SWB-CDT20Remote Control

Transmitter Using Description 1. Transmitter Key Description： Stop Start 2.Main function and operation： 1) Installation and connection: The product uses two CR2016 3V battery； 2) Setting: Initial paired with the receiver, it needs receiver to store the address code of transmitter (the factory has been set, do not re-learning)； 3.Key functions: Press the START button for one second,the light above transmitter keep bright, corresponding to the start and other functions of the receiver will be respond.Press the STOP button for one second，the light above transmitter keep bright,corresponding to the stop and other functions of the receiver will be respond。 4.Precautions： 1) Do not use a long press button, so electricity consumption will be less than the design life. 2) Normal use 3000 times or does not use during a year, it is recommended to replace the battery, or remote control distance may be shortened. 3) The product operating voltage is DC6V, when replace the battery, please pay attention to recognize to model of the battery. 4) If you loss or replacement transmitters， the new transmitters need to re-code to match the receiver.The specific method: Press the learn button on the receiver until learn indicator light, press any one key of the transmitter,the indicator light off after flashes three times, then learning successful. To prevent accidental learning, the learning process must be completed within the 2 seconds, otherwise the receiver will automatically stop learning window, learn indicator automatically turns off. 5) Although this product has a strong anti-interference, but please do not use in strong interference environment, otherwise the remote control distance may be shortened or not working properly. 5. FCC statement： a. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. b. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 6. IC statement - English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. - French: Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
