T2C-CP935WHD Wireless Conference Phone

Quick Start Guide(V1.0) HD Wireless Conference Phone CP935W English | Deutsch | Español | Français English ............................................................1 Deutsch ..........................................................7 Español ...........................................................13 Français ..........................................................19 Table of Contents Charging CradlePower AdapterCP935WQuick Start Guide Note: •Use Yealink-supplied power adapter (12V/1.25A). A third-party power adapter may damage the wireless conference phone. •Check the charging status in the upper-left corner of the LCD screen. Charging the CP935W CP935W Package Contents 1 E N G L I S H 1 112 1 3 4 5 7 6 8 Hardware Overview Getting Started 2 Mute Key Mute Key Volume(-) Key Home Key LCD Screen Volume(+) Key Contact Charging Por t USB Type-C Por t Security Slot E N G L I S H Note: •If the CP935W is registered to the base station successfully, the LCD screen prompts “Subscribe Succeeded”. •If the CP935W LCD screen prompts “Searching for Base”, check whether the registration LED indicator of your base station flashes. Power on: Press the home key for 3 seconds or charge the CP935W. Power off: Press the home key for 10 seconds then tap OK or tap More->Basic->Power Off->OK on the LCD screen of the CP935W. When the CP935W is powered on for the first time or reset to factory setting, the screen displays DECT Mode, choose one and click OK . If you want to switch modes, tap More- >Basic->Phone Mode on the LCD screen of the CP935W. Y ou can register up to 10 CP935W to one W70B base station. Each CP935W can only be regis- tered to one base station. When the CP935W LCD screen prompts “Unregistered!”, long press on the base station till the registration LED indicator flashes. There are two methods to register a new CP935W: Easy Registration: 1. Tap Reg on the CP935W screen to register quickly. Normal Registration: 1. Tap More->Basic->Registration->Register on the LCD screen of the CP935W. The CP935W begins searching the base station. 2. Tap OK after searching a base station successfully (if it’s not the base which you want to reg- ister to, tap Next to search another base). 3. Enter the base station password (default: 0000), and then tap OK to complete the registration. Power on/off the CP935W 3 Registration (DECT Mode) Select Mode E N G L I S H Before you start using the CP935W, please set up your account via web user interface of the base station. Follow the steps below: 1. Tap More->Status->Base Status->IPv4 on the LCD screen of the CP935W and access the IP address with a browser (the default username and password are admin). 2. Go to Account->Register, select the account, enable Active Line, enter account information and click Confirm. If you don’t know the server account, please contact the administrator to obtain the information. Account Settings (DECT Mode) Note: When you enter the account information, the Display Name, Register Name, Username and Server Host are required. E N G L I S H 4 Upgrade Firmware For a better experience, please go to the Yealink’s official website to download the latest firm- ware, then upgrade the base station and CP935W. DECT Mode: You can upgrade base station and CP935W in DECT Mode. 1. Ta p More->Status->Base Status->IPv4 IP on the screen of the CP935W and access the IP address with a browser (the default username and password are admin). 2. Go to Settings->Upgrade, you can upgrade the base station and CP935W that registered to the base station. If one of the CP935W is not upgraded successfully, tap More->Basic->upgrade Firmware on the screen of the CP935W, you can check the new firmware and upgrade the CP935W sepa- rately (make sure the provision server is configured). E N G L I S H 5 Regulatory Notices Operating Ambient Temperatures • Operating temperature: +14 to 122°F (-10 to 50°C) • Relative humidity: 5% to 90%, noncondensing • Storage temperature: -22 to +160°F (-30 to +70°C) Warranty Our product warranty is limited only to the unit itself, when used normally in accordance with the operating instructions and the system environment. We are not liable for damage or loss resulting from the use of this product, or for any claim from a third party. We are not liable for problems with Yealink device arising from the use of this product; we are not liable for financial damages, lost profits, claims from third parties, etc., arising from the use of this product. DC symbol is the DC voltage symbol. Restriction of Hazardous Substances Directive (RoHS) This device complies with the requirements of the EU RoHS Directive. State- ments of compliance can be obtained by contacting [email protected]. Safety Instructions Save these instructions. Read these safety instructions before use! The following basic safety precautions should always be followed to reduce risk of fire, electrical shock, and other personal injury. General Requirements • Before you install and use the device, read the safety instructions carefully and observe the situation during operation. • During the process of storage, transportation, and operation, please always keep the device dry and clean. • During the process of storage, transportation, and operation, please avoid collision and crash of the device. • Please attempt not to dismantle the device by yourself. In case of any discrepancy, please contact the appointed maintenance center for repair. • Without prior written consent, no organization or individual is permit- ted to make any change to the structure or the safety design of the device. Yealink is under no circumstance liable to consequences or legal issues caused by such changes. • Please refer to the relevant laws and statutes while using the device. Legal rights of others should be respected as well. Environmental Requirements • Place the device at a well-ventilated place. Do not expose the device under direct sunlight. • Keep the device dry and free of dusts. • Place the device on a…

Text truncated - open the document above for the full version.

YEALINK (XIAMEN ) NETWORK TECHNOLOGY CO., LTD. Date: 2022/11/14 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: T2C-CP935W To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with YEALINK (XIAMEN ) NETWORK TECHNOLOGY CO., LTD.. This authorization is valid until further written notice from the applicant. Print Name: Stone Lu Title: Vice General Manager Signature: On behalf of Company: YEALINK (XIAMEN ) NETWORK TECHNOLOGY CO., LTD. Telephone: 86-592-5702000 E-mail: [email protected]

YEALINK (XIAMEN ) NETWORK TECHNOLOGY CO., LTD. TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: T2C-CP935W LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within aforementioned days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Stone Lu Title: Vice General Manager Signature: On behalf of Company: YEALINK (XIAMEN ) NETWORK TECHNOLOGY CO., LTD. Telephone: 86-592-5702000 E-mail: [email protected]

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name YEALINK (XIAMEN ) NETWORK TECHNOLOGY CO., LTD. Address No.666 Hu’an Rd,Huli District Ximen City, Fujian, P.R. China Grantee Code T2C FCC ID T2C-CP935W Authorized Contact Name Stone Lu Contact Email [email protected] Contact Phone 86-592-5702000 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2022/11/14 Print Name: Stone Lu Title: Vice General Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States
