T5AKT902RFID 433 MHZ ACTIVE TAG

결 재 입안 심사 결정 MANUAL ■(KPC RFID System KT902) February 1, 2008■ Version 1.2■ 15.240(a) Operation must be limited to commercial & Industrial areas; ie Ports, rail terminals & warehouses. KPC, INC. Model Name: KT902Manual 2KPC, INC. [Contents] 1. Summary 2. Composition 2.1 Devices Composition 2.2 Outward Appearance of Device and Dimension 3. Specification of the System 3.1 RFID Tag 3.2 RFID Reader 4. Function of the System 5. Requirements of the System 6. Installation of the System 7. System Operation and Tests 8. A/S Information Model Name: KT902Manual 3KPC, INC. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS. (1)THE DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION ALSO, TO PREVENT INTERFERENCE TO FEDERAL GOVERNMENT READER SYSTEMS, OPERATION GOVERNMENT RADAR SYSTEMS, OPERATION UNDER THE PROVISIONS OF THIS SECTION IS NOT PERMITTED WITHIN 40 KILOMETERS OF THE FOLLOWING LOCATIONS: CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. As a further condition, the grantee shall provide information on the locations where the devices are installed to the FCC Office of Engineering and Technology, which shall provide this information to the Federal Goverment through the National Telecommunications and Information Administration. The user of the device shall be responsible for submitting updated information in the event the operating location or other information changes after the initial registration by the grantee. The information provided by the grantee or user to the Commission shall include the name, address, telephone number and e-mail address of the user, the address and geographic coordinates of the operating location, and the FCC identification number of the device. The material shall be submitted to the following address: Experimental Licensing Branch, OET, Federal Communications Commission, 445 12th Street, SW., Washington, DC 20554, ATTN: RFID Registration. Professional installation is required. Installers are responsible for ensuring that the proper antenna is used as described in the FCC filing. Model Name: KT902Manual 4KPC, INC. 1. Summary A) The RFID system for containers is composed of an "Active RFID Tag" and a "Reader", and the communication between the tag and reader follows a Master-Slave model. B) Containers are embedded with 433.92MhzRFID tag, and the reader, if necessary, gives a wake-up signal, activates the RFID tag, so that it can obtain container-related information. C) The reader works according to the order of middleware or a terminal(or a computer). The communication protocol between the reader and the tag follows ISO/IEC 18000-7. D) By using a RFID tag system, the recognition rate and recognition distance for containers is greatly improved, so that it can lay the foundation for the job automation of gate, CY storage, and shipment. E) By making the best use of wireless/network technology, this system can be flexibly applied regardless of container's movement of position Model Name: KT902Manual 5KPC, INC. 2. Composition 2.1 Deceives Composition No.Model NameTypeRemarks 1RFIDTag 433.92MHz active tag (wake-up, 7.5*4.5*3.0 cm) KT902 2RFID readerFixed typeKR951 2.2 Dimension SectionContents KT902 (KPC Tag 900)Dimension: 7.5≫cm*4.5cm*3.0 cm KR951 (KPC Reader 950) Dimension: 21.0cm*16.6cm*6.75cm≫ Model Name: KT902Manual 6KPC, INC. 3. Specification of the System 3.1 RFID Tag Tag NameKT902 UHFTransceiver Frequency433.92Mhz ModulationFSK Range100m Power3.6mW Tag Wake-upUHF Air ProtocolISO/IEC 18000-7 StandardsISO/IEC 18000-7 Memory Tag ID4bytes(RO) User ID16bytes(RW) User Memory64Kbytes Beaconyes Range(unobstructed)~100m Battery TypeNon-replaceable, Non-rechargeable Volts/Material3.6V/Lithium Life3years(5 read events/day) Re-Usableyes Temperature Operation: -10 to +50 Storage: -10 to +50 Humidity100% Condensing ApprovalMIC Model Name: KT902Manual 7KPC, INC. 3.2 RFID Reader Reader NameKR951 Case MaterialPolycarbonate with glass Environmental Temperature Operating: -10 to +50 Storage: -10 to +50 Humidity100% Condensing RF Frequency(Transceiver)433.92Mhz Range100m ModulationFSK, deviation 35Khz for receiver, 50Khz for transmit Sensitivity95 dBM IF Frequency307.2Khz Data Rate27.8Kbps Air ProtocolISO/IEC 18000-7 RFID Tag CompatibilityAll KPC RFID Tags Network InterfaceEthernet, RS485, RS232, Wireless LAN UpgradesSupports firmware downloads DiagnosticsSupports remote reader performance status reports DC Source7.5VDC Type ApprovalMIC Other MountingMounting Kit Model Name: KT902Manual 8KPC, INC. 4. Function of the System The communication protocol and operation between the reader and the tag follows□ ISO/IEC 18000-7. 5. Requirements of the System SectionDescriptionRemark Battery check (RFID tag) In case that the battery remains within 20% of its total power source. It sounds the alarm. When receiving a wake-up signal. It sends the alarm Read/Write Memory (RFID tag) At any time, users can read and write the data in a specified memory. Wake-up Range conrtrol (Reader) The wake-up signal range should be able to be controlled The wake-up range can be setatintervalsof5min time of its installation Firmware Upgrade (Reader) Upgrade is available through LAN Log storage (RFID tag/reader) Tag: Keeps 10 logs Reader: Keeps 50 logs Tag: Reader ID, Time of read/write memory Reader: Manages a tag history Encoding of data communication (RFID tag/reader) Encoding for data securityUse of T-DES Tolerance (RFID tag/reader) Be, tolerant of saltiness, humidity, impact, and temperature Self-examination (RFID tag/reader) Self-examination its hardware and software on a regular basis It sounds the alarm, and also has the function of restoration Model Name: KT902Manual 9KPC, INC. 6. Installation of the Syst…

Text truncated - open the document above for the full version.

55 44 33 22 11 D D C C B B A A TitleSize Document Number Re v Date: Sheet of <Doc> <RevCode > <Title> B 24 Wednesday, February 13, 2008 WatchDog SerialEEPROM VoltageDetector SCLSDA MCU Battery uPD78F0515 (8MHz) 512Kb KRS900 TAG(KT902) MAIN BLOCK DIAGRAM RF MODULE

Model Name: KT902Authorization Letter KPC, INC. KPC, Inc. Date:8thofMarch,2008 #830, Research Center for Industry Co-Operation,Dong-A Univ. 840, Hadan2-Dong, Saha-Gu,Busan 604-714, Korea To whom it may concern: We, the undersigned, hereby authorize KEL, to act on our behalf in all manners relating to application for equipment authorization, including signingofalldocumentsrelatingtothesematters.Anyandallacts carried out by KEL on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 15.240(Operation in the band 433.5-434.5 MHz.) In authorizing KEL as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records(including internal audit reports) and personnel for Authorization Letter Model Name: KT902Authorization Letter KPC, INC. the purposes of evaluation(e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certificationwhich the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation ofcertification, discontinue use of all advertising matter that contains any reference there to and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part there of is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product's compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; Model Name: KT902Authorization Letter KPC, INC. j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Doo-Won, Lee / President, CEO Signature

ModelName:KT902DeclareLetter KPC, INC. KPC, Inc. Date:8thofMarch,2008 #830, Research Center for Industry Co-Operation,Dong-A Univ. 840, Hadan2-Dong, Saha-Gu,Busan 604-714, Korea Gentlemen: This letter is to confirm with FCC 15.240(Operation in the band 433.5-434.5 MHz.) proves the following contents. The KPC's devices shall be provided with a means for automatically limiting operation so that the duration of each transmission shall not be greater than 60 seconds and be only permitted to reinitiate an interrogation in the case of a transmission error. Absent such a transmission error, the silent period between transmissions shall not be less than 10 seconds. Sincerely Yours, Doo-Won, Lee / President, CEO Signature Declare Letter

Model Name: KT902 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (T5A-KT902). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics PartList Layout KT902_Schem.pdf KT902_PartLst.pdf KT902_LayOut.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Doo-Won, Lee / President, CEO signature

FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. Appendix-B : External Photographs of E.U.T < EXTERNAL VIEW1 OF E.U.T > < EXTERNAL VIEW2 OF E.U.T > FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. < EXTERNAL VIEW3 OF E.U.T > < EXTERNAL VIEW4 OF E.U.T > FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. < EXTERNAL VIEW5 OF E.U.T > < EXTERNAL VIEW6 OF E.U.T >

FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. Appendix-D : FCC ID Label Sample and Location Tag Unit Label --------------------------------------------------------- 433.92 MHz RFID Active Tag KT902 FCC ID Label Location Information ■ The label is attached on the front panel S/N: TLTA- OOOOOO 433 MHz Active RFID Tag FCC ID : T5A-KT902 MADE IN KOREA

FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. Appendix-C : Internal Photographs of E.U.T < INTERNAL VIEW 1 OF E.U.T > < INTERNAL VIEW 2 OF E.U.T > FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. < INTERNAL VIEW 3 OF E.U.T > < INTERNAL VIEW 4 OF E.U.T >

Model Name: KT902Theory of operation KPC, INC. KT902 RF Circuit Specifications/FCC Tag Receives _ 433.92 MHz The signal sent into the antenna undergoes the conversion of both transmission and reception that is essential to TDD method. During this reception period, the signal is sent to U101 (1 Chip Transceiver IC, CC 1100). At this time, transmission is blocked. U101 (1 Chip Transceiver IC, CC1100) receives the signal from ANT101, separates the I signal and Q signal of 307.2 KHz through LNA and mixer, filters and amplifies both of them, generates the baseband digital signal via both ADC (analog to digital converter) and FSK demodulator, and sends it to the MCU of a main board. Tag Transmits _ 433.92 MHz The digital data in the MCU of a main board is modulated into FSK in the U101 (1 Chip Transceiver IC, CC1100), and then converted into the reference signal of VCO. The RF signal of 433.92 MHz transmitted from VCO is converted into the single ended signal via a phase shifter and MUX. U101 sends the RF signal to the antenna for a certain time. At thistime, reception is blocked. The RF signal inputted into the antenna is also transmitted from the antenna.

KEL-D-QP-25-24/0 Page of Pages: 12/ 12 Korea EMC Laboratory Co., Ltd. 390 Bora-dong, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea (446-904) Tel : 82-31-286-5881 Fax : 82-31-286-2661 www.koreaemc.com Report Ref. No : KEL08-F02066 TEST REPORT 1. Client ◦ Name : KPC, Inc. ◦ Address : #830, Research Center for Industry Co-Operation, Dong-A Univ 840, Hadan2-Dong, Saha-Gu, Busan 604-714, Korea ◦ Date of Receipt : Feb. 28, 2008 2. Name of Product / Model : UHF Band RFID Tag / KT902 (Low power transceiver – RX verified) 3. Manufacturer /Country of Origin : KPC, Inc. / KOREA 4. Date of Test : Feb. 28, 2008 ~ Mar. 10, 2008 5. Test Regulation : FCC Title 47, Part 15 Subpart C § 15.240 6. Equipment Class : DXT– Part 15 Low Power Transceiver, Rx verified 7. FCC ID : T5A-KT902 8. Testing Environment ◦ Environment : Temperature : ( 20.3 ± 1.0 ) , Relative Humidity : ( °C40. ± 3.0 ) % R.H. ◦ Location : ■ In Laboratory □ In Chamber □ On Site Test 9 Test Results : Pass Fail Affirmation Tested by Name : Bong-Ok Ko ( Signature) Technical Manager Name : Su-Gil Moon (Signature) Mar. 10, 2008 Korea EMC Laboratory Co., Ltd. As a test result of sample which was submitted from the client, this report does not guarantee the whole product quality. This test report should not be used and copied without a written agreement by Korea EMC Laboratory Co., Ltd. KEL-D-QP-25-24/0 Page of Pages: 2 / 12 FCC ID : T5A-KT902 Report Ref. No : KEL08-F02066 Korea EMC Laboratory Co., Ltd. TABLE OF CONTENTS DESCRIPTION Page 1. GENERAL..................................... ................................................................. ............3 1.1 Labelling Requirement.............................................................................3 1.2 Information to user..................................................................................3 1.3 Special Accessories...............................................................................4 1.4 Antenna Requirement.........................................................................4 2. TEST FACILITY .......... ...... ........................................................... ...............4 2.1 List of Test Equipment ................................................................................. 5 3. DESCRIPTION OF THE EQUIPMENT UNDER TEST ...............................................6 3.1 Rating and Physical Characteristics .............................................................. 6 4. TEST CONDITIONS ................................... ................................................................7 4.1 Condition of Test Setup ................................................................................. 7 4.2 List of Peripherals .......................................................................................... 7 4.3 Type of Used Cables ..................................................................................... 7 5. RADIATED EMISSION MEASUREMENT .. .................................................................8 5.1 Test Procedure ............................................................................................... 8 5.2 Photograph for the test configuration ............................................................ 8 5.3 Dwell time plot ............................................................................................... 9 5.4 Measurement data ....................................................................................... 10 5.5 Duration of transmission................................................................................ 12 KEL-D-QP-25-24/0 Page of Pages: 3 / 12 FCC ID : T5A-KT902 Report Ref. No : KEL08-F02066 Korea EMC Laboratory Co., Ltd. 1. GENERAL These tests were performed using the test procedure outlined in ANSI C63.4, 2003 for intentional radiators, and in accordance with the limits set forth in FCC Part 15.240 for Low Power Transceiver, Rx verified. The EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards. We attest to the accuracy of data. All measurements reported herein were performed by KOREA EMC LABORATORY CO., LTD. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 1.1 Labelling Requirement(Section 15.19) 1.1-1 Location of Label : User’ guide manual 1.1-2 How Applied : Printed 1.2 Information to User(Section 15.21) The following or similar statements were provided in the manual for user instruction. Please refer page 3 of the attached manual for details. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION : Any changes or modifications in construction of this device which are Not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. KEL-D-QP-25-24/0 Page of Pages: 4 / 12 FCC ID : T5A-KT902 Report Ref. No : KEL08-F02066 Korea EMC Laboratory Co., Ltd. 1.3 Special Accessories (Section 15.27) 1.3-1 Were the special Accessories provided? [ ] yes, [ ■ ] no 1.3-2 If yes, details for the special accessories are as follows : 1.3-3 If yes, were the appropriate instructions provided on the first page of the text concerned with the device? [ ] yes, [ ] no 1.3-4 Are these accessories provided of the type which can be readily obtained from multiple retail outlets? [ ] yes, [ ] no And therefore does the manual specify what additional components or accessories are required to used in order to comply with the Rules? [ ] yes, [ ] no 1.4 Antenna Requirement The Antenna is integral to the device. 2. TEST FACILITY Location : Korea EMC Laboratory Co., Ltd. 390 Bora-dong, Giheung-gu, Yongin-si, Gyeunggi-do, …

Text truncated - open the document above for the full version.

Results of Radiated Emissions(KEL) EMC Test Room Date : 2008-03-08 17:57:28 Company Name:KPCReference No.:04/Apr/2005 17:22:59 Model No.:KT902Power Supply:DC 3.6 V (Battery) Serial:Temp/Humi: Test Condition:3m Spurious Radiation TestOperator: Memo:Frequency : 433.92 MHz LIMIT : 1234 30 MHz ~ 1GHz 301000100200300300400500600700800900 0 10 20 30 40 50 60 70 80 90 100 No. FREQ READING ANT LOSS GAIN RESULT LIMIT MARGIN ANTENNA TABLE PEAK FACTOR [MHz] [dBuV] [dB] [dB] [dB] [dBuV/m][dBuV/m] [dB] [cm] [DEG] ----- Horizontal ------ 1434.165 89.2 15.8 2.8 27.1 80.7 80.7 80.7 100359 2869.425 37.4 22.2 4.4 27.6 36.4 36.4 36.4 100140 ----- Vertical ------ 3434.165 84.6 15.8 2.8 27.1 76.1 76.1 76.1 200230 4869.425 35.4 22.2 4.4 27.6 34.4 34.4 34.4 400359 Results of Radiated Emissions(KEL) EMC Test Room Date : 2008-03-08 18:53:07 Company Name:KPCReference No.:04/Apr/2005 17:22:59 Model No.:KT902Power Supply:DC 3.6 V (Battery) Serial:Temp/Humi: Test Condition:3m Spurious Radiation TestOperator: Memo:Frequency : 433.92 MHz LIMIT : 100030002000 0 10 20 30 40 50 60 70 80 90 100 No. FREQ READING ANT LOSS GAIN RESULT LIMIT MARGIN ANTENNA TABLE PEAK FACTOR [MHz] [dBuV] [dB] [dB] [dB] [dBuV/m][dBuV/m] [dB] [cm] [DEG] ----- Horizontal ------ 11301.278 36.3 25.4 2.5 38.2 26.0 26.0 26.0 100 69 21737.168 37.1 27.6 3.2 38.6 29.3 29.3 29.3 100 36 ----- Vertical ------ 31301.278 35.2 25.4 2.5 38.2 24.9 24.9 24.9 100 0 41737.168 35.9 27.6 3.2 38.6 28.1 28.1 28.1 100 1

FCC ID : T5A-KT902 Korea EMC Laboratory Co., Ltd. Appendix-A : Test Setup Photographs < RADIATED EMISSION SETUP PHOTOGRAPH - FRONT VIEW1 > < RADIATED EMISSION SETUP PHOTOGRAPH – FRONT VIEW2 >
