innovation, and innovative technology. Bluebird is a registered trademark from the global brand of Bluebird Inc. and is copyright protected. •Bluebird and stylized Bluebird Logo are registered trademarks and symbols of Bluebird Inc. • Adobe ® is a r egistered trademark of Adobe Systems Inc. • All other trademarks and copyrights are the property of their respective owners. User’s Guidance Device typeUser’s guidance Class B Device (Household Information & Communication) This device has qualified the electromagnetic wave suitable registration and can be used as a household device at a residential area as well as any other areas. Type Registration This wireless device may cause propagation interference, and so, it cannot be used for life-saving services. Safety Information Symbols This manual uses the following symbols to indicate hazards and additional information. SymbolNameDescription WarningIndicates situations that could cause injury to yourself or others. Caution Indicates situations that could cause damage to your device or other equipment. Note Indicates additional information that can help you get the most out of the device. Please read this safety precaution information carefully. Failure to follow the information provided may result in fire, electric shock, or other property damage or bodily injuries. Device • Do not press the Power button on the device if the device is wet or do not touch adapter or power cord with wet hands. There is risk of electric shock. • Do not use your device in an explosive danger zone. • If your device becomes wet, do not put your device in heaters, microwaves, etc. to dry it. There is a risk of explosion or malfunction. • Do not scratch the device’s touchscreen. Use only your fingers or a compatible pen. Never use an actual pen, or any other sharp object on the touchscreen. • Although this device is very sturdy, do not drop, hit, bend, or sit on it on purpose. It can be broken. • Do not modify, take apart, or repair the device. Contact to your customer service center. Failure to do so will void your warranty. • Do not attempt to modify your hardware or software. It may cause device malfunction and void your warranty. •You may not be able to use this wireless device in basements, open fields, skyscrapers, or other places where the signal is weak. • Backup the data and information from your device. Your data, such as ringtones, texts, and voice messages, may be erased during repairs or upgrades. • Do not paint your device. It can damage your screen or your device’s exterior. • Avoid using or storing this device at extreme temperatures. This device is designed to work at temperatures between 0°C and 50°C (14°F and 122°F), and humidity level between 5% and 90%. Safety Information Environment •Do not use the device while driving or operating heavy machinery. Doing so may r esult in death or serious injury. • Do not use the device in locations with combustible goods. Doing so may r esult in an explosion. •Do not use the device in dusty or hot locations. Doing so may damage the device. • Do not expose your device to direct sunlight such as on the dashboar d of a car for extended periods of time. • Do not use the device in humid locations. Doing so may damage the device and void the warranty . • Do not keep the device close to air conditioner vents. Corr osion within the device may occur due to condensation fr om changes in temperature. • Do not allow children to play with the device. Battery and Charging •Improper battery use may cause fire, explosion, or other hazard. • If the battery is removed due to impact, heat, submersion, or other damage, ther e is a risk of explosion. Keep away fr om children and animals. • Do not allow the battery’ s contacts to touch things like necklaces, coins, or electric conductors. Do not give any impact with sharp objects. Ther e is a risk of explosion. •Use only the approved battery and charger. Using an incompatible battery or charger may cause device malfunction or other damage, such as fir e. • When you ar e not using the device for a long period, take out the battery and keep the device and the battery in a dry, cool place. Also, charge the battery at least once a year. If you keep it without charging for a long time, it may cause device malfunction. Distraction In some situations, using your device may distract you and cause serious injuries and damages. For example, avoid talking on the phone or texting while driving or riding a bicycle. It is strictly prohibited by law in some jurisdictions. If you cannot avoid using your device while driving, stop your vehicle or use hand-free kit. Frequency Interference •This wireless device may cause radio frequency interference, so use Airplane mode or tur n off the device when prohibited. • The device emits an electromagnetic fields. It may interfer e with your medical devices. • Do not place credit cards, phone car ds, bankbook, and tickets next to the device. The magnetic field of the device can damage their magnetic strips. Package Contents ST102 Package Contents ST102 device Micro USB cable Power adapter The images in this manual may not reflect the color and shape of the actual device. These illustrations are intended for descriptive purposes only. Product Overview Device Front 6 1 2 4 3 5 7 8 9 No. NameDescription 1 Power button Turns on the device. 2 Front cameraCaptures pictures and video (2.0 megapixels). 3 Battery LED Indicates the status of th…

Text truncated - open the document above for the full version.

BLUEBIRD INC. (Dogok-dong, SEI Tower 13,14) 39, Eonjuro30-gil, Gangnam-gu, Seoul South Korea Date: Feb 03, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: SS4ST102 including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from BLUEBIRD INC. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Yongsik Jang QA Senior Manager

BLUEBIRD INC. (Dogok-dong, SEI Tower 13,14) 39, Eonjuro30-gil, Gangnam-gu, Seoul South Korea Date: Feb 03, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: SS4ST102 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, BLUEBIRD INC. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give BLUEBIRD INC. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 Tune up Procedure SHORT-TERM 6 Internal Photos 7 External Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Yongsik Jang QA Senior Manager

FCC ID: SS4ST102 IC : 22515-ST102 Copyright Ⓒ 2020, DT&C Co., Ltd. Page1 / 3 View 1 FCC ID: SS4ST102 IC : 22515-ST102 Copyright Ⓒ 2020, DT&C Co., Ltd. Page2 / 3 View 2 FCC ID: SS4ST102 IC : 22515-ST102 Copyright Ⓒ 2020, DT&C Co., Ltd. Page3 / 3 View 3

IC ID : 22515-ST102 Report No.: DREFCC1912-0354 FCC ID : SS4ST102 TRF-EM-151(00)190502 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 59 CONTENTS 1. General Remarks ...................................................................................................................... 3 2. Test Laboratory ......................................................................................................................... 3 3. General Information of EUT...................................................................................................... 4 4. EUT Operations and Test Configurations ............................................................................... 5 4.1 Principle of Configuration Selection ....................................................................................... 5 4.2 EUT Operation Mode ............................................................................................................. 5 4.3 Test Configuration Mode ........................................................................................................ 5 4.4 Supported Equipment ............................................................................................................ 6 4.5 EUT In/Output Port ................................................................................................................ 6 4.6 Test Voltage and Frequency .................................................................................................. 6 5. Test Summary ........................................................................................................................... 7 6. Test Environment ...................................................................................................................... 7 7. Test Results : Emission............................................................................................................ 8 7.1 Conducted Disturbance ......................................................................................................... 8 7.2 Radiated Disturbance .......................................................................................................... 15 8. Revision History...................................................................................................................... 59 IC ID : 22515-ST102 Report No.: DREFCC1912-0354 FCC ID : SS4ST102 TRF-EM-151(00)190502 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 59 1. General Remarks This report contains the result of tests performed by : DT&C Co., Ltd. 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 17042 http://www.dtnc.net Tel: +82-31-321-2664 Fax: +82-31-321-1664 2. Test Laboratory DT&C Co., Ltd. has been accredited / filed / authorized by the agencies listed in the following table; Certificate Nation Agency Code Remark Accreditation Korea KOLAS 393 ISO/IEC 17025 South Africa SABS 0006 ISO/IEC 17025 Ghana NCA NCA agreement 23rd,Oct,2018 - Site Filing USA FCC KR0034 101842 678747, 596748, 804488, 165783 Accredited 2.948 Listed Canada IC 5740A-3 5740A-4 Registered Japan VCCI C-1427 R-3385, R-4076, R-4180, R-4496, T-1442, G-10338, G-754, G-10815, G-20051 Registered Certification Korea KC KR0034 Designation Germany TUV CARAT 089112 0006 Rev.00 ISO/IEC 17025 Russia RMRS 17.10189.296 ISO/IEC 17025 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competent of calibration and testing laboratory”. IC ID : 22515-ST102 Report No.: DREFCC1912-0354 FCC ID : SS4ST102 TRF-EM-151(00)190502 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 59 3. General Information of EUT Applicant Bluebird Inc. (Dogok-dong, SEI Tower 13,14)39, Eonjuro30-gil, Gangnam-gu, Seoul, South Korea Manufacturer Bluebird Inc. (Dogok-dong, SEI Tower 13,14)39, Eonjuro30-gil, Gangnam-gu, Seoul, South Korea Factory Bluebird Inc. (SSang-young IT Twin tower-B 7~8F), 531, Dunchon-daero, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Product Name Smart Tablet Computer Model Name ST102 Add Model Name None Add Model Difference None Software version Windows 10 Enterprise LTSC 2019 Hardware version 2.0 Maximum Internal Frequency 1 580 MHz FCC ID SS4ST102 IC ID 22515-ST102 Rated Power 100-240V, 50/60Hz Remarks EUT Adapter - Model name : KSA29B0500200D5 - Manufacturer : Kuantech (Cambodia) Corporation Limited - Input : AC 100-240V, 50/60Hz, 0.5A - Output : DC 5V, 2A Related Submittal(s) / Grant(s) Original submittal only IC ID : 22515-ST102 Report No.: DREFCC1912-0354 FCC ID : SS4ST102 TRF-EM-151(00)190502 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 59 4. EUT Operations and Test Configurations 4.1 Principle of Configuration Selection Emission : The equipment under test (EUT) was configured to measure its highest possible radiation level. The test modes were adapted accordingly in reference to the instructions for use. For each testing mode different configurations were used, Refer to the individual tests. 4.2 EUT Operation Mode No. Mode Description 1 Camera Front Mode The EUT activates the front mounted camera to record images continuously. 2 Camera Rear mode The EUT activates the Rear mounted camera to record images continuously. 3 MP4 Mode EUT is in the state of playing MP4 files continuously. 4.3 Test Configuration Mode No. Mode Description 1 Camera Front Mode The EUT is connected to the adapter(EUT) Connect Micro SD Card to Micro SD Card Slot of EUT Connect headset to headset port of EUT Adapter(EUT) is connected to AC Main 2 Camera Rear mode The EUT is connected to the adapter(EUT) Connect Micro SD Card to Micro SD Card Slot of EUT Connect headset to headset port of EUT Adapter(EUT) is connected to AC Main 3 MP4 Mode The EUT is connected to the adapter(EUT) Connect Micro SD Card to Micro SD Card Slot of EUT Connect headset to headset port of EUT Adapte…

Text truncated - open the document above for the full version.

FCC ID : SS4ST102 / IC ID : 22515-ST102 Prohibits the copying and re-issue of this report without DT&C approval. Conducted Disturbance FCC ID : SS4ST102 / IC ID : 22515-ST102 Prohibits the copying and re-issue of this report without DT&C approval. Radiated Emission < 30 MHz ~ 1 GHz > FCC ID : SS4ST102 / IC ID : 22515-ST102 Prohibits the copying and re-issue of this report without DT&C approval. Radiated Emission < (1 ~ 6) GHz > FCC ID : SS4ST102 / IC ID : 22515-ST102 Prohibits the copying and re-issue of this report without DT&C approval. Radiated Emission < (6 ~ 18) GHz > FCC ID : SS4ST102 / IC ID : 22515-ST102 Prohibits the copying and re-issue of this report without DT&C approval. Radiated Emission < (18 ~ 40) GHz >
