T2C-T44Ultra-elegant Gigabit IP Phone

Ultra-elegant Gigabit IP Phone SIP-T44W www.yealink.com Quick Start Guide(V1.0) Stand Wall Mount Bracket 1. Attach the stand, as shown below: 2. Connect the handset and optional headset, as shown below: The following items are included in your package. If you find anything missing, contact your system administrator. Power Adapter Handset Cord Handset IP Phone Ethernet Cable Optional Optional 1 Quick Start Guide Package Contents Assembling the PhoneAssembling the Phone Note: You can also mount the phone to a wall. For more information on how to attach the wall mount bracket, refer to Yealink Wall Mount Quick Installation Guide for Yealink IP Phones. Desk Mount Method BBB 404040 AAA 454545 Note: We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in reduced performance. (2m CAT5E UTP Cable) 4. Connect the network and power, as shown below: 5. Connect the network and power, as shown below: You have two options for network and power connections. Your system administrator will advise you which one to use. 1. Press the Menu soft key when the phone is idle and select Settings > Basic Settings > Wi-Fi. 2. Press the Switch soft key to enable Wi-Fi and press the Save soft key. 3. Go to Available Network(s) and select a network to connect. 4. Enter its password if required and press the Save soft key. Press the OK key or go to Settings > Basic Settings > Wi-Fi > Wi-Fi Status to check the Wi-Fi status. Welcome Initializing...please wait After the IP phone is connected to network and supplied with power, it automatically begins the initialization process. After startup, the phone is ready for use. You can configure the phone via web user interface or phone user interface . If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the hub/switch is PoE-compliant. Note: The IP phone should be used with Yealink original power adapter (5V/2A) only. The use of the third-party power adapter may cause the damage to the phone. If you are connecting a PC to your phone, we recommend that you use the Ethernet cable provided by Yealink. Startup 2 A AC Power Option Power Adapter (DC 5V) PC Connection (Optional) PC IEEE 802.3af compliant PoE Hub/Switch B PoE ( Power over Ethernet ) Option PC Connection (Optional) PC 3. Connect the USB flash drive, as shown below: Note: The USB ports can also be used to connect other USB devices, such as EXP43, USB headset and so on. Yealink recommends that you connect Bluetooth USB dongle or Wi-Fi USB dongle to the upper USB port, and connect EXP43 to the lower USB port. PC Internet PC Internet a. Upper USB Port b. Lower USB Port Accessing the web user interface: Account Settings: Click on Account->Register->Account X (X=1,2,3...11,12) Parameters of the account: Network Settings: Account Settings: Configuring via phone user interface Configuring via web user interface Register status icons on the LCD screen: 1. Press the OK key when the phone is idle to obtain the IP address of the phone. You can configure the network settings in the following ways: It shows the register status of the current account. You can select Enabled/Disabled to enable/disable the account. It is shown on the LCD screen to identify the account. It is shown as Caller ID when placing a call. It is an authenticated ID for authentication provided by ITSP (required). It is provided by ITSP for registration (required). It is provided by ITSP for registration (required). It is provided by ITSP for registration (required). DHCP: By default, the phone attempts to contact a DHCP server in your network to obtain its valid network settings, e.g., IP address, subnet mask, gateway address and DNS address. Static IP: If your phone can not contact a DHCP server for any reason, you need to configure the IP address, subnet mask, gateway address, primary DNS address and secondary DNS address for the phone manually. Press the Menu soft key when the phone is idle, select Settings->Advanced Settings (default password: admin) ->Network->WAN Port/Wi-Fi Port/VLAN/Web Server/802.1x/VPN/LLDP/CDP/NAT to configure the network. Press the Menu soft key when the phone is idle, select Settings->Advanced Settings (default password: admin) ->Accounts to configure the account. 2. Open a web browser on your computer, enter the IP address into the address bar (e.g., "http://192.168.0.10" or "192.168.0.10"), and then press the Enter. Register Status: Line Active: Label: Display Name: Register Name: User Name: Password: Server Host: 3. Enter the user name (default: admin) and password (default: admin) in the login page and click Login. Network Settings: Click on Network->Basic->IPv4 Config 3 Configuring Your Phone Note: Check with your system administrator if any error appears during the registration process or a specific Note: For more information on account parameters, refer to Configuring via web user interface above. configuration is required for your registration. Note: The IP phone also supports IPv6, but IPv6 is disabled by default. The wrong network settings may result in the inaccessibility of your phone and may have an impact on the network performance. Contact your system administrator for more information. Registered Register Failed Registering 4 Basic Call Features Placing a Call Answering a Call Using the handset: Using the speakerphone: Using the headset: Using the handset: Using the speakerphone: Using the headset: 1. With the handset on-hook, press . 1. Pick up the handset. 2. Enter the number, and then press the Send soft key. 1. With the headset connected, press to activate the headset mode. 2. Enter the number, and then press the Send soft key. 2. Enter the number, and then press the Send soft key. Pick up the handset. Press . Press . Note: During a call, you can alternate between the headset, hands-free speakerphone and handset modes by Ending a Call Call Mute and Un-mute Redial Call Hold and Resume To place a call o…

Text truncated - open the document above for the full version.

YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu'an Rd. Huli District Xiamen City, Fujian, P.R. China Tel: 86-592-5702000 Fax: 86-592-5702455 Email: [email protected] Date: 2023-12-13 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, Our product Ultra-elegant Gigabit IP Phone, Model: SIP-T44W; FCC ID: T2C-T44, for marketing purpose, this product only supports BR (GFSK), EDR (π/4-DQPSK, 8DPSK), 2.4G Wi-Fi (2412-2462MHz, 802.11b/g/n20 modes), 5G Wi-Fi (5150-5250MHz, 5250-5350MHz, 5470-5725MHz, 5725-5850MHz, 802.11a/n20/n40/ac20/ac40/ac80 modes).The other functions, bands and modes was disabled to use by manufacturer in the software, the end user has no capability to activate it. Sincerely Yours, Signature Contact Person: Stone Lu Title: Vice General Manager

YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu'an Rd. Huli District Xiamen City, Fujian, P.R. China Tel: 86-592-5702000 Fax: 86-592-5702455 Email: [email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 2023-12-13 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: T2C-T44 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. certifies that the equipment for which authorization is sought, is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Contact Person: Stone Lu Title: Vice General Manager

YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu'an Rd. Huli District Xiamen City, Fujian, P.R. China Tel: 86-592-5702000 Fax: 86-592-5702455 Email: [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 2023-12-13 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: T2C-T44 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Contact Person: Stone Lu Title: Vice General Manager

U.S. AGENT LETTER OF ATTESTATION Date: 2023-12-22 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: T2C-T44 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. certifies that, as of the date of the filing of the application, Iconsigh Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Address: No.666 Hu'an Rd. Huli District Xiamen City, Fujian, P.R. China FRN: 0014702682 Tel: 86-592-5702000 Email: [email protected] Signed by (printed name): Stone Lu Signature:

YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu'an Rd. Huli District Xiamen City, Fujian, P.R. China Tel: 86-592-5702000 Fax: 86-592-5702455 Email: [email protected] QA-FR-170-B 7/29/2014 FCC Authorization Date: 2023-12-13 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD., the undersigned, hereby authorizes Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Stone Lu Vice General Manager

YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu'an Rd. Huli District Xiamen City, Fujian, P.R. China Tel: 86-592-5702000 Fax: 86-592-5702455 Email: [email protected] FCC Confidential Authorization Date: 2023-12-13 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: T2C-T44 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description  Software Security Description As well as short-term confidential treatment of information accompanying this application for a period of 180 days after grant is issued as outlined below:  Internal Photos  User’s Manual  External Photos  Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature Stone Lu Vice General Manager

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 1 of 13 External Photographs Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 2 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 3 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 4 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 5 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 6 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 7 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 8 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 9 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 10 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 11 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 12 of 13 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 13 of 13 ***** END *****

Label Label location

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 1 of 7 Internal Photographs Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 2 of 7 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 3 of 7 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 4 of 7 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 5 of 7 Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 6 of 7 RF Chip ANTENNA Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Project No.: RXZ231115070 Page 7 of 7 ***** END *****

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ231115070RF03 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 20 of 133 5 FCC §15.407(f), §1.1307(b)(3), §2.1091 – RF Exposure 5.1 Applicable Standard According to subpart 15.407(f) and subpart §2.1091, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of this section. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: (C) Or using Table 1 and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free- space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ231115070RF03 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 21 of 133 For multiple RF sources: Multiple RF sources are exempt if: in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation: 5.2 RF Exposure Evaluation Result Project info § 1.1307(b)(3)(i)(A) method is not applicable. § 1.1307(b)(3)(i)(C) The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates ERP (watts) is no more than the calculated value prescribed for that frequency R must be at leastλ/2π λ is the free-space operating wavelength in meters The BT and Wi-Fi can transmit simultaneously. Simultaneous transmitting consideration (worst case): The ratio=ERP BT /limit + ERP Wi-Fi /limit=23.93/768+151.01/768=0.23 < 1.0 So simultaneous exposure is compliant. Result: The device compliant the MPE-Based Exemption at 20cm distances. Band Freq (MHz) Tune‐up Power (dBm) Ant Gain (dBi) Distances (mm) Tune‐up Power (mW) ERP (dBm) ERP (mW) BT2402‐2480114.9420012.5913.79 23.93 WIFI 2.4GHz 2412‐2462194.9420079.4321.79 151.01 WIFI 5GHz 5180‐582516.53.4320044.6717.78 59.98

Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 1 of 25 FCC Part 15.407 RSS-247 ISSUE 3, August 2023 Dynamic Frequency Selection TEST REPORT For YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu’an Rd,Huli District Xiamen City, Fujian, P.R. China FCC ID: T2C-T44 IC: 10741A-T44W Report Type: Original Report Product Type: Ultra-elegant Gigabit IP Phone Report Producer : Coco Lin Report Number : RXZ231115070RF04 Report Date : 2023-12-28 Reviewed By: Andy Shih Prepared By: Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) 70, Lane 169, Sec. 2, Datong Road, Xizhi Dist., New Taipei City 22183, Taiwan, R.O.C. Tel: +886 (2) 2647 6898 Fax: +886 (2) 2647 6895 www.bacl.com.tw Bay Area Compliance Laboratories Corp.(New Taipei Laboratory) No.: RXZ231115070RF04 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 2 of 25 Revision History Revision No. Report Number Issue Date Description Author/ Revised by 0.0 RXZ231115070 RXZ231115070RF04 2023-12-28 Original Report Coco Lin Bay Area Compliance Laboratories Corp.(New Taipei Laboratory) No.: RXZ231115070RF04 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 3 of 25 TABLE OF CONTENTS 1 General Information ....................................................................................................... 4 1.1 Product Description for Equipment under Test (EUT) ......................................................... 4 1.2 Objective ............................................................................................................................... 5 1.3 Test Methodology .................................................................................................................. 5 1.4 Statement ............................................................................................................................... 5 1.5 Measurement Uncertainty ..................................................................................................... 5 1.6 Environmental Conditions ..................................................................................................... 6 1.7 Test Facility ........................................................................................................................... 6 2 System Test Configuration ............................................................................................. 7 2.1 Description of Test Configuration ......................................................................................... 7 2.2 Equipment Modifications ...................................................................................................... 7 2.2 EUT Software ........................................................................................................................ 7 2.3 Support Equipment List and Details ...................................................................................... 7 2.4 External Cable List and Details ............................................................................................. 7 2.5 Block Diagram of Test Setup ................................................................................................ 7 3 Summary of Test Results ................................................................................................ 8 4 Test Equipment List and Details ................................................................................... 9 5 Applicable Standards .................................................................................................... 10 5.1 DFS Requirement ................................................................................................................ 10 5.2 DFS Measurement System .................................................................................................. 14 5.3 Test Procedure ..................................................................................................................... 14 6 Test Result ..................................................................................................................... 15 6.1 Description of EUT ............................................................................................................. 15 6.2 Channel Loading ................................................................................................................. 15 6.3 Radar Waveform Calibration .............................................................................................. 16 7 Channel Move Time and Channel Closing Transmission Time ............................... 17 7.1 Test Procedure ..................................................................................................................... 17 7.2 Test Results ......................................................................................................................... 17 8 Non-Occupancy Period ................................................................................................. 24 8.1 Test Procedure ..................................................................................................................... 24 8.2 Test Result ........................................................................................................................... 24 Bay Area Compliance Laboratories Corp.(New Taipei Laboratory) No.: RXZ231115070RF04 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 4 of 25 1 General Information 1.1 Product Description for Equipment under Test (EUT) Applicant YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu’an Rd,Huli District Xiamen City, Fujian, P.R. China Brand(Trade) Name Yeal…

Text truncated - open the document above for the full version.

Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 1 of 133 FCC Part 15.407 RSS-247 ISSUE 3, August 2023 RSS-GEN Issue 5, February 2021 Amendment 2 TEST REPORT For YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. No.666 Hu’an Rd,Huli District Xiamen City, Fujian, P.R. China FCC ID: T2C-T44 IC: 10741A-T44W Report Type: Original Report Product Type: Ultra-elegant Gigabit IP Phone Report Producer : Coco Lin Report Number : RXZ231115070RF03 Report Date : 2024-01-26 Reviewed By: Andy Shih Prepared By: Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) 70, Lane 169, Sec. 2, Datong Road, Xizhi Dist., New Taipei City 22183, Taiwan, R.O.C. Tel: +886 (2) 2647 6898 Fax: +886 (2) 2647 6895 www.bacl.com.tw Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ231115070RF03 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 2 of 133 Revision History Revision No. Report Number Issue Date Description Author/ Revised by 0.0 RXZ231115070 RXZ231115070RF03 2024-01-26 Original Report Coco Lin Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ231115070RF03 Note: It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) Page 3 of 133 TABLE OF CONTENTS 1 General Information ....................................................................................................... 5 1.1 Product Description for Equipment under Test (EUT) .............................................. 5 1.2 Objective .................................................................................................................... 6 1.3 Test Methodology ...................................................................................................... 6 1.4 Statement ................................................................................................................... 6 1.5 Measurement Uncertainty .......................................................................................... 7 1.6 Environmental Conditions ......................................................................................... 7 1.7 Test Facility ............................................................................................................... 7 2 System Test Configuration ............................................................................................. 8 2.1 Description of Test Configuration ............................................................................. 8 2.2 EUT Exercise Software ........................................................................................... 10 2.3 Equipment Modifications ........................................................................................ 11 2.4 Test Mode ................................................................................................................ 11 2.5 Support Equipment List and Details ........................................................................ 11 2.6 External Cable List and Details ............................................................................... 11 2.7 Block Diagram of Test Setup .................................................................................. 12 2.8 Duty Cycle ............................................................................................................... 15 3 Summary of Test Results .............................................................................................. 18 4 Test Equipment List and Details .............................................................. ................... 19 5 FCC §15.407(f), §1.1307(b)(3), §2.1091 – RF Exposure ......................................... 20 5.1 Applicable Standard ................................................................................................. 20 5.2 RF Exposure Evaluation Result ............................................................................... 21 6 RSS-102 §4 – EXPOSURE LIMIT .............................................................................. 22 6.1 Applicable Standard ................................................................................................. 22 6.2 RF Exposure Evaluation Result ............................................................................... 23 7 FCC §15.203 & RSS-GEN §6.8 – Antenna Requirements ........................................ 24 7.1 Applicable Standard ................................................................................................. 24 7.2 Antenna Information ................................................................................................ 24 8 FCC §15.407(b)(9), §15.207(a) & RSS-GEN §8 – AC Line Conducted Emissions . 25 8.1 Applicable Standard .............................................................................................. 25 8.2 EUT Setup .............................................................................................................. 25 8.3 EMI Test Receiver Setup ...................................................................................... 26 8.4 Test Procedure ....................................................................................................... 26 8.5 Corrected Factor & Margin Calculation ............................................................. 26 8.6 Test Results............................................................................................................. 27 9 FCC §15.209, §15.205, §15.407(b) & RSS-247 §6.2, RSS-GEN §8.9, RSS-GEN §8.10 – Spurious Emissions ........................................................................................................... 28 9.1 Applicable Standard .............................................................................................. 28 9.2 EUT S…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (New Taipei Laboratory) No.: RXZ231115070RF03 Not…

Text truncated - open the document above for the full version.
