T2C-A20Video Conferencing Endpoint

Yealink MeetingBar A20 Teams&Zoom Kit English | 简体中文 Quick Start Guide 快速入门指南 (V15.1) 2 Package Contents MeeingBar A20 VCR20-Teams AAA Battery×2 3m Ethernet Cable 1.8m HDMI Cable×2 (for the display device) Cable Tie×5 Power Adapter ×4 ×2 ×2 Mounting Bracket and Accessories Silicone Pad×2 Quick Start Guide CTP187.5m Ethernet CableMounting Bracket Screwdriver and Accessories VCH51Interface7.5m Protective Cover Ethernet Cable Remote Control Package(only Teams edition)Touch Panel Package VCH51 Sharing Kit •Standard accessories •Optional accessories WPP20Type-C Adapter Wireless Presentation Pod 2 2 2 3M VelcroCable lock box Power Cord Ethernet Cable (3m CAT5E FTP cable) PSE Cable Lock BoxPoE Adapter 0.6m0.6m HDMI CableUSB Type-C Cable 3 CTP18 Connection Rese t MAC SN 3m Ethernet Cable 7.5m Ethernet Cable Endpoint Connection 1 2 2 1 PC Display Power Adapter 1.8m HDMI Cable 3m Ethernet Cable 7.5m Ethernet Cable VCH51 CTP18 POE 4 VCR20-Teams Remote Control Introduction(Teams) 1 2 3 4 5 Scroll Wheel/OK Key Mute Key Press to mute or unmute microphone. Teams Key Press to join meeting. 6 7 8 Navigation Key Back Key Volume Up/Down Key Press to return to the previous menu. Press to increase/decrease the volume. Navigate through menu items. • Scroll up to increase the focal length of the camera. • Scroll down to decrease the focal length of the camera. • Press to confirm the action. Answer Key Press to answer a call. End Call Key Press to leave a meeting. 1 2 3 4 5 6 7 8 Remote Control and Cable Ties Installation Wireless Sharing You can use Yealink WPP20 wireless presentation pod for wireless content sharing. 1. Connect the WPP20 to the USB port of the A20. 2. Wait for 3 seconds, the WPP20 LED indicator glows solid green after flashing twice. The WPP20 is paired with the A20 successfully. 3. Connect the WPP20 to the PC. 6) WPP20 Wireless Presentation Pod 5 For more information, see related documentations, including User Guide and Administrator Guide, on your phone’s Support page: http://support.yealink.com/. You can also contact the Yealink technical support team for help. Camera Settings You can configure your camera. Go to (Teams: More > Settings >Device Settings) (Zoom: Settings > System Settings) Select Exposure Settings, White Balance Settings and Graphics to configure exposure, white balance and so on. Go to (Teams: More > Settings >Device Settings > Others) (Zoom: Settings > System Settings > Others) 1.Select Manual, Auto Framing and Speaker Tracking in Framing Mode field. 2.Select Reset to reset camera settings. 6 包装清单 ×4 ×2 ×2 MeetingBar A203米网线 1.8米 HDMI线×2 （用于接显示设备） 束线带×5 电源适配器 支架配件 （用于安装主机） 硅胶垫 x2快速入门指南 • 标准配件 • 可选配件 VCR20-Teams 遥控器 7 号电池 ×2 CTP18 7.5米网线 挂墙架配件 螺丝刀 VCH51 接口保护罩 7.5米网线 遥控器触控平板 有线投屏盒子 WPP20 Type-C 转接头 无线传屏助手 2 2 2 USB锁线盒 PoE 电源 0.6米 HDMI 线 0.6米 USB Type-C 线 .
潞㬲愼 64#椋勃䫖
䤹䊔勃 偷单勃 ('51憍⊗偿⋨ⴭ单勃) PSE 7 连接终端 1 2 2 1 PC 显示设备 电源适配器 1.8 米 HDMI 线 3米网线 连接 CTP18 Rese t MAC SN 3米网线 7.5米网线 7.5米网线 VCH51 CTP18 POE 8 遥控器介绍（Teams） 1 2 3 4 5 滚轮/ OK 键 静音键 麦克风静音 / 取消静音。 Teams 键 按下按键加入会议。 6 7 8 导航键 返回键 音量加减键 返回上一级菜单。 提高 / 降低音量。 导航菜单项。 •向上滑动放大摄像机画面。 •向下滑动缩小摄像机画面。 •按下以确认执行操作。 接听键 接听来电。 挂断键 按下按键离开会议。 1 2 3 4 5 6 7 8 安装遥控器电池和使用束线带 无线辅流分享内容 你可以使用 WPP20 无线传屏助手进行无线辅流分享内容。 1. 将 WPP20 连接到 A20 的 USB 口。 2. 约 3 秒后，WPP20 指示灯闪烁 2 次并保持绿色常亮。 WPP20 与 A20 配对成功。 3. 将 WPP20 连接到电脑上。 6) WPP20 无线传屏助手 9 更多详细信息，请参阅技术支持网站（http://support.yealink.com/）上相关的用户指 南和管理员指南。或者你也可以联系亿联技术支持团队。 摄像机设置 你可以对摄像机进行设置： 进入（Teams: 更多 > 设置 > 设备设置） （Zoom: 设置 > 系统设置） 选择曝光设置，白平衡设置和图像设置曝光，白平衡等。 进入（Teams: 更多 > 设置 > 设备设置> 其他） （Zoom: 设置 > 系统设置 >其他） 1.选择手动，自动框全景和语音追踪在智能框选中。 2.选择重置重置摄像机设置。 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Web: www.yealink.com Copyright©2020 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD.All rights reserved. Regulatory Notices Operating Ambient Temperatures • Operating temperature: +32 to 104°F (0 to 40°C) •Relative humidity: 5% to 90%, noncondensing •Storage temperature: -22 to +160°F (-30 to +70°C) Warranty Our product warranty is limited only to the unit itself, when used normally in accordance with the operating instructions and the system environment. We are not liable for damage or loss resulting from the use of this product, or for any claim from a third party. We are not liable for problems with Yealink device arising from the use of this product; we are not liable for financial damages, lost profits, claims from third parties, etc., arising from the use of this product. Explanation of the symbols • DC symbol is the DC voltage symbol. •WEEE Warning symbol To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. • Restriction of Hazardous Substances Directive (RoHS) This device complies with the requirements of the EU RoHS Directive. Statements of compliance can be obtained by contacting [email protected]. •Safety Instructions Save these instructions. Read these safety instructions before use! General Requirements • Before you install and use the device, read the safety instructions carefully and observe the situation during operation. • During the process of storage, transportation, and operation, please always keep the device dry and clean,avoid collision and crash. •Please attempt not to dismantle the device by yourself. In case of any discrepancy, please contact the appointed maintenance center for repair. •Please refer to the relevant laws and statutes while using the device. Legal rights of others should be respected as well. Environmental Requirements •Place the device at a well-ventilated place. Do not expose the device under direct sunlight. •Keep the device dry and free of dusts. •Do not place the device on or near any inflammable or fire-vulnerable object, such as rubber-made materials. •Keep the devic…

Text truncated - open the document above for the full version.

SCS-F019: Confidentiality Request Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] W ebsite: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 7.0 YEALINK (XIAMEN) NETWORK TECHNOLOGY CO., LTD. (2021/02/06) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: T2C-A20 Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual Short Term Permanent i FCC software security declaration The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name & title: Stone Lu Vice General Manager Contact information / address: [email protected] 4th-5th Floor, South Building,NO.63 WangHai Road, 2nd Software Park, Xiamen, China i Permanent confidentiality may be requested in accordance with FCC KDB 726920

Page 1 of 5 External Photo Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

Label location

Page 1 of 7 Internal Photo Page 2 of 7 Page 3 of 7 Page 4 of 7 Page 5 of 7 Page 6 of 7 WIFI MODULE Page 7 of 7 BT Antenna WIFI Antenna

Report No.: FVC-ESH-P20112379B-15 Page 1 of 26 FCC/IC-ITE V1.1 FCC TEST REPORT Report No.: FVC-ESH-P20112379B-15 FCC ID: T2C-A20 Product: Video Conferencing Endpoint Test Model: MeetingBar A20 Received: Dec.30, 2020 ISSUED: Jan.23, 2021 Applicant: YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Address: 309, 3rd Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R. China Issued By: BUREAU VERITAS ADT (Shanghai) Corporation Lab Location: No. 829, Xinzhuan Road, Shanghai, P.R.China (201612) This test report consists of 35 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA, CNAS, or any government agency. The test results in the report only apply to the tested item. The test results in this report are traceable to the national or international standards. Report No.: FVC-ESH-P20112379B-15 Page 2 of 26 FCC/IC-ITE V1.1 Contents 1. TEST PROGRAM ......................................................................................................................................... 3 2. Summary of Test Procedure and Test Results ......................................................................................... 4 3. Test Configuration of Equipment under Test ........................................................................................... 5 3.1 Manufacturer information ................................................................................................................. 5 3.2 Feature of Equipment under Test ..................................................................................................... 5 3.3 Description of support units ............................................................................................................. 5 3.4 Measurement Uncertainty ................................................................................................................ 6 4 Test of Conducted Emission ...................................................................................................................... 7 4.1 Test Limit .......................................................................................................................................... 7 4.2 Test Procedures ............................................................................................................................... 8 4.3 Typical Test Setup ............................................................................................................................ 8 4.4 Measurement Equipment ................................................................................................................. 9 4.5 Test Result and Data ...................................................................................................................... 10 4.6 Test Photographs ........................................................................................................................... 14 5 Test of Radiated Emission ....................................................................................................................... 14 5.1 Test Limit ........................................................................................................................................ 15 5.2 Test Procedures ............................................................................................................................. 16 5.3 Typical Test Setup .......................................................................................................................... 16 5.4 Measurement Equipment ............................................................................................................... 17 5.5 Test Result and Data (30MHz ~ 1GHz) ......................................................................................... 18 5.6 Test Result and Data (1GHz ~ 18GHz) .......................................................................................... 22 5.7 Test Photographs (30MHz ~ 1000MHz) ......................................................................................... 24 5.8 Test Photographs (1000MHz ~ 18000MHz) ................................................................................... 25 6 Photographs of EUT ................................................................................................................................. 26 Report No.: FVC-ESH-P20112379B-15 Page 4 of 26 FCC/IC-ITE V1.1 2. Summary of Test Procedure and Test Results EMISSION (47 CFR FCC Part15, Subpart B) Test Item Normative References Test Result Conducted Emission 47 CFR FCC Part15, Subpart B 15.107 Meets the Class B requirements Radiated Emission 47 CFR FCC Part15, Subpart B 15.109 Meets the Class B requirements Report No.: FVC-ESH-P20112379B-15 Page 5 of 26 FCC/IC-ITE V1.1 3. Test Configuration of Equipment under Test 3.1 Manufacturer information Manufacturer : YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Address : 309, 3rd Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R. China 3.2 Feature of Equipment under Test Product Name: Video Conferencing Endpoint Brand: Yealink Test Model: MeetingBar A20 Model Discrepancy: -- EUT Power Rating: I/P: 48V, 0.7A for Video Conferencing Endpoint; I/P: 100-240Vac, 50/60Hz, 1.0A; O/P: 48V, 0.7A for AC Adapter. Note: 1. Please refer to user manual. 3.3 Description of support units NO. PRODUCT BRAND/ Manufacturer MODEL NO. 1 PC ThinkPad L470 2 Network Cable -- -- 3 LCD Monitor Lenovo T2054pC Report No.: FVC-ESH-P20112379B-15 Page 6 of 26 FCC/IC-ITE V1.1 3.4 Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT: This listed uncertainties are the worst case uncertainty for the entire range of measurement. Please note that the unce…

Text truncated - open the document above for the full version.

Page 1 of 3 Test Setup Photo Page 2 of 3 1. Radiated Emission Below 1GHz Above 1GHz Page 3 of 3 2. Conducted Emission
