Northwest EMC TCB Compliance Opinion Rev. 9/15/03 VENT0023 Information about the Applicant Company Name Ventana Medical Systems, Inc. Grantee Bill Richards Address 1910 E. Innovation Park Drive City, State, Zip Tucson, AZ 85737 Job Number vent0023 Model Symphony Staining System FCC ID T652160000 Agent Northwest EMC, Inc. Approval Type Original Equipment Class DXT Part 15, Low Power Transceiver, Rx Verified Rule Part 15.225 Overview This radio is installed in the Ventanna Symphony system, which is a high volume tissue slide staining system. It utilizes RFID technology with a module manufactured by Secura Key, A Division of Soundcraft. The radio transmits at 13.56MHz at a low output power. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature 5/24/2006 Dave Tolman, TCB Committee

NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 May 8, 2006 Dear Application Examiner: On behalf of Ventana Medical Systems, Inc., Northwest EMC Inc is submitting this application for the certification of the Symphony (TM) Slide Staining System, FCC ID: T652160000. The Symphony system is a high volume tissue slide staining system. It utilizes RFID technology with a module manufactured by Secura Key, A Division of Soundcraft. The radio transmits at 13.56MHz at a low output power. The RF functionality is per ISO/IEC 15693 protocols. The radio is part of the Symphony system which will be permanently installed in a hospital laboratory setting. The device will be connected to a dedicated facility power line. The radio utilizes a four different PCB etch antennas. This configuration satisfies the requirements of 47 CFR 15.203. The technical reports and exhibits demonstrate compliance with FCC rules 47 CFR 15.225. Your efforts in reviewing this application are greatly appreciated. Best regards, Northwest EMC, Inc.

NORTHWEST EMC Internal Photos PSA 2006.03.02 NORTHWEST EMC Internal Photos PSA 2006.03.02 NORTHWEST EMC Internal Photos PSA 2006.03.02

Date: May 4, 2006 To: Whom it may concern Subject: TCB Certification of Ventana Medical Systems, Inc model Symphony instrument Antenna information Information regarding the Symphony instrument antenna(s) is as follows: a. The Symphony employs four antennas which are internal to the system and are not accessible to the operator. b. The device is not a Part 15.247 transmitter c. Four PC board antennas are contained within the system as follows: i. Assy, PCB, Limonene Antenna, Ventana Medical Systems, Inc P/N 2142400 ii. Assy, PCB, Coverslipper Antenna, Ventana Medical Systems, Inc P/N 2137500 iii. Assy, PCB, Reagent Drawer Board A, Ventana Medical Systems, Inc P/N 2137000 iv. Assy, PCB, Reagent Drawer Board B, Ventana Medical Systems, Inc P/N 2217100 Bill Richards Electrical Engineering Fellow Ventana Medical Systems, Inc Ventana Medical Systems, Inc. 1910 Innovation Park Drive Tucson, Arizona 85737 Telephone: 520-887-2155 Toll Free: 800-227-2155 www.ventanamed.com Ventana Symphony Mult iplexed RFID Antennas May 10, 2006 W. Richards, Ventana Medical Systems, Inc. RFID Transceiver P/N 2142400 P/N 2137500 P/N 2137000P/N 2137000 P/N 2217100 Assy, PCB, Reagent Drawer Board A, V entana Medical Systems, Inc P/N 2137000 Six antennas, two boards per system, gain = unity. Assy, PCB, Reagent Drawer Board B, V entana Medical Systems, Inc P/N 2217100 Four antennas, one board per system, gain = unity. Assy, PCB, Coverslipper Antenna, Vent ana Medical Systems, Inc P/N 2137500 Two antennas, one board per system, gain = unity. Assy, PCB, Limonene Antenna, Vent ana Medical Systems, Inc P/N 2142400 One Antenna, one board per system, gain = unity.
