SV7DFHLFRX801767INHAWGNITO-Feeder RX RC

the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC: Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

All Seasons Feeders Inc FCC ID: SV7DFHLFRX801767 DATE: July 17, 2013 To whom it may concern: We the undersigned, hereby authorize Shenzhen Sinco Testing Technology Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Shenzhen Sinco Testing Technology Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from All Seasons Feeders Inc We additionally authorize teleconformity Mr. M. Koop to process this FCC application . Sincerely yours, All Seasons Feeders Inc LAURA GATES/ Manger Fax: (210) 648-0979 Tel: (210) 648-0999 E-mail: [email protected]

All Seasons Feeders Inc Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Zealous Audio would like the following documents regarding this submission for FCC ID: SV7DFHLFRX801767 to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, All Seasons Feeders Inc LAURA GATES/ Manger Fax: (210) 648-0979 Tel: (210) 648-0999 E-mail: [email protected]

External photos of the EUT For INHAWGNITO 765665801798 For Feeder RX 765665801811

Label and Label Location All Seasons Feeders Inc FCC ID: SV7DFHLFRX801767

Internal photos of the EUT For INHAWGNITO 765665801798 For Feeder RX 765665801811

FCC TEST REPORT 47 CFR FCC Part 15 Subpart C 12.231 FCC ID .............................................. : Report Reference No. ..................... : SV7DFHLFRX801767 SKW1305007 Compiled by ( position+printed name+signature) .. : File administrators Lion Cai Supervised by ( position+printed name+signature) .. : Technique principal Kendy Wang Approved by ( position+printed name+signature) .. : Manager Tony Wu Date of issue ..................................... : June 20, 2013 Representative Laboratory Name . : Shenzhen Sinco Testing Technology Co., Ltd. Address ............................................ : 4F, Block B, Famous Industry Products Center Baoyuan Rd., Xixiang, Baoan, Shenzhen, China Testing Laboratory Name .............. : Bontek Compliance Testing Laboratory Ltd Address ............................................ : 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Applicant’s name ............................ : All Seasons Feeders Inc Address ............................................ : 8424 HWY 87 East San Antonio, Texas 78263 Test specification: Standard ........................................... : 47 CFR FCC Part 15 Subpart C - Intentional Radiators ANSI C63.10: 2009 TRF Originator .................................. : Shenzhen Sinco Testing Technology Co., Ltd. Master TRF ....................................... : Dated 2012-06 Shenzhen Sinco Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Sinco Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Sinco Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ........................ : INHAWGNITO-Feeder RX RC Trade Mark ....................................... : / Manufacturer .................................... : Asia Sourcing Corporation Model/Type reference ....................... : INHAWGNITO 765665801798 Listed Models .................................. : Feeder RX 765665801811 Result................................................ : Positive V1.0 Page 2 of 24 Report No.: SKW1305007 T E S T R E P O R T Test Report No. : SKW1305007 June 20, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : INHAWGNITO-Feeder RX RC Model /Type : INHAWGNITO 765665801798 Listed Models : Feeder RX 765665801811 Applicant : All Seasons Feeders Inc Address : 8424 HWY 87 East San Antonio, Texas 78263 Manufacturer Asia Sourcing Corporation Address : 610 Monroe Avenue Memphis, TN 38013 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 24 Report No.: SKW1305007 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 2.7. Configuration of Tested System 6 2.8. NOTE 6 3. TEST ENVIRONMENT ............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Statement of the measurement uncertainty 7 3.5. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................. 9 4.1. Conducted Emissions Test 9 4.2. Radiated Emission Test 10 5. TEST SETUP PHOTOS OF THE EUT .......................................... 20 V1.0 Page 4 of 24 Report No.: SKW1305007 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart C - Intentional Radiators ANSI C63.10: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in theRange of 9 kHz to 40GHz V1.0 Page 5 of 24 Report No.: SKW1305007 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : June 15,2013 Testing commenced on : June 15,2013 Testing concluded on : June 20, 2013 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC z Other (specified in blank below) ALKALINE BATTERY 27A 12V Short description of the Equipment under Test (EUT) Product Name : INHAWGNITO-Feeder RX RC Model Number : INHAWGNITO 765665801798, Feeder RX 765665801811 Operation Frequency : 433.92MHz Modulation Technology : ASK Transmitter Type : manually operated Transmitter Sample Type : Prototype Channel Number : 4 (use the same TX frequency 433.92MHz) for INHAWGNITO 765665801798 Channel Number : 2 (use the same TX frequency 433.92MHz) for Feeder RX 765665801811 2.3. EUT operation mode The EUT has been tested under typical operating condition. 2.4. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: SV7DFHLFRX801767 filing to comply with the FCC Part 15, Subpart C 15.231 Rules. 2.5. Modifications No modifications were implemented to meet testing criteria. V1.0 Page 6 of 24 Report No.: SKW1305007 2.6. Configuration of Tested System Configuration of Tested System 2.7. NOTE 1. The EUT is a 433.92MHz INHAWGNITO-Feeder RX RC,The functions of the EUT listed as below: Test Standards Reference Report WLAN Radio FCC Part 15 Subpart C (Section15.31) SKW1305007 EUT V1.0 Page 7 of 24 Report No.: SKW1305007 3. TEST ENVIRONMENT 3.1. Address of the test laboratory Bontek Compliance Testing Laboratory Ltd 1/F, Block East H-3,…

Text truncated - open the document above for the full version.

Test setup photos of the EUT
