SWW2112SBattSwitch

Embedded Processor Designs, Inc.
BattSwitch - FCC ID SWW2112S - Embedded Processor Designs, Inc.
Click to zoom

Application Details

Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant
Feb 22, 2010
Application Purpose
Original Equipment
Date of Application
Feb 22, 2010
Equipment Note
BattSwitch
Frequency Range
902.88000000 - 927.18500000
Company
Embedded Processor Designs, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Printed in U.S.A. Limited Warranty EPD, Inc. warrants this product agains t manufacturing defect s in material and workmanship under normal use for one (1) year from date of purchase. EXCEPT AS PROVIDED HERE IN, EPD MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARR ANTIES, INCLUDING THOSE OF MERCHANTABLITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN EXCEPT AS PROVIDED HEREIN, EPD SHALL HAVE NO LIAB ILITY OR RESPONSIBILITY TO CUSTOMER OR OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE OR PR OFIT OR ANY INDI RECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF EPD HAS BEEN ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. Some states do not allow limitations on how long an implied warranty last or the exclusion of limitation of incidental or consequential dama ges, so the above limitations or exclusions may not apply to you. In the event of a product defect during the warranty period, call EPD for a Return Merchandise Authorization number. EPD will, at its option, unless otherwise provided by law: (a) correct the defect by product repair without charge for parts or labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase price. All replaced pa rts and products become the property of EPD, Inc. New or reconditioned parts and products may be used in the performance of warranty service. Repaired or replaced parts are warranted for the remainder of the original warranty period. You will be charged for the repair or replacement of the product made after the expiration of the warranty period. This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse, accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or maintenance, alteration, lightning or other incidence of excess voltage or current; (b) cosmetic damage; (c) transportation, shipping or insurance cost ; or (e) cost of product removal; (f) pager batteries; (g) electrical contacts, installation, set-up service adjustment or reinstallation. This warranty gives you sp ecific legal rights, and you may also have other rights, which vary, from state to state. Cat# 90− 002 Rev. 2 The BattSwitch Installation and Operating Guide Embedded Processor Designs, Inc INTRODUCTION TROUBLE SHOOTNG Congratulations on your purchase of the BattSwitch for the PlexCall system. EPD is dedicated to engineering the most innovative paging system possible. Your paging system is driven by microprocessor technology, which provides an endless array of features and convenience. To install the Battswitch, place the unit on a flat table surface and attach with 2 one half inch wood screws. To operate the BattSwitch, press the red button, the unit will illuminate and signal the PlexCall system that service is requested. When the server arrives at the table, th ey should press the BattSwitch to turn off the unit. FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This e quipment generates, uses and can radiate radio frequency energy and if not installe d and used in accordance w ith the instructions, may cause harmful interference to radio communica tions. However, there is no guarantee that interference will not occur in a particular installation. If th is equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ƒ Reorient or relocate the receiving antenna. ƒ Increase the separation between the equipment and receiver. ƒ Connect the equipment into an ou tlet on a circuit different from that to which the receiver is connected. ƒ Consult the dealer or an experien ced radio/TV technician for help. This equipment has been certified to comply with the limits for a class B computing device, pursuant to the FCC Rules. In order to maintain complianc e with FCC regulations, shielded cables must be used with this equipment. Operation with non-appr oved equipment or unshielded cables is likely to result in interference to radio and TV recepti on. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. BattSwitch does not operate ƒ Check the batteries. Be sure the batteries are correctly installed. ƒ Install a fresh set of batteries.

Attestation Statements

Embedded Processor Designs, Inc. 370 N. Louisiana Ave. Suite A1 . • Asheville, NC 28806 Ph: 828-251-1501 Fax: 828-667-1965 January 15, 2010 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Embedded Processor Designs, 370 N. Louisiana A ve., Suite AI; Asheville, NC 28806, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification ofthe following Embedded Processor Designs product: BattSwitch battery, wireless battery operated transceiver. Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of FCC Rules and Regulations. . Please also accept this letter ~s an attestation that neither Embedded Processor Designs nor any of its officers, directors, or persons holding 5% or more ofthe outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 ofthe Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Embedded Processor Designs will notify the Federal Communications Commission if, at any time, the situation changes . causing Embedded Processor Designs to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 828-251-1501. Sincerely, ~~~ David Thompson President

Attestation Statements

Embedded Processor Designs, Inc. 370 N. Louisiana Ave. Suite A1 Asheville, NC 28806 Ph: 828-251-1501 Fax: 828-667-1965 January 15, 2010 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Embedded Processor Designs, would like to declare that the application being submitted for the device with FCC 10: SWW2112S, has not been, submitted to another TCB or FCC for certification. The application was submitted to Compatible Electronics TCB on January 22, 2010. If you have any questions, please do not hesitate to contact us at 828-251-1501. Sincerely, ~~ David Thompson President •

Cover Letter(s)

Embedded Processor Designs, Inc. 370 N. Louisiana Ave. Suite A1 Asheville, NC 28806 Ph: 828-251-1501 Fax: 828-667-1965 January 15, 2010 Compatible Electronics TCB 114 Olinda Drive Bre~ California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, Embedded Processor Designs, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) ofthe Commission's Rules, and Section 552 (b)(4) ofthe Freedom ofInformation Act. These sections · authorize the withholding from public inspection, those materials which would be privileged as a matter of lawif retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at 828-251-150 L . Sincerely, ~~~ David Thompson President ..

Cover Letter(s)

1 Scott McCutchan From: Scott McCutchan [[email protected]] Sent: Thursday, February 18, 2010 12:14 PM To: '[email protected]'; '[email protected]' Cc: 'Jeff Klinger' Subject: FCC ID: SWW2112S Mr. Fujimoto: In order for processing of this certification application (FCC ID: SWW2112S) to continue, the following issue(s) will have to be addressed: 1) Since the two‐condition statement contained in section 15.19(a)(3) does not appear on the device’s label, the statement must be included in the user’s manual. Please submit a revised manual. 2) The operational description states that the device uses frequencies of 4.9152 MHz and 8 MHz, which do not appear in the block diagram. As per section 2.1033(b)(5) of the FCC rules, the block diagram must show “the frequency of all oscillators used in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block.” Please submit a revised diagram. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e‐mail date may result in application dismissal. and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is SWW2112S‐1. Best regards, Scott McCutchan Operations Manager Compatible Electronics TCB If you have any questions, please contact me. Best regards, Scott McCutchan Lab Manager Compatible Electronics Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589‐0700 fax (949) 589‐7700 [email protected]

Cover Letter(s)

Correspondence by Project Project Number: -1083522937 Correspondence Number Memo SWW2112S-1 1) Since the two-condition statement contained in section 15.19(a)(3) does not appear on the device’s label, the statement must be included in the user’s manual. Please submit a revised manual. Response: The Owners Manual has been Revised to Include this Statement. 2) The operational description states that the device uses frequencies of 4.9152 MHz and 8 MHz, which do not appear in the block diagram. As per section 2.1033(b)(5) of the FCC rules, the block diagram must show “the frequency of all oscillators used in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block.” Please submit a revised diagram. Response: The EUT only operates at 4.9152 MHz and NOT at 8 MHz. The 8 MHz was what the processor can go up to, but will never be operated at this speed. The Hardware Theory of Operation and Block Diagram have been revised.

ID Label/Location Info

Location of FCC ID: FCC ID: SWW2112S

Test Report

Report Number: B00119D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report BattSwitch Model: 1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 17 FCC PART 15, SUBPART B and C TEST REPORT for BattSwitch MODEL: 1 Prepared for EMBEDDED PROCESSOR DESIGNS, INC. 370 NORTH LOUISIANA AVENUE, SUITE A1 ASHEVILLE, NORTH CAROLINA 28806 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JANUARY 19, 2010 REPORT APPENDICES TOTAL BODY A B C D E PAGES 17 2 2 2 10 19 52 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B00119D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report BattSwitch Model: 1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 17 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 7. TEST PROCEDURES 14 7.1 RF Emissions 14 7.1.1 Conducted Emissions Test 14 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 15 8. CONCLUSIONS 17 Report Number: B00119D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report BattSwitch Model: 1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 17 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Test Site – 3 Meters Report Number: B00119D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report BattSwitch Model: 1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 17 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: BattSwitch Model: 1 P/N: 2130 Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Embedded Processor Designs 370 North Louisiana Avenue, Suite A1 Asheville, North Carolina 28806 Test Dates: Janaury 18 and 19, 2010 Test Specifications : EMI requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4: 2003 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B00119D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report BattSwitch Model: 1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 17 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz This test was not performed because the EUT is battery powered only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions 10 kHz – 9300 MHz (Transmitter Portion) Complies with the limits of CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.249 Highest reading in relation to spec limit: 50.6 dBuV @ 3611.52 MHz (*Uc = 6.51 dB) 3 Radiated RF Emissions 10 kHz – 9300 MHz (Digital and Receiver Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B. Highest reading in relation to spec limit: 45.72 dBuV @ 903.101 MHz (*Uc = 2.11 dB) Report Number: B00119D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report BattSwitch Model: 1 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake F…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Thompson(President)
[email protected](828) 251-1501Fax: (828) 667-1965

Technical Contact

Compatible Electronics, Inc.Kyle Fujimoto
[email protected]714-579-0500

114 Olinda Drive · Brea, California · United States

Test Firm

Compatible Electronics, Inc.Michael Christensen
[email protected]714-579-0500Fax: 714-579-1850

Technical Specifications

#Rule PartsFrequency RangePower Output
115C902.88 MHz - 927.185 MHz-
Confidentiality
Long Term
