SVC-M4UTWMTrue Wireless Micro Planar Earphones(PSB M4U TWM)

TRUE WIRELESS MICRO PLANAR EARPHONES OWNER’S MANUAL M4U TWM INTRODUCTION Thank you for purchasing a pair of PSB Speakers M4U TWM Earphones. Producing natural musical dynamics and precisely imaged sound, these high-fidelity earphones bring you closer to the music you love. Engineered with 50 years of audio excellence and research, the M4U TWM delivers unmatched sound quality, all-day comfort and fold-and-go portability, for music enthusiasts and professionals. PSB’s true-to-nature sound quality and stylish ergonomic design allow you to escape to a personal concert experience that travels anywhere with you. REGULATORY INFORMATION Operating temperature range: 5°C – 40°C Operating frequency range: Bluetooth 2.4G Input rating: 5V 1A Earphone battery life: 8 hours per charge Earphone charging time: 66 minutes Case charging time: 2 hours Number of full charges held in case: 3 Net weight of each earphone: 5 grams Total weight of earphones in the case: 45 grams M4U TWM is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Date of Manufacture: The second and third digits in the serial number indicates the year of manufacture; “21” is 2021. Responsible Party: Lenbrook Industries Limited. 633 Granite Court, Pickering, Ontario, Canada L1W 3K1. Phone: (905) 831-6333, Facsimile: (905) 831-6936 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by PSB Speakers is under license. The N-Mark is a trademark or registered trademark of the NFC Forum, Inc. in the United States and in other countries. To prevent possible hearing damage, do not listen at high volume levels for long periods. OSHA GUIDELINES FOR NOISE EXPOSURE LIMITS The Occupational Safety Health Administration (OSHA) has issued headphone usage recommendations for maximum daily exposure and sound pressure levels [measured in decibels (dB)]. A decibel is a unit of sound measurement that increases exponentially with volume. For example, conversational speech is typically around 60dB, and a rock concert in a stadium is often about 110dB. 90dB8 hours 95dB4 hours 100dB2 hours 105dB1 Hour 110dB30 minutes 115dB15 minutes 120dBAvoid as damage may occur FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction FCC ID: SVC-M4UTWM Because the True Wireless Micro Planar Earphones(PSB M4U TWM) is too small, the label information has been included in the user manual and outer packaging box, as shown in the manual. FCC lable: SIZE:40*20mm WARNING Warnings or announcements may be unnoticed when you are using the earphones. Please be aware of ambient sounds while wearing the earphones and recognize them as needed. •To prevent possible hearing damage, do not listen at high volume levels for long periods. •These earphones should only be connected to a USB interface of version USB2.0 or higher. •Risk of explosion if the battery is replaced by an incorrect type, dispose of used batteries according to the instructions. •Be sure to read the Owner’s Manual of the device that you want to connect to these earphones. •Check the volume settings when using the earphones when in public places and ensure that you do not disturb people around you. •These earphones are not guaranteed to work with all combinations of Bluetooth devices/ mobile phones. •These earphones do not support a connection with all Bluetooth devices/mobile phones. •Bluetooth wireless technology can communicate up to approximately 10 m. Obstructions (people, metallic objects, walls, etc.) and radio wave conditions affect the actual range. •The Bluetooth device that you want to connect with must support the same profile as these earphones in order to use the Bluetooth function. For details on profiles that the Bluetooth device is compatible with, see the Bluetooth device Owner’s Manual. •Due to features of Bluetooth wireless technology, playback of audio on the earphones is slightly delayed compared to the playback on the transmitting device. •Do not use your earphones while driving. •Remove the earphones immediately if you experience a warming sensation or loss of audio. •Do not use mobile phone adaptors to connect these earphones to airplane seat jacks, as this could cause overheating and result in injury or property damage. •The earphones and accessories contain small parts which may be a choking hazard. Not suitable f…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of ProcessLETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: THREE STONES MEDIA LLC FRN: 0033401761 Contact Name: Sijie Zhang Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Telephone No: +1 267 909 3692 Email: [email protected] Applicant: Company name: Lenbrook Industries Limited Product Description: True Wireless Micro Planar Earphones(PSB M4U TWM) Grantee code: SVC FCC ID: SVC-M4UTWM FRN: 0022583488 Contact Name: Taresh Vadgama Address: 633 Granite Court, Pickering, ON, CANADA, L1W 3K1 Telephone No: (905) 831-6333 Email: [email protected] [Lenbrook Industries Limited] certifies that, as of the date of this filing of the application with the TCB, [THREE STONES MEDIA LLC] is our designated US agent for service of process for the above referenced FCC ID. [Lenbrook Industries Limited] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [THREE STONES MEDIA LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicantis aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. 1/1 Date: 22/01/2024 Applicant’s Name: Taresh Vadgama US Agent’s Name: Sijie Zhang Title: Development Team Manager Title: President Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Lenbrook Industries Limited Grantee code: SVC FCC ID: SVC-M4UTWM Contact Name: Taresh Vadgama Address: 633 Granite Court, Pickering, ON, CANADA, L1W 3K1 Telephone No: (905) 831-6333 Fax No: (905) 831-6936 Email: [email protected] i.[Lenbrook Industries Limited] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii.[Lenbrook Industries Limited] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. Theapplicantmustsignthiscertification. Lenbrook Industries Limited dcertifies that, as of the date of the filing of theapplication, the applicant is not identified on the Covered List as an entity producing “covered”equipment. Date: 22/01/2024 Applicant’s Name: Taresh Vadgama Title: Development Team Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization < Lenbrook Industries Limited > Company: Lenbrook Industries Limited Address: 633 Granite Court, Pickering, ON, CANADA, L1W 3K1 Product Name: True Wireless Micro Planar Earphones(PSB M4U TWM) Model Number: M4U TWM FCC Identifier: SVC-M4UTWM We authorize LGAI Technological Center S.A., Ronda de la Font delCarme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Taresh Vadgama Date: 22/01/2024 Title: Development Team Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 < Lenbrook Industries Limited > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046Date: 22/01/2024 Subject: Request for Confidentiality FCC ID: SVC-M4UTWM To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No Block Diagram ☐ Schematics ☐ Test Report No No Test Setup Photos No User’s Manual ☐ NOTE 1 Internal Photos ☐ NOTE 1 Parts List / Tune Up / BOM List ☐ RF Exposure Info No No Operational Description ☐ Cover Letter(s) No No SOFTWARE SECURITY REQUIREMENTS FOR U- NII DEVICES No No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. C5266091_X10_Ed.2 1/1 It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Taresh Vadgama Title: Development Team Manager

1/1 Lenbrook Industries Limited label statement Date: 2024.01.29 Product/ Model Number:True Wireless Micro Planar Earphones(PSB M4U TWM) / M4U TWM FCC ID:SVC-M4UTWM Due to the small size of the product, it is not possible to label it. Therefore, the label information has been included in the user manual and outer packaging box, as shown in the manual. Signature of applicant Name: Taresh Vadgama Title: Development Team Manager User manual (Page 2) Packaging BOx

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 BT ANT Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 BT ANT Photo 17 Photo 18

FCC ID: SVC-M4UTWM Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BLE(1M): Antenna Type: FPCB antenna Antenna Gain: -0.5dBi Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n 1g SAR Exclusion threshold SAR test exclusion 2.4023.172.0754±15.03.162<50.980203.00YES 2.4414.272.6734±15.03.162<50.988133.00YES 2.4804.12.5704±15.03.162<50.995993.00YES 2.4024.052.5414.5±15.53.548<51.099813.00YES 2.4415.473.5245.5±16.54.467<51.395773.00YES 2.4805.753.7585.5±16.54.467<51.406883.00YES GFSK (Left) GFSK (Right) BLE(2M): Antenna Type: FPCB antenna Antenna Gain: -0.5dBi Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n 1g SAR Exclusion threshold SAR test exclusion 2.4023.852.4274±15.03.162<50.980203.00YES 2.4415.093.2285±16.03.981<51.243983.00YES 2.4805.693.7075±16.03.981<51.253883.00YES 2.4024.332.7104.5±15.53.548<51.099813.00YES 2.4415.093.2285±16.03.981<51.243983.00YES 2.4805.83.8025.5±16.54.467<51.406883.00YES GFSK (Left) GFSK (Right) Conclusion: For the max result : 1.40688≤ 3.0 for 1-g SAR, No SAR is required. Signature: Date: 2024-01-09 NAME AND TITLE (Please print or type): Alex /Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China

F Effi Effi Gi Gi UHIS DHIS M Mi itiit B idth AttH AttV Passive Test For BT F req Effi Effi G a i n G a i n UHIS DHIS M ax Mi n i rect i v it B eamw id t h A tt H A tt V (MHz) (%) (dB) (dBi) (dBd) (%) (%) (dB) (dB) (dBi) (3dB) (dB) (dB) 2400 32.4 -4.89 -0.5 -2.65 12.448 19.957 -0.5 -15.42 4.4 30 46.52 46.42 2410 31.97 -4.95 -0.76 -2.91 12.762 19.21 -0.76 -15.08 4.19 30 46.11 46.03 2420 26.89 -5.7 -1.89 -4.04 11.157 15.736 -1.89 -15.5 3.81 30 46.45 46.36 2430 28.32 -5.48 -1.56 -3.71 11.99 16.328 -1.56 -14.88 3.92 30 46.15 46.03 2440 27.52 -5.6 -1.47 -3.62 11.682 15.841 -1.47 -14.62 4.13 30 46.75 46.57 2450 29 86 -5 25 -0 97 -3 12 12 751 17 114 -0 97 -13 96 428 30 46 74 46 58 2450 29 . 86 - 5 . 25 - 0 . 97 - 3 . 12 12 . 751 17 . 114 - 0 . 97 - 13 . 96 4 . 28 30 46 . 74 46 . 58 2460 26.97 -5.69 -1.39 -3.54 11.592 15.375 -1.39 -13.69 4.3 90 46.92 46.75 2470 29.93 -5.24 -0.87 -3.02 12.871 17.06 -0.87 -12.71 4.37 90 46.63 46.48 2480 28.73 -5.42 -0.98 -3.13 12.169 16.557 -0.98 -13.22 4.44 0 46.92 46.8 Application Information O4VersionTotalTimeAdditionalInfor 4.95.3033m 57s 331msNULL Antenna shape and size Manufacturer's Name :Shenzhen Fbetter Electronic Co.,Ltd Address: Introduction Building 6F, Xinan Street 71, Baoan District,Shenzhen Guangdong, China Antenna model: A2145

Report No.: S23112803601001 Version.1.3 Page 1 of 95 RADIO TEST REPORT FCC ID:SVC-M4UTWM Product: True Wireless Micro Planar Earphones(PSB M4U TWM) Trade Mark: Model No.: M4U TWM Family Model: N/A Report No.: S23112803601001 Issue Date: Dec 13, 2023 Prepared for Lenbrook Industries Limited 633 Granite Court, Pickering, ON, CANADA, L1W 3K1 Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S23112803601001 Version.1.3 Page 2 of 95 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 4 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 5 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 6 3.1 FACILITIES..................................................................................................................................................... 6 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 6 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 6 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 7 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 9 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 10 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................................... 10 6.2 SUPPORT EQUIPMENT ............................................................................................................................... 11 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 12 7 TEST REQUIREMENTS .................................................................................................................................... 14 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 14 7.1.1 Applicable Standard .................................................................................................................................. 14 7.1.2 Conformance Limit ................................................................................................................................... 14 7.1.3 Measuring Instruments ............................................................................................................................. 14 7.1.4 Test Configuration .................................................................................................................................... 14 7.1.5 Test Procedure ........................................................................................................................................... 14 7.1.6 Test Results ................................................................................................................................................ 15 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 17 7.2.1 Applicable Standard .................................................................................................................................. 17 7.2.2 Conformance Limit ................................................................................................................................... 17 7.2.3 Measuring Instruments ............................................................................................................................. 18 7.2.4 Test Configuration .................................................................................................................................... 18 7.2.5 Test Procedure ........................................................................................................................................... 19 7.2.6 Test Results ................................................................................................................................................ 20 7.3 6DB BANDWIDTH ....................................................................................................................................... 31 7.3.1 Applicable Standard .................................................................................................................................. 31 7.3.2 Conformance Limit ................................................................................................................................... 31 7.3.3 Measuring Instruments ............................................................................................................................. 31 7.3.4 Test Setup .................................................................................................................................................. 31 7.3.5 Test Procedure ........................................................................................................................................... 31 7.3.6 Test Results ................................................................................................................................................ 31 7.4 DUTY CYCLE .........................................................................................…

Text truncated - open the document above for the full version.

Report No.: S23112803601001 Version.1.3 Page 71 of 95 Test Graphs -6dB Bandwidth NVNT BLE 2M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 72 of 95 -6dB Bandwidth NVNT BLE 2M 2480MHz Ant1 8.3.3 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 2M 2402 Ant1 2.055 NVNT BLE 2M 2440 Ant1 1.035 NVNT BLE 2M 2480 Ant1 2.043 Report No.: S23112803601001 Version.1.3 Page 73 of 95 Test Graphs OBW NVNT BLE 2M 2402MHz Ant1 OBW NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 74 of 95 OBW NVNT BLE 2M 2480MHz Ant1 8.3.4 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm) Limit (dBm) Verdict NVNT BLE 2M 2402 Ant1 -15.72 8 Pass NVNT BLE 2M 2440 Ant1 -10.85 8 Pass NVNT BLE 2M 2480 Ant1 -13.57 8 Pass Report No.: S23112803601001 Version.1.3 Page 75 of 95 Test Graphs PSD NVNT BLE 2M 2402MHz Ant1 PSD NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 76 of 95 PSD NVNT BLE 2M 2480MHz Ant1 8.3.5 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 2M 2402 Ant1 -53.56 -20 Pass NVNT BLE 2M 2480 Ant1 -54.43 -20 Pass Report No.: S23112803601001 Version.1.3 Page 77 of 95 Test Graphs Band Edge NVNT BLE 2M 2402MHz Ant1 Ref Band Edge NVNT BLE 2M 2402MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 78 of 95 Band Edge NVNT BLE 2M 2480MHz Ant1 Ref Band Edge NVNT BLE 2M 2480MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 79 of 95 8.3.6 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 2M 2402 Ant1 -54.49 -20 Pass NVNT BLE 2M 2440 Ant1 -56.02 -20 Pass NVNT BLE 2M 2480 Ant1 -56.68 -20 Pass Test Graphs Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 80 of 95 Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 81 of 95 Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 82 of 95 8.4 2M(RIGHT) 8.4.1 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT BLE 2M 2402 Ant1 4.33 30 Pass NVNT BLE 2M 2440 Ant1 5.09 30 Pass NVNT BLE 2M 2480 Ant1 5.8 30 Pass Report No.: S23112803601001 Version.1.3 Page 83 of 95 Test Graphs Power NVNT BLE 2M 2402MHz Ant1 Power NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 84 of 95 Power NVNT BLE 2M 2480MHz Ant1 8.4.2 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 2M 2402 Ant1 0.745 0.5 Pass NVNT BLE 2M 2440 Ant1 1.302 0.5 Pass NVNT BLE 2M 2480 Ant1 1.454 0.5 Pass Report No.: S23112803601001 Version.1.3 Page 85 of 95 Test Graphs -6dB Bandwidth NVNT BLE 2M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 86 of 95 -6dB Bandwidth NVNT BLE 2M 2480MHz Ant1 8.4.3 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 2M 2402 Ant1 2.053 NVNT BLE 2M 2440 Ant1 2.049 NVNT BLE 2M 2480 Ant1 2.061 Report No.: S23112803601001 Version.1.3 Page 87 of 95 Test Graphs OBW NVNT BLE 2M 2402MHz Ant1 OBW NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 88 of 95 OBW NVNT BLE 2M 2480MHz Ant1 8.4.4 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm) Limit (dBm) Verdict NVNT BLE 2M 2402 Ant1 -10.16 8 Pass NVNT BLE 2M 2440 Ant1 -14.31 8 Pass NVNT BLE 2M 2480 Ant1 -13.59 8 Pass Report No.: S23112803601001 Version.1.3 Page 89 of 95 Test Graphs PSD NVNT BLE 2M 2402MHz Ant1 PSD NVNT BLE 2M 2440MHz Ant1 Report No.: S23112803601001 Version.1.3 Page 90 of 95 PSD NVNT BLE 2M 2480MHz Ant1 8.4.5 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 2M 2402 Ant1 -53.25 -20 Pass NVNT BLE 2M 2480 Ant1 -55.27 -20 Pass Report No.: S23112803601001 Version.1.3 Page 91 of 95 Test Graphs Band Edge NVNT BLE 2M 2402MHz Ant1 Ref Band Edge NVNT BLE 2M 2402MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 92 of 95 Band Edge NVNT BLE 2M 2480MHz Ant1 Ref Band Edge NVNT BLE 2M 2480MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 93 of 95 8.4.6 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 2M 2402 Ant1 -54.04 -20 Pass NVNT BLE 2M 2440 Ant1 -53.25 -20 Pass NVNT BLE 2M 2480 Ant1 -55.03 -20 Pass Test Graphs Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 94 of 95 Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Emission Report No.: S23112803601001 Version.1.3 Page 95 of 95 Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Emission END OF REPORT

Radiated Measurement Photos- Left Radiated Measurement Photos- Right Conducted Measurement Photos
