ST6744501remote control for Dust Devil

9 V VEHICLE Removal of the battery cover requires a "phillips head" screwdriver, push the tab on the battery compartment lid and slide the lid back on its hinge. See Figure 3. Make sure the "AA" batteries are new or freshly charged batteries (Do not mix old or used batteries with new batteries). Place the batteries in the battery compartment being sure that the ( + ) and ( – ) poles of the batteries are positioned correctly. See Figure 4. Replace the cover. IMPORTANT! • Do not leave batteries in the vehicle or the transmitter when the toy is not in use. • Do not use old and new batteries together. • Do not mix different types of batteries. Only batteries of the same or equivalent type as recommended are to be used.(e .g. alkaline, Ni-Cd rechargeable, and manganese, or other non-alkaline batteries) • Dispose of old batteries in the proper manner ; do not burn or place near fire. • Non-rechargeable batteries are not to be recharged. • The supply terminals are not to be short-circuited. • Not suitable for children under 3 years of age due to small parts. • Remove rechargeable batteries from the unit before recharging. • Recharging of rechargeable batteries should only be done under adult supervision. • The screwdriver is not a toy. • Do not give the screwdriver to children. • Change the car body by adult only. • Exhausted batteries are to be removed from the toy. BATTERY REQUIREMENTS • This vehicle requires 4 "AA" (LR6) batteries (alkaline or Ni-Cd rechargeable batteries), and one 9V (6LR61) (alkaline) (6F22) (carbon zinc) battery for the transmitter. OPERATING R/C CAR INSTALLING BATTERIES INSTALLING THE BATTERIES TRANSMITTER Removal of the battery cover requires a "phillips head" screwdriver.See Figure 1. After removing this screw, slide the cover downward to remove. Place the 9 V battery in position so that the (+) and (-) are in the proper alignment ads noted.Replace screw to battery cover. See Figure 2. . IMPORTANT! • Do not use vehicle in mud, water, snow, or sand. • Do not play with vehicle in the street. • Do not crash vehicle into any object at high speeds. • When the vehicle slows down install new or freshly charged batteries. • Clean the vehicle with a damp paper towel after operating. (Do not use any chemicals to wipe off car) • Do not leave vehicle in direct sunlight for lengthy periods. Figure 1 Figure 2 Figure 3Figure 4 OPERATING CAR 1. Turn the car switch to "ON". (Located on bottom of car) See Figure 5. Figure 5 2. Start operating by moving speed control joysticks on the left forward. See Figure 7. 3. Release both control joysticks, the vehicle will stop. See Figure 8. 4. Vehicle steering is controlled by joystick on right by moving left or right. See Figure 9. 5. Do not let vehicle get out of transmitting range as you will then have no control. This range varies due to surroundings. 6. When finished, turn all switches to off position and remove all batteries. Vehicle operation varies from 35 to 45 minutes depending on how the car is used, and the age of the batteries. Figure 6 WIRE ANTENNA STEERING CONTROL JOYSTICK SPEED CONTROL JOYSTICK ON OFF DO NOT LEAVE THE SWITCH “ON” FOR LONG PERIODS WHEN IT IS NOT IN USE. FORWARD BACKWARD R L THINGS YOU SHOULD KNOW • Radio interference can cause your car to react strangely. • Another vehicle operating on the same frequency can disrupt your controlling the vehicle. • CB's, cellular telephones, two way radios, and other transmitting devices, and high tension wires may cause interference with operation. • Your vehicle can sometimes cause interference with television or even radio reception. Move to another area if you notice this occurrence. WHEEL ALIGNMENT Your steering can be adjusted with the trim switch located on the bottom chassis area. Turn either left or right until you have made the adjustment to maintain a straight path of movement. See Figure 10. Figure 10 Figure 7 Figure 9 Radio Controled Vehicle Full Function Buggy Series Scale: 1:14 MCS: 316500830 GOT A PROBLEM? We'll help you solve it. In spite of our best efforts,accidents do happen. If you're having trouble setting up your Artin Radio Control Car or you have a defective part, or just a question, we're here to help you. DO NOT RETURN PRODUCT TO PLACE OF PURCHASE We'll do our best to solve your problem on Email. If you need a replacement part, we will send it to you at once. LIMITED 1 YEAR WARRANTY ARTIN INTERNATIONAL LTD E-mail : [email protected] www.artin.com.hk E-mail: [email protected] All Artin Radio Control Cars are manufactured under strict quality control. However, if your set contains a defective part or if a part becomes defective within one year from the date of purchase (certified by proof of payment), just send us email for a free replacement part. Warranty does not cover misused or abused items or electric bulbs. This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. LIMITED WARRANTY WARNING : CHOKING HAZARD - Small parts. Not for children under 3 years of age. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Transmitter : 9V --- 0.05A NATURE POWER OF SUPPLY Receiver : 6V --- 1.2A ON OFF ON OFF Figure 8 STOP ON OFF ON OFF ON OFF Caution: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will no…

Text truncated - open the document above for the full version.

Artin International LTD Power of Attorney Date: 2013-4-25 To Whom It May Concern: Hellen Wang, whom from SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch is authorized to act on our behalf, until otherwise notified, for applications to PHOENIX TESTLAB GmbH. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: ___12 months_____ By: Ngai Kam Fai (Signature 1 ) (Print name) Title: ______President________ On behalf of: __ Artin International LTD (Company Name) Telephone: 852-31050701 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Artin International LTD Request for Confidentiality Date: 2013-4-25 Subject: Confidentiality Request for: _FCC ID: ST6744501 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operational Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _ Artin International LTD has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify PHOENIX in the event information regarding the product or the product is made available to the public. PHOENIX will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Ngai Kam Fai (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

1 Photographs - EUT Constructional Details (Test Model No.: 744501)

Label content：

1 Photographs - EUT Constructional Details (Test Model No.: 744501)

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM130400157901 Page: 1 of 13 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No. : SZEM1304001579RF Applicant: Artin International LTD Product Name: 1:14 Dust Devil Model No.(EUT): 744501 FCC ID: ST6744501 Standards: 47 CFR Part 15, Subpart C (2012) Date of Receipt: 2013-04-03 Date of Test: 2013-04-10 to 2013-04-15 Date of Issue: 2013-04-25 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130400157901 Page: 2 of 13 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Radiated Emission 47 CFR Part 15, Subpart C Section 15.227 ANSI C63.10（2009） PASS Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.215 ANSI C63.10（2009） PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130400157901 Page: 3 of 13 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 3 Contents Page 1 COVER PAGE................................................................................................................................................... 1 2 TEST SUMMARY .............................................................................................................................…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test Model No.: 744501) 1.1 Radiated Emission
