T7HU3741USB-A DECT Dongle USB DECT Dongle

RTX HONG KONG LTD TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.06.28 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (USB-A DECT Dongle, USB DECT Dongle / RTX3741, RTX3742, SDW D1 USB /FCC ID: T7HU3741) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description • BOM • Tune Up Procedure These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Ted Chong Signature:

Page 1 of 5 Report No.: STS2003266 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS FCC ID: T7HU3741 IC: 4979B-U3741 Model: RTX3741 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2003266 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2003266 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2003266 Model: RTX3742 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2003266 Photo 9 Photo 10

MODEL: RTX3741 S/N: YYWWSSSSSS FCC ID: T7HU3741 IC: 4979B-U3741 RTX3741 USB-A DECT Dongle Product Label (EMEA) 50004679 05-Mar-2020REV. C SIZE : W18mmx H 11mm MATERIAL : PET COLOR : Black text on white background BARCODE FORMAT : 2D barcode POSITIONING : Affix on product appointed area 2D Barcode need (Size 6.4mm x 6.4mm): 2D Barcode information shows horizontally after scanned: YYWWSSSSSS; 0EEEEZZZZZ; 0EEEEXXXXY 0EEEEXXXXY RFPI code in text (HEX format): Serial number format (YYWWSSSSSS): REMARK: (The serial number, IPEI code and RFPI code on products must be match with the one on packing box). YY: Year of manufacturing (e.g. 10=2010) WW: Week of manufacturing SSSSSS: Progressive serial number. Serial starting number is 000001, the serial number will only reset to 000001 if under the following condition: a) The start of new PO production lot, plus the production week "WW" increment to a new week. Otherwise the serial number will continuous the previous lot of production. IPEI format: 0EEEEZZZZZ IPEI code in text (HEX format) 0: this is a fix digit EEEE: EMC code ZZZZZ: start from 00001, this five digits cannot be all zero, mean 00000 is not allowedthat's 0: fix digit EEEE: EMC code XXXX: start from 0000 Y: This number should be either 0 or 8 RFPI format: Total 10 digits MODEL: RTX3741 S/N: YYWWSSSSSS FCC ID: T7HU3741 IC: 4979B-U3741 location

Page 1 of 4 Report No.: STS2003266 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS FCC ID: T7HU3741 IC: 4979B-U3741 Model: RTX3741 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2003266 Photo 3 Photo 4 Antenna A Antenna B Page 3 of 4 Report No.: STS2003266 Model: RTX3742 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2003266 Photo 7 Photo 8 Antenna A Antenna B

Ref : ACR.345.3.19.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 41/18 EPGO334 Calibrated at MVG US 2105 Barrett Park Dr. - Kennesaw, GA 30144 Calibration Date: 06/04/2019 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in MVG USA using the CALISAR / CALIBAIR test bench, for use with a COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.19.SATU.A Page: 2/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 12/11/2019 Checked by : Jérôme LUC Product Manager 12/11/2019 Approved by : Kim RUTKOWSKI Quality Manager 12/11/2019 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 12/11/2019 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.19.SATU.A Page: 3/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment .................................................................................................... 10 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.19.SATU.A Page: 4/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 41/18 EPGO334 Product Condition (new / used) New Frequency Range of Probe 0.45 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.191 M Dipole 2: R2=0.216 M Dipole 3: R3=0.197 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528 and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.19.SATU.A Page: 5/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic box illuminated with the fields from a half wave dipole. The…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] S T L A B S Testing Engineer : (Aaron Bu) Technical Manager : (Jason Lu) Authorized Signatory : (Vita Li) SAR Dipole Performance Measurement Report EUT Type： SAR Validation Dipole and Waveguide Model Name： DIP1G900-333 Brand Name: SATIMO Test Conclusion： Pass Test Date： 16 Aug. 2019 Date of Issue： 17 Aug. 2019 ISSUED BY Shenzhen STS Test Services Co., Ltd. 1. Equipment List Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until PC Acer N/A N/A N/A N/A E-Field Probe MVG SSE5 SN 14/16 EP309 2018.12.13 2019.12.12 Dielectric Probe Kit MVG SCLMP SN 32/14 OCPG67 2018.12.01 2019.11.30 Phantom1 MVG SAM SN 32/14 SAM115 N/A N/A Phantom2 MVG SAM SN 32/14 SAM116 N/A N/A Attenuator Agilent 99899 DC-18GHz N/A N/A Directional coupler Narda 4226-20 3305 N/A N/A Network Analyzer Agilent 8753ES US38432810 2019.03.02 2020.03.01 Multi Meter Keithley Multi Meter 2000 4050073 2018.10.13 2019.10.12 Signal Generator Agilent N5182A MY50140530 2018.10.16 2019.10.15 Power Amplifier DESAY ZHL-42W 9638 2018.10.13 2019.10.12 Power Meter R&S NRP 100510 2018.10.26 2019.10.25 Power Sensor R&S NRP-Z11 101919 2018.10.13 2019.10.12 Power Sensor Agilent E9301A MY41497725 2018.10.13 2019.10.12 hygrothermograph MiEO HH660 N/A 2018.10.11 2019.10.10 Thermograph Elitech RC-4 S/N EF7176501537 2018.10.15 2019.10.14 ISSUED BY Shenzhen STS Test Services Co., Ltd. 2.<Justification of the extended calibration> Referring to KDB 865664 D01, if dipoles are verified in return loss<-20dB, (within 20% of prior calibration),and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Body 1900 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -20.22 - 48.8 - 2018.08.16 -23.26 15.03 47.11 -1.79 2019.08.15 -24.15 3.83 48.71 1.60 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Body 1900 MHz

RTX3741_SAR Setup photo .Horizontal- Up side (separation distance is 5mm) .Horizontal- Down side (separation distance is 5mm) Vertical- Front (separation distance is 5mm) Vertical- Back (separation distance is 5mm) Body Top edge (separation distance is 5mm)

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +8 6-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2003266H01 Issued for RTX HONG KONG LTD 8TH FL CORPORATION SQUARE, 8 LAM LOK ST., KOWLOON BAY, HK. Product Name: USB-A DECT Dongle USB DECT Dongle Brand Name: RTX, EPOS Model Name: RTX3741 Series Model: RTX3742, SDW D1 USB FCC ID: T7HU3741 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Body: 0.082 W/kg S T L A B S Page 2 of 31 Report No.: STS2003266H01 Test Report Certification Applicant’s name ................. : RTX HONG KONG LTD Address ................................. : 8TH FL CORPORATION SQUARE, 8 LAM LOK ST., KOWLOON BAY, HK. Manufacture's Name ............ : RTX HONG KONG LTD Address ................................. : 8TH FL CORPORATION SQUARE, 8 LAM LOK ST., KOWLOON BAY, HK. Product description Product name ........................ : USB- A DECT Dongle USB DECT Dongle Brand name ......................... : RTX, EPOS Model name ......................... : RTX3741 Series Model .......................... : RTX3742, SDW D1 USB Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test Date (s) of performance of tests ............. : 08 Apr. 2020 Date of Issue ........................................... : 09 Apr. 2020 Test Result ............................................... : Pass Testing Engineer : ( Aaron Bu) Technical Manager : (Jason Lu) Authorized Signatory : (Vita Li) Page 3 of 31 Report No.: STS2003266H01 Table of Contents 1. General Information 5
1.1 EUT Description 5
1.2 Test Environment 5
1.3 Test Factory 6
2. Test Standards and Limits 7
3. SAR Measurement System 8
3.1 Definition of Specific Absorption Rate (SAR) 8
3.2 SAR System 8
4. Tissue Simulating Liquids 11
4.1 Simulating Liquids Parameter Check 11
5. SAR System Validation 13
5.1 Validation System 13
5.2 Validation Result 13
6. SAR Evaluation Procedures 14
7. EUT Test Position 15
7.1 Hotspot mode exposure position condition 15
7.2 USB connector Orientations Implemented on Laptop Computers 15
8. Uncertainty 16
8.1 Measurement Uncertainty 16
8.2 System validation Uncertainty 17
9. Conducted Power Measurement 18
9.1 Test Result 18
9.2 Tune-up Power 18
10. EUT and Test Setup Photo 19
10.1 EUT Photo 19
10.2 Setup Photo 22
11. SAR Result Summary 25
11.1 Body-worn SAR 25
12. Equipment List 26
Appendix A. System Validation Plots 27
Appendix B. SAR Test Plots 29
Appendix C. Probe Calibration and Dipole Calibration Report 31
Page 4 of 31 Report No.: STS2003266H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 09 Apr. 2020 STS2003266H01 ALL Initial Issue Note: Format version of the report - V01 Page 5 of 31 Report No.: STS2003266H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name USB-A DECT Dongle USB DECT Dongle Brand Name RTX, EPOS Model Name RTX3741 Series Model RTX3742, SDW D1 USB Model Difference Refer to below different list Hardware Version N/A Software Version N/A Type of Modulations GFSK Antenna Type Chip Antenna Frequency Range 1921.536-1928.448MHz Max. Reported SAR(1g) (Limit:1.6W/kg) ModeBody SAR (W/kg) DECT ANT0 0.055 DECT ANT1 0.082 Different List Product name Brand Series Model Number Customer Model number DECT Mode PCB LED color (start from Button side) Slide- switch Key1 pin USB-A DECT Dongle RTX RTX3741 RTX3741FP+PP8190790X D1 Red,D2 Blue, D3 Green Yes P1_5 USB DECT Dongle EPOS RTX3742 SDW D1 USB FP only8190790X D1 Blue, D2 Red, D3 White No P1_5 1.2 Test Environment Ambient conditions in the SAR laboratory: Page 6 of 31 Report No.: STS2003266H01 Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration No.: 625569 IC Registration No.: 12108A A2LA Certificate No.: 4338.01 Page 7 of 31 Report No.: STS2003266H01 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB 447498 D02 v02r01 SAR Procedures for Dongle (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrist…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2003266W02 Issued for RTX HONG KONG LTD 8TH FL CORPORATION SQUARE, 8 LAM LOK ST., KOW- LOON BAY, HK. Product Name: USB-A DECT Dongle USB DECT Dongle Brand Name: RTX, EPOS Model Name: RTX3741 Series Model: RTX3742, SDW D1 USB FCC ID: T7HU3741 IC: 4979B-U3741 Test Standard: Title 47 of the CFR, Part 15 Subpart D RSS-213 Issue 3, March 2015 RSS-Gen Issue 5, Amendment 1, March 2019 S T L A B S Page 2 of 88 Report No.: STS2003266W02 TEST RESULT CERTIFICATION Applicant’s Name ................. : RTX HONG KONG LTD Address .................................. : 8TH FL CORPORATION SQUARE, 8 LAM LOK ST., KOWLOON BAY, HK. Manufacture's Name ............ : RTX HONG KONG LTD Address .................................. : 8TH FL CORPORATION SQUARE, 8 LAM LOK ST., KOWLOON BAY, HK. Product Description Product Name ........................ : USB-A DECT Dongle USB DECT Dongle Brand Name ......................... : RTX, EPOS Model Name ........................... : RTX3741 Series Model .......................... : RTX3742, SDW D1 USB Test Standards ..................... : Title 47 of the CFR, Part 15. Subpart D RSS-213 Issue 3, March 2015 RSS-Gen Issue 5, Amendment 1, March 2019 Test procedure ........................ : ANSI C63.17-2013 This device described above has been tested by STS and the test results show that the equipment under test (EUT) is in compliance with the FCC/IC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 24 Mar. 2020 Date of performance of tests .................. : 24 Mar. 2020 ~ 21 May 2020 Date of Issue .......................................... : 21 May 2020 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 88 Report No.: STS2003266W02 TABLE OF CONTENTS Page 1 INTRODUCTION 7
1.1 TEST FACTORY 7
1.2 MEASUREMENT UNCERTAINTY 7
2 PRODUCT INFORMATION 8
3 TEST CONFIGURATION OF EQUIPMENT UNDER TEST 9
3.1 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9
4 MEASUREMENT INSTRUMENTS 10
5 TEST ITEMS 11
5.1 ANTENNA REQUIREMENT 11
5.2 MODULATION TECHNIQUES 11
5.3 EMISSION BANDWIDTH 12
5.4 PEAK TRANSMIT POWER 17
5.5 POWER SPECTRAL DENSITY 21
5.6 POWER ADJUSTMENT FOR ANTENNA GAIN 26
5.7 AUTOMATICALLY DISCONTINUE TRANSMISSION 27
5.8 SYSTEM ACKNOWLEDGE-MENT TEST 28
5.9 MONITORING THRESHOLD 29
5.10 DURATION OF TRANSMISSION 30
5.11SELECTED CHANNEL CONFIRMATION,POWER ACCURACY,SEGMENT OCCUPANCY 32
5.12 RANDOM WAITING 34
5.13 MONITORING REQUIREMENTS 35
5.14 MONITORING ANTENNA 36
5.15 DUPLEX CONNECTIONS 36
5.16 ALTERNATIVE MONITORING INTERVAL FOR CO-LOCATED DEVICES 37
5.17 FAIR ACCESS 37
5.18 SPURIOUS EMISSIONS 38
5.19 FRAME PERIOD 54
5.20 FREQUENCY STABILITY 56
5.21 CONDUCTED EMISSION MEASUREMENT 60
5.22 RADIATED SPURIOUS EMISSION 64
Page 4 of 88 Report No.: STS2003266W02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 21 May 2020 STS2003266W02 ALL Initial Issue Page 5 of 88 Report No.: STS2003266W02 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The following tests were conducted on a sample of the equipment for the purpose of demonstrating com- pliance with Part 15 Subpart D. Requirement FCC Part Canada RSS-213 Test Procedure Result Emission Bandwidth 15.323 (a) 5.5 6.1.3 Compliant Labeling Requirements 15.19(a)(3) RSS-Gen -- Compliant Conducted Emissions 15.315 & 15.207 5.4 ANSI C63.4 Compliant Antenna Requirements 15.317 & 15.203 RSS-Gen Declaration Compliant Use digital modulation 15.319 (b) 5.1 6.1.4 Compliant Peak transmit power 15.319 (c) 5.6 6.1.2 Compliant Power spectral density 15.319 (d) 5.7 6.1.5 Compliant Power adjustment for antenna gain 15.319 (e) 5.6 4.3.1 Compliant Automatically discontinue transmission 15.319 (f) 5.2 -- Compliant Spurious emissions conducted 15.323 (d) (1) & 15.323 (d) (2) 5.8 6.1.6 Compliant RF Exposure 15.319 (i) & 1.1307(b), 2.1091 and 2.1093 RSS-102 ANSI/IEEE C95.1 Compliant (The test data please refer to RF exposure report) Monitoring time 15.323 (c)(1) 5.2(1) 7.3.4 Compliant Monitoring threshold 15.323 (c)(2) 5.2(2) 7.3 Compliant Duration of transmission 15.323 (c)(3) 5.2(3) 8.2.2 Not Applicable System acknowledgment test 15.323(c)(4) 5.2(4) 8.2.1 Compliant Channel confirmation, Power accuracy, Segment occupancy 15.323 (c)(5) 5.2(5) 7.3.3 & 7.3.4 Compliant Random waiting 15.323 (c)(6) 5.2(6) 8.1.3 Not Applicable Page 6 of 88 Report No.: STS2003266W02 Monitoring bandwidth 15.323 (c)(7) 5.2(7) 7.4 Compliant Monitoring reaction time 15.323 (c)(1 ) 5.2(7) 7.5 Compliant Monitoring antenna 15.323 (c)(8) 5.2(8) 4 Compliant Monitoring threshold relaxation 15.323 (c)(9) 5.2(9) 4 Compliant Duplex connections 15.323 (c)(10) 5.2(10) 8.3 Not Applicable Alternate monitoring interval 15.323 (c)(11) 5.2(11) 8.4 Not Applicable Fair access 15.323 (c)(12) 5.2(12) Declaration Not Applicable Frame period 15.323 (e) 5.2(13) 6.2.2 & 6.2.3 Compliant Frequency stability 15.323 (f) 5.3 6.2.1 Compliant Radiated Out of Band Emissions 15.319 (g), 15.309 (b) & FCC Part 15 Subpart B, 15.109 and 15.209 5.8 -- Compliant Page 7 of 88 Report No.: STS2003…

Text truncated - open the document above for the full version.

Page 1 of2Report NO.:STS2003266 PUT Setup Photo Model: RTX3741 Conducted Emission Radiated Spurious Emission（Below 1GHz） Page 2 of2Report NO.:STS2003266 Radiated Spurious Emission（Above 1GHz ）
