T2C-MSPEAKERVideo Conferencing Soundbar

Soundbar MSpeakerII Quick Start Guide(V1.0) www.yealink.com English | 简体中文 You can connect the MSpeakerII to the Line Out port of the video conference system or the UVC series camera as an audio output device. The following is an example of connecting to the UVC80. Package Contents 1 MSpeakerII Quick Start Guide MSpeaker Connection MSpeaker Installation We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in poor performance. Expansion screws and Self-tapping screws 3.5mm Audio Cable + + 2 2 Power Select one of the following installation method: Mount on a Wall Horizontal Installation 168mm Silicone pad×2 Wall Mount Bracket UVC80 Power 3.5mm Audio Cable 2 Stick the MSpeakerIIat the edge of the table closest to the TV to deliver better sound output to everyone at the conference.Note: The height is not more than 2m. Vertical installation 168mm Stick to the table 150mm ×2 你可以将MSpeakerII作为音频输出设备连接到会议电视终端或UVC系列摄像机的 Line Out接口。 以下是MSpeakerII接到UVC80的图例： 包装清单 3 MSpeakerII 快速入门指南 连接MSpeakerII 安装MSpeakerII 膨胀螺丝和自攻螺丝 + + 2 2 电源 选择以下任意一种安装方式: 墙装 3.5mm音频线 挂墙架 168mm 横挂 UVC80 3.5mm 音频线 我们推荐使用由Yealink提供或经Yealink认可的配件和线缆，使用未经认可的第三方配件和线缆可能会 导致性能的下降。 硅胶垫×2 电源 将MSpeakerII固定在桌子顶部靠近屏幕的位置，使屏幕前听音者可以获取最佳音效。 4 竖挂 168mm 固定在桌面上 150mm ×2 Web: www.yealink.com Copyright ©2020YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD .All rights reserved. Regulatory Notices Operating Ambient Temperatures Operating temperature: +32 to 104°F (0 to 40°C) Relative humidity: 5% to 90%, noncondensing Storage temperature: -22 to +160°F (-30 to +70°C) Warranty Our product warranty is limited only to the unit itself, when used normally in accordance with the operating instructions and the system environment. We are not liable for damage or loss resulting from the use of this product, or for any claim from a third party. We are not liable for problems with Yealink device arising from the use of this product; we are not liable for financial damages, lost profits, claims from third parties, etc., arising from the use of this product. Explanation of the symbols DC symbol is the DC voltage symbol. WEEE Warning symbol To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Restriction of Hazardous Substances Directive (RoHS) All adapter devices comply with the requirements of the EU RoHS Directive. Statements of compliance can be obtained by contacting [email protected]. Safety Instructions Save these instructions. Read these safety instructions before use! General Requirements Before you install and use the device, read the safety instructions carefully and observe the situation during operation. During the process of storage, transportation, and operation, please always keep the device dry and clean, avoid collision and crash. Please attempt not to dismantle the device by yourself. In case of any discrepancy, please contact the appointed maintenance center for repair. Please refer to the relevant laws and statutes while using the device. Legal rights of others should be respected as well. Environmental Requirements Place the device at a well-ventilated place. Do not expose the device under direct sunlight. Keep the device dry and free of dusts. Do not place the device on or near any inflammable or fire-vulnerable object, such as rubber-made materials. Keep the device away from any heat source or bare fire, such as a candle or an electric heater. Operating Requirements Do not let a child operate the device without guidance. Do not let a child play with the device or any accessory in case of accidental swallowing. Please use the accessories provided or authorized by the manufacturer only. The power supply of the device shall meet the requirements of the input voltage of the device. Please use the provided surge protection power socket only. Before plugging or unplugging any cable, make sure that your hands are completely dry. Do not spill liquid of any kind on the product or use the equipment near water, for example, near a bathtub, washbowl, kitchen sink, wet basement or near a swimming pool. During a thunderstorm, stop using the device and disconnect it from the power supply. Unplug the power plug and the Asymmetric Digital Subscriber Line (ADSL) twisted pair (the radio frequency cable) to avoid lightning strike. If the device is left unused for a rather long time, disconnect it from the power supply and unplug the power plug. When there is smoke emitted from the device, or some abnormal noise or smell, disconnect the device from the power supply, and unplug the power plug immediately. Contact the specified maintenance center for repair. Do not insert any object into equipment slots that is not part of the product or auxiliary product. Before connecting a cable, connect the grounding cable of the device first. Do not disconnect the grounding cable until you disconnect all other cables. Cleaning Requirements Before cleaning the device, disconnect it from the power supply. Use a piece of soft, dry and anti-static cloth to clean the device. Keep the power plug clean and dry. Troubleshooting The unit cannot supply power to device other than Yealink device. There is a bad connection with the plug. 1. Clean the plug with a dry cloth. 2. Connect it to another wall outlet. The usage environment is out of operating temperature range. 1. Use in the operating temperature range. The cable between the unit and the Yealink device is connected incorrectly. 1. Connect the cable correctly. You cannot connect the cable properly. 1. You may have connected a wrong Yealink device. 2. Use the correct power supply. Some dust, etc., may be in the port. 1. Clean the port. Contact your…
