T2C-ME600Video Conferencing Endpoint

Yealink MeetingEye 600 Video Conferencing Endpoint Quick Start Guide V1.0 Yealink Network Technology CO., LTD English | 皍⡤⚥俒 1 Package Contents 3m Ethernet CableAAA Battery×2MeetingEye600 VCR20 Remote Control 1.8m HDMI Cable (for the display device) Cable Tie×5 Quick Start Guide We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in reduced performance. Use the Yealink original power adapter (48V/0.7A) to charge the endpoint only. The use of the third-party power adapter may cause the damage to the endpoint. Put the magnet rings on the HDMI cable to prevent electromagnetic interference. Endpoint Installation .PVOUJOH
#SBDLFU BOE
"DDFTTPSJFT 1PXFS
"EBQUFS 1. Placing MeetingEye 600 Mount the MeetingEye 600 below the TV when the mounting height of the TV is higher than 120cm. Mount the camera above the TV when the mounting height of the TV is lower than 120cm. $51 Optional Accessories 811
8JSFMFTT
1SFTFOUBUJPO
1PE TV TV #MVFUPPUI
8JSFMFTT
.JDSPQIPOFT– #5
#MVFUPPUI
64#
%POHMF
Wireless Sharing Package Touch Panel Package .JDSPQIPOF Package 2 Hole depth: 30mm Hole diameter: 6mm T4×30 screws 2. Wall Mounting Use the bracket to mount your endpoint on a wall. The mounting height affects your camera view. The recommended height is 1.6m above the ground. S S 3 4 5 3 Endpoint Connections 1.8m HDMI Cable 3m Ethernet Cable Display Power Adapter 3. Adjusting the Camera Tilt For more information on WPP20 wireless presentation pod, refer to Y ealink WPP20 Wireless Presentation Pod Quick Start Guide. 5IF
64#
1PSU
3BUJOH
7%$
N" PC Wireless Sharing WPP20 Wireless Presentation Pod 15° 15° ):6 4 Network Environment Bandwidth Requirements Both downlink bandwidth and uplink bandwidth should meet above requirements. The bandwidth mentioned above is based on a two-way call. Bandwidth in head office should be increased along with the growing number of connected branch offices. Network Deployment Choose Cloud deployment or traditional deployment according to your need. Cloud Deployment Cloud deployment does not need complex network settings. You only need to get account information from your system administrator, and log into the video conference platform. Do the following to log into the video conference platform via remote control: 1. Select More->Login->Advanced (Default Admin Password:0000)->Video Conference Platform. 2. Enable Cloud Account. 3. Select the desired platform from the pull-down list of Platform Type. 4. Configure the desired platform and log in. Video ResolutionRecommended Bandwidth Full HD 4K30/1080P60 4Mb People 1080P60+Content 1080P60 4Mb Remote ControlCable Ties Installation 5 Configure a Static IP The following introduces how to use the remote control to configure a static IPv4 address: 1. Select More->Setting->Network->Wired Network (Default Admin Password:0000). 2. Select IPv4 from the pull-down list of IP Mode. 3. Select IPv4, and then press OK key. 4. Disable DHCP. 5. Enter the IP address, subnet mask, gateway and DNS information in corresponding fields. 6. Save the change. The screen prompts “ Reboot now?”. 7. Select OK to reboot the endpoint. Configure Port Mapping If you deploy the endpoint in an Intranet, you must forward the following ports to the public network on the firewall, so that your endpoint can receive a public-to-private call. P ort Function H.323 signal port SIP optional  Audio & Video media stream port Web management port optional  Protocol Type UDP/TCP 5060-5061 443 50000-51000 1719-1720 TCP/UDP TCP/UDP TCP When you use intelligent traversal to deploy your endpoint, you have to open following ports on your firewall if they are restricted. It is recommended that you forward the web management port(443/TCP) to the public network, so that other office can remotely manage the office. P ortFunction H.323 signal port SIP optional  Audio & Video media stream port Protocol Type UDP/TCP TCP/UDP TCP/UDP 50000-51000 5060-5061 1719-1720 Do one of the following to deploy the endpoint: Option1: Assign a static public IP address to your endpoint. Option2: If you deploy the endpoint in an Intranet (behind the firewall), assign a static private IP address to it and do port mapping on the firewall. Option3: Deploy the endpoint using intelligent traversal. You only need to assign a private IP address to your endpoint. Make sure this private IP address can access the public network. Only outbound calls are available when using this method. Traditional Deployment 6 Troubleshooting Connectivity Testing After installation and deployment, you can test the endpoint by dialing the Yealink Demo Room ( 117.28.251.50 or 117.28.234.45 ). If you can’t dial out successfully, please contact your IT administrator to check the network. Configuring Static NAT If you do not use Cloud platform and deploy your endpoint in an Intranet, you have configured port mapping on the firewall or gateway, but you find that local endpoint appears black screen and you cannot hear sound when you call Yealink Demo or other endpoints. The most likely reason is that the firewall or gateway in your environment does not support the ALG feature. In this situation, please take the following actions so that the static NAT feature on the endpoint can solve this problem. To configure static NAT via the remote control: 1. Select More->Network->Wired Network (Default Admin Password:0000)->NAT/Firewall. 2.Select Automatic from the pull-down list of Type, the endpoint will obtain public IP address automatically. 3. If the endpoint does not obtain a public IP address automatically, select Manual Settings from the pull-down list of Type, and then enter the public IP address in the Public IP Address field. 4.Save the change. ⺫鄳幡支 7$3黔䱽㐼 〿歏寑Y
